Loopcomm LP-9327H User manual

Outdoor High Power
802.11b/g/n Wireless USB Adapter
USER MANUAL 2.0
© 2011

Contents
Contents.........................................................................................................................2
1Introduction................................................................................................................3
2 Hardware Installation..................................................................................................4
3 Driver Installation.......................................................................................................8
3.1 Windows XP/2K ..............................................................................................8
3.2 Windows Vista/7..............................................................................................8
4 Wireless Network Configuration ..............................................................................14
4.1 Utility Icon.....................................................................................................14
4.2 Client Mode ...................................................................................................15
4.2.1 Wireless Device Control.............................................................................15
4.2.2 General Setting ...................................................................................16
4.2.3 Profile Setting.....................................................................................17
4.2.4 Available Network Setting..................................................................18
4.2.5 Status...................................................................................................20
4.2.6 Statistics..............................................................................................21
4.2.7 Wi-Fi Protected Setup.........................................................................22
5Troubleshooting.........................................................................................................23
6Glossary.....................................................................................................................24

1Introduction
Thank you for your purchase of the WLAN Dongle.
Featuring wireless technology, this
wireless networking solution has been designed for both large and
small businesses, and it is
scalable so that you can easily add more users and new network
features depending on your
business scale.
SYSTEM REQUIREMENTS
Windows System : 2000, XP 32/64, Vista 32/64 , 7 32/64 PCs
must have a device driver installed. It allows you to communicate
with WLAN Dongle.
BEFORE YOU START
1. Contents confirmation
1. Wireless LAN USB Adapter
Driver CD
CONNECTING YOUR WLAN Dongle TO PC
2. Connect your WLAN USB Adapter to your PC after the driver
installation.

2 Hardware Installation
Appearance and Interface Introduction
Notes:The product shot is for reference only please refer to
physical product.
1.Wall MountPole Mount
2.WaterProof

3.WaterProof Sliding Door
4.Pass trough Etheme cable from this cable
5.Push these button to remove upper housing
6. Mini USB port

Hardware installation steps
Step1:
push buttons in the sides to remove upper housing.
Step2:
Pass through USB cable from the hole, insert the cable to Mini USB port.
Notes:USB cable is required
Step3:
Install the upper housing
Make sure the housing is well installed.

Step4:
Complete diagram

3 Driver Installation
Warning! Do not cover or block the airflow to the adapter. The adapter will reach a high
temperature during use.
3.1 Windows XP/2K
Step 1 :
Insert the installation CD into your CD-ROM. Installation program will prompt language setup. Choose the
Setup Language you would like to use and click Next button.

Step 2 : Welcome Installation dialog prompt shown. Click Next to continue. Click Cancel to close
installation. Installing and configuring WLAN utility.
Step 3 :
Click Install

Step 4 : Click Finish to complete installation.

3.2 Windows Vista/7
Step 1 :
Insert the installation CD into your CD-ROM. Installation program will prompt language setup. Choose the
Setup Language you would like to use and click Next button.

Step 2 : Welcome Installation dialog prompt shown. Click Next to continue. Click Cancel to close
installation. Installing and configuring WLAN utility.
Step 3 : Click Install.

Step 4 : Click Finish to complete installation
.

4 Wireless Network Configuration
The management software is provided for the WLAN dongle. When you insert the WLAN Adapter into your
laptop or desktop, an icon should appear in the Windows System Tray automatically.
4.1 Utility Icon
Client mode utility running but no WLAN Adapter plugged.
Client mode utility running and WLAN Adapter scan available network.
Client mode utility running and WLAN Adapter can not scan any AP.

4.2 Client Mode
4.2.1 Wireless Device Control
Show Tray Icon – Show icon or not show icon in systray.
Radio Off – Stop wireless signal.
Disable Adapter – Stop wireless device.

4.2.2 General Setting
Once device is set, double click on that icon and the configuration window will pop
up as shown. It shows the current connected network. The signal strength and link
quality are displayed also. The bar graph displays the quality and strength of the link
between the node and its Access Point. Link Quality is a measurement of receiving
and transmitting performances over the radio.
Network Address displays current MAC Address, IP Address, Subnet. and Gateway.
Click Renew IP button to refresh IP address leased from wireless AP.

4.2.3 Profile Setting
In profile tab, you can Add, Remove, Edit, Duplicate and Set Default to manipulate profile content manually.
Strongly recommend to use profile after you do Available Network.
.

4.2.4 Available Network Setting
Click Available Network tab and it will show all available networks that radio can reaches. Select proper
SSID & BSSID you want to connect. Click Refresh button to force and rescan available networks currently.
Select one of SSIDs, and click Add to Profile to create profile that can be configured more wireless
parameters.
In this page, you can edit your profile name, configure wireless security like WEP,
WPA, WPA2, 802.1x …etc. After finishing setup, click OK button to save
configuration. 15

4.2.5 Status
In this page, it shows all wireless, networking and device driver version in details
.
