COMPRO TN50 User manual

Android
˙ Connect an Ethernet cable between IP camera and your
network switch/router. ( If you have purchased a Compro USB
wireless adapter, please plug into the USB port of IP camera. )
˙ Attach the power adapter to the camera’s power connector
and connect the power plug to a power outlet.
˙ Make sure your smartphone is able to access the internet via
your switch/router.
˙ Using iPhone or Android phone to scan the QR code above
for download and install the C4Home app.
( Also you can download the C4Home app from App Store or
Google Play. )
˙ Start the C4Home app and register your personal account.
˙ Login the C4Home app and add new camera:
1. Scan the QR code on the back side of camera ( Or direct
input the 10 digits camera ID under the QR code )
2. Click “iWizard” to search/install camera from local network
˙ After installation, now you can watch the live video of camera
from C4Home app or login to the www.c4home.com from PC.
Technical Support Information
For any problems you may encounter, please refer to the user's manual on the
installation CD. If you need further assistance, you can fill out the online form
(www.comprousa.com/feedback/) or email us at [email protected].
Compro Technology, Inc. www.comprousa.com
Tel. [phone] | Fax [phone]
3GA0310854
TN50/TN50W Cloud Network Camera
Quick Start Guide
Compro Technology is the registered logo of Compro Technology, Inc. C4Home is the registered trademarks of AVSecur Technology, Inc. All other company and
product names mentioned in this document are registered trademarks of the respective companies. No part of this document may be copied or reproduced in any
form or by any means without the prior written consent of Compro Technology, Inc. The information in this document is subject to change without prior notice.
iPhone
www.c4home.com
1
2
3
C4Home app

13
98
7654
321
1211
10
Mount the CameraName of Each Part
4
1
2
3
5
Wireless Setup
31mm
31mm
2.5mm
Bracket Base
Base
Cover
Fastening Nut
One-click the reset button to setup WPS
If desired, you can mount the camera on a wall or ceiling.
The following section explains how to mount your camera.
Drill 2 mounting holes on the mounting surface. While
you are at it, bear in mind that there will have to be a
minimum space of 2.5 mm (0.098 inch) between the
screw head and the mounting surface. Also, the 2
mounting holes on the wall or ceiling should be spaced
exactly 31 mm (1.22 inch) apart to correspond to the
position of screw holes on the camera's bracket base.
Then, if you're mounting on a concrete wall, insert a
screw anchor into each of the mounting holes.
Loosen the fastening hex nut to detach the bracket
from the camera.
Remove the base cover by inserting a at blade
screwdriver into the small hole on the bracket base and
then pressing the screwdriver downward.
Put a screw into each of the mounting holes. Then
secure the bracket to the mounting surface.
Finally, click the base cover back into position. After
that, attach the camera body back to the bracket and
then adjust the camera to the desired viewing angle.
1. LED status indicator
2. Lens
3. Speaker
4. Ethernet port
5. Power connector
6. USB wireless adapter port
7. MicroSD card slot
8. Microphone pinhole
(on the bottom)
9. Illumination LED
10. PIR Sensor
11. Connection status indicator
12. Reset button
13. Network speed indicator
Search for available Wi-Fi access points and enter the passphrase manually
˙Make sure the IP camera is connected to the local network via network cable.
˙If you have the wireless adaptor for TN50, make sure it is plugged into the IP
camera.
˙The smartphone must be in the same local network in order to successfully
search and congure the camera.
˙Start C4Home app and enter "iWizard" on the "Add Camera" page to search
your camera and set up wireless connection.
˙After the wireless connection is successfully set up, you can remove the
ethernet cable.
Using WPS setup
˙Make sure your Wi-Fi router supports WPS, press the WPS button on the router
and one-click the RESET button on the IP camera. The blue LED will be blinking
during the WPS setup process and resume to steady lighting when the setup
is completed.
