Control Techniques Unidrive M700 Instruction Manual

WARNING! This document is a guide only. It does not provide safety
information. Incorrect installation or operation of the drive could result
in injury or equipment damage. Refer to the Unidrive M700/M701/M702
Control User Guide for essential safety information.
UNIDRIVE M700
UNIDRIVE M701
UNIDRIVE M702
High Performance
AC/Servo Drives
Quick Startup, Operation
and Maintenance Guide

www.controltechniques.com2
Power Wiring – Sizes 3 to 9A
Heatsink mounted braking resistor
A resistor has been especially designed to mount within the heatsink of
the Unidrive M sizes 3, 4 & 5. The design of the resistor is such that no
thermal protection circuit is required, as the device will fail safely under
fault conditions. On Unidrive M sizes 3, 4 & 5 the software overload
protection is set up at default for the designated heatsink mounted
resistor. If an external brake resistor is used, a thermal overload device is
required. NOTE: The heatsink mounted resistor is suitable for applications
with a low level of regen energy only.
WARNING
For
complete
wiring
and fusing
instructions, refer to
the Unidrive M Power
Installation guide.
*Thermal overload
for braking resistor to
protect against fire risk.
This must be wired to
interrupt the AC supply
in the even of a fault.
This is not required if
the optional heatsink
mounted braking
resistor is used.
Common DC bus connections
*Optional braking resistor
DC
+DC
BR

www.controltechniques.com 3
Control Wiring – Unidrive M700/M701
Digital input 6 (jog forward select)
Digital input 5 (analog input 1/2 select)
Digital input/output 2 (reset)
Digital input/output 1 (at zero speed)
+24 V output user supply
Analog input 3
Analog output 1 (speed/frequency)
Non-inverting input (analog freq ref 1)
+10 V user output
0V common
+24 V external supply
0V common external supply
Control connections
30
29
28
27
26
25
24
23
8
7
6
5
3
Minimum connections to run motor
Inverting input (analog freq ref 1)
Analog input 2 (analog freq ref 2)
Analog output 2 (torque active current)
0V common (analog)
0V common (digital)
0V common (digital)
Digital input/output 3 (run forward)
Digital input 4 (run reverse)
31
21
22
Run FWD
Run REV
STO (drive enable)
24 V
0V
Speed
reference
input
+10 V
51
52
Drive OK
Status relay
0V common (STO)
Safe Torque Off (drive enable)*
+24 V external supply†
0V common external supply†
21 31
41 42
111
The 0V terminals on the Safe Torque Off are
not isolated from each other and the 0V common.
* The Safe Torque Off / Drive enable terminal is
a positive logic only input.
†
Terminal 51 and 52 must be connected to an
external 24 V power supply if backup is required
(frame sizes 6-11E only).
Notes:
Programmable analog
Programmable digital
Non-programmable
The 0V terminals on the Safe Torque Off are not isolated from each other
and the 0V common.
* The Safe Torque Off/drive enable terminal is a positive logic only input.
† Terminal 51 and 52 must be connected to an external 24 V power supply
if backup is required (frame sizes 6-11E only).

www.controltechniques.com4
Control Wiring – Unidrive M702
The 0V terminals on the Safe Torque Off are
not isolated from each other and the 0V common.
* The Safe Torque Off / Drive enable terminal is
a positive logic only input.
†
Terminal 51 and 52 must be connected to an
external 24 V power supply if backup is required
(frame sizes 6-11E only).
Notes:
Programmable analog
Programmable digital
Non-programmable
• For frame size 5 to 9: STO input terminals
are 31 and 35; STO 0V terminals are 32 and 36.
* Terminal not available on frame size 1.
Notes:
Drive OK
Status relay
0V (STO 2)
Safe Torque Off 1 (drive enable 1)*
Digital output 2
Digital output 1 (at zero speed)
0V common
+24 V output user supply
0V common
52
51
42
41
8
7
6
5
3
Minimum connections to run motor
0V common
Digital input 4 (run forward)
Digital input 5 (run reverse)
12
13
Run FWD
Run REV
STO 1
STO 2
24 V
41 42
113
+24 V input external supply
Safe Torque Off 2 (drive enable 2)*
0V common external supply†
+24 V external supply†
Control connections
0V (STO 1)
* The Safe Torque Off/drive enable terminal is a positive logic only input.
† Terminal 51 and 52 must be connected to an external 24V power supply
if backup is required (frame sizes 6-11E only).

www.controltechniques.com 5
Terminal
Induction Servo / PM
AB
Pr 03.038 = 0
Endat
Pr 03.038 = 8
AB Servo
Pr 03.038 = 3
1 A DATA A
2 A\ DATA\ A\
3 B CLK B
4 B\ CLK\ B\
5 Z Freeze Z
6 Z\ Freeze\ Z\
7 Asim Out U
8 Asim\ Out U\
9 Bsim Out V
10 Bsim\ Out V\
11 Zsim Out W
12 Zsim\ Out W\
13 +V (power supply output)
14 0V
15 Thermistor
Encoder Wiring
Encoder connector 15-pin D-type as standard on
Unidrive M700/M701/M702
Encoder shielding connected to drive 0V and encoder 0V
For further information see the Unidrive M700/M701/M702 Control User Guide.

www.controltechniques.com6
Keypad & Display
By default, the keypad display is in “Status Mode” for viewing current
drive conditions, and can be changed to “Parameter Mode” for viewing
and editing drive configuration settings.
Status mode
When in status mode, the drive status message/alarm/trip code is
displayed on the upper left corner of the upper line, i.e., “Ready”,
“Inhibit”, “Trip”. See the “Display Messages” topic for more details.
Parameter mode
When in parameter mode, drive functionality can be viewed or modified
by using the keypad. The parameter number is displayed on the upper line
of the display (ex, 00.010), the parameter description is displayed on the
second line, and the parameter value is displayed on the right-hand side
of the bottom line.
Viewing parameters
The parameter number format is S.MM.PPP, where S = slot number
for option modules and built-in communications, MM = menu number
(menus are groupings of common functions), and PPP = parameter
number (parameters are specific drive functions). For example: Pr. 00.010
is menu 0, parameter 10. Note: Menu 0 contains the most common
parameters used in a typical setup and is programmable.
Upper line
Displays the parameter
number, drive status, or
drive trip code.
Middle line
Displays the parameter
description.
Lower line
Displays the
parameter value
Escape Enter
Navigation (x4)
Stop/Reset
Start Forward
Start reverse
(Auxiliary)

www.controltechniques.com 7
Keypad & Display
Navigating menus and parameters
You can find any parameter value using the arrow buttons. The and
buttons are used to navigate between the slots and menus. The and
buttons are used to navigate between the parameters in a menu.
To edit/modify parameters
In order to change the value of a parameter, go to the parameter you
would like to change and then press the enter button. Now the cursor
shifts to the parameter value. You can increase the parameter value by
pressing the up button or decrease the parameter value by pressing the
down button. The right and left buttons can be used to switch between
the digits within the parameter value. Pressing the enter button again will
set the newly selected parameter value, and the cursor will return to the
parameter number.
Note: Certain parameters are read only (RO) and cannot be changed. For
example Pr. 0.11– drive output frequency, cannot be changed. Pressing
the return button will return the keypad to status.
To Save parameter values
Changes made to parameters will be lost when the drive is turned off
unless parameters are saved. To save new parameter changes, enter 1001
into any Pr.MM.000 and then press the Stop/Reset button.
To reset to USA (60 Hz) defaults
To reset the drive to USA default parameter settings, open the drive
enable signal (Terminal 31), enter 1244 into Pr MM.000 and then press
the Stop/Reset button. Save the parameter values by entering 1001 into
Pr MM.000 and then pressing the Stop/Reset button.

www.controltechniques.com8
Display Messages
Alarm indications
Trip codes
Alarm string Description
Brake resistor Brake resistor overload. Braking resistor thermal accumulator (10.039) in the drive has
reached 75.0% of the value at which the drive will trip.
Motor overload Motor protection accumulator (04.019) in the drive has reached 75.0% of the value at
which the drive will trip and the load on the drive is >100%.
Inductor overload Regen inductor overload. Inductor protection accumulator (04.019) in the drive has
reached 75.0% of the value at which the drive will trip and the load on the drive is
>100%.
Drive overload Drive over temperature. Percentage of drive thermal trip level (07.036) in the drive is
greater than 90%.
Autotune The autotune procedure has been initialized and an autotune in progress.
Limit switch Limit switch active. Indicates that a limit switch is active and that is causing the motor
to be stopped.
Display Description - troubleshooting tips
Over volts • Increase deceleration ramp (Pr 00.004).
• Decrease the braking resistor value (staying above the minimum value).
• Check nominal AC supply level.
OI.AC • Acceleration/deceleration rate is too short.
• If seen during auto-tune reduce the voltage boost.
• Check for short circuit on the output cabling.
Encoder2 • Ensure that the position feedback device type selected in Pr 03.038 is correct for the
position feedback device connected to the P1 interface on the drive.
• If wire break detection on the drive encoder input is not required, set Pr 03.040 =
XXX0 to disable the encoder 2 trip.
• Check cable continuity.
• Check wiring of feedback signals is correct.
• Check encoder power supply is set correctly (Pr 03.036).
Status indications
For other display messages and trip codes with more recommended actions please refer to the
Unidrive M700/M701/M702 Control User Guide or to the mobile Diagnostic Tool app.
Display Description
Inhibit The drive is inhibited and cannot be run.
Ready The drive is ready to run.
Stop The drive is stopped/holding zero speed.
Run The drive is active and running.
Trip The drive has tripped and no longer controlling the motor.
Under voltage The drive is in the under voltage state either in low voltage or high
voltage mode.

www.controltechniques.com 9
Induction Motor Setup
Open loop
Unidrive M70x open loop induction motor setup
Parameter
description
Parameter Comments
USA defaults 00.000 = 1254 Drive USA defaults (60 Hz)
00.048 (11.031) = 1 (Open loop) mode
Reset the drive RESET Red button on keypad
User security status 00.049 (11.044) = 1 All menus
Reference selector 00.005 (01.014) = 4 (Keypad) Keypad control
Reset the drive RESET Red button on keypad
Max reference clamp 00.002 (01.006) = Motor nameplate value
Acceleration rate 00.003 (02.011) = 5.0 s/1000 rpm
Deceleration rate 00.004 (02.021) = 10.0 s/1000 rpm
Ramp mode 00.015 (02.004) = Standard "Fast" ramp if braking resistor
installed. Also ensure Pr 10.030,
Pr 10.031 & Pr 10.061 are set
correctly.
Motor rated voltage 00.044 (05.009) = Motor nameplate value
Rated speed 00.045 (05.008) = Motor nameplate value
Motor rated current 00.046 (05.007) = Motor nameplate value
Motor rated frequency 00.047 (05.006) = Motor nameplate value
Save parameters to NVM 00.000 = 1001
Reset the drive RESET Red button on keypad
Perform an autotune
Warning: A rotating autotune will cause the motor to accelerate up to 2/3 base speed in
the direction selected regardless of the reference provided. Once complete the motor will
coast to a stop. The enable signal must be removed before the drive can be made to run at
the required reference.
Autotune 00.040 (05.012) = 2 Motor loaded stationary autotune = 1
Motor unload/uncoupled autotune = 2
Close drive Safe Torque Off signal(s) – M700/701: (jumper terminal 22 to terminal 31);
M702: (jumper Terminals 2, 11, and 13)
Press keypad RUN (green) button
***** Wait for drive/motor to stop rotating and display “Ready” or “Inhibit” *****
Save parameters to NVM 00.000 = 1001
Reset the drive RESET Red button on keypad
Open Drive Safe Torque Off signal(s) – M700/701: (remove jumper from T22 to T31);
M702: (remove jumpers from T2, T11, and T13)
Save parameters to NVM 00.000 = 1001
Reference selector 00.005 (01.014) = 0 (AI A2) Terminal strip control
Reset the drive RESET Red button on keypad

www.controltechniques.com10
Induction Motor Setup
Closed loop
Unidrive M70x closed loop induction motor setup
Parameter description Parameter Comments
USA defaults 00.000 = 1254 Drive USA defaults (60 Hz)
00.048 (11.031) = 2 (RFC-A) Rotor Flux Control-Asynchronous
Reset drive RESET Red button on keypad
User security status 00.049 (11.044) =1 (All menus)
Reference selector 00.005 (01.014) = 4
(Keypad)
Keypad control
Reset drive RESET Red button on keypad
Max reference clamp 00.002 (01.006) = Motor nameplate value
Acceleration rate 00.003 (02.011) = 2.000 s/1000 rpm
Deceleration rate 00.004 (02.021) = 2.000 s/1000 rpm
Ramp mode 00.015 (02.004) = Standard
"Fast" ramp if braking resistor
installed. Also ensure Pr 10.030,
Pr 10.031 & Pr 10.061 are set
correctly.
Motor rated voltage 00.044 (05.009) = Motor nameplate value
Rated speed 00.045 (05.008) = Motor nameplate value
Motor rated current 00.046 (05.007) = Motor nameplate value
Motor rated frequency 00.047 (05.006) = Motor nameplate value
Drive encoder lines per rev 03.034 = 1024 Encoder technical information
Drive encoder supply voltage 03.036 = 0 (5V) Encoder technical information
Drive encoder type 03.038 = 0 (AB) Encoder setup
Save parameters to NVM 00.000 = 1001
Reset drive RESET Red button on keypad
Perform an autotune
Warning: A rotating autotune will cause the motor to accelerate up to 2/3 base speed in
the direction selected regardless of the reference provided. Once complete the motor will
coast to a stop. The enable signal must be removed before the drive can be made to run at
the required reference.
Autotune 00.040 (05.012) = 2 Motor loaded stationary autotune = 1
Motor unload/uncoupled autotune = 2
Close drive Safe Torque Off signal(s) – M700/701: (jumper terminal 22 to terminal 31);
M702: (jumper Terminals 2, 11, and 13)
Press keypad RUN (green) button
***** Wait for drive/motor to stop rotating and display “Ready” or “Inhibit” *****
Save parameters to NVM 00.000 = 1001
Reset the drive RESET Red button on keypad
Open Drive Safe Torque Off signal(s) – M700/701: (remove jumper from T22 to T31);
M702: (remove jumpers from T2, T11, and T13)
Save parameters to NVM 00.000 = 1001
Reference selector 00.005 (01.014) = 0 (AI A2) Terminal strip control
Reset the drive RESET Red button on keypad

www.controltechniques.com 11
Permanent Magnet Motor Setup
Closed loop
Unidrive M70x closed loop permanent magnet motor setup
Parameter description Parameter Comments
USA defaults 00.000 = 1254 Drive USA defaults (60 Hz)
00.048 (11.031) = 3 (RFC-S) Rotor Flux Control-Synchronous
Reset the drive RESET Red button on keypad
User security status 00.049 (11.044) = 1 (All menus)
Reference selector 00.005 (01.014) = 4 (Keypad) Keypad control
Reset the drive RESET Red button on keypad
Max reference clamp 00.002 (01.006) = Set to 1.2 x Pr 05.008 (rpm)
Acceleration rate 00.003 (02.011) = 2.000 s/1000 rpm
Deceleration rate 00.004 (02.021) = 2.000 s/1000 rpm
Ramp mode 00.015 (02.004) = Standard "Fast" ramp if braking resistor
installed. Also ensure Pr 10.030, Pr
10.031 & Pr 10.061 are set correctly.
Catch a spinning motor 00.033 (06.009) = 0 (Off)
Max switching frequency 00.041 (05.018) = Motor nameplate value (min.Fsw)
(kHz)
Number of motor poles 00.042 (05.011) = Motor nameplate value
Motor rated voltage 00.044 (05.009) = Motor nameplate value
Rated speed 00.045 (05.008) = Motor nameplate value
Motor rated current 00.046 (05.007) = Motor nameplate value
Volts per 1000 rpm 00.047 (05.033) = Motor nameplate value
Drive encoder lines per rev 03.034 = 1024 (Lines) Encoder technical info
Drive encoder supply voltage 03.036 = 0 (5V) Encoder technical info
Drive encoder type 03.038 = 0 (AB servo) 0 (AB servo) encoder technical info
Current reference filter 04.012 = 0.2 ms Current reference filter 1 time constant
High speed mode 05.022 = -1 (Limit)
Stop mode 06.001 = 1 (Ramp) No ramp is default
Hold zero speed 06.008 = 0 (Off)
Reset the drive RESET Red button on keypad
Save parameters to NVM 00.000 = 1001
Reset the drive RESET Red button on keypad
Perform an autotune
Warning: A rotating autotune will cause the motor to accelerate up to 2/3 base speed in the
direction selected regardless of the reference provided. Once complete the motor will coast to a
stop. The enable signal must be removed before the drive can be made to run at the required
reference.
Autotune 00.040 (05.012) = 2 Motor loaded stationary autotune = 1
Motor unload/uncoupled autotune = 2
Close drive Safe Torque Off signal(s) – M700/701: (jumper terminal 22 to terminal 31);
M702: (jumper Terminals 2, 11, and 13)
Press keypad RUN (green) button
***** Wait for drive/motor to stop rotating and display “Ready” or “Inhibit” *****
Save parameters to NVM 00.000 = 1001
Reset the drive RESET Red button on keypad
Open Drive Safe Torque Off signal(s) – M700/701: (remove jumper from T22 to T31);
M702: (remove jumpers from T2, T11, and T13)
Save parameters to NVM 00.000 = 1001
Reference selector 00.005 (01.014) = 0 (AI A2) Terminal strip control
Reset the drive RESET Red button on keypad

www.controltechniques.com12
Servo Motor Setup
Unidrive M70x servo motor setup
Parameter
description
Parameter Comments
USA defaults 00.000 = 1254 Drive USA defaults (60 Hz)
00.048 (11.031) = 3 (RFC-S) Rotor Flux Control-Synchronous
RESET Red button on keypad
User security status 00.049 (11.044) = 1 (All Menus)
Reference selector 00.005 (01.014) = 4 (Keypad) Keypad control
RESET Red button on keypad
Max reference clamp 00.002 (01.006) = Motor nameplate value
Acceleration rate 00.003 (02.011) = 0.200 s/1000 rpm
Deceleration rate 00.004 (02.021) = 0.200 s/1000 rpm
Ramp mode 00.015 (02.004) = Standard "Fast" ramp if braking resistor
installed. Also ensure Pr
10.030, Pr 10.031 & Pr 10.061
are set correctly.
Number of motor poles 00.042 (05.011) = Motor nameplate value
Motor rated voltage 00.044 (05.009) = Motor nameplate value
Rated speed 00.045 (05.008) = Motor nameplate value
Motor rated current 00.046 (05.007) = Motor nameplate value
Drive encoder lines per rev 03.034 = Encoder technical info
Drive encoder supply voltage 03.036 = 0 (5V) Encoder technical info
Drive encoder type 03.038 = 8 (EnDat) 8 (EnDat), 3 (AB Servo)
Encoder termination select 03.039 = 1
Stop mode 06.001 = 1 (Ramp) No ramp is default
RESET Red button on keypad
Save parameters to NVM 00.000 = 1001
RESET Red button on keypad
Perform an autotune
Warning: A rotating autotune will cause the motor to accelerate up to 2/3 base speed in
the direction selected regardless of the reference provided. Once complete the motor will
coast to a stop. The enable signal must be removed before the drive can be made to run at
the required reference.
Autotune 00.040 (05.012) = 2 Motor loaded stationary autotune = 1
Motor unload/uncoupled autotune = 2
Close drive Safe Torque Off signal(s) – M700/701: (jumper terminal 22 to terminal 31);
M702: (jumper Terminals 2, 11, and 13)
Press keypad RUN (green) button
***** Wait for drive/motor to stop rotating and display “Ready” or “Inhibit” *****
Save parameters to NVM 00.000 = 1001
Reset the drive RESET Red button on keypad
Open Drive Safe Torque Off signal(s) – M700/701: (remove jumper from T22 to T31);
M702: (remove jumpers from T2, T11, and T13)
Save parameters to NVM 00.000 = 1001
Reference selector 00.005 (01.014) = 0 (AI A2) Terminal strip control
Reset the drive RESET Red button on keypad

www.controltechniques.com 13
Terminal Encoder
15 way
D-type
connector
10 way
pluggable
connector
AB
Pr 1x.038 = 1
EnDat
Pr 1x.038 = 4
AB Servo
Pr 1x.038 = 3
1 A DATA A
2 A\ DATA\ A\
3 B CLK B
4 B\ CLK\ B\
5 Z Freeze Z
6 Z\ Freeze\ Z\
7 3 Asim Out U
8 4 Asim\ Out U\
9 5 Bsim Out V\
10 6 Bsim\ Out V\
11 8 Zsim Out W
12 9 Zsim\ Out W\
13 10 +V (power supply output)
14 2, 7 0V
15 Thermistor
1 +24 V freeze input
Universal Encoder Module
SI-UNI-ENCODER system integration module
This option provides an additional incremental or absolute encoder
feedback port and simulated encoder output.
10-way
pluggable
connector
15-way
female D-type
connector
12345
678910
For further information see the SI-Universal Encoder User Guide.

www.controltechniques.com14
Expanded I/O
SI-I/O system integration module
This option increases the number of I/O points on a drive. All connections
from the option module to the drive are made via the drive connector.
PL1 Function
T1 0V common
T2 Digital input/output 1
T3 Digital input/output 2
T4 Digital input/output 3
T5 Digital input/output 4
T6 0V common
T7 Analog input 1/digital input 5
T8 Analog input 1/digital input 6
T9 Analog input 1/digital input 7
T10 0V common
T11 Analog input 1/digital input 8
11 way pluggable screw connector
PL2 Function
T21 Relay 1
T22 Relay common
T23 Relay 2
3 way pluggable screw connector
PL1
1 2 3 4 5 6 7 8910 11
PL2
21 22 23
For further information see the SI-I/O User Guide.

www.controltechniques.com 15
PC Tools
Unidrive M Connect commissioning tool
The Unidrive M700/M702 comes with built-in Ethernet. The Unidrive
M Connect PC software can be used on a computer to access drive
parameters once the following drive and computer adjustments have
been made.
LED Status Description
Off Ethernet connection not detected
Solid green Ethernet connection detected but no data
Flashing green Ethernet connection detected and data flow
Parameter Function
Pr. 4.02.005 = Off Disable DHCP
Pr. 4.02.006 = 192.168.1.100 Set an IP address
Pr. 4.02.007 = 255.255.255.0 Set the subnet
Pr. 4.00.007 = On Enable new changes
Pr. s.mm.000 = ‘1001’ Save the parameters
Slot 4 - drive configuration
The Unidrive M701 comes with built-in RS485. The Unidrive M Connect
PC software can be used on a computer to access drive parameters by
connecting the computer to the drive using a CT-USB-CABLE (pictured below).

www.controltechniques.com16
Smartcard
Parameter storage / cloning
The Smartcard is a memory device that can be used to
back-up parameter sets and PLC programs, and copy
them from one drive to another.
Auto
Save
Auto
Save
Boot
Pr 0.30 = rEAD +
Drive reads all parameters
from the Smartcard.
Pr 0.30 = Prog +
Programs all drive parameters
to the Smartcard.
Note: overwrites only data
already in block 1.
Pr 0.30 = AutO +
Drive automatically writes
to the Smartard when a
parameter save is
performed.
Pr 0.30 = boot +
Drive boots from the Smartcard on
power-up and automatically writes to the
Smartcard when a parameter save is
performed.

www.controltechniques.com 17
Notes

www.controltechniques.com18
Notes

www.controltechniques.com 19
Notes

www.controltechniques.com20
Support
24/7 technical support
• 1-800-893-2321
• CTdrives.com/techsupport
For manuals, application notes and information
on our support services visit our website:
www.controltechniques.com
Control Techniques
7078 Shady Oak Road
Eden Prairie, MN 55344
QSG-M70X 03/21
C
R
I
T
I
C
A
L
S
P
A
R
E
S
T
E
C
H
N
I
C
A
L
D
O
C
U
M
E
N
T
A
T
I
O
N
C
U
S
T
O
M
E
R
C
A
R
E
T
E
C
H
N
I
C
A
L
S
U
P
P
O
R
T
C
U
S
T
O
M
E
R
C
A
R
E
