Converters.TV 989 User manual

Digital S/PDIF and Toslink Audio over single
Cat5e/6 Transmitter & Reciever - ID 989
Operation Manual

Introduction
Digital S/PDIF and Toslink Audio over single Cat5e/6 Transmitter &
Reciever is designed to transmit O tical and Coaxial digital audio
signals u to 150 meters using one CAT5e/6 cable. Su orts stereo
and multichannel LPCM, 7.1, DTS, Dolby Digital audio etc via Digital
TosLink cable (o tical fibre) or Coaxial cable. Out ut medium is the
same as the in ut medium ie O tical in = O tical out; Coaxial in =
Coaxial out. Plug'n'Play functionality and sim le, quick installation
makes this unit ideal for Digital Audio transmission over long distances
using CAT5e/6 cable.
Applications
•Coaxial audio signal extension over single CAT6 u to 150M away
•O tical audio signal extension over single CAT6 u to 150M away
System
Requirements
In ut Coxial/O tical audio signal source and out ut am lifier or s eaker with
connection cables and single CAT6 cable in between the transmitter and
receiver.
Features
•Su orts Coaxial or O tical digital audio SPDIF signal
•Su orts stereo and multichannel (7.1, DTS, DolbyDigital ... and etc.)
digital audio
•Su orts industry standard Category5/ 5e/6 cable
•Digital audio SPDIF erformance sam ling rate 96kHz
•Su orts single Coaxial in ut to Coaxial signal out ut
•Su orts single O tical in ut to O tical signal out ut

Operating Functions
and
Controls
Transmitter
1. Coaxial In: This slot is to connect with source audio equi ment such as DVD
or Blue-Ray layer for in ut audio signal sending.
2. Optical In: This slot is to connect with the audio source equi ment such as
DVD or Blue-Ray layer for in ut audio signal sending.
3. DC 5V: This slot is where you lug the 5V DC ower su ly into the unit and
connect the ada tor to an AC outlet. (Only one side of ower is require)
4. USB 5V: This slot is to connect with USB cable for ower su ly from PC/NB.
5. CAT6 Out: This slot is to connect with CAT6 cable to the receiver side.
Receiver
1. USB 5V: This slot is to connect with USB cable for ower su ly from PC/NB.
2. CAT6 In: This slot is to connect with CAT6 cable from the transmitter side.
3. Coaxial OUT: This slot is to connect with out ut audio equi ment such as
am lifier or active s eakers with coaxial in ut.
4. Optical Out: This slot is to connect with out ut audio equi ment such as
am lifier or active s eakers with o tical in ut.
5. DC 5V: This slot is where you lug the 5V DC ower su ly into the unit and
connect the ada tor to an AC outlet. (Only one side of ower is require)

Top Panel
1. Pow r LED: The blue LED will illuminate when the device is connected
with ower.
RJ-45 Pin Assignment
Transmitter Receiver
Pin Definition
Cat5/5e/6
150M
< >
Pin Definition
1 Signal A 1 Signal A
2 Signal B 2 Signal B
3 Signal C 3 Signal C
4 GND 4 GND
5 GND 5 GND
6 Signal D 6 Signal D
7 DC5V 7 DC5V
8 DC5V 8 DC5V

Connection

Specifications
Transmitt r
In ut 1 x Coaxial & 1 x O tical
Out ut 1 x CAT6
R c iv r
In ut 1 x CAT6
Out ut 1 x Coaxial & 1 x O tical
CAT6 Cable Distance 150 meters
Sam le Rate 32 / 44.1 / 48 / 88.2 & 96KHz
ESD Protection Human Body Model:
± 6kV (air-ga discharge)
± 4kV (contact discharge)
Dimension (mm) 22 (H) x 70 (W) x 50 (D)
Weight (g) 50
O erating Tem erature 0°C ~ 45°C / 32°F ~104°F
Storage Tem erature -20°C ~ 60°C/ -4°F ~140°F
Relative Humidity 20~90% RH (non-condensing)
Power Consum tion 2W
