QuickSpecs
Compaq Premier•Sound
PS115 Speakers
DA-10407 World Wide — Version 3 — June 14, 2001 1
M ODELS
Compaq Premier •
••
• Sound™ PS115 Speakers
133566-022
The Compaq Premier•Sound PS115 Speakers offer users a compact, high-end sound solution.
O VERVIEW
Compaq Premier•Sound PS115 Speakers offer users a compact, superb multimedia solution, providing crisp, clear highs, warm midranges and clean
robust basses for an impressive stereo sound experience.
This product is for users who need a more robust sound solution than a standard integrated desktop speaker. Specifically, this audience ranges from
mainstream application users to advanced film, video, and high-end post-production, to game developers and graphic designers.
Target Audience
The Compaq Premier•Sound PS115 Speaker system is targeted for both home and business users who need and want a more robust sound solution.
Specifically, this audience ranges from mainstream application users to advanced film, video, and high-end post- production, to game developers and
graphic designers.
Performance
The Compaq Premier•Sound PS115 Speakers are designed to exceed the customer’s expectation of audio quality in small, compact, cost-effective
loudspeakers using the following advanced technologies:
• Wide frequency bandwidth down to 75 Hz allows for controlled, smooth, hi-fi like bass
• An amplifier capable of transmitting 18 W per channel so that distortion is controlled at both typical as well as low frequencies levels that require
more power
• Transducer or speaker drive transforms the electric signals and delivers lower frequency output by lengthening the voice coils, increasing magnet
size, and enhancing the power handling capability
• Bass reflex loudspeaker enclosures contain the transducers and amplifiers and are specifically designed to enhance the bass output in a small
space
• The 10 stages of fixed equalization “shape” and “push the music back” so that a listener sitting 2-3 feet away is not blasted by the music, but rather
hears a natural sound reproduction.
Key Features
• Attractive, slim form factor with cloth grille
• Tone Control (loudness control) – User is able to optimize system’s performance and listening for full response even at very low levels
• Volume control
• On/Off push button
• Green on/off light
• Headphone jack located on front of speaker
• Line in for CD and other devices
• Color coded connectors for easy hook-up
• Integrated, low distortion, stereo amplifier rated at 10 watts per channel (RMS at 1% THD)
• Exceptional low frequency output to 75 Hz provides wide spatial imaging
• Acoustically tuned bass reflex enclosure
• Low distortion, long throw, 3” full range drivers
• Power in one box – master/slave configuration
• External power supply
• Same color scheme as all Compaq products

QuickSpecs
Compaq Premier•Sound
PS115 Speakers
DA-10407 World Wide — Version 3 — June 14, 2001 2
O VERVIEW (continued)
Quality and Compatibility
Compaq has a solid reputation for delivering high-quality, reliable enhancement products.
Compaq enhancement products are designed and tested to rigorous specifications, including tough qualification requirements for suppliers, stringent
performance specifications, and a thorough testing process to ensure consistent quality from prototype to production.
All Compaq enhancements are fully compatible with our entire commercial desktop product line to allow seamless transition to new products and
technologies.
Service and Support
The Compaq Premier•Sound PS115 Speakers carry the longer of either a one-year warranty or the remainder of the warranty period for the Compaq unit
with which it is installed. Round-the-clock support is offered by Compaq’s 7 x 24 technical support hotline and on-line support forums are available on
Prodigy, CompuServe, America Online and the Internet. Note: Certain restrictions and exclusions apply. Consult the Compaq Customer Support Center
for details.
S PECIFICATIONS
Compaq Premier•
••
•Sound PS115 Speakers
Speaker Size 3 inch, full range, high output
Cabinet Volume 140 cubic inches each
Frequency Response 75 Hz to 20 kHz
Speaker Impedance 4 Ohms
Input Impedance > 5k Ohms
Power Outputper Channel 10 Watts RMS @ < 1% THD+N (1 kHz)
AC Adapter High performance DC 14V, 1.4 amp power supply
S/N Ratio > 70 dBr @ 1 kHz
Physical Characteristics Dimensions (HxDxW) 9 x 5.5 x 3.5 in/23 x 14 x 24.1 cm
Weight 3.5 lbs/1.6 kg
Headphone Output 10mW RMS (Rl=32 Ohms) @ < 1% THD+N (1 kHz)
Headphone Impedance 16 to 32 Ohms
Enclosure Color Compaq Opal
Input cord length 2 meters
Color coded jacks/connectors 3.5mm stereo mini jack
Environmental Requirements Operating Temperature 32°to 131°F/0°to 55°C
Storage Temperature 68°to 158°F/20°C to 70°C
Humidity (Non-Condensing) Operating 140°F/60°C @ 90 to 95%
Non-Operating 32°to 131°F/0°to 55°C @ 90 to 95%
Warranty 3 years Note: Certain restrictions and exclusions apply. Consult the Compaq Customer Support Center for details.
Kit Contents 2 Speakers Yes
Installation guide Yes
Assembly Warranty Yes
Note: Certain restrictions and exclusions apply. Consult the Compaq Customer Support Center for details.
AC Adapter Yes
Audio Cable Yes
Non-Operating 32°to 131°F/0°to 55°C @ 90 to 95%

QuickSpecs
Compaq Premier•Sound
PS115 Speakers
DA-10407 World Wide — Version 3 — June 14, 2001 3
C OMPATIBILITY
Desktops
Compaq Deskpro EN Series Desktop
Compaq Deskpro EN Series Minitower
Compaq Deskpro EN Series Small Form Factor
Compaq Deskpro EP Series
