XBOX SERIES
MAXFIRE-SXS RAPID
FIRE V1.01
Instruction Manual
VERVIEW
O
The Xbox Series MAXFIRE-SXS Rapid Fire mod offers many
features more than you will find on any other mod available.
While there are many features on this controller we have
developed a method of accessing them which makes it quick and
easy.
On the following pages you will find information about each
feature and how to access it. Many features can be used in
combination allowing greater flexibility and a greater
enhancement to your gaming experience. Only features which
conflict with each other such as jump shot and drop shot cannot
be used at the same time.
EATURE ACCESS
FUB/EDIT MODES
S
The Xbox Series mod uses the “LEFT and
“UP directions on the D-pad for accessing all
of the controllers features. There is also an
option of a “MOD button on the back of the
controller. The MOD button can be used
instead of LEFT on the D-pad to allow faster
access to many features as you would not
need to remove your thumb from the left
thumbstick .
When enabling/disabling a feature unless
otherwise noted you will see the guide
button LED flash once when enabling and
twice when disabling.
Several of the mod features have sub modes
or edit modes. Sub modes are modifications
to the main feature. These will be explained
in the description of each feature. To change
a features sub mode HOLD UP + LEFT on the
D-pad while holding both tap the
corresponding features button to change the
Sub-Mode. Example: to change the Jump
Shot sub mode you would HOLD UP + LEFT
then TAP A, the LED will Flash to indicate
which sub mode you are currently in.
APID FIRE MODES
R
There are 10 built in modes to select from.
Each is pre-programed with a specific speed
(see the chart to the right) these can be
independently programmed to an new speed
in the programming mode(See page 4). To
change to the next mode you must HOLD
LEFT for 4 seconds. Or with the MOD button
installed you would HOLD the MOD button
for 4 seconds. You will see the main LED
flash count the number of flashes of the LED.
This will indicate which mode you are
currently in. (2 flashes = mode 2 3 flashes =
mode 3 etc…). You can also go back to the
previous mode by HOLDING LT along with
LEFT.
MODE SPEED
Mode 1: 7.7sps
Mode 2: 9.3sps
Mode 3: 13.8sps
Mode 4: 16.67sps
Mode 5: 20sps
Mode 6: 6.85sps
Mode 7: 8sps
Mode 8: 12.5sps
Mode 9: 18sps
Mode 10: 25sps
HOLD 4 Sec
APID FIRE
R
Rapid fire gives pistols and semi-auto riffles
that extra kick they need to compete with the
big guns.
Most weapons have a sweet spot for the rapid
fire speed and this is generally between 7 and
16SPS. Be aware that above this most
weapons will start to fire slow and erratic.
Rapid fire can be activated in several ways. 1.
double tap left on the D-pad 2. Hold left on
the D-pad and pull the Right Trigger. 3. Single
tap the mod button (if installed). When
activated the LED will make a constant flash.
HOLD PULL
TAP 2x
TAP
HOLD 4 Sec

URST FIRE
B
ROP SHOTDUMP SHOT
J
Burst fire is by default a 3-round burst. This
can be changed from 2-10 rounds in the
programming mode. Burst fire works with
semi-auto weapons.
To activate burst fire hold LEFT on the D-pad
and tap X. When activated the LED will light
up solid.
Drop shot allows you to quickly drop to Prone position as soon
as you start firing and stand back up as soon as you stop firing.
To activate drop shot for standard layouts hold LEFT on the D-
pad and tap B
To activate drop shot for tactical layouts hold LEFT on the D-pad
and tap R3 (Thumb click)
HOLD
TAP
Standard Layout
Jump shot will make you jump while firing automatically
making you a much harder target to hit.
This feature cannot be used at the same time as drop shot.
Turning this feature on while drop shot is already on will
automatically turn off drop shot.
Activate by holding LEFT on the D-pad and tapping A.
HOLD TAP
HOLD
TAP
HOLD
Tactical Layout
TAP
KIMBO (LT RAPID FIRE)
A
Akimbo or left trigger rapid fire gives you
rapid fire with dual weapons. This activation is
separate from normal rapid fire which allows
you to have left trigger only rapid fire.
To activate akimbo hold LEFT on the D-pad
and pull the LEFT TRIGGER.
HOLD PULL
IMIC (Auto Akimbo)M
When using mimic the right trigger controls
the left trigger. Just pull the right trigger and
you will scope automatically.
To activate mimic hold UP on the D-pad and
pull the RIGHT TRIGGER.
HOLD PULL
DROP SHOT SUB MODES
Drop shot has multiple sub modes which can be changed by
holding LEFT + UP on the D-Pad and tapping B.
1. Always Drop/Stand automatically
2. Drop/Stand, if NOT Aiming Down Sights
3. Drop Only
4. Drop Only, if NOT Aiming Down Sights
1. Jump only once
2. Continuous Jumping (Slow Jump Speed)
3. Continuous Jumping (Medium Jump Speed)
4. Continuous Jumping (Fast Jump Speed)
JUMP SHOT SUB MODES
Jump shot has multiple sub modes which can be changed by
holding LEFT + UP on the D-Pad and tapping A.
UTO RUN
A
HOLD TAP
Auto run allows you to run without needing
to tap L3.
To activate auto run hold UP on the D-pad
and tap L3 (Left thumbstick click).
AUTO RUN SUB MODES
Auto Run has multiple sub modes which can be
changed by holding LEFT + UP on the D-Pad and
tapping L3.
1. Always runs
2. Run suspended when prone with “B
3. Run suspended when prone with “R3
A
HOLD TAP
Auto sniper breath will automatically hold
your breath when you scope.
To activate hold LEFT on the D-pad and tap L3
(Left thumbstick click).
UTO SNIPER BREATH / ZOOM A
HOLD TAP
For Battlefield to automatically spot
opponents .
To activate hold UP on the D-pad and tap R3
AUTO SPOTTING SUB MODES
There are 2 sub modes which can be changed by
holding LEFT + UP on the D-Pad and tapping R3
UTO SPOTTING
1. BF4 on only when aiming down sights
2. BF4 on all the time

UICK SCOPE
Q
With quick scope active just hold the left
trigger and you will scope and automatically
fire at the speed set in the edit mode.
To activate hold UP on the D-pad and tap LT
HOLD TAP
OW PERFECT ACTIVE RELOAD
G
Have perfectly timed active reloads for the most popular weapons in Gears of
War automatically. When using this mod you select the weapon you are
using by following the process below. Once selected you reload as normal by
pressing “RB” and the second press of “RB” will be timed automatically.
To activate Jitter hold LEFT on the D-pad and tap RB.
HOLD
QUICK SCOPE EDIT MODE
The edit mode is accessed by holding UP + LEFT
on the D-pad and pulling LT. The LED will
quickly flash 10 times when entering/exiting
the edit mode.
Within the edit mode you can perform the
following functions.
Hold Only LT – Test the currently set speed.
Tap UP on D-pad – Makes shot happen earlier (LED will flash)
Tap DOWN on D-pad – Makes shot happen later (LED will flash)
Tap RIGHT on D-pad – Turn Rapid fire with quick scope ON/OFF
Hold LEFT on D-pad, Then Hold LT – Set new Quick Scope speed.
Recording starts when you press LT and stops when you either
release it or press RT.
Tap VIEW – Exit Edit Mode.
TAP
1. GOW 1 3. GOW 3
2. GOW 2 4. GOW 4
GOW SUB MODES
AST RELOAD
F
The adjustable fast reload allows you to shave precious
milliseconds off your reload time. This works by
cancelling the last part of the reload animation after
the ammo has been added to your weapon.
Note this does not work for all games / weapons
The fast reload must be set for the weapon you are
using as all weapons have different reload times. To
set the reload timing you must HOLD Xuntil you see
your ammo indicator at the bottom of the screen show
that you have full ammo (this will happen before the
reloading animation completes) when you see this
RELEASE X. This sets the timing and the next time you
reload by just tapping X the last part of the reload
animation will be cancelled.
To activate Fast Reload hold UP on the D-pad and tap X.
TAP
HOLD
URN OFF ALL FEATURES
T
Quickly turn off all features that are turned on by
holding both thumbstick clicks (R3 and L3) and tapping
UP or LEFT on the D-pad
HOLD HOLD TAP
HOLD HOLD TAP
MASTER RESET – To reset the mod to factory default settings turn off the controller
hold A + B + X + Y and turn on the controller. Continue to hold the buttons for
approximately 6 seconds. You will see the LED flash in a pattern of fast slow fast. After
this the mod will restart and be set to factory defaults. HOLD ALL BUTTONS WHILE TURNING ON CONTROLLER
ET GOW RELOAD WEAPON
S
To set the weapon you want to perfect active reload you must HOLD UP and
TAP RB. You will TAP RB 1-6 times depending on the weapon you want to
select from the list below. When you release UP the LED will flash 1-6 times
to confirm your selection.
HOLD TAP
GOW 2 Weapons
1. Lancer/Hammerburst
2. Pistols
3. Shotgun
4. Sniper/BoomShot
GOW 3 Weapons
1. Lancer
2. Hammerburst
3. Pistols
4. Sniper/BoomShot
5. Shotgun
6. Retro Lancer
GOW 1 Weapons
1. Lancer/Hammerburst
2. Pistols
3. Shotgun
4. Sniper/BoomShot
GOW 4 Weapons
1. Lancer/Hammerburst
2. Snub/Enforcer
3. Gnasher/Markza MK 1
4. Longshot/Boomshot
5. Retro Lancer
6. overkill

EFLEX REMAPPING BUTTONS
R
Reflex remapping buttons are optional buttons or paddles on the back of the controller which can be assigned to a standard controller button. These buttons
can also be made turbo. See the programming mode instructions below for more information.
ROGRAMMING MODE
P
Within the programming mode you can setup the reflex buttons change the rapid fire speed and change the burst fire shot amount.
Enter the programming mode: HOLD RT + RB + LT + LB for 8 seconds the LED will make one long flash.
Exit the programming mode: Tap VIEW
Change Rapid Fire Speed:
To change the rapid fire speed you only need to TAP UP or DOWN on the D-pad. UP to make the speed faster and DOWN to make it slower. The LED will flash
when increasing or decreasing. Once you have reached the MIN or MAX speed the LED will no longer flash.
Change Burst Fire Quantity:
To change the number of shots fired with the burst fire you must TAP LEFT or RIGHT on the D-pad. Left for fewer shots and Right for More shots.
Check Rapid Fire Speed Setting:
To check the currently set rapid fire speed you only need to TAP Y. The LED will make long flashes for the “tens” position and then short flashes for the single
digit. (example: 3 long flashes followed by 6 short you are now at speed setting 36) Refer to the table below for all of the speed setting options.
Check Burst Fire Setting:
To check the currently set burst fire setting just TAP A. The LED will flash 2-10 times to indicate the number of shots set for the burst fire.
Reset Current Mode to Default Settings:
To reset the rapid fire mode you are currently editing to the factory default you must HOLD X and B together for 7 seconds. After 7 seconds the LED will flash
very fast 20 times to indicate the Mode has ben reset.
Change Reflex Button Mapping:
HOLD one of the Reflex buttons and TAP the button you want to assign to it. The LED will flash 1 time to confirm your change. If you tap the controller button
which is already assigned to the reflex button this will disable the button and the LED will flash 3 times. The button will then not do anything when pressed
until it is reassigned to a new controller button.
Set Reflex Button to Turbo Speed:
Double tap the reflex button to cycle through the 5 speed settings listed below. The LED will flash 1-5 times to indicate the setting.
1. No Turbo 2. Turbo at the currently set rapid fire speed 3. Fixed 5sps turbo 4. Fixed 10sps turbo 5. Fixed 15sps turbo
HOLD ALL FOR 8 SECONDS
TAP
Rapid Fire Setting Shots Per Second Rapid Fire Setting Shots Per Second
140 13 8.33
230 14 7.8
325 15 7.35
420 16 7
518 17 6.5
616 18 6
714 19 5.5
812.5 20 5
911.35 21 4.5
10 10.4 22 4
11 9.6 23 3.5
12 924 3
RAPID FIRE SPEED SETTINGS

DVANCED FEATURE MANAGEMENT
A
All features of the Xbox Series MAXFIRE-RF-SXS have an advanced management option that allows you to disable them. This is especially useful if you find
there are features you do not use and do not want the possibility to accidentally activate the feature.
Enter AFM: HOLD A + B + X + Y for 8 seconds the LED will make 10 fast flashes.
Exit AFM: Tap the VIEW button
Managing Features: Now that you are in the AFM you can enable or disable any of the features listed below by just tapping the corresponding
button or button combination. When you tap a button the LED will either flash once for enabled or twice for disabled.
Competition Mode: Competition Mode disables all features except for the Reflex buttons. To change tap DOWN on the D-Pad
HOLD ALL FOR 8 SECONDS
•Jump Shot
•Drop Shot
•Burst Fire
•GOW Active Reload
•Sniper Breath
•Akimbo (Left Trigger Rapid Fire)
•Mimic
•Quick Scope
•Fast Reload
•Auto Run
•BF Auto Spotting
•Rapid Fire
LED Mode: By default the LED is set to flash repeatedly when rapid fire or Akimbo is turned on. This behavior can be changed with
the LED Mode. There are 3 possible settings indicated below. To change the LED mode Tap RIGHT on the D-pad. The LED will flash to
indicate the setting. To change tap RIGHT on the D-pad
1. The LED flashing is disabled for ALL feature activation.
2. The LED is flashing while rapid fire is on.
3. The LED is on solid while rapid fire is on.
LEFT/MOD Button Feature Activation: This option changes which button(s) will be used to activate the different
features. If you are using a mod button and do not want LEFT on the D-pad to turn features on/off this is the setting you will want to
change. There are 3 options LEFT on the D-pad only both or MOD button only. The default is both. When changing the LED will flash 1 2
or 3 times. To change tap left on the D-pad
1. Only LEFT on the D-pad.
2. LEFT and the MOD button can both be used.
3. Only the MOD button
UP/MENU Button Feature Activation: This option changes which button(s) will be used to activate the different
features. There are 3 options UP on the D-pad only both or MENU button only. The default is both. When changing the LED will flash 1 2
or 3 times. To change tap R3
1. Only UP on the D-pad.
2. UP and the MENU button can both be used.
3. Only the MENU button
TAP
Disable Left Double Tap for Rapid Fire Activation: This option will disable the ability to activate
rapid fire by double tapping left on the D-pad. This can help prevent accidental activation or deactivation of rapid fire. When
disabled the only ways that will work to turn rapid fire on/off will be LEFT + RT and tapping the mod button.
