Component Playgrounds PH30-10 User manual

Dear Customer:
Thank you for purchasing your equipment from Component Playgrounds!!! We are proud of
our commercial grade products made for kids of all ages & sizes, and we are confident that you
will enjoy your equipment for many years.
Because you have purchased a top of the line commercial grade product, you will need to
be aware of some specific shipping requirements that may be different from shipments you
have received in the past through other delivery companies (such as UPS), and you should
follow the guidelines below carefully.
1. In most cases your product will arrive via common carrier truck line directly to your
home with curbside delivery only. This means the driver will facilitate the offloading of the
shipment at the curb, or most reasonable place near the curb and your house. You are then
responsible to have someone physically capable to help unload the product upon delivery
and note the condition of the product as per below instructions.
2. Your product may arrive on a pallet and upon delivery—locate the packing list (usually
attached to the hardware box & orange & black in color) and verify that each piece listed is with
the shipment. *** Please disregard any delivery driver stated “time crunches” or “needs to
leave quickly” and in-speck the product to your satisfaction = this is your product so
make sure it is all there in good condition or noted properly before the driver leaves.***
3. If there are any parts/pieces missing, note this directly on the delivery receipt BEFORE
you sign and receive your copy of the receipt, with wording such as “missing xyz part” etc.
Note: some shipments will have more than one pallet so check both before noting missing.
4. Similar to #3 above, also note the condition of the pieces and if any parts have been
damaged in shipping note this directly on the delivery receipt BEFORE you sign and get your
copy from the driver (in particular inspect slides for damage).
5. If your shipment appears to have damage and /or missing pieces, a freight claim must
be fi led with the freight company w/in two business days. Component Playgrounds will assist
you with this process if it is necessary. Contact the shipping manager toll free @ 877-530-0222
for claims assistance.
6. Ask your driver to sign or initial the freight slip acknowledging any damage or
discrepancies.
7. Get a copy of the signed delivery receipt from your delivery driver BEFORE he leaves.
8. If you are concerned or don’t know what you should do with a certain situation
regarding the shipment, please call the shipping manager toll free @ 877-530-0222 before the
driver leaves.
All shortages and damaged items are the sole responsibility of the carrier. You are
responsible to notify Component Playgrounds of any shortages or damage relating to your
shipment w/in 2 business days of receipt of your equipment. After this time, any claim for
shortage or loss cannot be honored.
Component Playgrounds cannot be responsible for replacement of any parts,
missing or damaged, that have not been properly noted on the delivery receipt.
Component Playgrounds cannot be responsible for damaged or missing pieces due to
the fault of, or loss by the freight company.
Thanks again & remember to tell your friends about your product from Component Playgrounds!

Parts Identification
PH30-10 Swing Set
Quantity
Description
1
Box Containing Swing Set Parts
1
PH Full Barrier
2
PH Exit Barrier
1
PH Entrance Barrier
2
PH Canopy Side Support
1
PH Deck Package
(package will be in 1 Bundle of 8)
1
Slide

Quantity
Description
4
6’ PH Leg
2
1 7/8” x 9’ Leg
1
2 3/8” x 13’11” Top rail
1
2 3/8” x 13’11” Top rail
1
8’ Upright Ladder (Actual length 10’)
1
Triple end with Sleeve
1
Pirate Climber
2
4’ PH Joist Ends
3
4’ PH Floor Joist
1
PH Center Canopy Support
26
Pieces Total
Parts Identification
PH30-10 Swing Set
Page 2 of 2

PH30-10 Swing Set Parts Identification Page
The Small Parts
Flat Washer
Loc Washer
Nyloc Nut
Hex Nut
T-Nut
Tap Bolt
Hex Bolt
Carriage Bolt
Set Screw with Allen Wrench
#14 Sheet Metal Screw
Lag Screw
#14 Truss Screw
2 ½” Self-Tapping Screw
Carabineer/Spring
Clip
Panel Clamp
Plastic Plug
CH Deck Plug
Pictures are not to sale. The purpose of this sheet is to give you a general idea of the shape and names of the
parts of your swing set.
Clevis with Key

Installation Instructions
PH30-10
Required Crew: 2-4
Required Concrete: 18-22, 80 lb bags
Required Tools:
Wheelbarrow Shovel
Level Open end or Box Wrench’s: 5/8”, 9/16”, ¾”
Digging Bar or Pick Ratchet Handle & Sockets: 5/8”, 9/16”, ¾”, 17
mm 7/16”, 11/16”, ¼” deep socket
Allen Wrench (provided) Drill: Cordless or electric, or impact driver
Hammer or Mallet 13/64” and ¼” drill bit, Philips driver bit
Marker Pen Step Ladder (6’or taller)
Tape Measure Small Philips screw driver
Component Playgrounds is concerned about the safety of your vision. It is important that you
choose to protect your vision by wearing proper safety glasses during each and every phase of
this construction process.
PLEASE READ AND UNDERSTAND ALL INSTRUCTIONS BEFORE BEGINNING
*Before digging, please obey local laws by notifying your local underground utilities marking
organization*
1. Select an area in your yard that is reasonably level and meets the space requirements for your
equipment. PH30-10 Ground space: 20’ x 19’. Play space: 24’ x 30’.
2. Please refer to the top rail assembly sheet and assemble your top rail as instructed.
3. Position top rail in your yard where you want the unit to finally stand. Measure and be certain that all
necessary clearances for the deck and swinging space are available in this position.
4. Using a tape measure and marker, mark location of the ladder, swings and other items along the top
rail. See the detail on the front page of your installation instructions.
5. With top rail in position on the ground, locate, mark and dig the hole for upright ladder. (See #1: Hole
size for upright ladder) Move the top rail out of your way and about 12’ away from where the unit
will finally stand.
6. Assemble swing hangers as shown on the swing hanger assembly sheet and attach to the top rail as
instructed.
7. Turn the top rail upside down on the ground. Install the legs into the triple end as shown in: #3 A-
Frame Leg Assembly. Hint: Be certain that the rungs on the ladder will be properly positioned and

facing as desired in your space when the unit is finally standing. Also, be certain that the third leg bolt
is positioned to allow the third leg to be attached.)
8. Using a hammer, install the plug into the open end of the top rail.
9. The upright ladder should be positioned on the ground with the bottom of the ladder laying just over
the hole where it will finally stand. Loosely install set screws into the top sleeve of the ladder.
10. Using two strong adults, one at each end, stand the swing frame up, allowing the ladder to fall into the
hole previously dug. (Note: the set will not be level at this point.) Check to make sure that the top rail
is still in its proper place inside the ladder top sleeve. Adjust as necessary by holding onto the ladder
securely and pushing or pulling the “A” frame section causing the top rail to slide inside the top
sleeve of the ladder. When you are satisfied that the top rail is in its proper position, securely tighten
the set screws in the top sleeve of the ladder.
11. With the ladder still standing in its hole, situate the “A” frame end to the desired position in the play
area. Determine the position of the “A” Frame legs and mark the spot where you want to dig the
holes. Move the legs out of the way and dig the holes. (Hint: Keep most of the hole to the inside of
the legs.) Place the legs into the holes.
12. Slide 3rd leg sleeve onto the top rail that is sleeved into the outside of the 10’ ladder.
13. Measure 5 ½’ - 6’ away from the 10’ Upright Ladder to mark and dig the hole for the Third Leg (see
#1B hole sizes for cementing).
14. Before installing the third leg, locate the third leg. Insert ⅜” x 3½” Hex Bolt and loosely thread ⅜”
Nut into the bottom hole. Nut will not thread all the way on and bolt will be loose. (This is to act as
an anchor in the concrete and does not need to be tight.)
15. Install Third Leg by dropping the end into the hole and sleeving the top into the 3rd leg sleeve. Use
the 3/8” x 2 3/4” hex bolt and 3/8” nyloc nut. Then secure 3rd leg with set screw on under side. (see
diagram #4) When properly positioned, secure the set screws in the top of the 3rd leg sleeve.
16. Measure the height of the top rail to insure proper swing height. Level the structure.
17. Refer to: Playhouse Assembly and Installation Instructions. Assemble the Playhouse deck and
structure as shown.
18. Attach the slide as shown on the slide assembly sheet.
19. Attach any additional climbers as may be necessary.
20. Check the level of the entire structure and adjust as necessary.
21. When you are satisfied that the structure is level, mix and pour the concrete according to the package
directions. You will use approximately 6-7 80# bags in the ladder hole and 1 ½ bags in each of the leg
holes.
22. Allow the concrete to cure completely before using your swing set. (3-5 days).
23. Attach chains and swinging items and enjoy your Component Playground.

Top Rail Assembly
Step 1: Slide the ends of the 10’6” Top Rail as far as it will go into the Sleeve of the
Triple End.
Step 2: Insert and tighten (4) 3/8” x 3/8” set screws into the Triple End Sleeve using
Allen Wrench provided.
Step 1
Step 2

Two piece Top Rail
Assembly
*Make sure to line up the set screws so they make a straight line
as show in the graphic above.
Step 1:
Step 2:
Step 3:

PH30-10 Model
Overall Required Play Space Dimensions: 24’ x 28’
24’
28’
GROUND SPACE 20’ X 19’
MINIMUM RESIDENTAL PLAY
SPACE 24’ X 28’

(a) Upright
Ladder
Model PH30-10 Continued
(b) A-frame
Legs
(c) PH Leg
24”
28”
20”
12”
18”
Slide Top Rail joint into place
about 1 inch inside the Ladder
Top Sleeve & secure with two
3/8” x 3/8” Set Screws
Upright
Ladder
Top Rail
#1 Hole Sizes for Cementing in the Set
#2 Ladder to Top Rail Assembly
#3 A-frame Leg Assembly
12”
Hole 28”x20”x24”
(approx. 6-7 80 lb. bags of
concrete mix per hole)
Holes 18” x 12” (approx.
1 ½” 80 lb. bags
concrete mix per hole)
Holes 18” x 12” (approx.
1 ½” 80 lb. bags
concrete mix per hole)
Triple
End
A-frame
Leg
3/8” x 2 ¾” Hex Bolt
with 3/8” Nyloc Nut
(1 per leg)
3/8” x 3/8” set screw
(1 each per leg)
Slide in leg, bolt in
place and secure
with set screw
(d) 3rd Leg
Hole 18” x 18”
(approx. two 80 lb.
bags of concrete mix)
Set screws
Set screws
Set screw holes

Tighten 3/8” x1/2” set screws on the top
sleeve of the ladder (2 set screws)
Slide
½” x 2 ¾” bolt
through the two
holes and secure
with the 3/8”
nyloc jam nut.
Insert 3/8” x 3/8” and
3/8” x ¼” set screw
and tighten to help
secure the 3rd leg in
place.
3rd Leg Sleeve
Nyloc Nut
3rd Leg
#3 Third Leg Sleeve
Tighten 3/8” x 3/8” set screws on
top sleeve of ladder (2 set screws)

**Important Notice! Please read and understand prior to proceeding**
Pre-Assembly: Assembling the Play House Floor Joists
2.a. Locate the Floor Joist End with the four holes in it as shown below and determine which holes you
will be using for your particular swing set configuration. This is the end that will bolt to the vertical
ladder.
Determine which holes you will be using by identifying the configuration below
that most closely resembles the configuration you wish to achieve.
After configuring your swing
set, plug unused holes with ½”
plugs provided.
OR
2.b. Assemble the Deck Floor Joist structure as shown below using (8) set screws. Make sure that the set
screw holes are facing inward as shown below.

2.c. Position assembled deck frame on the ground as shown below. Mark the holes for the Club
House Legs. Dig the holes to the specifications below.
Hole size for Play House Legs is 18”
wide by 16” deep.
With top rail in place,
place deck frame square
with the top rail
overlapping 24”.

3.a. Assemble the triple end to the top rail as shown below.
3.b. Assemble the legs into the triple end and top rail as shown below.
1. Slide the end of the drilled top rail into the triple end.
2. Align the hole in the top rail with the hole in the sleeve of
the triple end and join together using 3/8” x 3/8” set
screws.
1. Slide the end of the drilled legs into the triple end.
2. Align the holes in the legs with the holes in the triple end and join
together using a 3/8” x 2 ¾” hex bolts and 3/8” nyloc nuts.
3. Insert and tighten set screws into triple end with allen wrench provided.
3/8” x 2 ¾” Hex Bolt
with 3/8” Nyloc Nut
(1 each per leg)
3/8” x 3/8”
Set Screw
(1 each per leg)
Slide in leg, bolt in
place and secure
with set screw
Triple End
“A”
Frame
Leg

3.c. Position parts as shown below and insert assembly into ladder. Use the mark previously made on
the top rail to show you how far the assembly needs to be inserted. Insert set screws into the ladder
top sleeve and tighten until barely snug. Do not secure them at this point.
**Notice Ladder rungs
are facing down.
3.d. Using two strong adults lift the ladder and the A Frame end and allow the ladder to fall into its hole. You can
allow the structure to stand but it will not be level at this time.
Situate the ladder and “A” frame legs as desired in the space. Be certain that the top rail has not slid away from
its correct position. If it has moved, hold onto the ladder and adjust its position on the top rail by pulling or
pushing as necessary. When you are content with the position of the top rail within the top sleeve, secure the set
screws in the top sleeve.
**Notice Top rail
should be flush
with end of ladder
top sleeve.

3.e. Make a mark in the soil for the A Frame Leg holes. Move the legs out of the way and dig the holes.
“A” Frame leg
holes are to be dug
at 18” in diameter
by 12” deep.
**Notice Most of the “A” frame leg hole needs to be dug towards the inside of the “A” frame leg.
3.f. When the holes are dug, place the legs into them and level the swing structure.
Level
Le
ve
l

A- Secure the first two boards into place at each end of the platform structure using the 13/64” drill bit to pre drill
the holes through the plastic and into the floor joist. Secure the boards into position using the #14 x 2 ½ pan Phillips
SMS. The leading edge of the board should be flush with the edge of the square tubing. Now that these two boards
are secure lay each of the remaining boards up and onto the floor structure and space them out evenly and to your
satisfaction. They will be approximately ½” apart from each other, as shown in the diagram below.
Installing the plastic Lumber
Tools needed:
Electric drill, 13/64” drill bit, 18 or 20 volt impact driver (preferred tool) or a cordless or electric drill
can be used to drive the screws.

4.c. Using two strong adults lift the ladder and the post end and allow them to fall not the previously
dug holes. You can allow the structure to stand it will not be level at this time.
4.b. Having pre-assembled the floor joist system, it is now best to have at least three people to
assemble the Play House Legs to the floor Joists. Insert all four legs. Then insert and secure one set
screw into each leg to hold them in place. *Note: We suggest you use a structure of some kind to
support the platform as you place the assembled deck structure in the previously dug holes as
shown. (see suggestion below.)
**Notice top rail should
be flush with end of
ladder top sleeve.
Jack stands or
structure to
support platform

4.d. Attach the Platform Support Structure to the vertical ladder using the 5” carriage bolts
pushed through the ladder and through the support structure as shown, attaching platform to 8’
vertical ladder. You may need to adjust the depth of the individual holes to make the platform
structure and the ladder level up to each other and to make the holes line up.
1. Insert 5” carriage bolts
2. On the back side, place a
3/8” flat washer, followed
by a 3/8” lock washer,
followed by a 3/8” hex nut.
3. Tighten

If you are assembling this structure in one day, disregard this step. When you are satisfied that the structure is
level, mix and pour the concrete according to the package directions. You will use approximately six to seven 80#
bags in both the ladder hole and post hole, one to one and a half bags in each Play House leg hole.
It is best to allow the concrete to cure at least overnight before proceeding with the installation. The next phase
will require placing heavy parts, body weight and movement onto the Play House platform. It is important that
you look at the new concrete and make your best determination as to whether or not it is safe to continue with the
next phase. Concrete will cure faster in warm conditions and slower in cold conditions. The package directions on
the concrete you buy will indicate approximate curing times. If you are in doubt, it is better to wait longer
allowing the concrete more time to cure.
The amount of concrete to be used in each hole may vary. For example: If you are installing your play structure
into a grassy area, you may want to leave the concrete about three to four inches low in the hole. This will allow
you to replace the sod and have enough depth of soil that the grass will grow the same as before the playground
was installed. As a result of this, you will use a lesser amount of concrete than someone who chooses to fill the
concrete to the top of the hole. The concrete should only be filled to the top of the hole if you are planning to
install 6 –12 inches of soft fall ground cover. The concrete footings should never be exposed as this presents a
potential risk of injury to those who use this play equipment.
4.e. Level the Play House platform and the swing structure completely.
LEVEL
LEVEL
LEVEL
LEV
EL
LE
VE
L
LEV
EL
LEV
EL
