Computex FP-30 User manual

Oct. 15, 2019
This document consists of the following contents.
●Technical Information SPI Flash Programmer FP-30 (Second Edition)
Refer this document before using FP-30.
●FP-30 User's Manual (Second Edition) - (Excerpted version(*))
This manual describes target interface specifications of FP-30.
※This is an excerpt of "Chapter 8 Target Interface Specifications" and "Chapter 16 External I/O functions of
FP-30" from the FP-30 User's Manual.

SPI Flash Programmer FP-30
Technical Information
Second Edition (Oct. 15, 2019）
Copyright (C)2019 Computex Co., Ltd.
Table of Contents
●SPI Flash Programmer FP-30 Technical Information
Change history .............................................................................................................................................................. 1
■Introduction............................................................................................................................................................... 2
■Applicable connector ................................................................................................................................................ 2
10 pin 2.54mm pitch connector................................................................................................................................ 2
■SPI interface signals................................................................................................................................................. 3
■Notes ........................................................................................................................................................................ 3

1
Change history
First Edition
Aug. 30, 2019
Initial version
Second Edition
Oct. 15, 2019
"Applicable connector" added the recommended connector model number.

Technical Information on SPI Flash Programmer FP-30 Oct. 15, 2019(Second Edition)
2
■
Introduction
This document explains the interface specifications for “On-board connection” method
programming.
FP-30 has two connection methods that are used for programing flash memory:
On-board programming
SPI flash memory on a hardware boards can be programmed using this method.
The FP unit and the hardware board are connected using an adapter cable.
Off-board programming
Individual flash memory chips inserted into a socket adapter can be programmed
using this method. A variety of socket adapters for flash memory packages are
available to support this operation.
■
Applicable connector
10 pin 2.54mm pitch connector
(Hardware board connector top view)
Recommended connector
Manufacturer : Hirosugi-Keiki Co., Ltd.
Model : PSS-410153-10
※
Please refer to the pin layout and be sure to confirm how to assign the pin number.
On-board programming example using
For On-board programming, it is recommended to use the adapter cable [ADP-FP30SA-CBL-S10] and to use
the ISP connector on the target board.
In case of hardware boards that have already been designed/manufactured without an ISP connector, a test
clip can be used to program the flash memory.
For details, refer to [Chapter 8 Interfacing with the hardware board (On-board connection)] in the FP-30 User’s
Manual.
Flash memory to
be programmed

Technical Information on SPI Flash Programmer FP-30 Oct. 15, 2019(Second Edition)
3
■
SPI interface signals
Signal table
Target connection reference diagram
Pin No. Signal name Input/output *1
1
SRST*2
Input
2
VTref
Output
3
SCK
Input
4
GND
-
5
CS1
Input
6
SI/SIO0
Bidirectional
7
SO/SIO1
Bidirectional
8
SIO2*3
Bidirectional
9
SIO3*3
Bidirectional
10
CS2*3
Input
*1: Input/output are determined based on the hardware board
side.
*2: The SRST signal is an open collector output.
When this signal is “LOW” on the hardware board, set each SPI
signal to high impedance state.
*3: NC if the pins are not used on the flash memory.
■
Notes
Make sure to use the appropriate adapter for FP-30. Operation is only guaranteed if the appropriate adapter is
used.
The wire length between the ISP connector and SPI should be as short as possible. The shorter the better.
It is recommended to insert a damping resistor between the ISP connector and the SPI flash memory.

Technical Information on SPI Flash Programmer FP-30 Oct. 15, 2019(Second Edition)
Technical Information on SPI Flash Programmer FP-30 (Second Edition)
Go through the required procedures as stated under Foreign Exchange and Foreign Trade Control Law in exporting (including the case where
travellers directly carry) this product or providing this product for residents outside Japan.
No part of this manual, whether in whole or in part, may be adapted, copied or reproduced without prior permission.
The content of and the specifications of this product are subject to change without prior notice.
Computex Co., Ltd. shall not be held liable for any loss or damage arising from the use of this product although all possible measures have been
taken by Computex Co., Ltd. in good faith to ensure the quality of the product.
Contact us for any questions, feedback, comments, requests or anything of concern to you (or in the event of malfunction) regarding this product or
misprinting or missing information within this manual.
Other names of CPUs etc. mentioned in this manual are trademarks or registered trademarks of their respective manufacturers.
COMPUTEX is registered trademark of Computex Co., Ltd. in Japan.

FP-30 User’s Manual Chapter 8 Interfacing with the hardware board (On-board connection) 84
Chapter 8
Interfacing with the hardware
board (On-board connection)
8.1
Introduction
This chapter explains how to use the adapter cable [ADP-FP30SA-CBL-S10] and program flash memory on a hardware board
using On-board connection method.
ADP-FP30SA-CBL-S10 adapter cable
For technical contents and reference circuits not described in this manual, refer to
the manual
[SPI Flash Programmer FP-30 Technical Data]
on our website
(https://www.computex.co.jp).
8.2
ISP connector specifications
ISP connector specifications is as follows:
Pin No.
Signal name
Input/output*1
FP-30 internal circuit
1 SRST Input 100Ωseries
Open collector output
2
Vtref
Output
4K
Ω
Pull-Down
3
SCLK
Input
22
Ω
series
4
GND
-
GND
5
CS1
Input
22
Ω
series
6
SI/SIO0
Bidirectional
22
Ω
series
7
SO/SIO1
Bidirectional
22
Ω
series
8
SIO2
*2
Bidirectional
47
Ω
series
9
SIO3*2
Bidirectional
22
Ω
series
10
CS2 *2
Input
22
Ω
series
*1 : Input/output are determined based on the hardware board side.
*2 : NC if the pins are not used on the flash memory.
Info.
ISP connector
FP-30 side ISP connector
Manufacturer : Hirosugi-Keiki Co., Ltd.
Model : FSS-41085-10
Target side applicable connector
Manufacturer : Hirosugi-Keiki Co., Ltd.
Model : PSS-410153-10

FP-30 User’s Manual Chapter 8 Interfacing with the hardware board (On-board connection) 85
8.2.1
Adapter cable dimensions
The dimensions of the cable type adapter are as follows:
(Unit : mm)
Figure: Target connector dimensions
8.2.2
Signal specifications
The ISP interface signal specifications are explained here:
SRST signal
FP-30 unit outputs a “Low” on this signal to communicate with the SPI flash memory. Make sure that the SPI flash memory
signals are in high impedance state on the hardware board. The output from the FP-30 is open collector.
Vtref signal
The flash memory power supply voltage is output on this signal (1.8V~3.3V).
SPI signal (SCLK, CS1, SI/SIO0, SO/SIO1, SIO2, SIO3, CS2)
These signals are used by the flash memory. NC if not used.
Cable length: about 17cm
Pin 1

FP-30 User’s Manual Chapter 8 Interfacing with the hardware board (On-board connection) 86
8.3
Electrical characteristics of the target interface
8.3.1
DC characteristics
SPI signals (SCLK, CS1, SI/SIO0, SO/SIO1, SIO2, SIO3,CS2)
Symbol
Min
Type
Max
Units
VIL (Input Low Voltage)
3.3V
0.8
V
2.5V
0.7
1.8V
0.38
VIH (Input High Voltage)
3.3V
2.0
V
2.5V
1.7
1.8V
0.8
VOL (Output Low Voltage)
3.3V
0.4
V
2.5V
0.4
1.8V
0.45
VOH (Output High Voltage)
3.3V
2.9
V
2.5V
2.1
1.8V
1.35
*: In the case of On-board connection, the signal/waveform may be disturbed/distorted depending on the length of the wire and load
from the FP-30 unit to the SPI flash memory. If the waveform distortion exceeds the device specifications, connect a damping
resistor into the signal line to suppress the disturbance.
8.3.2
AC characteristics
SPI signals (SI/SIO0, SO/SIO1, SIO2, SIO3)
Symbol
Min
Type
Max
Units
tSU (Input Setup Time)
10
ns
tHD (Input Hold Time)
0
ns
tHO (Output Hold Time)
5
ns

FP-30 User’s Manual Chapter 8 Interfacing with the hardware board (On-board connection) 87
8.4
Using a test clip in On-Board connection
For On-board programming, it is recommended to use the adapter cable [ADP-FP30SA-CBL-S10]and to use the ISP connector
on the target board.
In case of hardware boards that have already been designed/manufactured without an ISP connector, a test clip can be used to
program the flash memory. This procedure is described in this section.
It is recommended to use the supplied adapter cable [ADP-FP30SA-CBL-S10]
with the ISP connector whenever possible. The method described here is not
guaranteed to work always. Incorrect wiring may cause damage to the board or to
the flash memory and the FP-30 unit.
Follow this method at your own risk.
FP30 unit conversion adapter [J1 connector]signal table
No. Signal
name
FP-30
Internal circuit
No. Signal
name
FP-30
Internal circuit
1
Vtref
4KΩ Pull-Down
2
*2
(VCCOUT)
Power supply
3
SCLK
22Ω series
4
GND
GND
5
GND
GND
6
GND
GND
7
CS1
22Ω series
8
GND
GND
9
SI/SIO0
22
Ω
series
10
GND
GND
11
SO/SIO1
22Ω series
12
GND
GND
13
SIO2
*1
47Ω series
14
GND
GND
15
SIO3
*1
22Ω series
16
GND
GND
17
NC
NC
18
CS2
*1
22Ω series
19 SRST 100Ωseries
Open collector output
20 NC NC
*1 : NC if the pins are not used on the flash memory.
*2 : VCCOUT (the power output from FP-30) is output regardless of C-Flash settings.
Refer section “8.5 Supplying power to target from FP-30”.
In case of SOP 16pin 300mil and SOP 8pin 200mil package flash memory, use a commercially available SOP IC test clip and
connect the flash memory and the conversion adapter [J1 connector] of FP-30.
NOTE
FP30 conversion adapter
J1 connector
FP-30 unit
The (▼) mark on the connector is not a pointer
that points to Pin 1.
Flash memory to
be programmed

FP-30 User’s Manual Chapter 8 Interfacing with the hardware board (On-board connection) 88
Tips for connecting
・The cable length between FP-30 and the hardware board should be 20cm
or less. The shorter the better.
・The communication is stable at a slower clock speeds.
・Using one I/O data line is stable than using four.
・In additional to SPI signal lines, it is required to connect the SRST (Pin 19:
System reset signal). Note that this signal is not the SPI flash reset signal.
Info.

FP-30 User’s Manual Chapter 8 Interfacing with the hardware board (On-board connection) 89
8.5
Supplying power to target from FP-30
Power can be supplied from FP-30 to the hardware board using the adapter cable [ADP-FP30SA-CBL-S10]Rev 0-A and
[C-Flash for SPI] Ver. 1.05.00 or later. Flash memory on hardware boards with a light load can be written to without having to
supply external power.
Depending on various factors, some boards might still need an external power
supply. Refer to the board manual for details.
Incorrect connection may damage the target board and the FP-30 unit. Follow this
method at your own risk.
8.5.1
Check the revision of the adapter cable
Make sure the adapter revision is Rev 0-A before proceeding. The revision can be checked as explained in section “7.2.2
Hardware revision”.
8.5.2
Electrical characteristics
Voltage
1.8V / 2.1V / 2.2V / 2.5V / 2.6V / 2.9V / 3.0V / 3.3V
Current
200mA max
・The option [Supply power to the target from FP-30] has to be checked on the “On-board settings tab” of the
Detailed settings dialog.
・Ensure that power is supplied to the hardware board only through FP-30 and no other power supply sources are used.
・The current consumption of the hardware board must be less than the max current supported by the FP-30 unit.
NOTE
Back side

FP-30 User’s Manual Chapter 8 Interfacing with the hardware board (On-board connection) 90
8.5.3
Connection points
Power can be tapped from the FP-30 unit from these two pins/points:
①
FP-30 unit conversion adapter [J1 connector] Pin 2
②
[T1 through-hole] on the target connector
Pin 2
FP-30 unit
J1 connector
For details about the [J1 connector],
refer “8.4 Using a test clip in On-Board connection”.
T1 through-hole

FP-30 User’s Manual Chapter 16 External I/O functions 128
Chapter 16
External I/O functions
16.1
Introduction
FP-30 units can be controlled from External devices or can be connected in chain fashion. All adapters included with FP-30 have
been provided with Input/Output signal terminals for this purpose. Through-holes have been provided for convenient connection.
*Use only the pins indicated by the white boxes in the picture above. Other pins are not to be used.
Group name
Pin
Signal name
Input/Output
*1
FP-30 internal circuit
SW-OUT
1
EXSTARTOUT
Output
100Ωseries CMOS open drain output
G
GND
SW-IN
1
EXSTART
Input
22Ωseries 4.7KΩPull-UP
G
GND
STS
1
EXOK
Output
100Ωseries Open collector output
2
EXNG
Output
100Ωseries Open collector output
G
GMD
*1 : Input/output are determined based FP-30 unit side.
The above signals can be enabled/disabled and the output pattern of EXOK/EXNG can be configured on the [External
Input/Output settings tab]on the Detailed settings dialog.
Do not use
Do not use
Do not use

FP-30 User’s Manual Chapter 16 External I/O functions 129
16.2
C-Flash settings
External I/O signals have to be configured on the [External Input/Output settings tab]on the Detailed settings dialog.
After the settings are done, the [Write] button on C-Flash has to be clicked to configure the FP-30 unit to use these settings. Note
that these settings will come to effect only after the [Write] button is clicked.

FP-30 User’s Manual Chapter 16 External I/O functions 130
16.2.1
EXSTARTOUT signal
LOW is output on the EXSTARTOUT signal when the [PROGRAM]button on the FP-30 unit is pressed. It is in high impedance
state otherwise.
When two or more FP-30 units are used, the EXSTARTOUT signal can be connected to the EXSTART signal. When the
[PROGRAM]button on the first FP-30 unit is pressed, subsequent FP-30 units will also begin the write process. In this way
multiple units can be controlled with a single button press.
EXSTARTOUT signal is always output and there are no settings on C-Flash to disable it.
16.2.2
EXSTART signal
EXSTART signal can be used instead of the [PROGRAM]button on the FP-30 unit to begin the write operation.
As explained before, multiple FP-30 units can be controlled with a single button press by connecting the EXSTARTOUT signal of
one unit to the EXSTART signal of another.
To use this signal, choose [Enabled] under [EXSTART - External Write start signal (input)]group on the [External
Input/Output settings tab]on the Detailed settings dialog.
When EXSTART signal is enabled, write operation is started when a low level is detected on this line. During write operation,
EXSTART is ignored.

FP-30 User’s Manual Chapter 16 External I/O functions 131
16.2.3
EXOK signal
The status of write operation can be determined using EXOK signal. There are 3 patterns that can be selected from under
[EXOK - External OK signal (output)]group on the [External Input/Output settings tab]on the Detailed settings dialog.
①Low on success, Hi-Z on fail
On success
On fail
②Pulse output during write, Low on success, Hi-Z on fail
On success
On fail

FP-30 User’s Manual Chapter 16 External I/O functions 132
③Low during write, Hi-Z after write
When the write process is in progress, Low is output on EXOK. After write terminates a Hi-Z is output irrespective of whether the
write operation succeeds or fails.
16.2.4
EXNG signal
Success or failure of write operation can be determined using this signal. A low is output during write operation and write
success, and high on failure.
To use this signal, choose [Enabled(Hi-Z on success, Low on fail)]under [EXNG - External result signal (output)]
group on the [External Input/Output settings tab]on the Detailed settings dialog.
On success
On fail
