Compaq Evo D510 MT Manual

System Unit
1 Access Panel Not spared
2 Front bezel assembly, complete 299172-001
Front bezel main panel insert, EMEA only (Blue
Angel)
301645-001
3 Chassis assembly (reference only) Not spared
4 Front bezel I/O insert, 2 USB, 2 audio 292209-001
5Power supply, PFC, dual voltage 277979-001
Mass Storage Devices (not illustrated)
20-GB, UATA, 100/7200 Quiet hard drive 180476-001
20-GB, UATA, 100/5400 Quiet hard drive 254451-001
20-GB Hard drive, MultiBay 273407-001
36.2-GB U3 SCSI, 10 K hard drive 192197-001
40-GB UATA 100/7200 Quiet hard drive 202904-001
40-GB UATA 100/5400 Quiet hard drive 236921-001
80-GB UATA, 100/7200 Hard drive 250185-001
Diskette drive, 3.5-inch, buttonless, carbon 278644-001
24X CD-ROM drive 228746-001
48X CD-ROM drive, carbon 232320-001
16/10/24X CDRW drive 286691-001
40/12/40X CDRW drive 286711-001
8X CDRW drive, MultiBay 251292-001
6/10/40/12X CVD-DVD drive 281749-001
16X DVD drive 278647-001
Miscellaneous Screws (not illustrated)
Miscellaneous screw kit, includes: 257050-001
.197 dia x 17 TPI x 0.5 lg, Plastite flathead, Phillips
(4 ea) (247481-001)
6-19 x 3/8 hi-top, plastite with captive washer
(1 ea.) (114399-069) (not used this product)
6-19 x 1/4 hi-top, plastite with captive washer
(1 ea.) (114399-067)
6-32 x 3/16 hi-top, thread forming with serrations
(4 ea.) (192308-003)
6-32 x 3/16 buttonhead tamper-resistant, taptite with
serrations (1 ea.) (296769-002)
6-32 x 1/4 hi-top, thread forming with serrations
(5 ea.) (192308-001)
M3 x 5mm, hi-top, plastite with serrations (4 ea.)
(247348-001)
Cables
1Audio cable for CD ROM drive, 21” 149806-001
2Front panel audio cable, 451 mm (245152-001) 255440-001
*USB cable for front panel, 12.5” (245151-003) 289574-001
3Diskette drive cable (143218-005) 257309-001
4Power switch/LED cable with switch and LEDs
(174682-002)
257303-001
*Solenoid cable (244168-001) 255438-001
*IDE Ultra ATA dual device, hard drive/CD-ROM
cable, 10” with pull tab, center polarization
(108950-037)
257047-001
5IDE Ultra ATA dual device, hard drive/CD-ROM
cable, 14” (108950-038)
257048-001
*SCSI LED cable (225537-001) 247485-001
*SCSI data cable (155825-001) 158277-001
6Second serial port cable (284217-001) (use with
283094-001)
302652-001
7MultiBay signal cable (277521-001) 302604-001
Cable kit, includes: 303279-001
*MultiBay data cable (289050-001)
*Hard drive, optical drive data cable (108950-042)
*Not shown
Keyboards (not illustrated)
Easy Access, PS/2 271122-xxx
USB 271124-xxx
Arabic -171 International **
Belgian -181 Latin American Spanish -161
Brazilian Portuguese -201 Norwegian -191
BHCSY* -B41 Polish **
Czech -221 Portuguese -131
Danish -081 Russian -251
Dutch/Netherlands ** Slovakian -231
Finnish -351 Spanish -071
French -051 Swedish -101
French-Canadian -121 Swiss -111
German -041 Taiwanese -AB1
Greek -151 Thai -281
Hungarian -211 Turkish -141
Italian -061 United Kingdom -031
Japanese -191 U.S. -001
Korean (Hanguel) -AD1
*Bosnia-Herzegovina, Croatia, Slovenia, and Yugoslavia
**Use B31 for 240441-xxx, use -002 for 164996-xxx
Standard and Optional Boards
1 System board 283983-001
2 Memory module, 128 MB RAM, DDR 285648-001
* Memory module, 256 MB RAM, DDR 285649-001
* Memory module, 512 MB RAM, DDR 285650-001
Intel Celeron Processor with alcohol wipe
* 1.7 GHz 288691-001
* 1.8 GHz 288692-001
Pentium P4 Processor with alcohol wipe
* 1.7 GHz, 256 K cache 252919-001
* 1.8 GHz, 256 K cache 255435-001
* 1.9 GHz, 256 K cache 255436-001
* 2.0 GHz, 512 K cache/400 MHz 273051-001
* 2.2 GHz, 512 K cache/400 MHz 273052-001
* 2.4 GHz, 512 K cache/400 MHz 283925-001
* 2.26 GHz, 512 K cache/533 MHz 288688-001
* 2.4 GHz, 512 K cache/533 MHz 288689-001
* 2.53 GHz, 512 K cache/533 MHz 288690-001
Other Boards
* Front mounted Audio/USB board 284247-001
3NIC,3COM 253951-001
* Intel Pro 100 S NIC 215774-001
* Modem, Lucent v90 239411-001
* PCI Expansion card 252609-001
4 Second serial port card 283984-001
5 MultiBay adapter board 283985-001
* nVIDIA NV11 graphics, 64 MB, with ATX bracket 279777-001
* U3 SCSI controller 158364-001
* Not shown
Miscellaneous Parts
* Chassis fan assembly 289575-001
* Mouse, carbon 237241-001
Heatsink assembly Type 1, includes: 289576-001
1 Fan assembly with mounting base, heatsink, and attaching screws
Heatsink assembly Type 2, includes: 300871-001
2 Heatsink with fan assembly and retaining clips
* Heatsink mounting base and attaching screws
3 Power switch/LED holder 257051-001
4 Hood intrusion sensor 267529-001
* Rubber foot (4 ea) 266050-001
* Battery 153099-001
* Solenoid, 2-coil 201485-001
5 DiskOnKey, 8 MB 249911-001
* Labtech speakers (Japan only) 223492-291
*Not shown
Miscellaneous Plastics (not illustrated)
Diskette drive bezel, carbon 257403-001
Miscellaneous plastics kit, includes 257051-001
Switch holder (245154-001 (2 ea)
Bezel blank (166775-002)
Cable clip (172948-001)
Logo plate (243831-001)
Power switch spring (not for this product)
LED holder (not for this product)
Documentation and Packaging (not illustrated)
Service Reference Guide 259968-001
Quick Troubleshooting Guide 153837-001
Illustrated Parts Map 301291-001
Return kit 270020-001
b
© 2002 Compaq Information Technologies Group, L.P.
Compaq, the Compaq logo, and Evo are trademarks of
Compaq Information Technologies Group, L.P.
Intel, Pentium, and Celeron are trademarks of Intel
Corporation in the United States and other countries.
All other product names mentioned herein may be
trademarks of their respective companies.
Compaq shall not be liable for technical or editorial errors
or omissions contained herein. The information in this
document is provided “as is” without warranty of any kind
and is subject to change without notice. The warranties for
Compaq products are set forth in the express limited
warranty statements accompanying such products. Nothing
herein should be construed as constituting an additional
warranty.
August 2002
Document Part Number 292402-002
Spare Part Number 301291-001
Compaq Evo D510
Convertible Minitower
Illustrated Parts Map

Type1Heatsink
Type2Heatsink
System Board Connectors and Jumpers (position of some untitled components may vary in location)
CMOS Clear CMOS P11 Aux audio
CR1 5V Aux (ON)/PSON (OFF) P14 Boot block
CR2 Power button (OK) P16 Intrusion
CR4 3.3V_Aux P20 Primary ATA
E49 Password P21 Secondary ATA
J20 PCI Expansion slot 1 P24 Front USB
J21 PCI Expansion slot 2 P27 MultiBay
J22 PCI Expansion slot 3 P29 SCSI LED
J30 PCI extension P54 Com port B header
J40 AGP slot P70 CPU fan
P1 Power, main P124 Hood lock
P3 Power, processor (VCCP12V) P125 Hood sensor
P5 Power switch/LED XBT2 Battery
P6 Speaker XMM1 DIMM 1
P7 CD audio XMM2 DIMM2
P8 Chassis fan XU1 Processor socket
P10 Diskette
System Hardware Interrupts
IRQ System Function IRQ System Function
0Timer Interrupt 8 Real-Time Clock
1Keyboard 9 Available for PCI
2Interrupt Controller Cascade 10 Available for PCI
3Serial Port (COM B) 11 Available for PCI
4Serial Port (COM A) 12 Mouse
5Audio 13 Coprocessor
6Diskette Drive 14 Primary ATA (IDE) controller
7Parallel Port (LPT 1) 15 Secondary ATA (IDE) controller
Computer Diagnostic LEDs (on front of computer)
LED Color LED Activity State/Message
Power Green On (S0) Computer on
Power Green 1 blink every 2 seconds (S1) Normal Suspend Mode
Power Green 1 blink every 2 seconds (S3) Suspend to RAM
Power None Off (S4) Suspend to Disk (if applicable)
Power None Off (S5) Computer off
Power Red 2 blinks 1 second apart, fol-
lowedby2-secondpause-
Repeat
CPU thermal shutdown
Power Red On CPU not installed
Power Red 1 blink every 1 second ROM error
Power Red 1 blink every 2 seconds Power supply crow bar
Hard Drive Green Blinking Hard drive activity
Keyboard Diagnostic LEDs
LED Color LED Activity State/Message
Num Lock Green Flashing (Beeps - 1S, 2L) Memory error
Caps Lock Green Flashing (Beeps - 1L, 2S) No video
Scroll Lock Green Flashing (Beeps - 2L, 1S) System board failure, prior to video
Num, Caps,
Scroll Lock
Green Flash On-Off 2 times (Beeps -
1L, 3S)
Invalid system ROM detected. ROM forces
reflash.
Num, Caps,
Scroll Lock
Green On (Rising Tone) ROM reflashed successfully
Num Lock Green On Boot block recovery failed - ROMPaq diskette
not present, is bad, or drive not ready.*
Caps Lock Green On Enter password.
Num, Caps,
Scroll Lock
Green Blink On in sequence, one at a
time - N, C, SL
Keyboard locked in network mode
* Insert valid ROMPaq diskette in drive A. Turn power switch off, then on to reflash ROM. If ROM flash is successful, all
three keyboard LEDs will light up, and you will hear a rising tone series of beeps. Remove diskette and turn power off,
then on to restart the computer. For more information about flashing the ROM, refer to the Troubleshooting guide.
System Board Diagnostic Lights1
Main Power
Switch Status 3.3 V_Aux LED 5 V_Aux/PSON LED Power Button LED
OFF2ON ON4OFF
ON3ON OFF5ON
1. ON and OFF state of LEDs apply only to a good, working system board with AC power applied to the power supply.
2. Power LED on front of computer is OFF.
3. Power LED on front of computer is ON (Green).
4. 5V_Aux is ON.
5. PSON is active = power supply is turned ON.
Clearing CMOS
The computer's configuration (CMOS) may occasionally be corrupted. If it is, it is necessary to clear the CMOS
memory using switch SW50.
To clear and reset the configuration, perform the following procedure:
1. Prepare the computer for disassembly.
ÄCAUTION: The power cord must be disconnected from the power source before pushing the Clear CMOS
Button (NOTE: All LEDs on the board should be OFF). Failure to do so may damage the system board
2. Remove the access panel.
3. Press the CMOS button located on the system board and keep it depressed for 5 seconds.
4. Replace the access panel.
5. Turn the computer on and run F10 Computer Setup (delete-utility) to reconfigure the system.
Disabling or Clearing the Power-On and Setup Passwords*
1. Turn off the computer and any external devices, and disconnect the power cord from the power outlet.
2. Remove the access panel.
3. Locate the header and jumper labeled E49.
4. Remove the jumper from pins 1 and 2. Place the jumper over pin 2 only, in order to avoid losing it.
5. Replace the access panel.
6. Plug in the computer and turn on power. Allow the operating system to start. (Placing the jumper on pin 2 clears the
current passwords and disables the password features.)
7. To re-enable the password features, repeat steps 1-3, then replace the jumper on pins 1 and 2.
8. Repeat steps 5-6, then establish new passwords.
Refer to the Computer Setup (F10 Setup) instructions to establish new passwords.
