CS800 Firmware Upgrade Guidelines
1 / 13
DMR Series
CS800 Firmware Upgrade Guidelines (S1.01.04 Main and R1.00.02 Front Panel)
NOTICE
One of the firmware updates in this document involves
connecting and updating the front panel of the CS800. While it is
not an overly complicated process, caution is required since the
main radio update will not work without the front panel update,
and missteps during the front panel update can render it
inoperable. We have attempted to provide clear, careful
instructions for users. Please read through the entire procedure
and if you are uncertain of any of these steps, call us prior to
beginning the update process. We are available for assistance
Monday through Friday, 8:30 –4:30 Pacific Time.

CS800 Firmware Upgrade Guidelines
2 / 13
DMR Series
CS800 Firmware Upgrade Guidelines (S1.01.04 Main and R1.00.02 Front Panel
Preface:
The CS800 has two MCUs, one in the main radio body and the other in the front panel, and for this version
of firmware both will need to be updated. Since the front panel makes use of a Prolific USB to Serial
connection and driver, it is important to verify that this connection can be made prior to updating the radio.
Please read through these instructions and familiarize yourself with the required procedure, programs, and
binary files to be uploaded.
Downloading the Programs to Perform the Update
Download the ZIP file. If you sucessufly downloaded the zip file, you should have the following
programs:
If you sucessfully unzipped the the file you should have the following:

CS800 Firmware Upgrade Guidelines
3 / 13
Prolific USB Driver Installation and Verification
1) NOTE: Some of the early batches of front panel programming cables for the CS800 can be damaged
by the high current of some motherboard or backplane USB ports, so to be cautious please use the
front USB port of a desktop or the USB port of a laptop.
2) Make sure the programming cable is not plugged into the computer at this time
3) Please install the USB driver by running ‘PL2303_Prolific_DriverInstaller_v1.8.0.exe’. To do this find
the program, highlight it with the left buttom on the mouse, and then click the left button on the mouse.
You should see the following:
4) Click on “Run as administrator.
5) If prompted by the software, allow it to uninstall previous versions of Prolific drivers to insure that the
cable will properly connect.

CS800 Firmware Upgrade Guidelines
4 / 13
Press Nexr and if you follow the instructions it should remove the old driver and install a new driver.
6) Please insert your RJ45 programming cable on the front USB connector of your desk computer or any
USB connector of your laptop for one or two minutes (to verify that the USB to UART conversion IC
runs correctly).
7) Click your computer’s ‘Start’ button, find ‘Computer’ and right click.

CS800 Firmware Upgrade Guidelines
5 / 13
8) Double Click Manage with the left button and you now get the following:
9) Double Click ‘Device Manager’, and you get:

CS800 Firmware Upgrade Guidelines
6 / 13
10) expand the ‘Ports (COM & LPT)’ menu, and find ‘Prolific-USB-to-Serial Comm Port (COM#)’. Make
a note of the COM port # as it will be needed later in the upgrade program.
Note in this computer it says COM3

CS800 Firmware Upgrade Guidelines
7 / 13
11) Right click ‘Prolific-USB-to-Serial Comm Port (COM#)’ and select ‘Properties’.
12) Select the ‘Port Settings’ tab and change the ‘Bits per second’ value to 19200. Click the ‘Driver’ tab
and verify that the version is 3.6.78.350. Click the OK button and close Device Manager.

CS800 Firmware Upgrade Guidelines
8 / 13

CS800 Firmware Upgrade Guidelines
9 / 13
13) If the driver version does not match the number above, click the ‘Update Driver’ button, the ‘Browse
my Computer’ selection, and ‘Let me pick from a list …’ selection.

CS800 Firmware Upgrade Guidelines
10 / 13
If 3.6.78.350 is available in the displayed list, highlight it and select ‘Next’. Clicking next will install

CS800 Firmware Upgrade Guidelines
11 / 13
the driver. If it is not available in the list, click ‘Cancel’ to return to the Device Manager screen, right
click on ‘Prolific-USB-to-Serial Comm Port (COM#)’ and select ‘Properties’ again, click the ‘Driver’
tab, ‘Update Driver’, and this time click ‘Search automatically for updated driver software’. Verify
that the proper driver is installed, confirm the COM port # and bits per second value, and exit Device
Manager. You can leave the front panel update cable plugged into the USB port for the update process,
or remove it if there is only one port available.
14) If the correct driver cannot be obtained, you should not proceed with the updates as there will be
control problems if the Main MCU is updated but the Front Panel MCU is not. Please call Connect
Systems for support to assist you with updating your CS800.
For the CS800 Main MCU
To begin, there is an important update to the bootloader software to provide differentiation between CS
radios to avoid the inadvertent loading of CS750 firmware into a CS800. Please start by upgrading the
bootloader to R2.02S using the FlashBurn1.10_CSI program. Once that is complete, you will use
FlashBurn2.00_CSI for the firmware and all future updates.
1) Connect your Mobile and PC with the DB15 programming cable. Run ‘Flashburn1.10_CSI.exe’, and
then press the ‘P1 and Power Key’ to power on the CS800. The LED should flash red and green and
the software should indicate that the device is connected. Load ‘CS800_Bootloader_R2.02S.bin’, and
then click the Flash button to start the update.
After completion, please power off the radio and then power on. When there are characters shown on
the front LCD, please power off the radio again. This process will backup the bootloader to its proper
memory address.

CS800 Firmware Upgrade Guidelines
12 / 13
2) Run ‘Flashburn2.00_CSI.exe’ and then press the ‘P1 and Power Key’ to power on the CS800 again.
Load ‘CS800_Host_S1.01.04_080315.bin’, and then click the Flash button. After completion, please
power off the radio and disconnect the DB15 cable. This completes the update to the main MCU.
For the CS800 Front Panel MCU
1) Please insert your RJ45 programming cable on the front USB connector of your desk computer or any
USB connector of your laptop for one or two minutes (to verify that the USB to UART conversion IC
runs correctly).
2) Press and hold P7 (do not spin) and then press ‘Power’, the RED LED will be lit and the front MCU
will enter ‘Program Mode’
3) Run ‘MobileFrontPanelUpgradeTool R1.0.exe’ and set the correct serial port and baud rate (based on
the information you obtained in step 5 of the driver installation procedure. Click the ‘…’ button in the
‘MCU Rewrite’ field and load ‘CS800_FrontPanel_R1.00.02.bin’. Click the ‘Flash’ button in the same
field to run the update. Please keep the radio and cable on a firm, stable surface to avoid inadvertant
disconnections during the update.

CS800 Firmware Upgrade Guidelines
13 / 13
4) After the ‘Upgrade Success’ prompt from the PC, you can press the POWER key to power off the
radio, disconnect the cables, and then power on it to check. Please note you need to upgrade the
mobile MCU before you can operate the front panel keys, as there has been a change to the protocol of
the key-values.
