Conel ER75i v2 SL User manual

EDGE router ER75i v2
USER’S MANUAL

USED SYMBOLS
Used symbols
Danger – important notice, which may have an influence on the user’s safety or the function
of the device.
Attention – notice on possible problems, which can arise in specific cases.
Information, notice – information, which contains useful advice or special interest.
GPL license
Source codes under GPL license are available free of charge by sending an email to:
[email protected].
Conel s.r.o., Sokolska 71, 562 04 Usti nad Orlici, Czech Republic
Manual issued in CZ, August 18, 2014
i

CONTENTS
Contents
1 Safety instruction 1
2 Product disposal instructions 2
3 Router description 3
4 Contents of package 4
5 Router design 5
5.1 Routerversions.................................... 5
5.2 Deliveryidentification ................................ 6
5.3 Orderingcodes.................................... 7
5.3.1 Basicversion................................. 7
5.3.2 Fullversion .................................. 7
5.4 Basic dimensions of plastic box . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
5.5 Basic dimensions of metal box . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
5.6 Mechanical dimensions and mounting recommendations . . . . . . . . . . . . . 9
5.7 Removing from the DIN rail . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
5.8 Description of the front panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
5.8.1 Statusindication ............................... 13
5.8.2 PowerconnectorPWR............................ 14
5.8.3 Antenna connector ANT (and AUX) . . . . . . . . . . . . . . . . . . . . . 15
5.8.4 SIMcardreader ............................... 16
5.8.5 Ethernetport ................................. 16
5.8.6 PORT1 .................................... 18
5.8.7 PORT2 .................................... 18
5.8.8 USBPort ................................... 19
5.8.9 I/OPort .................................... 20
5.8.10Reset ..................................... 22
6 First use 23
6.1 Connecting the router before first use . . . . . . . . . . . . . . . . . . . . . . . 23
6.2 Start.......................................... 24
6.3 Configuration ..................................... 24
6.3.1 Configuration over web browser . . . . . . . . . . . . . . . . . . . . . . . 24
6.3.2 Configuration over Telnet . . . . . . . . . . . . . . . . . . . . . . . . . . 24
7 Technical parameters 25
ii

CONTENTS
7.1 Technical parameters of router . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
7.2 Technical parameters of module . . . . . . . . . . . . . . . . . . . . . . . . . . 25
7.3 Technical parameters of processor . . . . . . . . . . . . . . . . . . . . . . . . . 26
7.4 Technical parameters I/O port . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
7.5 Technical parameters of expansion port . . . . . . . . . . . . . . . . . . . . . . 26
8 Recommended literature 27
9 Possible problems 28
10 FAQ 29
11 Customers support 31
iii

LIST OF FIGURES
List of Figures
1 Contentsofpackage................................. 4
2 FrontpanelER75iv2B................................ 5
3 FrontpanelER75iv2F................................ 5
4 FrontpanelER75iv2BSL.............................. 5
5 FrontpanelER75iv2FSL.............................. 5
6 LabelER75iv2B ................................... 6
7 LabelER75iv2BSL ................................. 6
8 LabelER75iv2F ................................... 6
9 LabelER75iv2FSL ................................. 6
10 Basic dimensions of plastic box . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
11 Basic dimensions of metal box . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
12 Spacearoundantennas ............................... 9
13 Space around antennas for SL . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
14 Cablerouting ..................................... 10
15 Cable routing for SL version . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
16 Space in front of connectors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
17 Space in front of connectors – SL . . . . . . . . . . . . . . . . . . . . . . . . . . 10
18 Default position of DIN holder . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
19 RemovingfromtheDINrail ............................. 11
20 FrontpanelER75iv2F................................ 12
21 FrontpanelER75iv2FSL.............................. 12
22 Powerconnector ................................... 14
23 Connection of power supply connector . . . . . . . . . . . . . . . . . . . . . . . 14
24 Connection of power supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
25 Externalantenna................................... 15
26 Connectingoftheantenna.............................. 15
27 EjectedSIMholder.................................. 16
28 Ethernetconnector.................................. 17
29 Connection of ethernet cable . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
30 Example of router connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
31 PORT1cableconnection .............................. 18
32 PORT2cableconnection .............................. 19
33 USBconnector .................................... 19
34 Connection PLC to the router . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
35 Connection flash memory to the router . . . . . . . . . . . . . . . . . . . . . . . 20
36 I/Oconnector..................................... 20
37 ConnectionofI/Ocable ............................... 21
38 Connection of input and output to the router . . . . . . . . . . . . . . . . . . . . 21
39 Routerreset...................................... 22
40 Routerconnection .................................. 23
iv

LIST OF TABLES
List of Tables
1 Routerversions.................................... 5
2 Deliveryidentification ................................ 6
3 Ordering codes of basic version . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
4 Ordering codes of full version . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
5 Frontpaneldescription................................ 12
6 Routerstatusindication ............................... 13
7 Connection of power connector . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
8 Connection of Ethernet connector . . . . . . . . . . . . . . . . . . . . . . . . . . 16
9 Connection of USB connector . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
10 ConnectionofI/Oport ................................ 20
11 Description of reset and restart router . . . . . . . . . . . . . . . . . . . . . . . 22
12 Technical parameters of router . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
13 Technical parameters of module . . . . . . . . . . . . . . . . . . . . . . . . . . 25
14 Technical parameters of processor . . . . . . . . . . . . . . . . . . . . . . . . . 26
15 Technical parameters I/O port . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
v

1. SAFETY INSTRUCTION
1. Safety instruction
Please, observe the following instructions:
•The router must be used in compliance with all applicable international and national laws
and in compliance with any special restrictions regulating the utilization of the router in
prescribed applications and environments.
•To prevent possible injury to health and damage to appliances and to ensure that all
the relevant provisions have been complied with, use only the original accessories.
Unauthorised modifications or utilization of accessories that have not been approved
may result in damage to the router and in a breach of applicable regulations. Unautho-
rized modifications or utilization of accessories that have not been approved may result
in the termination of the validity of the guarantee.
•The router can not be opened.
•Before handling of the SIM card turn off the router and disconnect it from power supply.
•Caution! The SIM card could be swallowed by small children.
•It must not be exceeded by the maximum voltage 30 V DC power connector on the router.
•Do not expose the router to extreme ambient conditions. Protect the router against dust,
moisture and high temperature.
•The router should not be used at petrol stations of flammable and explosive materials.
We remind the users of the duty to observe the restrictions concerning the utilization
of radio devices at petrol stations, in chemical plants, or in the course of blasting works
in which explosives are used.
•Switch off the router when travelling by plane. Utilization of the router in a plane may
endanger the operation of the plane or interfere with the mobile telephone network, and
may be unlawful. Failure to observe these instructions may result in the suspension
or cancellation of telephone services for the respective client, or, it may result in legal
sanctions; it may also result in both eventualities.
•When using the router in the close proximity of personal medical devices, such as cardiac
pacemakers or hearing aids, you must proceed with heightened caution.
•If it is in the proximity of TV sets, radio receivers and personal computers, the telephone
may cause interference.
•It is recommended that you should create an appropriate copy or backup of all the im-
portant settings that are stored in the memory of the device.
1

2. PRODUCT DISPOSAL INSTRUCTIONS
2. Product disposal instructions
The WEEE (Waste Electrical and Electronic Equipment: 2002/96/EC) directive has been
introduced to ensure that electrical/electronic products are recycled using the best available
recovery techniques to minimize the impact on the environment. This product contains high
quality materials and components which can be recycled. At the end of it’s life this product
MUST NOT be mixed with other commercial waste for disposal. Check the terms and condi-
tions of your supplier for disposal information.
2

3. ROUTER DESCRIPTION
3. Router description
GPRS/EDGE ER75i v2 router is used to wirelessly connect various equipments and de-
vices via Ethernet interface 10/100 to the Internet or intranet. Thanks to high security level and
wide coverage of GPRS/EDGE technology provided by mobile phone operators, it is mostly
used in industrial applications, for remote maintenance and service of machines, or for data
transfer from solar or wind power plants. Other benefits and advantages includes high mod-
ularity – the router offers option to connect various user devices via Ethernet 10/100, RS232,
RS485, RS422, MBUS or I/O.
As a standard, this industrial router is equipped with one Ethernet 10/100, one USB Host
port, one binary input/output (I/O) port and one SIM card. To save and backup communication
data a version with two SIM cards is available. The wide range of interface options of the router
further expands expansion Port1 and Port2, which are selected by the customer. For Port1
are available: Ethernet port 10/100, serial interface ports RS232/RS485/RS422/MBUS or in-
puts/outputs (I/O – CNT). Port2 may be equipped with serial interfaces RS232/RS485/RS422/
MBUS, wireless interfaces WIFI/WMBUS, SDH expansion port or inputs/outputs (I/O – CNT).
Both of ports can be fitted with internal switch (exp. port SWITCH). This wireless router is
supplied either in a plastic or metal casing, based on the requirements of the customer.
Configuration is done via web interface protected by password. The GPRS/EDGE router
supports creation of VPN tunnels using technologies IPsec, OpenVPN and L2TP to ensure
safe communication. Web interface provides detail statistics about the wireless router activi-
ties, signal strength, detailed log, etc. Router supports functions: DHCP, NAT, NAT-T, DynDNS,
NTP, VRRP, control by SMS and many other functions.
Other diagnostic functions ensuring continuous communication include automatic inspec-
tion of PPP connection offering an automatic restart feature – in case of connection losses,
or hardware watchdog which monitors the status of the router. With the help of a special win-
dow (start up script window) you may insert Linux scripts for various actions. For some appli-
cations the key option to create several different configurations for one wireless GPRS/EDGE
router, the so-called profiles (maximum of 4), and the option to switch between them (for exam-
ple via SMS, binary input status, etc.) is essential. Cellular wireless routers may automatically
upgrade configuration and firmware from server. This allows mass reconfiguration of many
routers in one time.
For easy use additional software may be used – communication VPN server Digicluster
and software for router monitoring R-SeeNet.
Examples of possible applications:
•mobile office
•fleet management
•security system
•telematic
•telemetric
•remote monitoring
•vending and dispatcher machines
3

4. CONTENTS OF PACKAGE
4. Contents of package
Basic delivered set of router includes:
•router,
•power supply,
•crossover UTP cable,
•external antenna,
•clip for the DIN rail,
•installation CD containing instructions,
•paper start guide.
Figure 1: Contents of package
Note: The router box and DIN mount are supplied in a metal case in the SL version.
The router can also be supplied as expansion accessories:
•One (Basic version) or two (Full version) expansion ports: RS232, RS485/422, MBUS,
ETHERNET, CNT, SWITCH, WIFI, WMBUS or SDH. Separation columns for mounting
expansion boards are included.
4

5. ROUTER DESIGN
5. Router design
5.1 Router versions
ER75i v2 router is supplied in the following versions:
Box SIM1 SIM2 I/O USB PORT1 PORT2 ETH
ER75i v2B Plastic     
ER75i v2B SL Metal     
ER75i v2F Plastic       
ER75i v2F SL Metal       
Table 1: Router versions
Figure 2: Front panel ER75i v2B
Figure 3: Front panel ER75i v2F
Figure 4: Front panel ER75i v2B SL
Figure 5: Front panel ER75i v2F SL
5

5. ROUTER DESIGN
5.2 Delivery identification
Trade name Type name Other
ER75i v2B ER-75i-v2 Basic version
ER75i v2B SL ER-75i-v2 Basic version in the metal box
ER75i v2F ER-75i-v2 Full version
ER75i v2F SL ER-75i-v2 Full version in the metal box
Table 2: Delivery identification
Figure 6: Label ER75i v2B
Figure 7: Label ER75i v2B SL
Figure 8: Label ER75i v2F
Figure 9: Label ER75i v2F SL
6

5. ROUTER DESIGN
5.3 Ordering codes
5.3.1 Basic version
Expansion port Ordering code
Version without expansion port ER75i v2B set
Version with Ethernet expansion port ER75i v2B ETH set
Version with RS232 expansion port ER75i v2B RS232 set
Version with RS485 expansion port ER75i v2B RS458 set
Version with MBUS expansion port ER75i v2B MBUS set
Version with CNT expansion port ER75i v2B CNT set
Table 3: Ordering codes of basic version
5.3.2 Full version
Expansion port Possible participation Ordering code
Version without expansion port ER75i v2F set
Version with Ethernet expansion port PORT1 ER75i v2F ETH set
Version with RS232 expansion port PORT1 a PORT2 ER75i v2F RS232 set
Version with RS485 expansion port PORT1 a PORT2 ER75i v2F RS458 set
Version with MBUS expansion port PORT1 a PORT2 ER75i v2F MBUS set
Version with CNT expansion port PORT1 ER75i v2F CNT set
Version with SWITCH expansion port PORT1 + PORT2 ER75i v2F SWITCH set
Version with WIFI expansion port PORT2 ER75i v2F WIFI set
Version with WMBUS expansion port PORT2 ER75i v2F WMBUS set
Version with SDH expansion port PORT2 ER75i v2F SDH set
Table 4: Ordering codes of full version
Second expansion port is written after first expansion port in the ordering code.
Example:
•Full version with Ethernet and RS232 port: ER75i v2F ETH RS232 set.
•Full version with Ethernet and RS232 port in metal cover:
ER75i v2F ETH RS232 SL set.
7

5. ROUTER DESIGN
5.4 Basic dimensions of plastic box
Figure 10: Basic dimensions of plastic box
5.5 Basic dimensions of metal box
Figure 11: Basic dimensions of metal box
8

5. ROUTER DESIGN
5.6 Mechanical dimensions and mounting recommendations
Mounting recommendations:
•possibility to be put on a work surface,
•DIN rail with clips CPD2 (ELPAC clip SL for metal version) are included.
For the most of applications with a built-in router in a switch board it is possible to recognize
two kinds of environments:
•no public and industry environment of low voltage with high interference,
•public environment of low voltage without high interference.
For both of these environments it is possible to mount router to a switch board, the following
there is no need to have examination immunity or issues in connection with EMC according to
EN 60439-1 ed.2:00 + A1:04.
For compliance of EN 60439-1 ed.2:00 + A1:04 specification it is necessary to observe next
assembly of the router to the switch – board:
•for whip antennas we recommend to observe a distance of 6 cm from cables and metal
surfaces on every side according to the next picture due to the elimination of interfer-
ence, while using an external antenna except for the switch-board it is necessary to fit a
lightening conductor,
•before mounting a router on sheet-steel we recommend using an external antenna,
Figure 12: Space around antennas Figure 13: Space around antennas for SL
9

5. ROUTER DESIGN
•For every cables we recommend to bind the bunch according to the following picture, we
recommend for this use:
–Length of the bunch (combination of power supply and data cables) can be max-
imum 1,5 m. If the length of data cables exceeds 1,5 m or in the event of, the
cable leads towards the switch – board. We recommend installing over – voltage
protectors (surge suppressors).
–With data cables they mustn’t carry cables with reticular tension ∼230 V/50 Hz.
–All signals to sensors must be twisted pairs.
Figure 14: Cable routing Figure 15: Cable routing for SL version
•Sufficient space must be left before individual connectors for handling of cables,
Figure 16: Space in front of connectors Figure 17: Space in front of connectors – SL
•For correct function of the router we recommend to use in the switch-board earth-bonding
distribution frame for grounding of power supply of router, data cables and antenna.
10

5. ROUTER DESIGN
5.7 Removing from the DIN rail
Default position of CPD2 holder (or CKD2 holder for SL version), which is used for mount-
ing the router on a DIN rail, is shown in the following figure:
Figure 18: Default position of DIN holder
For removing from the DIN rail it is necessary to lightly push upward the router so that the
top part of the CPD2 holder (or CKD2 for SL version) hitched to the DIN rail get out of this rail
and then fold out the top part of the router away from the DIN rail.
Figure 19: Removing from the DIN rail
11

5. ROUTER DESIGN
5.8 Description of the front panel
On the front panel is located:
Caption Connector Description
PWR 2-pin Connector for the power supply adapter.
ETH RJ45 Connector for connection into the local computer network.
PORT1 RJ45 Connector for expansion port RS232, RS458/422, MBUS,
ETHERNET, CNT or SWITCH.
PORT2 RJ45 Connector for expansion port RS232, RS485/422, MBUS,
SWITCH, WIFI, WMBUS or SDH (only FULL version).
ANT SMA Connector for main antenna.
USB USB-A Host Connector for connection of USB devices to the router. Sup-
ports devices with PL-2303 and FTDI USB/RS232 converters.
I/O 3-pin Connector for connection of the binary input and output.
SIM1 — Holder for the first SIM card.
SIM2 — Holder for the second SIM card (only FULL version).
Table 5: Front panel description
Figure 20: Front panel ER75i v2F
Figure 21: Front panel ER75i v2F SL
12

5. ROUTER DESIGN
5.8.1 Status indication
About router status inform eight LED indicators on the front panel and on every port are
two LED indicators, which inform about port status.
Caption Color State Description
PWR Green Blinking
On
Fast blinking
Router is ready
Starting of the router
Updating firmware
GSM Red Blinking Communication in progress on radio channel
PPP Yellow 1x flash per second
2x flash per second
3x flash per second
Signal strength is from –50 dBm to –69 dBm
Signal strength is from –70 dBm to –89 dBm or differ-
ence between neighbours cells is exactly 3 dBm
Signal strength is from –90 dBm to –113 dBm or differ-
ence between neighbours cells is smaller than 3 dBm
USR Yellow Function selected by user
OUT Green On Binary output active
IN Green On Binary input active
ETH Green On
Off
Selected 100 Mbit/s
Selected 10 Mbit/s
ETH Yellow On
Blinking
Off
The network cable is connected
Data transmission
The network cable is not connected
PORT Green Depends on the expansion port (see user’s guide of used port)
PORT Yellow Depends on the expansion port (see user’s guide of used port)
SIM1 Yellow On SIM card 1 is active
SIM2 Yellow On SIM card 2 is active
Table 6: Router status indication
State indication of PPP LED is updated every 10 seconds.
13

5. ROUTER DESIGN
5.8.2 Power connector PWR
Panel socket 2-pin.
Pin number Signal mark Description
1 VCC(+) Positive pole of DC supply voltage (+10 to +30 V DC)
2 GND(-) Negative pole of DC supply voltage
Table 7: Connection of power connector
Figure 22: Power connector
Power supply for router is required between +10 V to +30 V DC supply. Protection against
reversed polarity without signaling is built into the router.
The power consumption during receiving is 2 W. The peak power consumption during data
sending is 5,5 W. However, values of consumption can be increased, if some expansion port
is eqquipped. For correct operation it is necessary that the power source is able to supply a
peak current of 1 A.
Connector on the power cable connects into the power connector on the router head and
tightens locking screws (see figure below).
Figure 23: Connection of power supply connector
Circuit example:
Figure 24: Connection of power supply
The positive pole VCC is marked by a red socket on the power.
14
