Connect SmartHome CSH-SLRODCAM User manual

Manual
Wireless Outdoor Camera with Adjustable
Floodlight & Solar Panel
(CSH-SLRODCAM / LSH-SLRODCAM)
* Thanks for purchasing and using our product. Please read this manual
before using, and keep for future reference.
* Manual contents are subject to change without notice in accordance
with our policy of continuous product improvement.

1. Please consult below checklist for all the components.
Installation guide
Floodlight Camera Solar Panel User Manual Screw & Tools
（x2）

TABLE OF CONTENTS
What's in the box
Camera Diagram
Charging the Battery
Downloading the APP
Wi-Fi set up
Live View Interface
Running a test
Smart Playback and Multi-View Function
Menu settings
Frequently asked questions

Please check the box for each of the following items before installing
your camera:
1. WHAT'S IN THE BOX
2. CAMERA DIAGRAM
2 LEDS 1000LM
PIR Motion Sensor
LED Indicator
2MP Camera
Solar Panel Power Port
Microphone
3
2
1
4
56
9
8
SD Card Slot
9
7 12V 2A Port DC 5.5*2.1MM
10
Reset Button
On/Off Button
10
8
1
2
3
4
5
6
7
Floodlight Camera Solar Panel User Manual Screw & Tools
（x2）

1. Download and install the “Connect SmartHome or Laser SmartHome App by searching for it from the Google Play Store or
Apple App Store.
2. The App is also available by scanning the QR code below, using a QR code scanner in your smart phone.
3. CHARGING THE BATTERY
4. DOWNLOADING THE APP
1. The batteries inside the camera may not be fully charged. Please charge approx 8-10 hours using the Solar Panel before first use.
2. Install the Solar Panel in an area where you are able to get strong direct sunlight for most of the day.
3. The built-in rechargeable battery and solar panel can provide non-stop power once installed. You can also use a 12V 2A power
adapter (not included) plugged into (7).

5. WI-FI SET UP
Before you start the Wi-Fi configuration, please note below:
1. The camera only works on 2.4GHz Wi-Fi networks (no 5GHz support)
2. Press the ON/OFF button (8). The LED (1) will turn on and the Indicator Light (5) will start to Blink.
Note: If the Indicator Light does not blink press and hold the RESET button (10) for approx 5 seconds and the Indicator Light should blink RED.
6. RUNNING A TEST
After set up, tap on the live view window in the app for a test. Then take your Floodlight Camera outside to the installation spot and run a test
there. Make sure the installation spot is covered by a strong 2.4 GHz Wi-Fi signal.
Note: If the video quality from the Floodlight Camera outside is not as good as it was indoors, you may need to move your router closer to the
installation spot, or invest in a Wi-Fi extender.
TIP
If device
not found
please check
Only 2.4G Wi-Fi
networks are supported
Please aim this QR code at the Camera
approx 15-20cm away

2020-11:55:59
Floodlight Camera
90%
Cloud Storage Photo albumPlay back
Multi-View
5
Quit live view
Wi-Fi signal status
Battery status
Speak
Cloud Storage
On Screen Display
Listen
Full screen mode
Record on the phone
Photo Album
3
6
9
Setting menu
HD/SD switch
Screenshot button
Playback Recordings
Multi-View
Multiple cameras
need to be installed
4
1
7
10
2
5
8
11
5
7. LIVE VIEW INTERFACE

REPLAY
19:00 19:01 19:02 19:03 19:04
Floodlight Camera
8. SMART PLAYBACK AND
MULTI-VIEW FUNCTION
MON TUE WED THU FRI S AT
234567
910 11 12 13 14
16 17 18 19 20 21
23 24 25 26 27 28
SUN
1
8
15
22
29 30 31
Jul 2020
56
5
Time Line
Drag the time line to left or right to check the recorded video
- The grey bar means recorded video length
Date
Check motion detected video history by dates
Screenshot
Tap to capture a photo and save to Phone album
Record
Tap to record local video and save to Phone album
Multi-View
Up to 4 different cameras can be viewed at the same time

Back to Live View Interface Edit Device Name Device Basic Information
Automation Setting Basic function setting IR Night Vision Setting
Alarm Setting PIR Sensitivity Setting Power Management Setting
Storage Setting Cloud Storage Subscription
9. MENU SETTINGS
Basic Function Settings
Flip Screen
Time Watermark
Storage Settings
Total Capacity
Used
Remaining Capacity
STORAGE SETTINGS
PIR
1.Motion Detection Setting 3.SD Card Setting2. Basic Function
O
Low
High
STORAGE CAPACITY
Schedule
Format

For more
helpful guides
visit us at
LASER
www.youtube.com/LasercoAu
CONNECT
www.youtube.com/channel/UCCYzBiADapJN55Zzp3yfvLQ
WARRANTY
Our goods come with guarantees that cannot be excluded under the Australian Consumer Law. You are entitled to a replacement
or refund for a major failure and compensation for any other reasonably foreseeable loss or damage. You are also entitled to have
the goods repaired or replaced if the goods fail to be of acceptable quality and the failure does not amount to a major failure.
www.laserco.com.au www.connectsmarthome.com.au
1. The Device is not Connecting to App
Please check your Wifi username and password are correct and you are only using 2.4Ghz Wifi
connections as the 5Ghz band is not supported.
2. No Power When Using Solar Panel
Make sure the device has approx 30% power before using with Solar Panel. With strong direct
sunlight the Solar Panel will recharge the battery approx 5% every hour while also
powering the camera.
3. Micro SD Card is Not Recognised
Make sure the USB or Micro SD Card is 32gb or less. Check USB or Micro SD Card has been
formatted to the FAT32 or exFAT file system. If not please format on a Windows based computer.
4. What happens when the SD card is full?
The camera will automatically overwrite the oldest footage.
TROUBLESHOOTING
5. Why does the camera lose the Wi-Fi connection?
Please check the network connection. You may need to move the router closer or invest
in a Wi-Fi extender.
6. What’s the capacity of the Battery?
The camera has 4 x 18650 batteries with 12000mAh capacity.
7. What is the viewing angle of the camera?
The camera has a wide angle view of 120 degrees.
