Connect PowerNet VT Technical Document

Supported Equipment Manual
for the Dolphin 9900 Mobile Computer Manufactured by Honeywell

Copyright ©1996 - 2009 by Connect, Inc.
All rights reserved. This document may not be reproduced in full or in part, in any form,
without prior written permission of Connect Inc., 1701 Quincy Avenue, Suites 5 & 6,
Naperville, IL 60540.
Connect, Inc. makes no representation or warranties with respect to the contents
of this document and specifically disclaims any implied warranties of
merchantability or fitness for any particular purpose. Further, Connect, Inc.
reserves the right to revise this publication and to make changes to it from time to
time without obligation to notify any person or organization of such revision or
changes.
Trademarks
PowerNet OpenAir™, OpenAir Linux™, OpenAir Windows™, OpenAir 400™,
PowerNet Twin Client™, and PowerNet AirLinc™ are trademarks of Connect,
Inc.
Other product names mentioned in this manual may be trademarks or registered
trademarks of their respective companies and are hereby acknowledged.
Production
This manual was written, edited, and produced by:
Connect, Inc.
931 W. 75th St.,
Suite 137-192
Naperville, IL 60565
www.connectrf.com
Printed in the U.S.A.
Please let us know about any errors in this document at:
http://12.235.112.67/isoxpert/calltrak.nsf/WebTracking?OpenForm

Table of Contents
Chapter 1 • Introduction..........................................................................1
Descriptions 1
Picture 1
Setup Requirements 1
Accessories 2
Synchronization Tools 2
Installation 2
Release Notes 2
Chapter 2 • Keypad Configuration.........................................................1
35-Key 1
43-Key 6
56-Key 13
Supported Equipment Manual • January, 2009 iii

Chapter 1 • Introduction
Descriptions
The Dolphin 9900 mobile computer is equipped with all the features needed for mobile
applications, including the Intel®X-Scale processor and the Pocket PC, Windows
Mobile, or Windows Mobile 2nd Edition operating system platform, lithium-ion battery
technology, and WLAN, WWAN and/or WPAN support.
This wireless mobile computer has a lightweight and ergonomic design, a large ¼ VGA
display, and multiple keyboard options. The Dolphin 9900 is constructed to withstand
harsh environments and rough treatment.
For more information, visit: http://www.handheld.com
Setup Requirements
Installation of PowerNet Twin Client requires, at a minimum, the following:
•A Pentium-class processor
•32 MB of RAM
•10 MB of free hard disk space available
•for the 7400: Microsoft Windows Pocket PC or Windows CE
•for the 9900: Microsoft Windows Pocket PC or Windows Mobile
Supported Equipment Manual
• January, 2009
1

Introduction
Accessories
The following accessories are available to use with the Dolphin terminals:
•Dolphin HomeBaseTM: Dolphin terminal charging andcommunication station,
includes power adapter
•Dolphin Quad Battery Charger: Charges four batteries in under three hours and
conditions in under eight hours
•Dolphin HomeBaseTM Power Adapter: Replacement power adapter for Dolphin
HomeBaseTM Use only power adapters approved for use with Honeywell. Failure to
do so may result in improper operation or damage to the unit.
•NiMH Battery Pack:Nickel Metal Hydride (NiMH) 2700mAh rechargeable
battery for the Dolphin
•RS-232 Serial Cable: Allows the Dolphin to connect to other computer systems
for file transfer or to connect the Dolphin terminal using the terminal’s serial RS-232
interface
Synchronization Tools
ActiveSync, version 3.1 or later, is required for desktop synchronization and
communication. ActiveSync is freely downloadable from the Microsoft®web site
at http://www.microsoft.com/windowsmobile/downloads/default.mspx.
Installation
Refer to the Honeywell Twin Client V8 Reference for installation and configuration
instructions.
Release Notes
None.
Supported Equipment Manual •April, 2008
2

Release Notes
This page is intentionally blank.
Supported Equipment Manual • January, 2009 3

Chapter 2 • Keypad Configuration
35-Key
The 35-key diagrams begin on the following page.
Supported Equipment Manual
• January, 2009
1

Keypad ConfigurationKeypad Configuration
Supported Equipment Manual • January, 2009
2
Supported Equipment Manual • January, 2009
2

Supported Equipment Manual • January, 2009
3
Supported Equipment Manual • January, 2009
3

Keypad ConfigurationKeypad Configuration
Supported Equipment Manual • January, 2009
4
Supported Equipment Manual • January, 2009
4

35-Key Keypad Table
Key VT 3270 5250
a <Alpha><2> <Alpha><2> <Alpha><2>
b <Alpha><2><2> <Alpha><2><2> <Alpha><2><2>
c <Alpha><2><2><2> <Alpha><2><2><2> <Alpha><2><2><2>
d <Alpha><3> <Alpha><3> <Alpha><3>
e <Alpha><3><3> <Alpha><3><3> <Alpha><3><3>
f <Alpha><3><3><3> <Alpha><3><3><3> <Alpha><3><3><3>
g <Alpha><4> <Alpha><4> <Alpha><4>
h <Alpha><4><4> <Alpha><4><4> <Alpha><4><4>
i <Alpha><4><4><4> <Alpha><4><4><4> <Alpha><4><4><4>
j <Alpha><5> <Alpha><5> <Alpha><5>
k <Alpha><5><5> <Alpha><5><5> <Alpha><5><5>
l <Alpha><5><5><5> <Alpha><5><5><5> <Alpha><5><5><5>
m <Alpha><6> <Alpha><6> <Alpha><6>
n <Alpha><6><6> <Alpha><6><6> <Alpha><6><6>
o <Alpha><6><6><6> <Alpha><6><6><6> <Alpha><6><6><6>
p <Alpha><7> <Alpha><7> <Alpha><7>
q <Alpha><7><7> <Alpha><7><7> <Alpha><7><7>
r <Alpha><7><7><7> <Alpha><7><7><7> <Alpha><7><7><7>
s <Alpha><7><7><7><7> <Alpha><7><7><7><7> <Alpha><7><7><7><7>
t <Alpha><8> <Alpha><8> <Alpha><8>
u <Alpha><8><8> <Alpha><8><8> <Alpha><8><8>
v <Alpha><8><8><8> <Alpha><8><8><8> <Alpha><8><8><8>
w <Alpha><9> <Alpha><9> <Alpha><9>
x <Alpha><9><9> <Alpha><9><9> <Alpha><9><9>
y <Alpha><9><9><9> <Alpha><9><9><9> <Alpha><9><9><9>
z <Alpha><9><9><9><9> <Alpha><9><9><9><9> <Alpha><9><9><9><9>
A <Sft><Alpha><2> <Sft><Alpha><2> <Sft><Alpha><2>
B <Sft><Alpha><2><2> <Sft><Alpha><2><2> <Sft><Alpha><2><2>
C <Sft><Alpha><2><2><2> <Sft><Alpha><2><2><2> <Sft><Alpha><2><2><2>
D <Sft><Alpha><3> <Sft><Alpha><3> <Sft><Alpha><3>
E <Sft><Alpha><3><3> <Sft><Alpha><3><3> <Sft><Alpha><3><3>
F <Sft><Alpha><3><3><3> <Sft><Alpha><3><3><3> <Sft><Alpha><3><3><3>
G <Sft><Alpha><4> <Sft><Alpha><4> <Sft><Alpha><4>
H <Sft><Alpha><4><4> <Sft><Alpha><4><4> <Sft><Alpha><4><4>
I <Sft><Alpha><4><4><4> <Sft><Alpha><4><4><4> <Sft><Alpha><4><4><4>
J <Sft><Alpha><5> <Sft><Alpha><5> <Sft><Alpha><5>
K <Sft><Alpha><5><5> <Sft><Alpha><5><5> <Sft><Alpha><5><5>
L <Sft><Alpha><5><5><5> <Sft><Alpha><5><5><5> <Sft><Alpha><5><5><5>
M <Sft><Alpha><6> <Sft><Alpha><6> <Sft><Alpha><6>
N <Sft><Alpha><6><6> <Sft><Alpha><6><6> <Sft><Alpha><6><6>
O <Sft><Alpha><6><6><6> <Sft><Alpha><6><6><6> <Sft><Alpha><6><6><6>
P <Sft><Alpha><7> <Sft><Alpha><7> <Sft><Alpha><7>
Q <Sft><Alpha><7><7> <Sft><Alpha><7><7> <Sft><Alpha><7><7>
R <Sft><Alpha><7><7><7> <Sft><Alpha><7><7><7> <Sft><Alpha><7><7><7>
S <Sft><Alpha><7><7><7><7 <Sft><Alpha><7><7><7><7 <Sft><Alpha><7><7><7><7
T <Sft><Alpha><8> <Sft><Alpha><8> <Sft><Alpha><8>
U <Sft><Alpha><8><8> <Sft><Alpha><8><8> <Sft><8><Alpha><8>
V <Sft><Alpha><8><8><8> <Sft><Alpha><8><8><8> <Sft><Alpha><8><8><8>
W <Sft><Alpha><9> <Sft><Alpha><9> <Sft><Alpha><9>
X <Sft><Alpha><9><9> <Sft><Alpha><9><9> <Sft><Alpha><9><9>
Y <Sft><Alpha><9><9><9> <Sft><Alpha><9><9><9> <Sft><Alpha><9><9><9>
Z <Sft><Alpha><9><9><9><9 <Sft><Alpha><9><9><9><9 <Sft><Alpha><9><9><9><9
/ forward slash <Blue><F1> <Blue><F1> <Blue><F1>
* asterisk <Blue><F2> <Blue><F2> <Blue><F2>
_ underscore <Sft><F3> <Sft><F3> <Sft><F3>
+ addition sign <Sft><F2> <Sft><F2> <Sft><F2>
- dash <Blue><F3> <Blue><F3> <Blue><F3>
: colon <Blue><F4> <Blue><F4> <Blue><F4>
; semicolon <Red><Blue><F2> <Red><Blue><F2> <Red><Blue><F2>
= equal sign <Sft><F4> <Sft><F4> <Sft><F4>
\ backward slash <Blue><Comma> --- ---
Supported Equipment Manual • January, 2009
5

Keypad Configuration
‘ apostrophe <Red><Blue><F1> <Red><Blue><F1> <Red><Blue><F1>
“ quote <Red><F1> <Red><F1> <Red><F1>
! exclamation <Red><Comma> <Red><Comma> <Red><Commal>
? question mark <Red><F2> <Red><F2> <Red><F2>
< less than sign <Sft><0> <Sft><0> <Sft><0>
> greater than sign <Sft><SP> <Sft><SP> <Sft><SP>
[ left bracket <Red><Blue><F3> <Red><Blue><F3> <Red><Blue><F3>
] right bracket <Red><Blue><F4> <Red><Blue><F4> <Red><Blue><F4>
{ left brace <Red><F3> <Red><F3> <Red><F3>
} right brace <Red><F4> <Red><F4> <Red><F4>
( left parenthesis <Sft><F1> <Sft><F1> <Sft><F1>
) right parenthesis <Sft><BKSP> <Sft><BKSP> <Sft><BKSP>
@ at sign <Red><Blue><5> <Red><Blue><5> <Red><Blue><5>
# pound <Red><Blue><SP> <Red><Blue><SP> <Red><Blue><SP>
$ dollar <Blue><SP> <Blue><SP> <Blue><SP>
% percent <Red><BKSP> <Red><BKSP> <Red><BKSP>
^ carat <Sft><period> <Sft><period> <Sft><period>
& ampersand <Red><Blue><0> <Red><Blue><0> <Red><Blue><0>
` grave accent <Red><Blue><BKSP> <Red><Blue><BKSP> <Red><Blue><BKSP>
~ tilde <Blue><F3> <Blue><F3> <Blue><SP>
| vertical bar <Red><SP> <Red><SP> <Red><F5>
. period <period> <period> <period>
, comma <comma> <comma> <comma>
1 <1> <1> <1>
2 <2> <2> <2>
3 <3> <3> <3>
4 <4> <4> <4>
5 <5> <5> <5>
6 <6> <6> <6>
7 <7> <7> <7>
8 <8> <8> <8>
9 <9> <9> <9>
0 <0> <0> <0>
F1 <Red><1> <Red><1> <Red><1>
F2 <Red><2> <Red><2> <Red><2>
F3 <Red><3> <Red><3> <Red><3>
F4 <Red><4> <Red><4> <Red><4>
F5 <Red><5> <Red><5> <Red><5>
F6 <Red><6> <Red><6> <Red><6>
F7 <Red><7> <Red><7> <Red><7>
F8 <Red><8> <Red><8> <Red><8>
F9 <Red><9> <Red><9> <Red><9>
F10 <Red><0> <Red><0> <Red><0>
F11 <Blue><1> <Blue><1> <Blue><1>
F12 <Blue><2> <Blue><2> <Blue><2>
F13 <Blue><3> <Blue><3> <Blue><3>
F14 <Blue><4> <Blue><4> <Blue><4>
F15 <Blue><5> <Blue><5> <Blue><5>
F16 <Blue><6> <Blue><6> <Blue><6>
F17 <Blue><7> <Blue><7> <Blue><7>
F18 <Blue><8> <Blue><8 > <Blue><8>
F19 <Blue><9> <Blue><9> <Blue><9>
F20 <Blue><0> <Blue><0> <Blue><0>
F21 --- <Red><Blue><1> <Red><Blue><1>
F22 --- <Red><Blue><2> <Red><Blue><2>
F23 --- <Red><Blue><3> <Red><Blue><3>
F24 --- <Red><Blue><4> <Red><Blue><4>
Shift <Sft> <Sft> <Sft>
Esc <Esc> <Esc> <Esc>
Alpha <Alpha> <Alpha> <Alpha>
Alt <Alt> <Alt> <Alt>
Red <Red> <Red> <Red>
Blue <Blue> <Blue> <Blue>
Ctrl <Ctrl> <Ctrl> <Ctrl>
Tab <Tab> <Tab> <Tab>
Enter <Ent> <Ent> <Ent>
Sp <Sp> <Sp> <Sp>
Supported Equipment Manual • January, 2009
6

Light <Light> <Light> <Light>
Del <Del> <Del> <Del>
Backspace <Bksp> <Bksp> <Bksp>
On • Scan <On • Scan> <On • Scan> <On • Scan>
F1 <F1> <F1> <F1>
F2 <F2> <F2> <F2>
F3 <F3> <F3> <F3>
F4 <F4> <F4> <F4>
F5 <F5> <F5> <F5>
F6 <F6> <F6> <F6>
Up <▲> <▲> <▲>
Down <▼> <▼> <▼>
Left <◄> <◄> <◄>
Right <►> <►> <►>
Attention --- <Red><Ent> <Red><Ent>
Backtab <Blue><BKSP> <Blue><BKSP> <Blue><BKSP>
Clear --- <Blue><Esc> <Blue><Esc>
Contrast+ <Red><Tab> <Red><Tab> <Red><Tab>
Contrast- <Red><Esc> <Red><Esc> <Red><Esc>
EOF --- <Blue><Ent> ---
Erinp --- <Red><Blue><Ent> <Red><Blue><Ent>
ErEOF --- <Blue><Del> <Blue><Del>
Field exit --- --- <Blue><Ent>
FM --- <Red><Blue><8> <Red><Blue><8>
Home --- <Red><Blue><9> <Red><Blue><9>
Ins --- <Blue><Tab> <Blue><Tab>
Page up <Red><▲> <Red><▲> <Red><▲>
Page down <Red><▼> <Red><▼> <Red><▼>
Reset --- <Red><Blue><7> <Red><Blue><7>
Start <Blue><Bksp> <Blue><Bksp> <Blue><Bksp>
Sys req --- <Red><Blue><6> <Red><Blue><6>
Vol+ <Blue><▲> <Blue><▲> <Blue><▲>
Vol- <Blue><▼> <Blue><▼> <Blue><▼>
Supported Equipment Manual • January, 2009
7

Keypad Configuration
43-Key
The 43-key diagrams begin on the following page.
Supported Equipment Manual • January, 2009
8

Supported Equipment Manual • January, 2009
9
vt emulation
Supported Equipment Manual • January, 2009
9

Keypad Configuration
3270 emulation
Supported Equipment Manual • January, 2009
10

5250 emulation
Supported Equipment Manual • January, 2009
11

Keypad Configuration
43-key Keypad Table
KEY VT 3270 5250
a <a> <a> <a>
b <b> <b> <b>
c <c> <c> <c>
d <d> <d> <d>
e <e> <e> <e>
f <f> <f> <f>
g <g> <g> <g>
h <h> <h> <h>
i <i> <i> <i>
j <j> <j> <j>
k <k> <k> <k>
l <l> <l> <l>
m <m> <m> <m>
n <n> <n> <n>
o <o> <o> <o>
p <p> <p> <p>
q <q> <q> <q>
r <r> <r> <r>
s <s> <s> <s>
t <t> <t> <t>
u <u> <u> <u>
v <v> <v> <v>
w <w> <w> <w>
x <x> <x> <x>
y <y> <y> <y>
z <z> <z> <z>
A <Sft><a> <Sft><a> <Sft><a>
B <Sft><b> <Sft><b> <Sft><b>
C <Sft><c> <Sft><c> <Sft><c>
D <Sft><d> <Sft><d> <Sft><d>
E <Sft><e> <Sft><e> <Sft><e>
F <Sft><f> <Sft><f> <Sft><f>
G <Sft><g> <Sft><g> <Sft><g>
H <Sft><h> <Sft><h> <Sft><h>
I <Sft><i> <Sft><i> <Sft><i>
J <Sft><j> <Sft><j> <Sft><j>
K <Sft><k> <Sft><k> <Sft><k>
L <Sft><l> <Sft><l> <Sft><l>
M <Sft><m> <Sft><m> <Sft><m>
N <Sft><n> <Sft><n> <Sft><n>
O <Sft><o> <Sft><o> <Sft><o>
P <Sft><p> <Sft><p> <Sft><p>
Q <Sft><q> <Sft><q> <Sft><q>
R <Sft><r> <Sft><r> <Sft><r>
S <Sft><s> <Sft><s> <Sft><s>
T <Sft><t> <Sft><t> <Sft><t>
U <Sft><u> <Sft><u> <Sft><u>
V <Sft><v> <Sft><v> <Sft><v>
W <Sft><w> <Sft><w> <Sft><w>
X <Sft><x> <Sft><x> <Sft><x>
Y <Sft><y> <Sft><y> <Sft><y>
Z <Sft><z> <Sft><z> <Sft><z>
/ forward slash <Red><p> <Red><p> <Red><p>
* asterisk <Red><Blue><h> <Red><Blue><h> <Red><Blue><h>
_ underscore <Blue><t> <Blue><t> <Blue><t>
+ addition sign <Blue><s> <Blue><s> <Blue><s>
- dash <Blue><w> <Blue><w> <Blue><w>
: colon <Red><s> <Red><s> <Red><s>
; semicolon <Red><Blue><u> <Red><Blue><u> <Red><Blue><u>
= equal sign <Red><t> <Red><t> <Red><t>
Supported Equipment Manual • January, 2009
12
