Compatico CMP52131W User manual

CMP52131W / CMP52142S
HIGH BACK SCREEN MANAGER CHAIR
OPERATING INSTRUCTIONS
FEATURES
• PNEUMATIC SEAT HEIGHT ADJUSTMENT
To raise seat remove pressure from seat and lift lever (1) up.
To lower seat height sit on chair and lift lever (1) up.
NOTE: It is normal for chair to slightly lower under body weight.
• SEAT SLIDER ADJUSTMENT
To slide seat forward or backward, lift lever (2) up. Release
lever (2) to lock desired seat position.
• 3 POSITION 2-TO-1 TILT & LOCK ADJUSTMENT
This deluxe control allows the back to tilt 2 degrees for every 1
degree of the seat tilt. Back also locks in 3 positions (fully back,
mid & upright). The back has an anti-kickback which needs
pressure on the back in order to release. To tilt or free float, push
lever (3) backwards and lean back. To lock, push lever (3) forward.
NOTE: In the mid and fully back position you will hear a click when
it is locked. To unlock, push lever (3) backward and apply pressure
to back.
NOTE: Anti-kickback keeps chair back from making unwarranted
sudden forward movement.
• TILT TENSION ADJUSTMENT
To adjust title tension, Turn knob (4) clockwise to increase tension
and counter-clockwise to decrease or ease tension.
NOTE: Be careful not to loosen back tilt adjustment knob completely.
• ARM HEIGHT ADJUSTMENT
To adjust arm height, push button (5) in to allow the arms to move
up or down freely. Release the button (5) once the desired height is
reached.
WARNING
1. Use this product only one person at a time.
2. Do not use this chair unless all bolts screws and knobs are securely
tightened.
3. Check that all bolts screws and knobs are tight every three months
or as needed.
4. Do not overturn back tilt knob when decreasing tension.
5. Dispose of packing material properly. Do not use plastic cover as
head covering. It may cause suffocation.
6. Do not use chair as a stepladder.
7. Use this chair for its intended purpose only.
8. Use mild detergent only for cleaning.
LIMITED LIFETIME WARRANTY
Compatico chairs are warranted from the date of purchase against failure due to material and workmanship as follows:
• Lifetime on component parts including pneumatic cylinder, control mechanism, base and casters.
• 3 Years on upholstery fabric and foam against wear and deterioration.
• Leather is not warranted against routine scratching and scuffing, as leather is subject to minor blemishes in use.
To make a warranty claim, contact: Compatico Quality Control Department. Provide model number, description of the problem, photos, purchase order number
and obtain a confirmation number. At its option, Compatico will:
(a) Supply compatible components of current manufacture.
(b) Repair the customer’s component. It is the customer’s responsibility to prepay freight on any components returned to the factory. Return freight
on components covered by warranty will be paid by Compatico.
All warranties are limited to the original purchaser for normal commercial usage defined as a standard forty hour work week by persons weighing 250 lbs. or
less. This warranty will not cover labor, freight or damage from misuse, abuse, negligence, alteration, accident, vandalism, rusting, acts of nature or any other
event beyond the control of Compatico. The warranty does not cover cosmetic damage that may result from normal use Liability for incidental or consequential
damages is excluded. The user assumes all risk of injury resulting from use of this product. When usage is more than 40 hours per week, a five year warranty on
all parts applies. Fabric is warranted for one year. This warranty gives you specific legal rights, and you may also have other rights which vary from state to state.
Contact us via e-mail [email protected], by Fax [phone], or toll free parts number 800-336-1772, Monday through Friday 8:00 a.m. - 5:00 p.m.
Eastern Standard Time.
CMP52142S
(not shown)
5
2
4
3
1
rear
front

STEP 1 STEP 2
STEP 4 STEP 5
STEP 3
August 2017
PART QTY
1. Base ..............................1
2. Casters ............................5
3. Pneumatic Cylinder ...................1
4. Mechanism .........................1
5. Seat Cushion........................1
6. Backrest............................1
7. Arms (7L & 7R) ......................2
8. Flat Washers ........................6
9. Mechanism Screws ...................4
10. Arm Screws ........................6
11. Back Support Screws ................3
12. Back Support (pre-installed) ...........1
13. Allen Wrench (not shown) .............1
Remove all parts from carton, separate by part numbers indicated on parts list, and verify part quantities.
STEP 1 Insert five Casters (2) into Base (1), push hard until you feel or hear the Caster (2) snap into place.
STEP 2 Align the holes in the Arms (7L & 7R) with the holes in the Seat Cushion (5), attach Arms (7L & 7R) to Seat Cushion (5) using three Flat
Washers (8) and three Arm Screws (10) for each Arm (7). FULLY TIGHTEN ALL SCREWS USING ALLEN WRENCH (13).
STEP 3 Attach Mechanism (4) to Seat Cushion (5) with the arrow towards the front of the chair using four Mechanism Screws (9).
FULLY TIGHTEN ALL SCREWS USING ALLEN WRENCH (13).
STEP 4 Attach Back Support (12) to rear of Mechanism (4) using three Back Support Screws (11),
FULLY TIGHTEN ALL SCREWS USING ALLEN WRENCH (13).
STEP 5 Insert Pneumatic Cylinder (3) into Base (1), Place the assembled seat on top of Pneumatic Cylinder (3) and apply downward pressure.
ATTENTION: MAKE SURE ALL SCREWS ARE FULLY TIGHTENED BEFORE USING CHAIR.
CMP52131W / CMP52142S
HIGH BACK SCREEN MANAGER CHAIR
ASSEMBLY INSTRUCTIONS
2
1
1
8
8
9
10
10
7R
7L
55
4
11
3
12
5
4
6
