Comtrend Corporation PowerGrid-9171n User manual

PowerGrid-9171n
Powerline Ethernet Adapter
User Manual
261
072
-
035
Version A2.0, November 3, 2015

1
Preface
This manual provides information related to the installation and operation of this device. The individual
reading this manual is presumed to have a basic understanding of telecommunications terminology and
concepts.
If you find the product to be inoperable or malfunctioning, please contact technical support for immediate
service by email at INT-s[email protected]
For product update, new product release, manual revision, or software upgrades, please visit our website
at http://www.comtrend.com
Important Safety Instructions
With reference to unpacking, installation, use, and maintenance of your electronic device, the following
basic guidelines are recommended:
Do not use or install this product near water, to avoid fire or shock hazard. For example, near a
bathtub, kitchen sink or laundry tub, or near a swimming pool. Also, do not expose the equipment
to rain or damp areas (e.g. a wet basement).
To safeguard the equipment against overheating, make sure that all openings in the unit that offer
exposure to air are not blocked.
Avoid using a telephone (other than a cordless type) during an electrical storm. There may be a
remote risk of electric shock from lightening. Also, do not use the telephone to report a gas leak
in the vicinity of the leak.
WARNING
Disconnect the Ethernet Adapter from the power source before servicing.
Copyright
Copyright©2015 Comtrend Corporation. All rights reserved. The information contained herein is
proprietary to Comtrend Corporation. No part of this document may be translated, transcribed,
reproduced, in any form, or by any means without prior written consent of Comtrend Corporation.
This program is free software: you can redistribute it and/or modify it under the terms of the GNU General
Public License as published by the Free Software Foundation, either version 3 of the License, or (at your
option) any later version.
This program is distributed in the hope that it will be useful, but WITHOUT ANY WARRANTY; without even
the implied warranty of MERCHANTABILITY or FITNESS FOR A PARTICULAR PURPOSE. See the GNU
General Public License for more details.
You should have received a copy of the GNU General Public License along with this program. If not, see
http://www.gnu.org/licenses/
NOTE: This document is subject to change without notice.

2
Protect Our Environment
This symbol indicates that when the equipment has reached the end of its useful life, it must be
taken to a recycling centre and processed separate from domestic waste.
The cardboard box, the plastic contained in the packaging, and the parts that make up this
Ethernet Adapter can be recycled in accordance with regionally established regulations.
Never dispose of this electronic equipment along with your household waste; you may be
subject to penalties or sanctions under the law. Instead, please be responsible and ask for
disposal instructions from your local government.
FCC
Federal Communication Commission Interference Statement
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment
generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
FCC Caution:
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not
cause harmful interference, and (2) this device must accept any interference received, including interference that may cause
undesired operation.
Non-modification Statement:
Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate
the equipment.
FCC Radiation Exposure Statement:
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be
installed and operated with minimum distance 20cm between the radiator & your body.

3
Table of Contents
Chapter 1 Product Information............................................................................................................................5
1.1 Front Panel and LED indicators ..................................................................................................................5
1.2 Bottom Panel .............................................................................................................................................6
1.3 How to understand the COVERAGE LED colors .........................................................................................7
1.4 Point-to-Point Network..............................................................................................................................8
1.5 Point to Multipoint Network .....................................................................................................................9
Chapter 2 Log In Procedure ...............................................................................................................................10
2.1 Configure STATIC IP MODE.......................................................................................................................10
2.2 Logging In.................................................................................................................................................11
Chapter 3 G.hn Interface ...................................................................................................................................12
3.1 Basic Configuration ..................................................................................................................................13
3.2 NDIM Configuration.................................................................................................................................13
3.3 Encryption Configuration via WEB UI ......................................................................................................13
Chapter 4 IP Interface ........................................................................................................................................14
4.1 IP config ...................................................................................................................................................15
Chapter 5 Ethernet Interface .............................................................................................................................16
Chapter 6 Device Interface ................................................................................................................................17
6.1 Hardware information .............................................................................................................................17
6.2 Software information...............................................................................................................................18
6.3 Security ....................................................................................................................................................18
6.4 SW update................................................................................................................................................18
Chapter 7 Multicast Interface............................................................................................................................19
7.1 MCAST Configuration...............................................................................................................................19
Chapter 8 QoS menu..........................................................................................................................................20
8.1 QoS Configuration....................................................................................................................................21
Chapter 9 VLAN Interface ..................................................................................................................................24
9.1 VLAN Configuration .................................................................................................................................24
Chapter 10 G.hn spectrum Interface .................................................................................................................25
10.1 Notches ..................................................................................................................................................25
Chapter 11 Log file Interface .............................................................................................................................26
11.1 Log File ...................................................................................................................................................26
Chapter 12 Advanced Interface .........................................................................................................................27
Chapter 13 Connecting to PG-9171nWireless-N Powerline Adapter by web browser .....................................28
13.1 Windows 7 IP address setup..................................................................................................................29
13.2 Connecting to Web Management Interface ..........................................................................................30
13.3 Quick Setup............................................................................................................................................31
13.3.1 LAN Settings....................................................................................................................................31
13.3.2 Wireless Settings.............................................................................................................................32
13.3.3 Security Settings..............................................................................................................................33
13.4 Status .....................................................................................................................................................34
13.4.1 Device Status ..................................................................................................................................34
13.4.2 System Log ......................................................................................................................................35
13.4.3 Statistics..........................................................................................................................................36
13.5 General Setup .....................................................................................................................................37

4
13.5.1 Time Zone Setting ...........................................................................................................................37
13.5.2 Password.........................................................................................................................................38
13.5.3 TR-069 Client...................................................................................................................................39
13.5.4 LAN Settings....................................................................................................................................41
13.6 Wireless .................................................................................................................................................42
13.6.1 Basic settings ..................................................................................................................................42
13.6.2 Advanced settings...........................................................................................................................45
13.6.3 Security settings..............................................................................................................................47
13.6.4 Access Control ................................................................................................................................50
13.6.5 WPS.................................................................................................................................................51
13.7 Tools .......................................................................................................................................................53
13.7.1 Configuration Tools.........................................................................................................................53
13.7.2 Firmware Upgrade ..........................................................................................................................54
13.7.3 Factory Defaults..............................................................................................................................55

5
Chapter 1 Product Information
1.1 Front Panel and LED indicators
WPS Button: Press for 2 – 10 seconds to start the WPS function. Press for over 10 seconds to reset to
factory defaults.
Power Button: Push once to power up the PG-9171n
Push once to power down the PG-9171n
LED COLOR MODE Description
Security
Green
On Node is secure (it has either received or
generated network keys)
Off
Node is not secure, it has neither received nor
generated network key parameters (domain
name
and encryption key)
Blink Node is in configuration mode (able to
exchange network keys)
COVERAGE
Green On The current connection (estimated
throughput
) is greater than 40 Mbps
Orange On
The current connection (estimated
throughput) is greater than 20 Mbps and less
than 40 Mbps
Red
On
The current connection (estimated
throughput) is between 1 and 20 Mbps per
second)
Off No PLC connection exists
Blink Adapter in power saving mode (blinks twice
every 5 seconds)
WLAN
Green
Off WLAN is off
Blink Wireless is activity (tx/rx data and message)

6
WPS
Green
Off WPS function is disabled or there is no activity
Blink There is activity occurring
Ethernet
Green
On LAN connection established
Off LAN connection is not established
Blink Data transmitting/receiving
Power
Green
On The device is powered up
Off The device is powered down
1.2 Bottom Panel
Item Name Description
Config
Press more than 2 seconds (“Security” LED starts slow
blinking) and released: the “One Button Security
Setup” (OBUS) procedure is started and configuration
period is open.
Press more than 5 seconds (“Security” LED starts quick
blinking) and released: security settings are set to
default values.
Press more than 10 seconds (“Security” LED switches
off) and released: a factory reset is performed.

7
1.3 How to understand the COVERAGE LED colors
The COVERAGE LED displays quality of the network and provides important information that will
provide solutions to common questions, such as why a High Definition (HD) movie is not showing or
shows with pixels. The COVERAGE LED indicator will vary its color depending on the estimated speed of
the Powerline connection. The speed is measured in Megabits Per Second (Mbps).
C
olo
r
I
n
fo
r
ma
t
io
n
RED
The current connection has standard quality, normal Internet
activities ex. 20Mbps are possible but the Powerline is unable to
transmit either a Standard Movie or High Definition (HD) Movie.
ORANGE
The current connection has good quality and Internet activities
ex. greater than 20Mbps and less than 40Mbps to transmit
Standard Movie and HD Movie.
GREEN
The current connection has excellent quality and Internet
activities ex. greater than
40Mbps to transmit multiple Standard
Movies and HD Movies.

8
1.4 Point-to-Point Network
CASE 1: Estimated throughput is less than 20 Mbps. The PLC channel is not able to transmit an
SDTV channel. The COVERAGE LED will be RED as shown in the following figure:
CASE 2: Estimated throughput is greater than 20 Mbps but less than 40 Mbps. The PLC channel is
able to transmit an SDTV channel, but not two SDTV channels simultaneously or one HDTV channel.
The COVERAGE LED will be ORANGE as shown in the following figure:
CASE 3: Estimated throughput is greater than 10 Mbps. The PLC channel is able to play at least two
SDTV channels or 1 HDTV. The COVERAGE LED will be GREEN as shown here:

9
1.5 Point to Multipoint Network
In the case where the PLC network is composed of three or more adapters, similar situations could arise as
with a point-to-point network.
CASE 1: The COVERAGE LED in G.hn adapter 2 and G.hn adapter 3 will show the estimated level of
the PLC link receiving from G.hn adapter 1.
CASE 2: The COVERAGE LED in G.hn adapter 1 will show the estimated level of the PLC link from
which it is receiving the most amount of traffic at any given time. For example, if G.hn adapter 1 is
receiving traffic at 50Mbps from G.hn adapter 2 and is receiving 25Mbps from G.hn adapter 3, the
COVERAGE LED will show the level with reference to the G.hn adapter 2 link, as shown in the following
figure.

10
Chapter 2 Log In Procedure
2.1 Configure STATIC IP MODE
In static IP mode, you assign IP settings to your PC manually.
Follow these steps to configure your PC IP address to use subnet 192.168.0.x.
NOTE: The following procedure assumes you are running Windows XP. However, the general steps
involved are similar for most operating systems (OS). Check your OS support documentation
for further details.
STEP 1: From the Network Connections window, open Local Area Connection (You may also access this
screen by double-clicking the Local Area Connection icon on your taskbar). Click the
Properties button.
STEP 2: Select Internet Protocol (TCP/IP) and click the Properties button.
STEP 3: Change the IP address to the domain of 192.168.0.x (5<x<255) with subnet mask of
255.255.255.0. The screen should now display as below.
STEP 4: Click OK to submit these settings.

11
2.2 Logging In
Perform the following steps to login to the web user interface.
STEP 1: Start the Internet browser and enter the default IP address for the device in the Web address
field. For example, if the default IP address is 192.168.0.5, type http://192.168.0.5
STEP 2: A dialog box will appear, such as the one below. Input the default Authentication Password.
Authentication Password: admin
Click OK to continue.
Note:
The Factory Reset password is: betera

12
Chapter 3 G.hn Interface

13
3.1 Basic Configuration
MAC Address Displays the MAC address of the device.
Device ID Device ID of this node.
Domain Name string of all nodes in the network.
Force node Type force the modem to have a particular role (END POINT or DOMAIN MASTER)
G.hn profile of all nodes in the network: selecting which G.hn profile must be applied to the
network (PLC 50MHz, PLC 50MHz with MIMO, PLC 100MHz, COAX 100MHz and PHONE 100MHz).
3.2 NDIM Configuration
NDIM mode set to Automatic for enabling automatic DOD selection functionality and set to Manual
for manual configuration of DOD.
Domain ID (DOD) manually set the DOD number from 1 to 15 to use a different preamble seed
than the default 0.
3.3 Encryption Configuration via WEB UI
Pairing Password used for authentication. Write a custom password to manually create a secure
domain.
Available Connections
In this tab table, all the available G.hn connections are presented. Remote node DID and MAC
address, transmission and reception physical speeds.

14
Chapter 4 IP Interface

15
4.1 IP config
In the IP configuration tab of one G.hn node, the IPv4 and IPv6 settings can be read and changed.
IPv4 subsection:
DHCPv4 enabled: in the case of choosing ”NO" IP configuration in the following parameters, the
IPv4 Address, Subnet Mask, Default Gateway and DNS should be configured; fill these fields in. In
the case of choosing “YES” they will be filled automatically when configuration is received from the
DHCPv4 server.
IPv4 address/netmask: IPv4 address / netmask of this device.
Default Gateway: IPv4 gateway to connect the device to other LAN segments.
DNS: Domain Name Server IP (IPV4).
Additional address #1/2: additional fixed IPv4 addresses that will always be configured at boot
time.
IPv6 subsection:
DCHPv6 enabled: in the case of choosing ”NO" IP configuration in the following parameters, the
IPv6 Address, prefix, Default Gateway and DNS should be configured; fill these fields in. In the case
of choosing “YES” they will be filled automatically when configuration is received from the DHCPv6
server.
IPv6 Address / prefix: IPv6 address / prefix of the device to read the node's DHCPv6 address in
case the DHCPv6 is enabled.
Default Gateway: IPv6 gateway to connect the node to other LAN segments.
DNS: Domain Name Server IP (IPV6).
Additional address #1/2/3/4: additional fixed IPv6 addresses that will always be configured at
boot time.
IPv6 Link-Local Address: to read the node's Link Local address.
IPv6 SLAAC address: IPv6 address, automatically obtained by means of the SLAAC mechanism.
NTPv4/v6 subsection:
NTPv4/v6 client enabled: Enable/disable NTP client.
Resynchronization time: Configure re-synchronization interval time in minutes.
NTP IPv4/v6 address: Hostname or IP (IPv4 or IPv6) of NTP server.

16
Chapter 5 Ethernet Interface
The Ethernet table shows the coverage & Info of the Ethernet interface; including Interface, Speed, Duplex,
Interface Type, Mode, Internal PHY & Link.
Powersaving
Ethernet powersaving can be disabled, enabled by Ethernet link or enabled by Ethernet activity; idle timer
can be configured as well.

17
Chapter 6 Device Interface
6.1 Hardware information
In this tab, basic information such as MAC Address and Serial Number of the selected node is shown.

18
6.2 Software information
Shows the FW version and system uptime.
6.3 Security
The nodes in the network: to change the configuration password string from the default ("admin") to
another; decided by the user.
6.4 SW update
Current loaded firmware version is shown. Any flash section can be upgraded; the first flash section should
be selected and after clicking on the "OK" button the corresponding file should be chosen. Usually, a reboot
should be performed afterwards to make sure the changes are effective.
The protocol is by FTP client or TFTP client. L2 is proprietary and is reserved for future use.

19
Chapter 7 Multicast Interface
7.1 MCAST Configuration
In the MCAST Configuration tab of "My Network", IGMP snooping and MLD features can be enabled or
disabled. Also, IGMP multicast IP addresses ranges which the G.hn PLC network will sniff; can be
configured.
IGMP Snooping: Enable or Disable.
MLD Snooping: Enable or Disable.
IGMP/MLD broadcast report (allowed): set to NO for enabling reports dropping until the video
source is detected, this is a recommended setting when IGMP/MLD is enabled. Set to YES for
broadcasting reports until the video source is detected; this implies the multicast video stream is
sent as broadcast and it is the recommended state when IGMP/MLD is disabled.
IGMP Multicast ranges configuration: 4 multicast IP address ranges can be configured defining the
minimum and maximum IP addresses of each range. Only multicast traffic within these ranges will be
processed.
