Microsoft Windows 2000 Installation
Guide for HP Servers
NOTICE: The information in this document was last updated for the HP NetServer Navigator CD-ROM version
M.04.05. If you don't have the M.04.05 version CD-ROM and you're obtaining this document from the HP web site as
a reference to install an operating system, be sure to also check the HP web site for the latest available drivers.
©Copyright Hewlett-Packard Company
August 26, 2002
Table of Contents
Introduction
Requirements
Process Flow ( High Level View )
Installation Planning Sheet
Installation Methods
Automatic Installation – Using the HP Navigator CD
Manual Installation
Creating the Drivers Diskettes
Selecting the Manual Installation Method
Special Instructions for Installing Windows 2000 on HP NetServer LH 6000 or LT
6000r Systems
Special Instructions for Installing Windows 2000 on an HP NetServer LP 1000r or LP
2000r
Installing Windows 2000
Hardware Status Check
Initialize Hard Drives
Configure Server IP Address
Attach Clients to Network
Domain Controller Setup
Adding Terminal Server Services
Installing Citrix MetaFrame for Microsoft Windows 2000
Installing Citrix MetaFrame XP 1.0 for Windows 2000
Installing Windows 2000 DataCenter from the HP-Provided CD-ROM

Troubleshooting Tips and Tricks
Tip #1. Upgrading from NT 4.0 to Windows 2000
Tip #2. HP NetRaid-1 Partition >8GB Not supported
Tip #3. NetServer LH Pro, LD Pro and LH II with DAC present hangs during high
work load
Tip #4. Windows 2000 Installation halts about three minutes after starting to boot
from CD-ROM
Tip #5. LX Pro, LX, LXe, LH Pro, LD Pro & LH II hang when booting from the
Windows 2000 CD
Tip #6. Avoid using IRQ 9 on NetServer LH 4
Tip #7. Using the Windows 2000 integrated backup utility with NetServer E60 and E
50 bundled tape drives
Tip #8. Configure the Parallel (LPT) Port for ECP Mode
Tip #9. Event Viewer Error 3013 On NT Clients
Tip #10. Mirror Drive Issue
Tip #11. Upgrading Windows 2000 from Uniprocessor HAL to Multiprocessor HAL
Tip #12. Installing the NetRAID-4M, 2M, or 1M Driver After Windows 2000 is
Installed
Tip #13. Windows 2000 Driver Signatures
Tip #14. Upgrading D5013B NIC Drivers for Windows 2000
Tip #15. Installation Fails to Boot after First Reboot
Tip #16. Installing Citrix on HP NetServer LT 6000
Tip #17. Windows 2000 Recovery Options
Tip #18. Installing the HP NetRaid-4M Drivers when Upgrading to Windows 2000
Tip #19. Page Address Extension /PAE not added by Windows 2000 DataCenter
installer
Tip #20. Hibernate Tab Not Available in Windows 2000 DataCenter
Tip #21. Windows 2000 DataCenter WINMSD.EXE utility reports wrong BIOS
version
Frequently Asked Questions
Appendix A. Informational Tables
Appendix B. Installing TopTools Agents or Instant TopTools on Windows 2000
Server/Advanced Server
On-Line Information and Software Sources
Introduction
This document was created by Hewlett-Packard for the purpose of helping you install
Microsoft Windows 2000 on your HP Server based on procedures tested by HP. The
objective of this document is to provide the information needed to achieve the following
tasks.
· Install Windows 2000 from Diskette or CD-ROM

· Create boot diskettes from CD-ROM
· Configure system as Domain Controller and DNS Server
· Change IP Address
· Provide installation troubleshooting tips and tricks
Before you start installing or upgrading to Windows 2000 check the following documents
and make sure you develop an action plan to complete the installation. Use the following
informational resources to help you.
· read1st.txt (Windows 2000 CD-ROM)
· readme.doc (Windows 2000 CD-ROM)
· Troubleshooting Tips and Tricks at the end of this document.
Requirements
· Microsoft Windows 2000 CD-ROM.
· Target system to be tested with minimum of P166 Processor and 64Meg of RAM
(128Meg Recommended).
· One or more Network Interface Cards (NIC).
· One or more hard drives.
· Latest system BIOS update. (http://www.hp.com)
· Two or more clients for testing purpose. (Optional)
· HP Driver's diskette if installing devices that have no drivers included in the
Windows 2000 CD-ROM. Example: HP NetRAID-4M, HP Fiber Channel adapter
(Optional), etc. (This driver’s diskette may contain updated Windows 2000 drivers
for HP components.)
Process Flow ( High Level View )
1. Locate and install optional components.
2. Install Windows 2000 on NetServer as stand alone system.
3. Hardware status check with "Device Manager" tool.
4. Prepare all logical drives and shared directories.

5. Configure IP address as needed.
6. Attach clients to network.
7. Test network link using the ping utility.
8. Domain controller setup.
9. Create shared directories.
10. Verify that all clients can access the shared directories.
11. Perform a file copy test.
Installation Planning Sheet
Complete the following table before you begin the installation process. You will need
this information in order to answer questions that you will be asked during the installation
process.
Partition Table: ______________________(List target partitions)
User Name: _________________________
Organization: ________________________
Licensing: ___________________________
Computer Name: ______________________
Admin Password: _____________________
Date Time Zone: ______________________
Workgroup or Domain Name: ______________
Registration Key: ____________________________
Installation Methods
There are several ways of installing Windows 2000. The most popular methods are listed
below. Select a method and go to the appropriate section of this guide to begin.
Depending upon your system and its configuration, it may also be necessary to create a
drivers diskette.
1. Automatic Installation – boot from the HP Navigator CD and run the Configure the
Server utility.

2. Manual Installation – do the following:
· Create the HP NetServer Windows 2000 drivers diskettes using the HP
NetServer Navigator CD-ROM.
· Select one of the following methods for installation:
- Create Windows 2000 Setup diskettes. Use those diskettes to begin the
installation. Insert and use the Windows 2000 CD when prompted. You may
need to use this method if you have an HP NetServer LX Pro (see
troubleshooting tip 5, later in this document).
Or
- Boot directly from the Windows 2000 CD to begin the installation.
(Supported on all HP NetServer systems except the LX Pro–see
troubleshooting tip 5, later in this document).
Automatic Installation – Using the HP Navigator CD
HP recommends that you follow this method to install Windows 2000. This is the easiest
method because it requires less user intervention. Following are the steps to complete the
installation of Windows 2000 using the HP Navigator CD.
1. Boot the system from the HP Navigator CD.
2. Select "Configure the Server" from the Navigator main menu.
3. At the next screen, select "Guided Setup".
4. Follow the on-screen prompts to complete the installation.
Manual Installation
Creating the Drivers Diskette
Before you begin, use one of the following two methods that can be used to create the
drivers diskette. One method is to create the drivers diskette using a system booted from
the Navigator CD. The other method is to create the drivers diskette using a system that
is running Windows NT, Windows 2000, or Windows 95/98.
Creating the Drivers Diskette at the server after booting from the Navigator CD
1. Boot the system from the Navigator CD.
2. Select “Diskette Library” from the Navigator main menu and follow the on-screen
instructions to create the desired diskette(s).

Create the Drivers Diskette using a system running Windows NT, Windows 2000, or
Windows 95/98
1. Insert the Navigator CD in the CD-ROM drive on the Windows-based system.
NOTE: The system’s monitor must be set for at least 800 x 600 resolution.
2. Your system should auto-detect the presence of the CD and start the Navigator
process. If your system does not auto-start the Navigator process, start it by
executing LAUNCH32.EXE which can be found at the root level of the Navigator
CD.
3. Once the Navigator process has started, select the target HP NetServer system from
the drop-down menu and select “Continue”.
4. From the “NetServer Navigator Select a NOS” screen, select the operating system
that you will be installing. Then, select “Continue”.
5. At the “NetServer Navigator Main Menu” screen, select “Diskette Library”.
6. From the “Diskette Title” window, select the diskette that you want to create and then
select “Create Diskette(s)”. Follow the on-screen instructions to create the desired
diskette(s).
Selecting the Manual Installation Method
Before using this method of installation, decide whether you want to install Windows
2000 using Setup Diskettes, or by booting directly from the Windows 2000 CD.
· If you wish to create Setup Diskettes (perhaps because you have other systems that do
not support booting from CD), proceed to the following section "Creating Setup
Diskettes."
· If you want to start the setup by booting directly off the Windows 2000 CD
(supported for all NetServers), proceed to the following section "Installing Windows
2000."
Creating Setup Diskettes
If you opt for starting the Windows 2000 installation from Setup Diskettes, do the
following:
1. You need four blank, formatted diskettes. Label them as listed below:
Windows 2000 Setup Boot.
Windows 2000 Setup Disk #2.
Windows 2000 Setup Disk #3.
Windows 2000 Setup Disk#4

2. Place the Windows 2000 CD on a system running Windows NT or Windows 95.
3. Open a command prompt and change to the d:\bootdisk directory (assuming that D: is
your CD-ROM drive).
4. At the command prompt type:
makebt a: (If using a DOS or Win 9X system)
makebt32 a: (If using an NT system)
5. Follow the on-screen instructions provided by the utility.
Starting the Installation Windows 2000 Using Setup Diskettes
1. Boot from the "Windows 2000 Setup Boot" diskette. Follow instructions displayed,
replacing diskettes as necessary.
2. When prompted for the Windows 2000 CD-ROM, place the CD in the drive and then
proceed to Step 2 in the next section "Installing Windows 2000" to continue the
installation.
Special Instructions for Installing Windows 2000 on HP NetServer LH
6000 or LT 6000r Systems
The Windows 2000 installation process automatically sets “write combine” on which
causes the HP NetServer LH 6000 and LT 6000r to hang under various conditions. If
you are installing Windows 2000 on an LH 6000 or LT 6000r, carefully perform the
following special instructions for installing Windows 2000 on an LH 6000 or LT 6000r.
1. Before you begin the installation of Windows 2000 on an LH 6000 or LT 6000r,
create the “Windows 2000 Drivers Diskette.” (Created from HP Navigator CD-ROM)
See the instructions for creating drivers diskettes earlier in this document.
2. Install Windows 2000 using the procedure given below.
3. On the first boot of the system following the completion of the installation of
Windows 2000, shut the system down by pressing CTL-ALT-DEL, use the right
arrow key to select “shutdown”. DO NOT USE THE MOUSE DURING THE
SHUTDOWN PROCESS AS IT COULD CAUSE YOUR SYSTEM TO HANG.
4. When the system reboots press F8 at the start of the Windows 2000 boot sequence.
5. Select”Enable VGA mode” from the choices listed on the display.
6. When prompted to login, press CTL-ALT-DEL and login as administrator. (You can
use the mouse while you are running in VGA mode.)
7. Insert the Windows 2000 drivers diskette that you created earlier.
8. Open the My Computer folder.

9. Open Drive A: folder.
10. Open the w2kvp folder.
11. Double click w2kvp.reg. (You may not see the file extension depending upon how
you have your system configured.)
The content of the w2kvp.reg file is as follows:
REGEDIT4
[HKEY_LOCAL_MACHINE\SYSTEM\ControlSet001\Control\Graphics
Drivers\DisableUSWC]
12. Click Yes at the popup dialog box to confirm the registry changes.
13. Click OK to finish the registry update.
14. Remove the diskette and perform a Shutdown, Restart.
15. Let the system boot as usual and login.
16. Test the system by changing the video resolution to 800x600 and running “Disk
Administrator” to prepare the system.
Special Instructions for Installing Windows 2000 on an HP NetServer
LP 1000r or LP 2000r
NOTE: There are no embedded 53C1010 Ultra 3 SCSI boot device drivers
included on the Windows 2000 CD-ROM
Before you begin the installation of Windows 2000 on an LP 1000r or LP 2000r, create
the “Windows 2000 Drivers Diskette for the embedded 53C1010 Ultra 3 SCSI.” (Created
from HP Navigator CD-ROM) See the instructions for creating drivers diskettes earlier
in this document.
After the installation of Windows 2000, the Windows 2000 Device Manager will detect
SDR GEM318 SCSI Processor Device as Other Device because Windows 2000 does not
have the SAF-TE.INF file.
To solve this issue, perform the following steps:
1. Create the “HP SAF-TE.INF file Diskette.” (Created from HP Navigator CD-ROM).
See the instructions for creating drivers diskettes earlier in this document.
2. Install Windows 2000 using the procedure given below.
3. After the installation, go to the Device Manager, click on Other Devices.

4. Right click on SDR GEM318 SCSI Processor Device.
5. Click on the Driver Tab then the Upgrade Driver button.
6. Click Next on the Upgrade Device Driver Wizard menu.
7. Select the “Search suitable Driver for My Device” then click Next.
8. Insert the “HP SAF-TE.INF file Diskette” created from HP Navigator CD-ROM in
the floppy drive.
9. Check the “Floppy Disk Driver” option then click Next.
10. Windows 2000 will search the floppy diskette for the INF file and then install it.
11. After this process the SDR GEM318 SCSI Processor Device will disappear from the
Other Devices list, and display under System Devices.
Install Windows 2000 using the procedure given below.
Installing Windows 2000
NOTE: An intermittent, but critical cache manager timeout issue in Windows
2000 Server and Windows 2000 Advanced Server has been identified. To avoid
potential data loss in certain situations, it is strongly recommended that you install
a Microsoft fix after you install Windows 2000 Server or Windows 2000
Advanced Server.
To obtain this fix refer to Microsoft knowledgebase article Q252332 at
http://support.microsoft.com/directory. Refer to the Microsoft website for any
updates.
1. If you have opted not to use Setup Diskettes, place the Windows 2000 CD in the CD-
ROM drive. Power off and on to reboot the system. You will see a message that reads
"Setup is inspecting your hardware configuration.". Then the setup screen will be
displayed.
NOTE: If you experience any hang or issue during this time, consult the
Tips/Tricks section of this document for help.
2. If you have new drivers to add then press F6 to add OEM SCSI, DAC. Read the
message that shows at the bottom of the display indicating when to press F6.
NOTE: If the boot device driver is not included on the Windows 2000 CD-ROM,
for example the “HP NetRAID-4M”, then do the following steps after pressing F6
a) Press Sto select additional hardware.
b) Select Other and press Enter.

c) When prompted to insert driver diskette, please insert the target adapter
driver’s diskette created with the HP Navigator CD-ROM. Press Enter to
continue.
d) Select the target device driver from the list provided on the display. For
example, if you have the “HP NetRAID-4M”, select "Hewlett Packard NetRAID-
4M RAID CONTROLLER".
if you have the “HP NetRAID-1M/2M”, select "Hewlett Packard NetRAID-
1M/2M RAID CONTROLLER".
Please repeat the above step for the “HP NetRAID-2M and 1M”
e) If you have no other drivers that you need to install, press Enter to continue
with the installation.
3. Press Enter to continue at the "Windows 2000 Server Setup. Setup Notification…"
screen.
4. Press Enter to continue at the "Windows 2000 Server Setup. Welcome to Setup…"
screen.
5. Press Cto continue Setup at the "Setup has determined that your computer's startup
hard disk is new…" prompt.
6. Press F8 to accept the licensing agreement.
7. At the drives partitioning screen, select the target drive. If you want to use the entire
drive to install Windows 2000 then press Enter. Otherwise, press Cto create a drive
a partition.
(In this example we will create a 2GB partition. Please note that Windows 2000 does
not have the 2GB partition size limitation present on NT 4.0.)
8. Type 2048 and press Enter at the Create partition size prompt.
9. HP recommends that you create all the partitions needed for each hard drive present
on your system at this time.
10. Select the target drive to be used to install Windows 2000. Press Enter.
11. Select Format the partition using the NTFS file system and press Enter.
12. The installer will format and copy files to the hard drive. The system will then reboot.
13. Click Next to continue at the Setup Wizard first dialog box.
14. The Installing Devices screen will be shown with a progress bar on the display. This
may take 10 to 15 minutes.

NOTE: If you see a dialog box titled "Digital Signature Not Found".
Please click “Yes” to continue the installation and read Tip #14 in the
troubleshooting section of this guide.
15. Click Next at the regional Settings screen.
16. At the Personalize Your Software screen, enter a name and organization. Then
click Next.
17. Enter the product license key.
18. Click the Per Seat radio button. (At the Licensing modes screen)
19. Click Next
20. At the Computer Name and Administrator Password type in your computer name,
administrator password and password confirmation. Then click Next.
21. Click Next at the Windows 2000 Component screen to accept default values.
22. Enter the proper date and time and click Next .
23. The Networking Setting screen starts with a progress bar chart.
24. Click Next to accept the default Typical settings.
25. Click Next at the Workgroup or Computer Domain to accept the default:
"No, This computer is not on a network, or is on a network without a domain…"
and
"Workgroup or computer domain: WORKGROUP."
NOTE: For Windows 2000 DataCenter, you must enter either the domain or
workgroup name before you can proceed to the next step.
26. The Installing Components screen starts with a progress bar chart. It takes about 20
minutes to complete this section. The wizard will then start the "Performing Final
Tasks" section to complete the installation.
27. Click Finish to complete the installation. Remove the CD from the drive. The system
will then reboot from the hard drive.
NOTE: There may be a period of time with no apparent activity after it displays a
message that reads "OS Loader Version 5.0". Be patient.
28. Follow screen instructions to logon. Enter user-id and password.
29. Read Tip #18 to install the Windows 2000 Recovery Console to enhance the system's
configuration.

Hardware Status Check
In this section you will run the "Device Manager" tool to identify any issues with the
installed devices or resource conflicts.
1. Right click My Computer.
2. Click Properties. This brings up the "System Properties" panel.
3. Click Hardware tab.
4. Click Device Manager… button.
5. Verify that no devices have either a yellow band (!) or question mark (?) symbol next
to it. (See following note for pointer to exceptions)
Yellow (!) means that there is a resource issue with the device.
Question (?) means that the device is unknown.
NOTE: Hewlett Packard and Microsoft have identified some devices that
under normal conditions can produce (!) or (?) marks. Please see table 5 in
the Appendix A of this document for an interpretation.
6. If no (!) or (?) symbols are reported then you are done. Go to step 9. Otherwise, do
the next step.
7. Double click on each of the devices with (!) or (?). Note the "Device Status"
message. Or if a printer is available, use the View, Print from the menu to get a
report.
8. See table 5-7 to verify any errors detected in steps 6 and 7.
9. Verify if the installed drivers are digitally signed.
A. In the Device Manager, click on the device (e.g HP NETRAID 1M/2M) that
want to verify.
B. Right click on that device.
C. Click Properties option.
D. Click on Driver Tab
E. Locate the” Digital Signer:” If the driver of that device is digitally signed then
it will display “MS Windows 2000 Publisher” or “ Microsoft Windows
Hardware Compatibility Publisher”.
If the driver of the device is not digitally signed we recommend that you

check the HP Website www.hp.com. for the latest driver package. If available
install new driver.
10. Exit device manager and system properties application.
11. Check the Event viewer to make sure that there are no errors in the log.
Click on Start | Programs | Administrative tools | Event viewer.
12. Exit event viewer.
13. Initialize Hard Drives
To start the disk administrator use the following procedure.
1. Click Start | Programs | Administrative Tools | Computer Management.
2. If necessary click the +sign next to Storage to open this folder.
3. Double click Disk Management.
4. The "Write signature and Upgrade" wizard will start if you have new hard drives with
no signatures on them.
5. Follow the instructions provided by the wizard to create the new hard drive signature.
6. Perform formatting and partitioning.
NOTE: There are two types of hard drive configuration: Dynamic and Basic.
You can select the appropriate type by right clicking on the drive icon on the
screen. Dynamic drives are used to create volumes which can contain more than
one physical hard drive. Basic drives are used to create primary or local
partitioned drives.
Configure Server IP Address
During the installation process the system was configured to use DHCP. Also, when no
DHCP server is found on the network the system will auto-configure a random IP address
to start functioning. It is important that you configure the proper IP address to be able to
communicate with the clients.
Configuring IP Address Steps.
1. Right click My Network Places.
2. Click Properties.
3. Double click Local Area Connection. There is one "Local Area Connection" icon
for each Network Interface Card (NIC) present on the system. Identify the proper NIC
by browsing each one.

4. Click Properties at the Local Area Connection Status screen.
5. Click Internet Protocol(TCP/IP).
6. Click Properties.
7. Click Use the following IP address.
8. Enter appropriate IP address selected on the planning section listed above. For
example 100.100.100.1.
9. Click the OK button to continue.
10. Open a command prompt window to verify the TCP/IP configuration. Enter the
command:
ipconfig /all
You should get a display showing the configuration information you entered above.
11. Test the link by entering the following at the command prompt:
ping computername
Where computername is the server name. You should get four reply's from
100.100.100.1, if you don't get this result then there is a link problem which must be
fixed before going any further.
12. Test the link by doing a ping to one of the clients attached to the server, for example:
ping 100.100.100.2
You should get four reply's from the client.
Attach Clients to Network
Follow normal procedure to patch the clients to the proper hub with the server.
Domain Controller Setup
The Windows 2000 reference guide calls this process "Promoting the server to a domain
controller".
1. Click Start | Run and enter the command:
dcpromo
2. Click Next at the "Active Directory Installation Wizard".

3. Click Next at the "Domain Controller Type" to accept default "Domain Controller for
a new Domain" radio button enabled.
4. Click Next at the "Create Tree or Child Domain" to accept default "Create a new
domain tree" radio button enabled.
5. Click Next at the "Create or Join Forest" to accept default "Create a new forest of
domain trees" radio button enabled.
6. At the text box for "Full DNS name for new domain:" type in the assigned DNS name
for your server (for example: hostname.com).
7. Click Next. The system will take a few minutes with the hour clock on the display
before moving to next screen.
8. Click Next at the "NetBIOS Domain Name" dialog box to accept default "Domain
NetBIOS name:"
9. Click Next to accept "Database and Log Locations" default values:
Database Location: C:\WINNT\NTDS
Log Location: C:\WINNT\NTDS
10. Click Next to accept default "Shared System Volume".
Folder Location: C:\WINNT\SYSVOL
11. The system will display a dialog box that reads "The Wizard can not contact the DNS
Server…." Confirm your DNS configuration, or install and configure a DNS server
on this computer. Click OK.
12. Click the Yes, Install and config DNS on this computer radio button for this
choice. Click Next.
13. Click the Permissions compatible with pre Windows2000 Server radio button.
Click Next to continue.
14. Enter the Administrator password and click <Next>.
15. Review the Summary display and click Next to continue.
16. The system will start configuring the active directory display. It shows an animation
of a pencil writing on a note pad. This will take a few minutes to complete..
17. If prompted, insert Windows 2000 CD-ROM and click OK to continue.
18. Configuring active directory display shows again. Click Finish to close the Wizard
utility. This completes the active directory installation.

19. Click Restart Now to reboot the system. Remove CD-ROM if present.
20. At the login prompt type in the password. Click the Options button and verify that
the "Log on to: HOST" appears on the dialog box. Click OK to start the logon
process.
Adding Terminal Server Services
1. Open Control Panel.
2. Double click Add Remove Programs.
3. Click Add/Remove Windows Components.
4. Scroll to and click Terminal Services checkbox.
5. Click Next.
6. Select the mode you want to use: "Remote administration mode" or "Application
sever mode". These instructions will use "Application server mode". Click the radio
button for "Application server mode". Please note the licensing requirement listed
on the screen for this mode. Consult with your Microsoft representative for setting the
licensing server.
7. Click Next.
8. Select "Permissions compatible with Terminal Server 4.0 Users".
9. Click Next.
10. Click Next to accept support tools and administrator tools settings.
11. If prompted, insert the Windows 2000 CD-ROM.
12. Click Finish to close the Wizard.
13. Click Yes to restart the system. (Remove the CD-ROM).
14. After the system reboots, Login to system.
15. Open Control Panel.
16. Open Administrative Tools folder. You should see the following icons present
"Terminal Services Client Creator", "Terminal Services Configuration" and
"Terminal Services Manager".
Create Client Installation Diskettes
17. Double click "Client Services Client Creator".

18. Select Terminal Services for 32-bit x86 windows. (Select the appropriate client type
for your environment).
19. Click Format disk if needed.
20. Label two diskettes as "Terminal Services for 32-bit x86 Disk1" and "Terminal
Services for 32-bit x86 Disk2".
21. Click OK.
22. Insert diskette one when prompted and click OK.
23. Insert diskette two when prompted and click OK.
24. Click OK at the screen that reads "2 floppies were created….".
25. Click the Close button to end the "Create Installation disks" utility.
26. Install Client Utility on each workstation that you want to use to connect to Terminal
Server.
27. Configure clients to connect to target Terminal Server and test for communication
functionality.
Installing the Client Utility on a Workstation
28. Insert diskette 1 in the target client and run setup.exe.
29. Click Continue.
30. Complete the "Name and Organization Information" form. You will be prompted for
this information only the first time the diskettes are used.
31. Click OK.
32. Click OK to confirm.
33. Click I Agree.
34. Click Large Icon button to start installation.
35. Click Yes to accept initial settings. (Make the choice you feel appropriate).
36. Insert diskette 2 when prompted and follow screen instructions.
37. Shutdown and restart workstation.
Test the Connection
38. Click Start | Programs | Terminal Services Client.

39. Select the target server from "Available Servers" list provided on the screen.
40. Select the appropriate screen resolution. In this case click the down arrow and select
800x600.
41. "Enable Data compression" is selected by default.
42. Click Cache bitmaps to disk. (Make the choice you fell appropriate)
43. Click Connect button.
44. Complete "UserID, Password" login form.
Installing Citrix MetaFrame Version 1.8 for Microsoft Windows 2000
The objective of this section is to assist customers with manual installation of "Citrix
MetaFrame for Windows 2000 Terminal Service" on a Hewlett-Packard NetServer
system.
NOTE: You Need to install Windows 2000 Terminal Service before you install Citrix
MetaFrame Windows 2000 Servers.
Required Tools
Citrix 1.8 MetaFrame for Windows 2000 CD-ROM. Windows 2000 installed with
Terminal Service.
1. Insert "Citrix MetaFrame Windows 2000 Servers" CD in the CD-ROM drive.
2. Click MetaFrame Setup button in the Citrix MetaFrame CD-ROM screen.
3. Click "I agree" in the MetaFrame License Agreement screen.
4. Click Next in the Welcome screen of MetaFrame 1.8 for Windows 2000 Setup.
5. Click Next in the Setting Up MetaFrame screen of MetaFrame 1.8 for Windows
2000 Setup
6. Click Add License Packs in the Setting up MetaFrame screen of MetaFrame 1.8
for Windows 2000 Setup.
7. Enter the product serial number in the Enter License Serial Number screen.
8. Click OK in the Important Message screen.
9. Click No in the Citrix Licensing screen.
10. Click Next in the MetaFrame 1.8 for Windows 2000 screen.

11. Click Next in the Network ICA Connections screen.
12. Click Next in the TAPI Modem setup screen.
13. Click Next in the Drive Mapping screen.
14. Click Next in the Server Reassignment screen.
(Please takes note of the original and new drive letters)
15. Click Finish in the System Reboot screen.
16. After the system reboot, click OK in the Citric License Warning Notice screen.
Installing Citrix MetaFrame XP 1.0 for Windows 2000
The objective of this section is to assist customers with a manual installation of "Citrix
MetaFrame XP for Windows 2000 Terminal Service" on an HP NetServer system.
NOTE: You Need to install Windows 2000 Terminal Service before you install
Citrix MetaFrame XP.
To Install Citrix MetaFrame XP
1. Insert "Citrix MetaFrame XP 1.0" CD in the CD-ROM drive.
2. Click MetaFrame XP Setup button in the Citrix MetaFrame XP CD-ROM screen.
3. Click I agree in the MetaFrame License Agreement screen.
4. Click Next in the Welcome screen of MetaFrame XP Setup.
5. Click Next in the Data Store Configuration screen.
6. Select "Create a New Server Farm" in the eServer Farm selection screen. Click
Next.
7. Select "Use a Local Database for the Data Store" in the Data Store configuration
screen. Click Next.
8. Verify that "Use Default Zone Name" is selected. Click Next at the Zone Name
screen.
9. Enter " new server Farm name " in the Enter Server Farm screen.
10. Confirm correct server Farm Name. (Note: If need to change/rename the server farm
name then click Back, otherwise click Next in the Confirm Server Farm screen.

11. Choose default option "Operate Independently in Native IMA-Only Mode". Click
Next in the MetaFrame Interoperability screen.
12. Enter User Name and Domain Name at the Farm Administration screen and then
click Next.
13. Click Yes if the account name entered correct in the Validate User Name screen
14. Click Next in the Network ICA Connections screen.
15. Click Next in the TAPI Modem setup screen.
16. Click Next in the ICA Session Shadowing screen
17. Except default setting "Allow Shadowing of ICA sessions on this Server". Click Next
in the Shadowing Setup screen.
18. Click Next in the Drive Mapping screen.
19. Click Next in the Server Reassignment screen. (Note: click the option "Remap the
Server Drivers" if need to reassign server driver letter)
20. Except default setting "Share default TCP/IP port with Internet Information Server".
Click Next in the Citrix XML service screen.
21. Except default setting and click NEXT in the NFuse Setup screen.
22. Click Next in the Perform Installation screen.
23. Click Cancel in the Citrix ICA Client Distribution Wizard screen.
24. Enter License Serial Number in the MetaFrame XP 1.0 Licensing screen then click
Add. Click Next in the MetaFrame XP 1.0 Licensing screen.
25. Click Next in the MetaFrame XP Product Code.
26. Click Cancel.
27. Click Restart in the System Reboot screen.
28. After the system reboot, click OK in the Citric License Warning Notice screen.
NOTE: when you install MetaFrame XP using the MetaFrame XP Setup option
the Citrix Management console is automatically install by default.
To upgrade additional users license
1. Launch Citrix Management Console.
