conceptD 7 User manual

USER’S MANUAL
ConceptD7 / ConceptD7 Pro

2 -
© 2019. All Rights Reserved.
ConceptD 7 / ConceptD 7 Pro
Covers: CN715-71 / CN715-71P
This revision: September 2019
Register your ConceptD product
If your new device runs on Windows OS, you may have had your
product registered automatically while you start up your device with
Windows OS.
Log in at www.acer.com/myproducts with the email address you
registered for Windows OS to review your product record. (Reset your
password if you do not know it.)
If the record is not found, please follow the steps below to register.
1. Ensure you are connected to the Internet.
2. Go to www.acer.com/register-product.
3. Sign in or sign up for an Acer ID.
4. Enter S/N or SNID of your device to register it.
Important
This manual contains proprietary information that is protected by
copyright laws. The information contained in this manual is subject to
change without notice. Some features described in this manual may not
be supported depending on the Operating System version. Images
provided herein are for reference only and may contain information or
features that do not apply to your computer. Acer Group shall not be
liable for technical or editorial errors or omissions contained in this
manual.
Model number: _________________________________
Serial number: _________________________________
Date of purchase: ______________________________
Place of purchase: ______________________________

Table of contents - 3
TABLE OF CONTENTS
First things first 6
Your guides ............................................. 6
Basic care and tips for using your
computer.................................................. 6
Turning your computer off........................... 6
Taking care of your computer ..................... 7
Taking care of your AC adapter .................. 8
Cleaning and servicing................................ 8
Your ConceptD notebook tour 9
Screen view ............................................. 9
Keyboard view ....................................... 10
Left view ................................................ 11
USB 3.1 Gen 1 information ....................... 11
Right view ............................................. 12
USB Type-C information ........................... 12
Rear view............................................... 13
Base view .............................................. 13
Using the keyboard 14
Lock keys............................................... 14
Hotkeys.................................................. 14
Windows keys........................................ 15
Using the Precision Touchpad 16
Touchpad gestures................................ 16
Changing touchpad settings .................. 18
Recovery 19
Creating a factory default backup.......... 19
Backing up your wireless and LAN
drivers.................................................... 21
Restoring your computer ....................... 21
Reset this PC and keep my files ............... 22
Reset this PC and remove everything ...... 23
Using a Bluetooth connection 26
Enabling and disabling Bluetooth .......... 26
Enable Bluetooth and add a device .......... 26
Connecting to the Internet 28
Connecting to a wireless network.......... 28
Connecting to a wireless LAN................... 28
Connecting with a cable ........................ 31
Built-in network feature ............................. 31
Connecting to a cellular network ........... 31
ConceptD Palette 32
The ConceptD Palette main screen....... 32
Color profile setting ................................... 32
TrueHarmony setting ................................ 33
Monitoring.............................................. 33
Split Screen ........................................... 34
App Center ............................................ 34
Advanced Settings................................. 35
Bluelight Shield 36
Securing your computer 38
Using a computer security lock.............. 38
Using passwords ................................... 38
Entering passwords .................................. 39
BIOS utility 40
Boot sequence....................................... 40
Setting passwords ................................. 40
Power management 41
Saving power ......................................... 41
Battery pack 43
Battery characteristics ........................... 43
Charging the battery ................................. 43
Optimizing battery life ............................... 44
Checking the battery level......................... 45
Battery-low warning .................................. 45
Traveling with your computer 46
Disconnecting from the desktop ............ 46
Moving around ....................................... 46
Preparing the computer ............................ 46
What to bring to meetings ......................... 47
Taking the computer home .................... 47
Preparing the computer ............................ 47
What to take with you................................ 48
Special considerations .............................. 48
Setting up a home office ........................... 48
Traveling with the computer................... 49
Preparing the computer ............................ 49
What to take with you................................ 49
Special considerations .............................. 49
Traveling internationally......................... 49
Preparing the computer ............................ 50
What to bring with you .............................. 50
Special considerations .............................. 50
Universal Serial Bus (USB) 52
Thunderbolt 3 port 53
Displays ................................................. 53
Video and audio connectors 54
Connecting a monitor............................. 54
Headphones and microphone................ 54
HDMI 55
Frequently asked questions 57
Requesting service ................................ 59
Tips and hints for using Windows 10 ..... 60
How do I get to Start? ............................... 60
How do I turn off my computer?................ 60
How do I unlock my computer?................. 60
How do I set the alarm? ............................ 62
Where are my apps?................................. 63
What is a Microsoft ID (account)?............. 63
How do I check for Windows updates?..... 64
Where can I get more information?........... 64

4 - Table of contents
Troubleshooting..................................... 65
Troubleshooting tips.................................. 65
Error messages......................................... 65
Internet and online security 67
First steps on the net ............................. 67
Protecting your computer.......................... 67
Choose an Internet Service Provider........ 67
Network connections................................. 69
Surf the Net!.............................................. 70
Internet security software.......................... 71

Getting started...
In this section you will find:
• Useful information on caring for your computer and your health
• Where to find the power button, ports and connectors
• Tips and tricks for using the touchpad and keyboard
• How to create recovery backups
• Guidelines for connecting to a network and using Bluetooth
• Information on using ConceptD’s bundled software

6 - First things first
FIRST THINGS FIRST
We would like to thank you for making this ConceptD notebook your
choice for meeting your mobile computing needs.
Your guides
To help you use your ConceptD notebook, we have designed a set of
guides:
First off, the Setup Guide helps you get started with setting up your
computer.
The Quick Guide introduces you to the basic features and functions
of your new computer. For more on how your computer can help you
to be more productive, please refer to the User’s Manual.This guide
contains detailed information on such subjects as system utilities, data
recovery, expansion options and troubleshooting.
Once you have connected to the internet, you can download updates
for your computer from:
http://go.acer.com/?id=17883
1. The link will open the Acer Support webpage.
2. Scroll down to Drivers and Manuals and search for your model by
pasting in or manually entering the serial number, SNID, or
product model.
3. From this page you can also download and install the Acer
identification utility that will automatically detect your computer’s
serial number and SNID and allow you to copy it to the clipboard.
4. Once you have found your product model, any updates, or
documents will be listed.
Basic care and tips for using your computer
Turning your computer off
To turn the power off, do any of the following:
• Use the Windows shutdown command: Press the Windows key or
select the Windows Start button, select Power > Shut down.

First things first - 7
• Right-click the Windows Start button > Shut down or sign out >
Shut down.
If you need to power down the computer for a short while, but don’t
want to completely shut it down, you can put it to Sleep by doing any
of the following:
• Press the power button.
• Press the sleep hotkey.
• Press the Windows key or select the Windows Start button, select
Power > Sleep.
• Right-click the Windows Start button > Shut down or sign out >
Sleep.
Taking care of your computer
Your computer will serve you well if you take care of it.
• Only use the adapter provided with your device, or an Acer-
approved adapter to power your device.
• Do not expose the computer to direct sunlight. Do not place it near
sources of heat, such as a radiator.
• Do not expose the computer to temperatures below 0º C (32º F) or
above 50º C (122º F).
• Do not subject the computer to magnetic fields.
• Do not expose the computer to rain or moisture.
• Do not spill water or any liquid on the computer.
• Do not subject the computer to heavy shock or vibration.
• Do not expose the computer to dust or dirt.
• Never place objects on top of the computer.
• Do not slam the computer display when you close it.
• Never place the computer on uneven surfaces.
Note
If you cannot power off the computer normally, press and hold the power
button for up to ten seconds to shut down the computer. If you turn off the
computer and want to turn it on again, wait at least two seconds before
powering up.

8 - First things first
Taking care of your AC adapter
Here are some ways to take care of your AC adapter:
• Do not connect the adapter to any other device.
• Do not step on the power cord or place heavy objects on top of it.
Route the power cord and any cables away from where people walk.
• When unplugging the power cord, do not pull on the cord itself but
pull on the plug.
• The total ampere ratings of the equipment plugged in should not
exceed the ampere rating of the cord if you are using an extension
cord. Also, the total current rating of all equipment plugged into a
single wall outlet should not exceed the fuse rating.
Cleaning and servicing
When cleaning the computer, follow these steps:
1. Turn off the computer.
2. Disconnect the AC adapter.
3. Use a soft, moist cloth. Do not use liquid or aerosol cleaners.
If your computer is dropped or visibly damaged, or does not work
normally, please contact your nearest authorized Acer service center.

Your ConceptD notebook tour - 9
YOUR CONCEPTD NOTEBOOK TOUR
After setting up your computer as illustrated in the Setup Guide, let us
show you around your new ConceptD computer.
Screen view
2
3
1
#Icon Item Description
1Microphones Internal stereo digital microphones
for sound recording.
2Webcam
Web camera for video
communication.
A light next to the webcam indicates
that the webcam is active.
3Screen Displays computer output.

10 - Your ConceptD notebook tour
Keyboard view
1
1
2
3
4
#Icon Item Description
1Backlit keyboard
For entering data into your computer.
See "Using the keyboard" on page
14.
2Touchpad Touch-sensitive pointing device.
3 Power button Turns the computer on and off.
4Ventilation
Allows the computer to stay cool.
Do not cover or obstruct the
openings.

Your ConceptD notebook tour - 11
Left view
21 3 4 5 6 7
#Icon Item Description
1Ventilation and
cooling fan
Allows the computer to stay cool.
Do not cover or obstruct the
openings.
2DC-in jack Connects to an AC adapter.
3Ethernet (RJ-45)
port
Connects to an Ethernet 10/100/
1000Mbps/2.5Gbps-based network.
4
USB port with
power-off
charging
Connects to USB devices.
5HDMI port Supports high-definition digital video
connections.
6Mic-in jack Connects to an external microphone
for recording audio.
7Headset/
speaker jack
Connects to audio devices (e.g.,
speakers, headphones)
USB 3.1 Gen 1 information
• USB 3.1 Gen 1 compatible ports are blue.
• Compatible with USB 3.1 Gen 1 and earlier devices.
• For optimal performance, use USB 3.1 Gen 1-certified devices.
• Defined by the USB 3.1 Gen 1 specification (SuperSpeed USB).

12 - Your ConceptD notebook tour
Right view
123654
#Icon Item Description
1
Battery indicator
Indicates the computer’s battery
status.
Blinking Amber when the battery is
charging or reaches the low battery
level.
Amber when fully charged (with the
AC adapter plugged in).
Power indicator Indicates the computer’s power
status.
2
USB Type-C /
Thunderbolt 3
port
Connects to USB devices with a USB
Type-C connector.
Supports Thunderbolt™3 and
displays.
3Mini DisplayPort Connects to an external display
device.
4USB port Connects to USB devices.
5Ventilation and
cooling fan
Allows the computer to stay cool.
Do not cover or obstruct the
openings.
6Kensington lock
slot
Connects to a Kensington-compatible
security lock.
USB Type-C information
• USB 3.1 Gen 2 with transfer speeds up to 10 Gbps.
• Supports DisplayPort™audio/video output.
• Compatible with Thunderbolt™3.
• Delivers up to 3 A at 5 V DC for USB charging.

Your ConceptD notebook tour - 13
Rear view
1
#Icon Item Description
1Ventilation and
cooling fan
Allows the computer to stay cool.
Do not cover or obstruct the
openings.
Base view
1
3
2
#Icon Item Description
1Ventilation and
cooling fan
Allows the computer to stay cool.
Do not cover or obstruct the
openings.
2Battery reset
pinhole
Simulates removing and reinstalling
the battery.
Insert a paperclip into the hole and
press for four seconds.
3Speakers Deliver stereo audio output.

14 - Using the keyboard
USING THE KEYBOARD
The keyboard has full-sized keys, a numeric keypad, separate cursor,
lock, Windows keys and hotkeys.
Lock keys
The keyboard has lock keys which you can use to turn keyboard
functions on and off.
Hotkeys
To activate hotkeys, press and hold the Fn key before pressing the
other key in the hotkey combination.
Lock key Description
Caps Lock When Caps Lock is on, all alphabetic characters
typed are in uppercase.
Num Lock
When Num Lock is on, the keypad is in numeric
mode. The keys function as a calculator (complete
with the arithmetic operators +, -, *, and /). Use this
mode when you need to do a lot of numeric data
entry.
Scroll Lock
When Scroll Lock is on, the screen moves one line
up or down when you press the up or down arrow
keys respectively. Scroll Lock does not work with
some applications.
Hotkey Icon Description
Fn + F1 Puts the computer in Sleep mode.
Fn + F2 Turns on / off the computer's network devices.
Fn + F3 Decreases the screen brightness.
Fn + F4 Increases the screen brightness.
Fn + F5
Switches display output between the display
screen, external monitor (if connected) and both.

Using the keyboard - 15
Windows keys
The keyboard has two keys that perform Windows-specific functions.
Fn + F6 Turns the display screen backlight off to save
power. Press any key to return.
Fn + F7 Turns the built-in touchpad on and off.
Fn + F8 Turns the speakers on and off.
Fn + F9 Decreases the intensity of the keyboard
backlight.
Fn + F10 Increases the intensity of the keyboard
backlight.
Fn + F11 NumLk Turns Numeric Lock on or off.
Fn + F12 Scr Lk Turns Scroll Lock on or off.
Fn + Home Stop playing the selected media file.
Fn + Pg Up Play or pause a selected media file.
Fn + Pg Dn Return to the previous media file.
Fn + End Jump to the next media file.
Fn + Increases the sound volume.
Fn + Decreases the sound volume.
Hotkey Icon Description
Key Description
Windows key Pressed alone it returns to the Start screen
or to return to the last open app.
Application key This key has the same effect as clicking
the right mouse button.

16 - Using the Precision Touchpad
USING THE PRECISION TOUCHPAD
The touchpad controls the arrow (or 'cursor') on the screen. As you
slide your finger across the touchpad, the cursor will follow this
movement. The Precision Touchpad (PTP) is designed to provide a
more uniform, smooth, and accurate touchpad experience. Many
applications support precision touchpad gestures that use one or
more fingers, however, some gestures may not be supported by the
specific application or program you are using.
Touchpad gestures
Single-finger slide
Slide a finger across the touchpad to move the cursor.
Single-finger press or tap
Press the touchpad down, or lightly tap the touchpad with
your finger, to perform a 'click', which will select or start an
item. Quickly repeat the tap to perform a double tap or
'double click'.
Two-finger press
Lightly tap the touchpad with two fingers to perform a
'right click'. In the Start screen, this will toggle the app
commands. In most apps this will open a context menu
related to the selected item.
Two-finger slide
Swiftly scroll through web pages, documents and playlists
by placing two fingers on the touchpad and moving both in
any direction.
Two-finger pinch
Zoom in and out of photos, maps and documents with a
simple finger-and-thumb gesture.

Using the Precision Touchpad - 17
The precision touchpad includes added technology features that help
recognize and prevent unintentional gestures such as accidental taps,
gestures, and pointer movement.
Three-finger press
Lightly tap the touchpad with three fingers to open the
Search Windows.
Three-finger swipe
Swipe across the touchpad with three fingers.
• Swipe up to open Task View. Move the cursor over a
window and tap the touchpad to select that window, or
swipe downwards to exit Task View.
• Swipe down to minimize all open windows and show
Desktop; swipe upwards to restore the minimized
windows.
• Swipe left or right to switch between open windows.
Four-finger press
Lightly tap the touchpad with four fingers to open the
Action Center.
Four-finger swipe
Swipe across the touchpad with four fingers.
• Swipe up to open Task View. Move the cursor over a
window and tap the touchpad to select that window, or
swipe downwards to exit Task View.
• Swipe down to minimize all open windows and show
Desktop; swipe upwards to restore the minimized
windows.
Note
The touchpad is sensitive to finger movement; the lighter the touch, the better
the response. Please keep the touchpad and your fingers dry and clean.

18 - Using the Precision Touchpad
Changing touchpad settings
To change the touchpad settings to suit your personal requirements,
please do the following.
1. In the icon tray in the lower right-hand corner of the screen, select
the Notifications icon to open the Notifications pane.
2. Select All settings.
3. Select Devices > Touchpad
4. Now you can adjust the settings to suit your personal needs. You
can switch off the touchpad if you prefer to use a mouse. Or you can
adjust the touchpad sensitivity to suit your needs. Scroll down to see
more settings.

Recovery - 19
RECOVERY
If you are having trouble with your computer, and the frequently asked
questions (see Got a question? on page 56) do not help, you can
recover your computer.
This section describes the recovery tools available on your computer.
Acer provides Acer Care Center, which allows you to reset your PC,
refresh your PC, or create a factory default backup. If you cannot
access Acer Care Center, click Settings in the Start menu, select
Update & Security and then click Recovery.
Creating a factory default backup
Recovery Management allows you to quickly and easily back up your
operating system, installed apps and data.
Note
Acer Care Center vary depending on model or Operating System.
Important
We recommend that you create a Factory Default Backup as soon as
possible. In certain situations a full recovery will require a USB
recovery backup.
Note
Since the recovery backup requires at least 8 GB of storage after formatting,
it is recommended to use a USB drive with a capacity of 16
GB or larger.

20 - Recovery
1. From Start, select Care Center then Recovery Management.
2. Select the Backup tab and click Get Started for Create Factory
Default Backup to open the Recovery Drive window.
3. Make sure Back up system files to the recovery drive is selected
and click Next.
