COMSOL BT05TR User manual

User Manual v1.1
Model: BT05TR
Bluetooth Audio Adapter
Transmitter & Receiver
Made in China
www.mycomsol.com.au
USB-C is a trademark of USB Implementers Forum.
iPhone and AirPods are trademarks of Apple Inc. registered in the U.S. and other countries.
In the box
1 x BT05TR Bluetooth Audio Adapter
1 x USB-A to USB-C Charge Cable
1 x User Manual
1
2
3
4
5
6
Charge LED
Charge your device using the included USB-C cable to get up to 16 hours playback.
Connect to any standard USB phone charger
Power/Status
LED
Transmit or
Receive
Selector Switch
USB-C Charge
Port
Port Description
Displays solid Red when unit is charging. Flashes when device needs to be charged
Power &
Pairing Button
This multi-function button is used to turn the adapter on or off, activate Pairing mode for
new Bluetooth connections and Pause/Play current track
Indicates if device is powered on, searching for a new bluetooth connection or a Bluetooth
connection has been established
3.5mm Male
Audio
Switch to RX mode to play music through your car stereo or portable speaker, streamed
directly from your iPhone, smartphone or tablet
Insert this jack to either your transmitting or receiving device
3
2
6
5
Switch to TX mode to transmit audio from an aircraft in-flight entertainment system, gym
equipment or gaming console to your wireless AirPods, headphones or earbuds
1
4

For full battery performance (Up to 16hrs), please charge the device fully before use. When the device is low on power, the Charge LED
will flash Red. When you device is charging the Charge LED will be constant Red. It will go out when the device is fully charged.
Transmit Mode (TX) is used to send audio from a device such as an in-flight TV or any audio device with a 3.5mm headphone socket to
your wireless Bluetooth headphones. Receive Mode (RX) is used to receive Bluetooth audio from any device such as a phone or tablet
and connect it to your AUX-IN port of any stereo such as a car or soundbar that does not have Bluetooth.
To switch your Comsol device On or Off at any time hold the centre button for 2 seconds.
1. First time connection in Transmit mode (TX)
Ensure your Comsol device is set to TX mode. Before switching On, ensure your Wireless headphones’ previous connection (eg Phone or
Watch) has Bluetooth mode switched off. Now switch on the device by holding the Power button for 2 seconds. The device will flash Red
quickly indicating it is looking automatically for its first connection. On your wireless headphones you will now initiate pairing by pressing
your Bluetooth Pair button or removing your Pod style headphones from their case. The device will flash Red slowly when pairing is
complete. Once connected plug the jack in the socket on the entertainment system and use that device to control your desired volume.
2. Pair a second set of wireless headphones (TX)
With your primary connection active and your device on, you can connect a second pair of headphones to the same audio stream by
establishing a second connection. To do this tap the centre button 2 times quickly. Your Comsol device will now flash Red quickly
indicating Pairing Mode is active. As before press the Bluetooth Pair or remove your Pod style headphones from their case. When the
dual connection is established your Comsol unit will now show a steady Red light indicating that dual pairing is complete. If at anytime
you wish to return to using your headphones with your phone or tablet etc then simply turn off your Comsol device and re-connect your
other device as normal.
3. Connecting your Comsol device in Receive Mode to Aux-In (RX)
Ensure your Comsol device is set to RX mode. Switch on by holding the Power button for 2 seconds. The device will flash Blue quickly
indicating it is ready to pair. Open Bluetooth Settings on your device and under the “Devices” list you will see Comsol BT05TR listed. Tap
the screen to connect. Once connected, your Comsol device will show a steady Blue light indicating a connection has been made.
Connect your device to the AUX-IN socket on your playback device and ensure the playback device has its “Source” set to “AUX-IN”.
Handy Tip: Ensure your phone or tablet has its volume output selected to “On” and the output volume is set to above 50%.
4. Clear the connection list
At anytime you can clear the connection list and reset your Comsol device to factory defaults. Turn on your Comsol device and press the
Power button 4 times quickly. Your device will flash intermittently Red and Blue to indicate list is clear. You must now press and hold the
Power button for 2 seconds to switch off the device. Wait a few seconds and then restart the device as normal to pair a new connection.
Operation
Trouble Shooting
If your Comsol device continues to flash Red quickly and does not pair, then your headphones or host device may not be in ”Pair”
mode. Ensure your headphones or host device are switched on, charged and in “Pair” mode.
If your Comsol device flashes Red slowly to indicate successful pairing but you get no audio to your headphones, check to see if it
has paired to a different nearby headphones or speaker by mistake. (This can happen if a nearby device is in auto-pairing mode).
If you hear no sound through your headphones, your source maybe on pause or its volume turned down. Press the Power button to
resume play or turn up the volume until audio is heard.
If there is no response from your Comsol device and it appears to be frozen, connecting to a charging source may fix this problem.
