HTDP200EM – Hotpoint®6.8 cu. ft. capacity DuraDrum™electric dryer
Dryer Dimensions (in inches)
Specification Created 6/11
470159
Exhaust Options:
4-way via rear, right, left and bottom.
Circuit Requirements:
An individual, properly-grounded branch circuit, protected by a
30-amp circuit breaker or a time-delay fuse, is required.
Electric Dryer Rating:
240V, 5600W, 60Hz, 24 Amp
208V, 4400W, 60Hz, 22 Amp
Installation Information: For complete information, see installation
instructions packed with product for current dimensional data.
Listed by
Underwriters
Laboratories
Special Installation Requirements
Alcove or Closet Installation:
• If your dryer is approved for installation in an alcove or closet, it will be stated on a
label on the dryer back.
• The dryer MUST be exhausted to the outside.
• Minimum clearances between dryer cabinet and adjacent walls or other surfaces are:
0" either side
3" front and rear
• Minimum vertical space from floor to overhead cabinets, ceilings, etc. is 52”.
• Closet doors must be louvered or otherwise ventilated and must contain a minimum of
60 sq. in. of open area equally distributed. If this closet contains both a washer and a
dryer, doors must contain a minimum of 120 sq. in. of open area equally distributed.
• No other fuel-burning appliance shall be installed in the same closet with a gas dryer.
Bathroom or Bedroom Installation:
• The dryer MUST be exhausted to the outdoors.
• The installation must conform with the local codes, or in the absence of local codes,
with the National Electric Code and National Fuel Gas Code, ANSI Z223 for gas dryers.
Minimum Clearances other than Alcove or Closet Installation:
• Minimum clearances to combustible surfaces
0" both sides
3" rear

Listed by
Underwriters
Laboratories
Dryer Exhausting Information – Use Metal Duct Only
Vertical and Horizontal Ducting
0 90 ft. 60 ft.
1 60 ft. 45 ft.
6.8 and 5.8 cu. ft. 2 45 ft. 35 ft.
Capacity Models 3 35 ft. 25 ft.
all Electric Dryers 4 25 ft. 15 ft.
0 90 ft. 60 ft.
6.8 and 5.8 cu. ft. 1 60 ft. 45 ft.
Capacity Models 2 45 ft. 35 ft.
all Gas Dryers 3 30 ft. 25 ft.
Portable/StationaryModels
DSKS433EB 0 46 ft. 37 ft.
DSKS333EC 1 38 ft. 30 ft.
DSKP333EC 2 31 ft. 22 ft.
WSM2780H 3 24 ft. 15 ft.
0 56 ft. 42 ft.
1 46 ft. 36 ft.
Unitized Model 2 34 ft. 28 ft.
WSM2700H 3 32 ft. 18 ft.
Unitized Models 0 43 ft. 36 ft.
WSM2420D 1 33 ft. 26 ft.
WSM2480D 2 23 ft. 16 ft.
Number
of
90°
Turns
Maximum Length of
4"-Dia.Rigid MetalDuct
Exhaust Hood Type
Domestic
Dryer Models
A
4" Opening
B
2-1/2"
Opening
Best Performance
B
2-1/2
4
A
A
For complete information, see installation instructions packed with your dryer.
Ducting Materials:
For best performance, this dryer should be vented with 4" diameter all rigid metal exhaust duct.
If rigid metal duct cannot be used, then UL-listed flexible metal (semi-rigid) ducting can be used
(Kit WX08X10077). In special installations, it may be necessary to connect the dryer to the
house vent using a flexible metal (foil-type) duct. A UL-listed flexible metal (foil-type) duct may
be used ONLY in installations where rigid metal or flexible metal (semi-rigid) ducting cannot be
used AND where a 4” diameter can be maintained throughout the entire length of the transition
duct. Please see installation instruction packed with your dryer for complete instructions when
using flexible metal (foil type) ducting.
Exhaust Length Calculation:
1. Determine the number of 90° turns needed for your installation. If you exhaust to the side or
bottom of dryer, add one turn.
2. The maximum length of 4' rigid (aluminum or galvanized) duct which can be tolerated is
shown in the table.
A turn of 45° or less may be ignored. Two 45° turns within the duct length should be treated
as a 90° elbow. A turn over 45° should be treated as a 90° elbow.
Dryers must be exhausted to the outside.
Caution: For personal safety do not terminate exhaust into a chimney, under any enclosed
house floor (crawl space), or into an attic, since the accumulated lint could create a fire hazard or
moisture could cause damage. Never terminate the exhaust into a common duct or plenum with
a kitchen exhaust, since the combination of lint and grease could create a fire hazard.
Exhaust ducts should be terminated in a dampered wall cap to prevent back drafts, bird nesting,
etc. The wall cap must also be located at least 12" above the ground or any other obstruction
with the opening pointed down.
HTDP200EM – Hotpoint®6.8 cu. ft. capacity DuraDrum™electric dryer
Specification Created 6/11
470159

Features and Benefits
• Auto Dry - Monitors air temperature with an automatic thermostat and ends the cycle
when clothes are properly dried
• Rotary electromechanical controls - Easy-to-use controls make it simple to set cycles
• 4 heat selections - Provide the right temperatures for your clothes-drying needs
• Reverse-a-Door - Door opening can be reversed to meet laundry room needs
• Upfront lint filter - With placement of the lint filter in the front of the dryer, air flow
is optimized through the drum, and access to the filter simplifies cleaning
• Cottons cycle - Heat and time are pre-set to take great care of cotton fabrics
• Up to 90 ft. venting capability - Has long equivalent ducting performance for more
flexible installation
• Model HTDP200EMWW – White on white
