CARROT 3 BOOSTER KIT- CHILD RESTRAINT SYSTEM
For Children with Special Needs
Kit Assembly Manual
Read all instructions
before using this
restraint system.
WARNING

Carrot 3 Booster Seat
The Carrot 3 Booster Seat offers a larger
seat to meet the needs of children who
have outgrown the standard Carrot 3
restraint system. Consult your doctor to
make sure that this restraint system is
suitable for your child.
Use only with occupants who weigh more
than 79lbs (36kg) and less than
165lbs (75kg). This child restraint system
has been successfully crash tested.
Before assembling the Booster Seat, make sure all parts are in the kit:
1. Booster Seat Base
2. H- Harness (4-point)
3. Metal Yoke
4. Metal Rods (pair)
2
1
3
4

Booster Seat
Replace the standard seat with the Booster Seat using the same
backrest assembly.
NOTE: Strongly recommend that this Booster Seat installation is
done by your local dealer.
Remove the Velcro®tapes from the back of the Headrest and detach
straps from the harness bracket (Fig. A & B).
Detach and remove the seat assembly from the Backrest by pulling and
releasing the D-shape ring attached on the back (Fig. C, D & E).
NOTE: The seat depth knobs will be reused to attach the Booster Seat.
3. Remove the seat depth adjustment knobs (Fig F).
Seat Depth Adjustment Knobs
FIG.A
FIG.C FIG.D FIG.E
FIG.F
FIG.B
3
2
1

Metal Rods
Booster Seat Installation
Replace the existing metal rods, on the
right and left side of the seat, with the
2” (50mm) longer metal rods. Attach the
metal rods to the Booster Seat using the
seat depth adjustment knobs.
IMPORTANT NOTE: When attaching the
metal rods to Booster Seat, the ridges of
the rods must be directed and attached
inward. If installed in the opposite
direction, this will cause the adjustment
feature not lock to. The metal rods are
interchangeable (Fig. G).
Insert the 2” (50mm) longer rods into the standard Carrot 3 backrest while
simultaneously pulling the D-Shape Ring on the back (Fig. H & I).
FIG.G
FIG.H FIG.I
5
4
Ridges
D-Shape Ring

Harness Strap
1. Remove the end loops from the Metal Yoke (Fig. J & K).
2. Fold the loop end of the harness into a triangle to easily threading through
the front open slots located underneath the Headrest and pull out the back
(Fig. L, M & N).
FIG.KFIG.J
FIG.L FIG.M FIG.N
NOTE: Make sure that the webbing is not twisted.
1
2
4-point
H-Harness
Remove from the
Metal Yoke
Fold the tip for
easier threading. Pull it out
to the
backside.
Put it through from
the front side.

Pull the H-harness padded cover
strap through the same slot used
to pull the H-Harness and attach to
the back of the headrest with the
end of the Velcro®strap. Repeat on
opposite side (Fig. O).
Re-attach the back loop ends to the Metal Yoke and securely lock it on the eight (8)
hooks located on the Yoke (Fig. P & Q).
Remove slack from the backrest
by rmly pulling the front of the
harness by the buckle towards you
(Fig. R).
FIG.O
FIG.P
FIG.R
FIG.Q
Make sure the loops
are locked at 8 hooks
Pull
H-Harness padded strap
Yoke
3
5
6

Backrest Extension
Attach the 2” (50mm) backrest
extension from the standard Carrot 3
child restraint system and attach it to
the Carrot 3 Booster Seat, that comes
standard with your Carrot 3
NOTE: The metal rods used to
attach the Booster seat extends the
height of the standard backrest by
2” (50mm). The standard 2” (50mm)
backrest extension is required to
cover the back gap (Fig. S).
After successfully converting your standard
Carrot 3 child restraint system into a Carrot 3
Booster Seat, it is ready for use.
NOTE: Read the Carrot 3 Booster Seat
Instruction Manual before using this
restraint system.
FIG.S
Pull
7
2” Backrest Extension

Now You
’re Going Places
2830 California Street, Torrance, CA 90503
[phone] · [phone] · Fax: [phone]
Website: www.convaid.com · Email: [email protected]
UG0022-ENG-Rev-02022016
