Comprehensive CVG-VP4xl User manual

USER MANUAL
Model:
CVG-VP4xl
1:4 VGA Distributor
For maximum results, use Comprehensive
Brand Premium High Resolution cables
and connectors.

i
Contents
1Introduction 1
2Getting Started 1
3Overview 1
4Your CVG-VP4xl 1:4 VGA Distributor 2
5Connecting Your CVG-VP4xl 1:4 VGA Distributor 3
6Technical Specifications 4
Figures
Figure 1: CVG-VP4xl 1:4 VGA Distributor 2
Figure 2: Connecting the CVG-VP4xl 1:4 VGA Distributor 3
Tables
Table 1: Front Panel CVG-VP4xl 1:4 VGA Distributor Features 2
Table 2: Rear Panel CVG-VP4xl 1:4 VGA Distributor Features 2
Table 3: Technical Specifications of the CVG-VP4xl 1:4 VGA Distributor 4

1
1 Introduction
Congratulations on purchasing your CVG-VP4xl 1:4 VGA Distributor. This
product is:
• Ideal for any professional system requiring superb VGA/XGA
distribution to multiple monitors / projectors
• Easily expandable to create larger systems
• Ideal as a multi-channel video DA for other signal formats via adapter cables
The package includes the following items:
• CVG-VP4xl 1:4 VGA Distributor
• Power adapter
• This user manual
2 Getting Started
We recommend that you:
• Unpack the equipment carefully and save the original box and packaging
materials for possible future shipment
• Review the contents of this user manual
3 Overview
The high quality CVG-VP4xl 1:4 VGA Distributor is a 1:4 distribution
amplifier designed for VGA-type signals including VGA, SVGA, XGA and
UXGA. It accepts an input, provides necessary buffering and isolation and
then distributes the signal to 4 identical outputs. In addition, the input and
outputs are DC coupled and conform to the highest standards.
Achieving the best performance means:
• Connecting only good quality connection cables, thus avoiding
interference, deterioration in signal quality due to poor matching, and elevated
noise levels (often associated with low quality cables)
• Avoiding interference from neighboring electrical appliances that may
adversely influence signal quality
• Positioning your CVG-VP4xl unit in a location free from moisture and
away from excessive sunlight and dust

2
4 Your CVG-VP4xl 1:4 VGA Distributor
Figure 1 and Tables 1 and 2 define the CVG-VP4xl 1:4 VGA Distributor
unit:
Figure 1: CVG-VP4xl 1:4 VGA Distributor
Table 1: Front Panel CVG-VP4xl 1:4 VGA Distributor Features
# Feature Function
1 Power Switch Illuminated switch supplying power to the unit
Table 2: Rear Panel CVG-VP4xl 1:4 VGA Distributor Features
# Feature Function
1 OUTPUT HD15F Connector Connect to the VGA/XGA acceptor (from 1 to 4)
2 INPUT HD15F Connector Connect to the VGA/XGA source
3 12V DC +12V DC connector for powering the unit

3
5 Connecting Your CVG-VP4xl 1:4 VGA Distributor
To connect the CVG-VP4xl 1:4 VGA Distributor to up to 4 outputs, do the
following1:
1. Connect an XGA source (for example, a PC’s digital graphics card) to the
INPUT HD15F connector.
2. Connect the OUTPUT HD15F connectors to up to 4 XGA acceptors2, as
follows:
• Connect the OUTPUT 1 connector to Acceptor 1 (for example, an analog
monitor)
• Connect the OUTPUT 2 connector to Acceptor 2 (for example, a
projector)
• Connect the OUTPUT 3 connector to Acceptor 3 (for example, an analog
monitor)
• Connect the OUTPUT 4 connector to Acceptor 4 (for example, a
projector)
3. Connect the 12V DC power adapter to the power socket and connect the
adapter to the mains electricity.
Figure 2: Connecting the CVG-VP4xl 1:4 VGA Distributor
1 Switch OFF the power on each device before connecting it to your CVG-VP4xl. After connecting your CVG-VP4xl, switch
on its power and then switch on the power on each device
2 When only one output is required, use one of the outputs, and leave the other outputs unconnected

4
6 Technical Specifications
Table 3 includes the technical specifications:
Table 3: Technical Specifications of the CVG-VP4xl 1:4 VGA Distributor
INPUT: 1 VGA/XGA on an HD 15F connector
OUTPUTS: 4 VGA/XGA on HD15F connectors
VIDEO BANDWIDTH: 350 MHz -3dB
DIFF. GAIN: 0.5%
DIFF. PHASE: 0.1 Deg
S/N RATIO: 73dB
COUPLING: AC, inputs and outputs, with input protection circuitry
DIMENSIONS: 22cm x 18 cm x 4.5 cm (8.7" x 7" x 1.7"), W, D, H.
POWER SOURCE: 12VDC, 75mA, (tobeusedwith acurrentlimitedpowersupply)
WEIGHT: 1.1 kg. (2.4 lbs.) approx.
ACCESSORIES: 12VDC power supply
