RF SOLUTIONS WIFI-RF User manual

WIFI-RF
DS-WIFI-RF-3
ELITE-RX /
MAINSINK
LIGHTING
WATER
FEATURES
WIFI-RF
UP TO 500M
RANGE
SUPPLY
Features
• Control home appliances from
your phone
• Operates with RF Solutions
ELITE and MAINSLINK series
products.
• Up to 500m Range
• Simple plug and play
Installation–
• ETHERNET and WIFI network
connectivity
• Android, iPhone apps available
CONTROL YOUR WORLD - WITH THE WIFI RF
Description:
The WIFI-RF is a radio transceiver with
Ethernet connection for controlling almost
any RF Solutions radio product.
The WIFI-RF plugs into your WIFI router al-
lowing you to control all of your RF Solutions
products from your iPhone or Android.
The WIFI-RF is incredibly easy to install. It’s
auto configure capability means that instal-
lation is simply a case of plugging into your
router and waiting a few seconds for the
WIFI-RF to detect and configure to your
network.
Ordering Information:
Part Number: WIFI-RF
How does it work?

WIFI-RF
DS-WIFI-RF-3
What’s in the box?
Included in the box for the WIFI-RF is everything you need to get your existing RF
Solutions products controlled from your mobile phone (Android or iPhone).
If when you receive your WIFI-RF you do not have the below, please contact your
supplier directly.
Power Supply
9V 1A
2.1mm Jack Plug
UK Plug socket and lead
868MHz Antenna
SMA Male Connector
CAT 5 Cable
WIFI-RF
Ethernet to RF convertor Box
500m Range
For connection to any home
router

WIFI-RF
DS-WIFI-RF-3
How it works:
The WIFI-RF acts as a bridge between your home network and almost all RF Solu-
tions’ remote control systems. This means that while you are connected to your
home WIFI network via your phone or tablet you can use the WIFI-RF APP to re-
motely control almost anything. You can configure outdoor lighting, a pond pump, a
gate or combinations of all of these. All to work from our simple to use smart phone
APP.
Part number:
Part Number Description Power Supply Range**
WIFI-RF WIFI RF interface 12Vdc (supplied) 500m
**Range stated is optimal Line of sight range between the WIFI-RF and the
chosen receiver. Obstructions and close proximity to metal works or the
ground may severely affect performance.
Receivers:
Compatible Products
Transmitters WIFI-RF will work alongside:
MAINSLINK-RXELITE-RX TRAP-RX
ELITE-T / ELITE-XT SWITCHLINK-TXMAINSLINK-TX

WIFI-RF
DS-WIFI-RF-3
Installation of the WIFI-RF:
Please follow the steps below accurately and IN ORDER :
1. Screw the antenna onto the WIFI-RF.
2. Connect the ETHERNET cable to the WIFI-RF.
3. Connect the ETHERNET cable to any free port on your router.
4. Connect the power supply to the WIFI RF.
WAIT 30 SECONDS—for the WIFI-RF to register on the network.
5. Press and hold the CONFIG button on the back of the WIFI-RF for 3 seconds—data
LED will flash.
6. After you release the CONFIG button wait while your WIFI-RF auto-configures to op-
erate on your home network.
7. When the auto configure process is complete then the ‘Data’ LED will stop flashing.
8. Install the APP on your phone.
Downloading the APP:
From the Google Play or the iStore - search for RF Solutions or RFRemote and you
should find our free app, download and install. Please see page 5 for app connection
instructions.
9. Pairing process for buttons on the app will be as per your receiver instructions.
Notes on location and antenna:
A. Try to choose a location for your WIFI-RF which is not too close to walls and/or large
expanses of metal work as this will reduce the operational range.
B. Try to keep the antenna vertical - or perpendicular to the maximum required range.
NOTE: The WIFI-RF has a very long range and therefore you shouldn’t need to worry
about to much any installation location. You can always call our technical support helpline
if you are having trouble—Technical support: +(44)1444 227909.
See installation diagram overleaf….

WIFI-RF
DS-WIFI-RF-3
ADSL
ETHERNET
BACK OF MOST STANDARD ROUTERS
DO NOT USE
WIFI-RF
1
2
3
4
CONFIG
1
2
3
4
Connect the Antenna
Connect the Ethernet Cable
Connect the power supply
Press and hold the Config button for 3
seconds.

WIFI-RF
DS-WIFI-RF-3
The RFRemote App
The RFRemote app provide a platform from which to control your existing or new
RF Solutions remote control receivers. Once you have installed the WIFI-RF
hardware and have downloaded the App onto your phone. Open the app and cre-
ate switching buttons to control your products as you require.
The below diagram shows the functionality of the RFRemote App.
Please note that once the WIFI-RF is plugged in and the app installed no set-up
should be required
other than pressing the auto configure button.
