Conservator NTX62 User manual

Dryer Owner’s Manual
Contents
Safety Information.................2
Using the Dryer ...................4
Controls ........................5
Settings ........................5
Loading..........................6
Care and Cleaning.................7
Venting ..........................8
Reversing the door ................9
Troubleshooting Tips .............10
Limited Warranty .................13
Consumer Support ...............14
Model: NTX62 English/Español
Write the model and serial numbers here:
Model # _______________________________
Serial # _______________________________
They are on the label on the front of the dryer
behind the door.
05-22 GEA
49-3000332
Rev 0

249-3000332 Rev 0
WARNING
To reduce the risk of fire, explosion, electric shock, or injury to persons when using your
appliance, follow basic precautions, including the following:
• Read all instructions before using the appliance.
• DO NOT dry articles that have been previously cleaned in, washed in, soaked in, or spotted with gasoline,
dry-cleaning solvents, or other flammable or explosive substances, as they give off vapors that could ignite
or explode.
• DO NOT place items exposed to cooking oils in your dryer. Items contaminated with cooking oils may
contribute to a chemical reaction that could cause a load to catch fire. To reduce the risk of fire due to
contaminated loads, the final part of the tumble dryer cycle occurs without heat (cool down period). Avoid
stopping a tumble dryer before the end of the drying cycle unless all items are quickly removed and spread
out so that the heat is dissipated.
• DO NOT allow children to play on or in this appliance. Close supervision of children is necessary when this
appliance is used near children.
• Before the appliance is removed from service or discarded, remove the door to the drying compartment.
• DO NOT reach into the appliance if the drum is moving.
• DO NOT install or store this appliance where it will be exposed to the weather.
• DO NOT tamper with controls.
• DO NOT climb or stand on this unit.
• DO NOT repair or replace any part of this appliance or attempt any servicing unless specifically recommended
in the user-maintenance instructions or in published user-repair instructions that you understand and have the
skills to carry out.
• Follow all fabric care instructions and warnings to prevent melting of garments or damage to the appliance.
• DO NOT use fabric softeners or products to eliminate static unless recommended by the manufacturer of the
fabric softener or product.
•DO NOT dry articles containing foam rubber or similarly textured rubber-like materials.
• Clean lint screen before or after each load.
• DO NOT operate the dryer without the lint filter in place.
• DO NOT store combustible materials, gasoline or other flammable liquids near the dryer. Keep area around
the exhaust opening and adjacent surrounding areas free from the accumulation of lint, dust and dirt.
• The interior of the appliance and exhaust duct should be cleaned periodically by qualified service personnel.
• Unplug the appliance or turn off the circuit breaker before servicing. Pressing the Power or Start/Pause
button DOES NOT disconnect power.
• DO NOT operate this appliance if it is damaged, malfunctioning, partially disassembled, or has missing or
broken parts, including a damaged cord or plug.
• DO NOT spray any type of aerosol into, on or near dryer at any time. DO NOT use any type of spray cleaner
when cleaning dryer interior. Hazardous fumes or electrical shock could occur.
• See “ELECTRICAL CONNECTION” located in the Installation Instructions for grounding instructions.
READ AND SAVE THESE INSTRUCTIONS
Proper Disposal of your Appliance
■
Dispose of or recycle your appliance in accordance with Federal and Local Regulations. Contact your local
authorities for the environmentally safe disposal or recycling of your appliance.
SAFETY INFORMATION
IMPORTANT SAFETY INFORMATION
READ ALL INSTRUCTIONS BEFORE USING THE APPLIANCE

49-3000332 Rev 0 3
Failure to follow safety warnings exactly could result in serious injury, death, or property
damage.
- DO NOT store or use gasoline or other flammable vapors and liquids in the vicinity of
this or any other appliance.
- WHAT TO DO IF YOU SMELL GAS:
• DO NOT try to light any appliance.
• DO NOT touch any electrical switch; DO NOT use any phone in your building.
• Clear the room, building, or area of any occupants.
• Immediately call your gas supplier from a neighbor’s phone. Follow the gas supplier’s
instructions.
•If you cannot reach your gas supplier, call the fire department.
- Installation and service must be performed by a qualified installer, service agency, or
the gas supplier.
ADDITIONAL GAS DRYER WARNINGS
- Fire or Explosion Hazard
WARNING
SAFETY INFORMATION
READ AND SAVE THESE INSTRUCTIONS
IMPORTANT SAFETY INFORMATION
READ ALL INSTRUCTIONS BEFORE USING THE APPLIANCE

449-3000332 Rev 0
Throughout this manual, features and appearance may vary from your model.
Step 3
Step 1
• Press the Start button.
• Clean lint filter
• Loosely add items.
• Close door.
NOTE: Dryer will not
start with door open.
To reduce the risk of fire, electric shock, or injury to persons, read the IMPORTANT SAFETY
INFORMATION before operating this appliance.
WARNING
• Keep flammable materials and vapors, such as
gasoline, away from dryer.
• DO NOT dry anything that has ever had anything
flammable on it (even after washing).
• No washer can completely remove oil.
• DO NOT dry anything that has ever had any type of oil
on it (including cooking oils).
• Items containing foam, rubber, or plastic must be dried
on a clothesline.
• Follow all fabric care instructions and warnings
to prevent melting of garments or damage to the
appliance.
• Failure to do so can result in death, explosion, or fire.
WARNING - Fire Hazard
Start
Getting started
USING THE DRYER
Step 2
• Select a dry cycle. (Defaults are set for each dry
cycle. These default settings can be changed.
See the cycle descriptions for more information.)
Off
Off
Off
Off
More Dry
10
20
30
40
50 60 70 80
More Dry
More Dry
Normal
Less Dry
Less Dry
Less Dry
Cooling
Cooling
Cooling
Cottons Perm. Press
DelicatesTime Dry
Minutes

49-3000332 Rev 0 5
Off
Off
Off
Off
More Dry
10
20
30
40
50 60 70 80
More Dry
More Dry
Normal
Less Dry
Less Dry
Less Dry
Cooling
Cooling
Cooling
Cottons Perm. Press
DelicatesTime Dry
Minutes
Temperature
High
Medium
Low
Start
CA B
Model: NTX62
USING THE DRYER
Getting started
CStart
Press Start to begin the cycle.
NOTE: The door must be closed for the dryer to start the cycle.
NOTE: Opening the door during operation will pause the dryer.
ADrying
Cycles
Sensor cycles automatically determine fabric dryness.
Timed cycles run for the selected time.
Cottons For cottons and most linens.
Perm. Press For wrinkle-free, permanent press, delicate items and knits.
Delicates For delicate items, special-care fabrics and knits.
Time Dry Set the Cycle Selector at the desired drying time.
Settings
BTemperature
High For regular to heavy cottons.
Medium For synthetics, blends, delicates and items labeled permanent press.
Low For delicates, synthetics and items labeled tumble dry low.

649-3000332 Rev 0
Always follow fabric manufacturer’s care label when laundering.
As a general rule, if clothes are sorted properly for the washer, they are sorted properly for the dryer. Try also to
sort items according to size. For example, do not dry a sheet with socks or other small items.
Do not add fabric softener sheets once the load has become warm. They may cause fabric softener stains. Bounce®
Fabric Conditioner Dryer Sheets have been approved for use in this dryer when used in accordance with the
manufacturer’s instructions.
Do not overload. This wastes energy and causes wrinkling.
• Keep flammable materials and vapors, such as
gasoline, away from dryer.
• DO NOT dry anything that has ever had anything
flammable on it (even after washing).
• No washer can completely remove oil.
• DO NOT dry anything that has ever had any type of oil
on it (including cooking oils).
• Items containing foam, rubber, or plastic must be dried
on a clothesline.
• Failure to do so can result in death, explosion, or fire.
Sorting and Loading Hints
- Fire Hazard
WARNING
Drying Rack (on some models)
A handy drying rack may be used for drying delicate items such as
washable sweaters.
To install the drying rack:
1Lift the lint filter slightly. (Do not remove the lint filter completely).
2Place the rack in the dryer and lower its front legs and hook them
in the slots.
3Press the rack down flat and lower the lint filter back down in
position.
NOTES:
• The drying rack must be used with the Time Dry cycle. Use with
sensor cycles may result in damp items or extended cycle times.
• Do not use this drying rack when there are other clothes in the dryer.
• If your model did not come with a drying rack, order WE01X25160
on-line at GEApplianceparts.com, 24 hours a day or by phone at
877.959.8688 during normal business hours.
Lift filter and hook
front rack legs in slots
Loading
LOADING

49-3000332 Rev 0 7
Lint Filter
Clean the lint filter before each use.
Remove by pulling straight up. Run your fingers across the filter. A waxy buildup may
form on the lint filter from using dryer added fabric softener sheets.
To remove this buildup, wash the lint screen in warm, soapy water. Dry thoroughly
and replace.
Vacuum the lint from the dryer lint filter area if you notice a change in dryer
performance.
NEVER OPERATE THE DRYER WITHOUT ITS FILTER IN PLACE.
CARE AND CLEANING
Care and cleaning
Exterior
Wipe or dust any spills or washing compounds with a damp cloth. Dryer control panel and finishes may be damaged
by some laundry pretreatment soil and stain remover products. Apply these products away from the dryer. The fabric
may then be washed and dried normally. Damage to your dryer caused by these products is not covered by your
warranty.
Stainless Steel
To clean stainless steel surfaces use a damp cloth with a mild, non-abrasive cleaner suitable for stainless steel
surfaces. Remove the cleaner residue and then dry with a clean cloth.
The stainless steel used to make the dryer drum provides the highest reliability available in a GE Appliances dryer.
If the dryer drum should be scratched or dented during normal use, the drum will not rust or corrode. These surface
blemishes will not affect the function or durability of the drum.
Interior and Duct
The interior of the appliance and exhaust duct should be cleaned once a year by qualified service personnel.
The Exhaust Duct: Inspect and clean the exhaust ducting at least once a year to prevent clogging. A partially clogged
exhaust can lengthen the drying time.
Follow these steps:
1Turn off electrical supply by disconnecting the plug from the wall socket.
2Disconnect the duct from the dryer.
3Vacuum the duct with the hose attachment and reconnect the duct.
The Exhaust Hood: Check with a mirror that the inside flaps of the hood move freely when operating. Make sure that there
is no wildlife (birds, insects, etc.) nesting inside the duct or hood.
Drum Light
The drum light is an LED light. Replacement must be done by a qualified technician.

849-3000332 Rev 0
VENTING
Venting
Venting the Dryer
For the best drying performance, the dryer needs to be properly vented. The dryer will use more energy and run longer if it is
not vented to the specifications below. Carefully follow the details on Exhausting in the Installation Instructions.
nUse only rigid metal 4” diameter ductwork inside the dryer cabinet. Use only rigid metal or UL listed flexible metal 4”
diameter ductwork for exhausting to the outside.
nDo not use plastic or other combustible ductwork.
nUse the shortest length possible.
nDo not crush or collapse.
nAvoid resting the duct on sharp objects.
nVenting must conform to local building codes.
This dryer MUST be exhausted to the outdoors.
Use only 4” rigid metal ducting for the home exhaust duct.
Use only 4” rigid metal or UL-listed dryer transition duct to connect the dryer to the home exhaust.
DO NOT use a plastic vent.
DO NOT exhaust into a chimney, kitchen exhaust, gas vent, wall, ceiling, attic, crawl space, or
concealed space of a building.
DO NOT install a screen in or over the exhaust duct.
DO NOT install a booster fan in the exhaust duct.
DO NOT use duct longer than specified in the exhaust length table.
Failure to follow these instructions can result in death or fire.
WARNING - Fire Hazard
Correct
Venting
Incorrect
Venting

49-3000332 Rev 0 9
REVERSING THE DOOR
Reversing the door
Tools needed:
nStandard #2 nTape-tipped
nPhillips screwdriver nputty knife
1Open the door and remove the filler plugs opposite the
hinges. With the door completely open, remove the
bottom screw from each hinge on the dryer face. Insert
these screws about half way into the TOP holes, for each
hinge, on the opposite side (where you removed the filler
plugs). Apply firm pressure to get the screw started in
new holes.
2Loosen top screw from each hinge on the dryer face half
way. With one hand holding the top of the door and the
other hand holding the bottom, remove the door from the
dryer by lifting it UP and OUT.
3Remove the blind plate from the hinge side of the dryer
by removing its two screws. Remove the strike plate
from the opposite side of the dryer by removing its two
screws. Reinstall the plates, on the opposite sides,
using two screws in each plate.
4Rotate the door 180°. Insert it on the opposite side of the
opening by moving the door IN and DOWN until the top
hinge and the bottom hinge are resting on the top screws
inserted in step 1.
5Remove the remaining screws from the side of the opening
from which the door was removed. With these screws,
secure each hinge at the bottom. Tighten the two top
screws of each hinge. Reinsert the plastic plugs on the
side from which the door was removed.
INSTALL AND TIGHTEN
BOTTOM SCREWS AND
TIGHTEN TOP SCREWS INSERT PLUGS
INTO HOLES ON
OPPOSITE SIDE
REMOVE BOTTOM SCREW FROM
EACH HINGE AND INSTALL HALF
WAY INTO EACH TOP OF OPPOSITE
HINGE HOLES
REMOVE 4 PLUGS AND
KEEP FOR INSERTION
INTO THE
OPPOSITE
SIDE
LOOSEN EACH TOP
HINGE SCREW HALF
WAY AND LIFT THE
DOOR UP AND OFF
FRONT PANEL
SWITCH
STRIKE
PLATE
BLIND
PLATE
ROTATE DOOR 180º AND
HANG IT ON TOP HINGE
SCREWS

10 49-3000332 Rev 0
TROUBLESHOOTING TIPS
Troubleshooting Tips... Before you call for service
Problem Possible Cause What To Do
Dryer shakes or
makes noise Some shaking/noise is normal. Dryer may be sitting unevenly. Move dryer to an even floor space, or adjust leveling legs as necessary until even.
Clothes take
too long to dry Improper or obstructed ducting Check the Installation Instructions to make sure the dryer venting is correct.
Make sure ducting is clean, free of kinks and unobstructed.
Check to see if outside wall damper operates easily.
Improper sorting Separate heavy items from lightweight items (generally, a
well-sorted washer load is a well-sorted dryer load).
Large loads of heavy fabrics
(like beach towels) Large, heavy fabrics contain more moisture and take longer to dry. Separate large, heavy fabrics into smaller loads to speed drying
time.
Controls improperly set Match control settings to the load you are drying.
Lint filter is full Clean lint filter before every load.
Blown fuses or tripped
circuit breaker Replace fuses or reset circuit breakers. Since most dryers use 2 fuses/breakers, make sure both are operating.
Overloading/combining loads Do not put more than one washer load in the dryer at a time.
Underloading If you are drying only one or two items, add a few items to ensure
proper tumbling.
Dryer doesn’t
start Dryer is unplugged Make sure the dryer plug is pushed completely into the outlet.
Fuse is blown/circuit breaker
is tripped Check the building’s fuse/circuit breaker box and replace fuse or reset breaker. NOTE:Electric dryers use two fuses or breakers.
Dryer doesn’t
heat Fuse is blown/circuit breaker is tripped; the dryer may
tumble but not heat
Check the building’s fuse/circuit breaker box and replace both
fuses or reset both breakers. Your dryer may tumble if only one
fuse is blown or one breaker tripped.
Gas service is off (gas
models only) Make sure gas shutoff at dryer and main shutoff are fully open.
LP gas supply tank is empty
or there has been a utility
interruption of natural gas
(gas models only)
Refill or replace tank. Dryer should heat when utility service is
restored.
No heat temperature selected Select another heat setting
Inconsistent
drying times Type of heat Drying time will vary according to the type of heat used. If you recently changed from an electric to a gas (natural or LP)
dryer, or vice versa, the drying time could be different.
Type of load and drying
conditions The load size, types of fabric, wetness of clothes and the length and condition of the exhaust system will affect drying
times.

49-3000332 Rev 0 11
Troubleshooting Tips... Before you call for service
TROUBLESHOOTING TIPS
Problem Possible Causes What To Do
Clothes are still
wet and dryer
shut off after a
short time
The door was opened
mid-cycle. The load was then
removed from the dryer and
a new load put in without
selecting a new cycle
A dry cycle must be reselected each time a new load is put in.
Small load When drying 3 items or less, choose Time Dry.
Load was already dry except
for collars and waistbands Choose Time Dry to dry damp collars and waistbands. In the future, when drying a load with collars and waistbands, choose
More Dry.
Dryer is not level Move dryer to an even floor space or adjust leveling legs as
necessary until even.
Clothes are
wrinkled Overdrying Select a shorter drying time. Remove items while they still hold a slight amount of moisture.
Select a Less Dry setting.
Letting items sit in dryer after
cycle ends Remove items when cycle ends and fold or hang immediately.
Overloading Separate large loads into smaller ones.
Clothes shrink Some fabrics will naturally
shrink when washed. Others
can be safely washed, but
will shrink in the dryer.
To avoid shrinkage, follow garment care labels exactly.
Some items may be pressed back into shape after drying.
If you are concerned about shrinkage in a particular
item, do not machine wash or tumble dry it.
Greasy spots
on clothes Improper use of fabric softener Follow directions on fabric softener package.
Drying dirty items with clean
ones Use your dryer to dry only clean items. Dirty items can stain clean items and the dryer.
Clothes were not completely
clean Sometimes stains which cannot be seen when the clothes are wet appear after drying. Use proper washing procedures before drying.
Lint on clothes Lint filter is full Clean lint screen before each load.
Improper sorting Sort lint producers (like chenille) from lint collectors (like corduroy).
Static electricity can attract
lint See suggestions in this section under Static occurs.
Overloading Separate large loads into smaller ones.
Paper, tissue, etc., left in
pockets Empty all pockets before laundering clothes.

12 49-3000332 Rev 0
TROUBLESHOOTING TIPS
Troubleshooting Tips... Before you call for service
Problem Possible Causes What To Do
Static occurs No fabric softener was used Try a fabric softener.
Bounce®Fabric Conditioner Dryer Sheets have been approved for
use in all GE Appliances dryers when used in accordance with the
manufacturer’s instructions.
Overdrying Try a fabric softener.
Adjust setting to Less Dry.
Synthetics, permanent press
and blends can cause static Try a fabric softener.
Collars and
waistbands still
wet at end of
cycle
The dryness monitor senses
that the body of the clothes
is dry
Choose Time Dry to dry damp collars and waistbands. In the
future, when drying a load with collars and waistbands, choose
More Dry.
Slight variation
in metallic color This is normal Due to the metallic properties of paint used for this unique product, slight variations of color may occur due to viewing angles and
lighting conditions.

49-3000332 Rev 0 13
What is not covered:
Conservatorappliances.com
Your appliance is covered by a limited warranty, as listed below, by GE Appliances. All warranty service is provided by
a GE Appliances Factory Service Technician, or an authorized service technician. To schedule service, call Crosley at
800.544.4780. Please have your serial number and your model number available when calling for service.
Conservator®Limited Warranty
Staple your receipt here. Proof of the original purchase
date is needed to obtain service under the warranty.
LIMITED WARRANTY
For the period of: We will replace:
One year
From the date of the
original purchase
Any part of the appliance which fails due to a defect in materials or workmanship.
During this limited one-year warranty, we will also provide, free of charge, all labor
and related service to replace the defective part.
■Service trips to your home to teach you how to use
the product.
■Improper installation, delivery or maintenance.
■Failure of the product if it is abused, misused, or used for
other than the intended purpose or used commercially.
■Replacement of house fuses or resetting of circuit
breakers.
■Products which are not defective or broken, or which
are working as described in the Owner’s Manual.
■Damage to the product caused by accident, fire,
floods or acts of God.
■Incidental or consequential damage caused by
possible defects with this appliance.
■Defects or damage due to operation in freezing
temperatures.
■Damage caused after delivery.
■Product not accessible to provide required service.
EXCLUSION OF IMPLIED WARRANTIES
Your sole and exclusive remedy is product repair as provided in this Limited Warranty. Any implied warranties,
including the implied warranties of merchantability or fitness for a particular purpose, are limited to one year or the
shortest period allowed by law.
This limited warranty is extended to the original purchaser and any succeeding owner for products purchased for
home use within the USA. If the product is located in an area where service by a GE Appliances Authorized Servicer
is not available, you may be responsible for a trip charge or you may be required to bring the product to an Authorized
GE Appliances Service location for service. In Alaska, the limited warranty excludes the cost of shipping or service
calls to your home.
Some states do not allow the exclusion or limitation of incidental or consequential damages. This limited warranty
gives you specific legal rights, and you may also have other rights which vary from state to state. To know what your
legal rights are, consult your local or state consumer affairs office or your state’s Attorney General.
Warrantor: GE Appliances, a Haier company
Louisville, KY 40225

14 49-3000332 Rev 0
Consumer Support
CONSUMER SUPPORT
Conservator®Website
Have a question or need assistance with your appliance? Try the Conservator website 24 hours a day, any day of
the year at Conservatorappliances.com. You can also shop for more great Conservator products on our website.
Schedule Service
Crosley repair service is only one step away from your door. Call 800.544.4780 during normal business hours to
schedule service.
Parts and Accessories
Individuals qualified to service their own appliances can have parts or accessories sent directly to their homes (VISA,
MasterCard and Discover cards are accepted). Order on-line today 24 hours every day. Visit GEApplianceparts.com
or by phone at 877.959.8688 during normal business hours.
Instructions contained in this manual cover procedures to be performed by any user. Other servicing
generally should be referred to qualified service personnel. Caution must be exercised, since improper
servicing may cause unsafe operation.

Secadora Manual del
Propietario
Contenido
Información de Seguridad ..........2
Instrucciones de Operación .........4
Paneles de control .................5
Funciones .......................5
Carga ...........................6
Cuidado y Limpieza................7
Ventilación .......................8
Cómo cambiar el sentido de apertura
de la puerta ......................9
Consejos para la Solución de
Problemas ......................10
Garantía Limitada ................13
Soporte al Consumidor............14
Modelo: NTX62
Escriba los números de modelo y de serie aquí:
Modelo # ______________________________
Serie # ________________________________
Estos números se encuentran en una etiqueta en la
parte delantera de la secadora, detrás de la puerta.
05-22 GEA
49-3000332
Rev 0

249-3000332 Rev 0
LEA Y GUARDE ESTAS INSTRUCCIONES
Para reducir el riesgo de incendio, explosión, descargas eléctricas o lesiones sobre las
personas al usar su electrodoméstico, siga las precauciones básicas, incluyendo lo siguiente:
■
Lea todas las instrucciones antes de usar este electrodoméstico.
■
NO seque prendas que en forma previa hayan sido secadas, lavadas, penetradas, o manchadas con gasolina,
solventes de limpieza en seco, u otras sustancias inflamables o explosivas, ya que despiden vapores que se podrían
encender o explotar .
■NO coloque prendas expuestas a aceites de cocción en su secadora. Las prendas contaminadas con aceites
de cocción podrán contribuir a una reacción química que podría hacer que una carga de ropa se prenda fuego.
Para reducir el riesgo de incendio debido a unas cargas contaminadas, la parte final del ciclo de la secadora se
produce sin calor (período de enfriamiento). Evite detener una secadora antes del final del ciclo de secado a
menos que todos los artículos se retiran y se dispersan rápidamente para que el calor se disipe.
■
NO permita que los niños jueguen sobre o dentro de este electrodoméstico. Cuando el electrodoméstico se use cerca
de niños, será necesario supervisarlos de cerca .
■
Antes de que este electrodoméstico quede fuera de uso o se descarte, retire la puerta del compartimiento de secado .
■
NO introduzca las manos en la secadora cuando el tambor se encuentre en movimiento .
■
NO instale ni guarde este electrodoméstico donde quede expuesto a los factores climáticos .
■
NO manipule indebidamente los controles.
■
NO se trepe ni se pare sobre la unidad.
■
NO reparar ni reemplazar cualquier parte del electrodoméstico o realizar cualquier otro trabajo técnico, a
menos que esto sea específicamente recomendado en las instrucciones de mantenimiento del usuario o en
instrucciones publicadas sobre reparaciones del usuario, que entienda y para las cuales posea las destrezas
necesarias.
■
Siga todas las instrucciones y advertencias de cuidado de tejidos para evitar el derretimiento de las prendas o daños
al aparato.
■
NO utilice suavizantes de tela ni productos para eliminar la estática, a menos que esto sea recomendado por el
fabricante del suavizante de tela u otro producto .
■
NO secar artículos que contengan gomaespuma o materiales de goma con textura similar.
■
Limpie la pantalla de pelusa antes o después de cada carga.
■
NO utilice la secadora si el filtro de pelusas no se encuentra colocado .
■
NO guarde materiales combustibles, gasolina u otros líquidos inflamables cerca de la secadora. Evite la
acumulación de pelusa, polvo o tierra alrededor del área de la apertura de ventilación y áreas adyacentes.
■
La parte interior del electrodoméstico y el conducto de ventilación se deberán limpiar periódicamente por personal
calificado del servicio técnico.
■
Desenchufe el electrodoméstico o apague el disyuntor antes de realizar el servicio técnico. Presionar el botón Power
(Encendido) o Start/Pause (Inicio/Pausa) NO desconecta el encendido .
■
NO utilice este electrodoméstico si se encuentra dañado, funcionando mal, parcialmente desensamblado, o si tiene
partes faltantes o rotas, incluyendo un cable o enchufe dañado .
■
NO rocíe ningún tipo de aerosol dentro, sobre ni cerca de la secadora en ningún momento. NO use ningún tipo de
limpiador en espray para limpiar el interior de la secadora. Se podrán producir vapores o una descarga eléctrica.
■
Para acceder a las instrucciones de conexión a tierra, lea los “CONEXIÓN ELÉCTRICA” ubicados en las Instrucciones
de Instalación .
ADVERTENCIA
Forma adecuada de descartar su electrodoméstico
■
Descarte o recicle su electrodoméstico de acuerdo con las Regulaciones Federales y Locales. Comuníquese con
las autoridades locales para descartar o reciclar su electrodoméstico de forma ambientalmente segura.
INFORMACIÓN DE SEGURIDAD
INFORMACIÓN IMPORTANTE DE SEGURIDAD
LEA TODAS LAS INSTRUCCIONES ANTES DE USAR

49-3000332 Rev 0 3
INFORMACIÓN IMPORTANTE DE SEGURIDAD
LEA TODAS LAS INSTRUCCIONES ANTES DE USAR
INFORMACIÓN DE SEGURIDAD
El incumplimiento estricto de las advertencias de seguridad podría resultar en lesiones
graves, la muerte o daños a la propiedad.
- NO guarde ni use gasolina u otros vapores y líquidos inflamables cerca de éste ni de
otros electrodomésticos.
- QUÉ DEBE HACER SI HUELE GAS:
■NO intente iluminar ningún electrodoméstico.
■NO toque ningún interruptor eléctrico; NO use teléfonos en su edificio.
■Haga que se retiren los ocupantes de la sala, edificio o área.
■De inmediato llame a su proveedor de gas desde el teléfono de un vecino. - Siga las
instrucciones del proveedor de gas.
■Si no se puede comunicar con su proveedor de gas, llame al departamento de
bomberos.
- La instalación y las reparaciones deberán ser realizadas por un instalador calificado,
agencia de servicios o el proveedor de gas.
ADVERTENCIAS ADICIONALES SOBRE LA SECADORA A
GAS
- Riesgo de incendio o de explosión
ADVERTENCIA
LEA Y GUARDE ESTAS INSTRUCCIONES

449-3000332 Rev 0
Paso 1
Es posible que las funciones y apariencias varíen con relación a su modelo a lo largo del manual.
Para reducir el riesgo de incendios, descargas eléctricas o heridas, lea las INFORMACIÓN
IMPORTANTE DE SEGURIDAD antes de utilizar este electrodoméstico.
ADVERTENCIA
• Mantenga cualquier material y vapores inflamables,
tales como gasolina, alejados de la secadora.
• NO seque nada que alguna vez haya tenido algo
inflamable en éste (incluso luego de lavar).
• Ninguna lavadora puede eliminar el aceite por
completo.
• NO seque nada que alguna vez haya tenido algún
tipo de aceite (incluyendo aceites de cocina).
• Las prendas con gomaespuma, goma, o plástico
deberán ser secadas en un tendedero.
• Siga todas las instrucciones y advertencias de
cuidado de tejidos para evitar el derretimiento de las
prendas o daños al aparato.
• Si no se cumple con esto, se podrá producir muerte,
explosión o incendio.
- Riesgo de incendio
ADVERTENCIA
• Seleccione un ciclo de secado. (Existen
configuraciones por defecto para cada ciclo
de secado. Estas configuraciones por defecto
pueden modificarse. Para más información,
consulte las descripciones de los ciclos.)
• Presione el botón Start
(iniciar).
• Filtro para la limpieza
de pelusa
• Agregue las prendas.
• Cierre la puerta.
NOTA: La secadora no
se iniciará con la puerta
abierta.
Paso 2 Paso 3
Puesta en Marcha
COMO USAR LA SECADORA
Start
Off
Off
Off
Off
More Dry
10
20
30
40
50 60
70
80
More Dry
More Dry
Normal
Less Dry
Less Dry
Less Dry
Cooling
Cooling
Cooling
Cottons Perm. Press
DelicatesTime Dry
Minutes

49-3000332 Rev 0 5
Puesta en Marcha
COMO USAR LA SECADORA
Start (Inicio)
Presione Start (Inicio) para comenzar el ciclo.
NOTA: La puerta debe estar cerrada para que la secadora inicie el ciclo.
NOTA: Si abre la puerta durante el funcionamiento la secadora se pausará.
C
ACiclos de
Secado
Los ciclos del sensor determinan de forma automática cuán seca está la tela.
Los ciclos por tiempo funcionan durante una cantidad de tiempo seleccionada
Cottons
(Algodones) Para algodones y la mayoría de las prendas blancas.
Perm. Press
( Casuals) Para prendas sin arrugas, planchado permanente, prendas delicadas y tejidos.
Delicates
(Prendas
Delicadas)
Para prendas delicadas, telas y tejidos que requieren cuidado especial.
Time Dry (Secado
por Tiempo)
Configure Cycle Selector (Selector de Ciclo) durante el tiempo de secado que desee.
Configuraciones
BTemperature
High (Alta) Para algodones de regular a pesados.
Medium (Media) Para ropas sintéticas, combinadas, delicadas y prendas con etiqueta de planchado
permanente.
Low (Baja) Para prendas delicadas, sintéticas y con etiqueta para secado en la secadora a nivel bajo.
Off
Off
Off
Off
More Dry
10
20
30
40
50 60 70 80
More Dry
More Dry
Normal
Less Dry
Less Dry
Less Dry
Cooling
Cooling
Cooling
Cottons Perm. Press
DelicatesTime Dry
Minutes
Temperature
High
Medium
Low
Start
CA B
Modelo: NTX62

649-3000332 Rev 0
Siempre siga las instrucciones del fabricante de la ropa cuando lave.
Como regla general, si las prendas están bien clasificadas para la lavadora, estarán bien clasificadas para la
secadora. También trate de clasificar las prendas de acuerdo al tamaño. Por ejemplo, no seque una sábana con
medias u otros elementos pequeños.
No agregue suavizante de telas una vez que la carga se ha calentado. Esto puede provocar manchas de
suavizante. El acondicionador de telas Bounce®en hojas para secadoras ha sido aprobado para su uso en esta
secadora cuando se utiliza de acuerdo con las instrucciones del fabricante.
No la sobrecargue. Eso malgasta energía y provoca arrugas.
Consejos de clasificación y carga
• Mantenga cualquier material y vapores inflamables,
tales como gasolina, alejados de la secadora.
• NO seque nada que alguna vez haya tenido algo
inflamable en éste (incluso luego de lavar).
• Ninguna lavadora puede eliminar el aceite por
completo.
• NO seque nada que alguna vez haya tenido algún
tipo de aceite (incluyendo aceites de cocina).
• Las prendas con gomaespuma, goma, o plástico
deberán ser secadas en un tendedero.
• Si no se cumple con esto, se podrá producir muerte,
explosión o incendio.
- Riesgo de incendio
ADVERTENCIA
La rejilla de secado se puede usar para secar artículos delicados tales
como suéteres lavables.
Para instalar el estante de secado:
1Levante el filtro de pelusa ligeramente. (No quite el filtro de pelusa
por completo).
2Coloque la rejilla de secado en la secadora, baje las patas
delanteras y engánchelas en las ranuras.
3Presione la rejilla de secado hacia abajo y baje el filtro de pelusa
nuevamente en su posición.
NOTAS:
■La rejilla de secado debe utilizarse con el ciclo Time Dry (Secado
cronometrado). El uso con ciclos por sensor pueden dejar las
prendas húmedas o generar ciclos prolongados.
■No utilice esta rejilla de secado cuando haya otras prendas en la
secadora.
■Si tu modelo no viene con la rejilla de secado, ordena hoy
WE01X25160 vía on-line a GEApplianceparts.com, 24 horas al
día o por teléfono al 877.959.8688 durante las horas normales de
trabajo.
La rejilla de secado (en algunos modelos)
Levante el filtro y
enganche las patas
delanteras de la rejilla
en las ranuras
Carga
CARGA
