Compaq Evo D510 - Convertible Minitower Manual

System Unit
1 Computer cover Not spared
2 Front bezel assembly, complete 262011-001
* Front bezel assembly, complete, EMEA only (Blue
Angel)
288694-001
3Expansion card cage Not spared
4Power supply, PFC, dual voltage 274427-001
5 Chassis assembly with drive cage (reference only) Not spared
6 Front trim (below front bezel) 273034-001
* Front trim (below front bezel), CKK only 302605-001
Mass Storage Devices
120-GB, UATA, 100/7200 Quiet hard drive 180476-001
*20-GB, UATA, 100/5400 Quiet hard drive 254451-001
*20-GB, UATA, 100/4200, MultiBay 273407-001
* 40-GB UATA 100/ 7200 Quiet hard drive 202904-001
* 40-GB UATA 100/5400 Quiet hard drive 236921-001
*80-GB, UATA 100/7200 hard drive 250185-001
2Diskette drive, 3.5-inch, buttonless 278644-001
316/10/40X CD-RW/DVD-ROM drive, carbon 281749-001
*40/10/40X CD-RW drive, carbon 286711-001
*16/10/24X CD-RW drive, carbon 286691-001
* 48X CD-ROM drive, carbon 232320-001
* 24X CD-ROM drive 228746-001
* 16X DVD-ROM drive, carbon 278647-001
* 8X DVD-RW MultiBay drive 251292-001
*DiskOnKey, 8-MB 249911-001
*Not shown
Cables
Cable kit, includes: 192263-001
2 CD-ROM audio cable, 12 in. (387527-002)
* CD data cable (108950-017) (not this product)
Other Cables
1 Diskette drive cable (168999-004) 289048-001
3 Hard drive data cable (108950-035) 258209-001
4 MultiBay drive data cable (277521-001) 302604-001
* CD-ROM drive data cable (108950-039) 289049-001
* Solenoid cable 265954-001
*Not shown
Documentation and Packaging (not illustrated)
Service Reference Guide 259968-001
Quick Troubleshooting Guide 153837-001
Illustrated Parts Map 302343-001
Return kit 266280-001
Keyboards (not illustrated)
PS2, Easy Access 271122-001
USB, Smart Card, Easy Access 271124-001
Arabic -171 Korean -KD8
Belgian -181 International -B31
Brazilian Portuguese -201 Latin American Spanish -161
BHCSY* -B41 Norwegian -091
Chinese -AA1 Polish -241
Czech -221 Portuguese -131
Danish -081 Russian -251
Dutch/Netherlands -331 Slovakian -231
Finnish -351 Spanish -071
French -051 Swedish -101
French Canadian -121 Swiss -111
German -041 Taiwanese -AB1
Greek -151 Thai -281
Hebrew -BB1 Turkish -141
Hungarian -211 United Kingdom -031
Italian -061 U.S. -001
Japanese -191
* Bosnia-Herzegovina, Croatia, Slovenia, and Yugoslavia
Standard and Optional Boards
1 System board 277977-001
2 Memory module, 128 MB, DDR 285648-001
* Memory module, 256 MB, DDR 285649-001
* Memory module, 512 MB, DDR 285650-001
3 Riser board 252298-001
4 PCA, 10/100, IPSEC, NIC, Intel 215774-001
*NIC,3COM 253951-001
* Modem, PCI v92 239411-001
Pentium Celeron Processor with alcohol pad and thermal grease
* 1.7 GHz / 128K cache, 400 FSB 288691-001
* 1.8 GHz / 128K cache, 400 FSB 288692-001
Pentium P4 Processor with alcohol pad and thermal grease
* 1.7 GHz / 256K cache, 400 FSB 252919-001
* 1.8 GHz / 256K cache, 400 FSB 255435-001
* 1.9 GHz / 256K cache, 400 FSB 255436-001
* 2.0 GHz / 512K cache, 400 FSB 273051-001
* 2.2 GHz / 512K cache, 400 FSB 273052-001
* 2.4 GHz / 512K cache, 400 FSB 283925-001
* 2.26 GHz / 512K cache, 533 FSB 288688-001
* 2.4 GHz / 512K cache, 533 FSB 288689-001
* 2.53 GHz / 512K cache, 533 FSB 288690-001
Graphics Solutions
* nVIDIA P60-C04 graphics card, NV 11, 64 MB
memory, with LPX bracket
289593-001
* nVIDIA P60-C04 graphics card, NV 11, 64 MB
memory, with ATX bracket
279777-001
* Not shown
Miscellaneous Parts
1 PCA, MultiBay 283985-001
2 Front bezel assembly, complete 262011-001
* Front bezel assembly, complete, EMEA only (Blue
Angel)
288694-001
3 Speaker 249968-001
4 Front trim (below front bezel) 273034-001
* Front trim (below front bezel), CKK only 302605-001
5 Solenoid, 2-coil 201485-001
Air baffles, include: 293324-001
6 Air baffle, D-HS (250805-002)
7 Air baffle, D-HS-2 (250805-004)
Plastics kit, includes: 257051-001
* Bezel blank (166775-002)
* Cable clip (172948-001) (not this product)
* Power switch spring (166837-002) (not this product)
* LED holder (112589-001) (not this product)
* Power switch holder (245154-001) (not this product)
Other Parts
* Heatsink with alcohol pad 254286-001
* Chassis fan assembly 289051-001
* Rubber foot (4 ea) 266051-001
* Labtec Spin-22 speakers, Japan 223492-291
* Mouse, carbon, 2-button with ratchet wheel 237241-001
*Not shown
b
© 2002 Compaq Information Technologies Group, L.P.
Compaq, the Compaq logo, and Evo are trademarks of
Compaq Information Technologies Group, L.P.
Intel, Pentium, and Celeron are trademarks of Intel
Corporation in the United States and other countries.
All other product names mentioned herein may be
trademarks of their respective companies.
Compaq shall not be liable for technical or editorial errors
or omissions contained herein. The information in this
document is provided “as is” without warranty of any kind
and is subject to change without notice. The warranties for
Compaq products are set forth in the express limited
warranty statements accompanying such products. Nothing
herein should be construed as constituting an additional
warranty.
June 2002
Document Part Number 292401-001
Spare Part Number 302343-001
Compaq Evo Deskpro D510
Small Form Factor
Pentium Models
Illustrated Parts Map

System Board Connectors and Jumpers
CR1 Power LED (front of computer) P6 Speaker
CR2 HD LED (front of computer) P7 CD ROM audio
CR21 3.3V AUX LED (see sticker for location) P10 Diskette
CR28 +5V AUX (ON) / PSON LED (OFF)
(see sticker for location)
P20 Primary ATA
DMM1 DIMM 1 P21 Secondary ATA
DMM2 DIMM 2 P27 MultiBay header
E15 Boot block P70 Chassis fan
E49 Password jumper P124 Hood lock
J30 Riser board connector SW6 Power button (front of computer)
J40 AGP socket* SW50 CMOS reset
J4002 CPU power XBT2 Battery
P1 Power supply XU1 Processor socket
* Note: AGP socket has a different front retainer latch that requires rotation before the card can be removed.
Riser Board Connectors and Jumpers
E9029 SCSI LED P9030 Aux CD audio
J9020 PCI Slot SW9001 Security hood switch
J9021 PCI Slot
System Hardware Interrupts
IRQ System Function IRQ System Function
0Timer Interrupt 8 Real-Time Clock
1Keyboard 9 Available for PCI
2Interrupt Controller Cascade 10 Available for PCI
3Serial Port (COM B) 11 Available for PCI
4Serial Port (COM A) 12 Mouse
5Audio 13 Coprocessor
6Diskette Drive 14 Primary ATA (IDE) controller
7Parallel Port (LPT 1) 15 Secondary ATA (IDE) controller
System Board Diagnostic Lights1
Main Power Switch Status 3.3 V_Aux LED 5 V_Aux/PSON LED
OFF2ON ON4
ON3ON OFF5
1. ON and OFF state of LEDs apply only to a good, working system board with AC power applied to the power supply.
2. Power LED on front of computer is OFF.
3. Power LED on front of computer is ON (Green).
4. 5V_Aux is ON.
5. PSON is active = power supply is turned ON.
Computer Diagnostic LEDs (on front of computer)
LED Color LED Activity State/Message
Power Green On (S0) Computer on
Power Green 1 blink every 2 seconds (S1) Normal Suspend Mode
Power Green 1 blink every 2 seconds (S3) Suspend to RAM
Power Clear Off (S4) Suspend to Disk (if applicable)
Power Clear Off (S5) Computer off
Power Red 2 blinks 1 second apart, fol-
lowed by 2-second pause -
Repeat
CPU thermal shutdown
Power Red On CPU not installed
Power Red 1 blink every 1 second ROM error
Power Red 1 blink every 2 seconds Power supply crow bar
Hard Drive Green Blinking Hard drive activity
Keyboard Diagnostic LEDs
LED Color LED Activity State/Message
Num Lock Green Flashing (Beeps - 1S, 2L) Memory error
Caps Lock Green Flashing (Beeps - 1L, 2S) No video
Scroll Lock Green Flashing (Beeps - 2L, 1S) System board failure, prior to video
Num, Caps,
Scroll Lock
Green Flash On-Off 2 times (Beeps -
1L, 3S)
Invalid system ROM detected. ROM forces
reflash.
Num, Caps,
Scroll Lock
Green On (Rising Tone) ROM reflashed successfully
Num Lock Green On Boot block recovery failed - ROMPaq diskette
not present, is bad, or drive not ready.*
Caps Lock Green On Enter password.
Num, Caps,
Scroll Lock
Green Blink On in sequence, one at a
time - N, C, SL
Keyboard locked in network mode
* Insert valid ROMPaq diskette in drive A. Turn power switch off, then on to reflash ROM. If ROM flash is successful, all
three keyboard LEDs will light up, and you will hear a rising tone series of beeps. Remove diskette and turn power off,
then on to restart the computer. For more information about flashing the ROM, refer to the Troubleshooting guide.
Clearing CMOS*
The computer's configuration (CMOS) may occasionally be corrupted. If it is, it is necessary to clear the CMOS
memory using switch SW50.
To clear and reset the configuration, perform the following procedure:
1. Prepare the computer for disassembly.
ÄCAUTION: The power cord must be disconnected from the power source before pushing the Clear CMOS
Button (NOTE: All LEDs on the board should be OFF). Failure to do so may damage the system board
2. Remove the access panel.
3. Press the SW50 button located on the system board and keep it depressed for 5 seconds.
4. Replace the access panel.
5. Turn the computer on and run F10 Computer Setup (setup utility) to reconfigure the system.
Disabling or Clearing the Power-On and Setup Passwords*
1. Turn off the computer and any external devices, and disconnect the power cord from the power outlet.
2. Remove the access panel.
3. Locate the header and jumper labeled E49.
4. Remove the jumper from pins 1 and 2. Place the jumper over pin 2 only, in order to avoid losing it.
5. Replace the access panel.
6. Plug in the computer and turn on power. Allow the operating system to start. (Placing the jumper on pin 2 clears the
current passwords and disables the password features.)
7. To re-enable the password features, repeat steps 1-3, then replace the jumper on pins 1 and 2.
8. Repeat steps 5-6, then establish new passwords.
Refer to the F10 Computer Setup (setup utility) instructions to establish new passwords.
Computer Setup (F10) Utility Features (not all features may be available)
File
System Information
About
Set Time and date
Save to Diskette
Restore From Diskette
Set defaults and Exit
Ignore Changes and Exit
Save Changes and Exit
Storage
Device Configuration
Options
IDE DPS Self-Test
Controller Order
SCSI Narrow Termination
Boot Order
Security
Setup Password
Power-On Password
Password Options
Smart Cover
Smart Sensor
DriveLock
Master Boot Record Security
Save Master Boot Record
Restore Master Boot Record
Device Security
Network Service Boot
System IDs
Power
Energy Saver
Timeouts
Energy Saver Options
Advanced
Power-On Options
Onboard devices
PCI Devices
Bus Options
Devise Options
PCI VGA Configuration
Note: See Computer Setup (F10) Utility Guide on the Documentation Library CD.
