Conceptronic CIPCAM720PTIWL User manual

Wireless Network Camera
User Manual
CIPCAM720PTIWL,CIPCAM720OD,CIPCAM720ODWDR,CIPDC
AM720OD
V1.0

DEFAULT SETTINGS
IPAddress
192.168.1.58
User/Password
admin/123456
1、Installation Environment
Keep away from the places for high-temperature, heat source and direct sunlight;
Keep away from water and if wet, cut off the power immediately.
Avoid using in a damp environment; the reference range for operation humidity is below
85%RH.
Avoid using in too hot and too cold environment, the reference range for operation
temperature is -10℃~ +50℃
Please install it horizontally or wall mount, avoid strenuous vibration and do not place
other items on top of the unit.
2、Transport and Handling
Please handle the item with care.
Do not use in areas around condensation.
Please disconnect the item from the mains before moving.
Notice:
1. Be careful not to damage the camera or subject it to strong impacts or shocks.
2. Do not touch the optical components for the image sensor, such as the lens, if
necessary, please place a clean and moistened cloth with alcohol and wipe the dirt
gently; When not in use, please place the dust cover on to the item to protect the image
sensor.
3. Do not aim the camera directly into the sun or at other intense light sources that could
affect the image quality, this will also shorten the service life for the image sensor.
4. Keep away from laser when it is working, otherwise the image sensor can be damaged.
5. If the equipment is not working properly, please contact the store or the service centre,
do not disassemble or modify the equipment in any way.
Default
Notice

2
Index
1. PRODUCT INTRODUCTION ......................................................................................................4
2. INSTALLATION AND OPERATION GUIDE .............................................................................4
2.1. VIEW VIDEO BY MOBILE PHONE SOFTWARE...............................................................................4
2.2. VIEW VIDEO BY WIRED CONNECTION IN LAN...........................................................................4
2.3. VIEW VIDEO BY WIFI CONNECTION IN LAN .............................................................................8
2.4. VIEW VIDEO IN INTERNET .........................................................................................................9
2.5. VIEW VIDEO BY PC CLIENT SOFTWARE...................................................................................10
2.6. VIEW VIDEO BY OTHER WAY...................................................................................................10
2.6.1. Other Web Browser........................................................................................................10
2.6.2. Other common software................................................................................................. 11
3. ALL SETTINGS...........................................................................................................................11
3.1. VIDEO SETTING.......................................................................................................................11
3.1.1. Video parameters...........................................................................................................12
3.1.2. Audio parameters ..........................................................................................................12
3.1.3. Image parameters..........................................................................................................13
3.2. WEB SETTING .........................................................................................................................14
3.2.1. Basic web setting ...........................................................................................................14
3.2.2. WIFI setting...................................................................................................................14
3.2.3. WAN access setting........................................................................................................14
3.2.4. ONVIF setting................................................................................................................15
3.3. ALARM SETTING .....................................................................................................................15
3.3.1. External Alarm Input.....................................................................................................15
3.3.2. Motion Detection Setting...............................................................................................15
3.3.3. Alarm mode setting........................................................................................................16
3.3.4. Alarm time setting..........................................................................................................17
3.4. ADVANCE SETTING .................................................................................................................17
3.4.1. User management..........................................................................................................17
3.4.2. Auto Capture Setting .....................................................................................................18
3.4.3. Timer recording .............................................................................................................18
3.4.4. E-mail Setting................................................................................................................18
3.4.5. FTP setting ....................................................................................................................19
3.4.6. Multiple settings ............................................................................................................20
3.5. SYSTEM SETTING ....................................................................................................................20
3.5.1. Device information........................................................................................................20
3.5.2. Date and time setting.....................................................................................................21
3.5.3. Initialize setting .............................................................................................................21
3.5.4. System Log.....................................................................................................................21
4. PRODUCT FAMILY FOR SMARTP2P CAMERA .................................................................22
4.1. HD WDR WATERPROOF CAMERA FOR CIPCAM720ODWDR................................................22
4.2. HD PTZ CAMERA FOR CIPCAM720PTIWL..........................................................................22
4.3. OUTDOOR HD WATERPROOF PTZ CAMERA CIPDCAM720OD..............................................23

3
4.4. HD WATERPROOF CAMERACIPCAM720OD.........................................................................23
5. FAQ...............................................................................................................................................24

4
1. Product introduction
Main features:
Monitor your home or office from anywhere in the world
Built-in Infrared LEDs for night viewing
Supports motion detection and event notification via e-mail or FTP
Digital input/output (1DI/1DO) for sensor and alarm
Wireless security with WEP, WPA and WPA2 encryption
Supports iPhone/smartphone/PDAremote viewing over the Internet
Free 64-channel monitoring software included
Supports cloud functionality
2. Installation and Operation Guide
2.1. View video by mobile phone software
You need to download and install iSmartviewPro mobile phone client software from
attached CD, and then scan QR code on the camera body to add camera for viewing video, for
detail, please see “Product Quick Application Guide”.
2.2. View video by wired connection in LAN
Power on the IP camera（please check carefully the voltage of power adaptor, don’t
insert incorrect power, otherwise it will be damaged）, connect IP camera to router by
network cable and connect computer to the same router, example of figure 1.
Figure 1
Router
LAN Computer
IPcamera

5
Insert attached CD to computer driver, double click “H&MSearch_en.exe” in the CD,
will pop up the interface as figure 2, please operate as the following steps:
Figure 2
1) Click “Search”（Please make sure your firewall will not block up the item to be
searched）
2) Choose a camera;
3) Change the ip address of the ip camera according to the information in the red
frame on the left. The numbers in the red circle should not be the same. The
Http port should be a number between 80~65535;
4) Enter user name and password for the device, the default is “admin” and
“123456”;
5) Click “update”;
6) After updating successfully, click “Search (F3)”, choose the device again and
click “Browse (F4)”. Then you can run the web browser, enter user name and
password and login IP camera to view the video, example of figure 3.（please
use IE browser at first time）

6
Figure 3
Notice: Need to download ActiveX when first use, click “download ActiveX( when first
use)” in figure 3, will display prompt as figure 4, click ‘run’ will download and install the
ActiveX automatically.
Figure 4
Tips: You can hold on reset button on the camera for 10 seconds to restore factory
default if you forget user name and password, or not sure the device parameters.
Click “Video View”in figure 3 to access video interface as below.

7
1) Status bar
Figure 4-1
①Display connection status;
②Display record status: if click “Record”, it will show “REC” which stands for
recording; click record button again, it will stop;
③Zoom out, zoom in and restore digital zoom;
④Set saving file path: set the location for recording and capturing file storage;
⑤Talk button: Click this button to hear what the person at the side of computer
talks. Click it again, it will stop playing;
⑥Audio monitor button: Click this button to hear what people talking about at the
side of IP Cameras,
2) Choose video stream
You can choose primary stream or second stream, third stream to view the video.
Recommend to view by primary stream in LAN, by second stream in WAN and by third
stream in mobile phone.
You can view the video by four, nine pictures in same screen, but need to set the camera
in 3.6.6 multiple setting.
3) PTZ control
If the camera supports PTZ function, you can click up, down, left, right arrow to control
the camera moving, click button to center and stop the camera.
When you set camera to a preset position, and then click ‘ , after the camera is
changed to other direction, click can move the camera to the position you have

8
set.
4) Snap /record / SD card/playback
Click “Snap” button, to save the picture to the specified file.
Click “Record” button to start record. Click again to stop record.
Click “Check TF/SD card” can browse the files in the SD card (If the SD card
already inside the camera), you can select file to download it;
Click “Playback” button, it will show a player which can play the record video.
For these buttons means: play; stop; open video file; slow
play; quick play.
2.3. View video by WiFi connection in LAN
After finishing the wired connection as chapter 2.2, you can connect the camera by WiFi.
Login camera in wired connection and enter wifi setting, and then operate as the
following step, example of figure 5.
Figure 5
Select ‘On’ and click ‘Search’, and then select wireless router in pop up menu, click ‘OK’
and enter its password, click ‘apply’ to save the wireless settings. And you can click
‘check’ to check if the wireless setting is successful. After setting successfully, please pull
out network cable and reboot the camera to use the wireless connection to view video.
Because the camera supports WPS/QSS, so you can set wireless by simple way as
below.
1) Please confirm if the router connected to camera supports WPS/QSS (you can check
user manual of the router or get the support from router factory);
2) Press WPS/QSS button on the router, it will launch the function.
3) Press and hold on reset button for 2~5 seconds after it ran normally（not need
connect cable）, it will launch theWPS/QSS function, then match the setting with the
router, the status LED always on when it was matching, and it will flash after
matching successfully.
4) Unplug power adaptor and reboot the camera, then you can use the wireless
connect function.

9
Note: The camera will automatically stop the function when the matching is unsuccessful
after continuing 50 seconds. Due to different kinds of the router, we don’t sure our
camera can be connected to all routers successfully.
2.4. View video in internet
You should connect your internal network to the internet first and configure port
forwarding, consult your router’s manual for further details, as figure 6.
Figure 6
For example: operation step of port forwarding as figure 7.
Figure 7
1) Please go to the setting interface of Router, and choose “Port Forwarding”;
IP camera
Computer
Computer
Router
ADSL
Internet
IOS
Android
