Contemporary Controls CTRLink EIMK-100T/FT User manual

EIMK
Installation Guide
EIMK Ethernet Media Converters allow transparent, low-cost and robust
connections between copper and fibre media. Each model supports full-
duplex operation for 100BASE-TX and 100BASE-FX segments. Two
models support multimode fibre optic connections: the EIMK-100T/FT
makes the fibre optic connection via ST-style connectors, whereas the
EIMK-100T/FC does so via SC-style connectors. The model EIMK-100T/FCS
supports single-mode fibre via SC-style connectors.
Maximum distance with 62.5/125 µm fibre cables is 2 km in full-duplex mode.
Single-mode fibre can span up to 15 km. All models support auto-negotiation
operation so that the data rate of the copper partner is matched automatically.
Two RJ-45 connectors (one MDI port and one MDIX port) allow either
straight-through or crossover copper cabling. Link and activity LEDs allow
troubleshooting from front-panel observations.
All units mount on TS-35 DIN-rail, operate from low-voltage AC or DC power
and offer redundant power connections.
Designed for automation applications, all models comply with
EMC immunity and emissions compatibility standards for
industrial environments.
Ethernet Media Converters for Automation Systems

Specifications
Electrical
INPUT DC AC
Voltage: 10–36 V 24 V
Power: 2 W 4 VA
Frequency: N/A 47–63 Hz
Class 2 Circuits Only
Environmental
Operating Temperature: 0°C to +60°C
Storage Temperature: – 40°C to +85°C
Humidity, non-cond.: 10% to 95%
Protection: IP 30
Mounting TS-35 DIN-rail
Shipping Weight 1 lb (0.45 kg)
Regulatory Compliance
CE Mark; CFR 47 Part 15, Class A
UL508 Industrial Control Equipment
Functional
Compliance: ANSI/IEEE 802.3
Data Rates: 10 and 100 Mbps
Signalling: 100BASE-TX and
100BASE-FX
Connectors: Shielded RJ-45
SC and ST style
Segment length: 100 m, copper
2 km, multimode fibre
15 km, single-mode fibre
LED Indicators
Power green
Link green
Activity green
RJ-45 Pin Assignments
Pin Function
1 TD+
2 TD–
3 RD+
6 RD– (All other pins are unused.)
Mechanical
This device is
intended for use
with Class 2 circuits.

Power Considerations
Applied voltage must be in the range
specified and deliver a current that is
commensurate with 4 VA of power
consumption. The recommended size
for solid power conductors is 16–20
AWG. Zero volts (COM) is isolated
from chassis (earth). Input connections
are reverse-polarity protected.
LED Indicators
The power LED glows when proper power is applied. Each port has two LEDs. Link
glows solid if the port has a proper connection to an operating Ethernet device and
Activity flashes as data is exchanged with the attached device.
Copper Cabling Option
A cabling option exists for copper lines: crossover wiring attached to the “normal” port
(marked X) or straight-through wiring attached to the “uplink” port (MDI).
NOTE: the two RJ-45 ports can NOT be used simultaneously.
Uplink Ports Vs Normal Ports

Need More Help Installing this Product?
More information can be found in the Technical Support part of our web site
at www.ccontrols.com. If contacting our office, ask for Technical Support.
Warranty
Contemporary Controls (CC) warrants this product to the original purchaser for two
years from the shipping date. If it fails to operate in compliance with its specification
during this period, CC will, at its option, repair or replace the product at no charge.
Product returned to CC for repair is warranted for one year from the date that the
repaired product is shipped back to the purchaser or for the remainder of the original
warranty period, whichever is longer. The customer is responsible for shipping product;
CC assumes no responsibility for product until received. This limited warranty covers
products only as delivered. User modification may void the warranty. Damage from
abuse, accident, disaster, misuse, or incorrect installation are not covered. This
warranty in no way warrants suitability of the product for any specific application. More
warranty information can be found at www.ccontrols.com.
Warning: This is a Class A product. In a domestic environment this product may cause
radio interference in which case the user may be required to take adequate measures.
Returning Products for Repair
Return the product to the location where it was purchased by following the
instructions at the URL below:
www.ccontrols.com/rma.htm
Declaration of Conformity
Information about the regulatory compliance of this product can be found at
the URL below:
www.ccontrols.com/compliance.htm
September 2012 TD090200-0IC
