Maintenance and Service Guide
Compaq Presario 5000, 5100, and 5200 Series Computers
Models: 5070, 5184, 5201, 5206, 5221, 5240
Product
Description
Troubleshooting
Illustrated Parts
Catalog
Removal &
Replacement
Procedures
Jumper & Switch
Information
Specifications
See the Notice for copyright and trademark information, and the Preface for symbol
conventions and Technician Notes.
