USER MANUAL
GAS CONVECTION OVEN
MODEL: CC-100
USR Brands, Inc.
Phone: [phone] | www.usrestaurant.com | [e-mail]

USRESTAURANT® RESERVES THE RIGHT TO CHANGE SPECIFICATIONS WITHOUT NOTICE
WARNINGS!
• Do not store or use gasoline or other flammable vapors or liquids in the vicinity of this or any other
equipment.
• Improper installation, adjustment, alteration, service or maintenance can cause property damage,
injury or death.
• Read the installation and maintenance instructions thoroughly before installing or servicing this
equipment.
• Have the equipment installed by a qualified installer in accordance with all federal, state and local
codes.
• Do not install or use without all 4 legs.
• This equipment is for use in non-combustible locations only.
• Do not obstruct the flow of combustion and ventilation air.
• Do not spray controls or the outside of the equipment with liquids or cleaning agents
• Allow for hot parts to cool before cleaning or moving.
• This equipment should only be used in a flat, level position.
• Do not operate unattended.
• Any loose dirt or metal particles that are allowed to enter the gas lines on this equipment will
damage the valve and affect its operation.
• If you smell gas, follow the instructions provided by the gas supplier. Do not touch any electrical
switch; do not try to light the burner; do not use a telephone within close proximity.
• Never attempt to move grates while cooking.
This manual contains important information regarding
your purchased equipment. Please read the manual thoroughly
prior to equipment set-up, operation and maintenance.
Failure to comply with regular maintenance guidelines
outlined in this manual may void the warranty. Please keep it for
future reference after installation and do not throw it away!
This is a universal installation and operation instruction book
which would apply to different models.
PLEASE READ!!!

USRESTAURANT® RESERVES THE RIGHT TO CHANGE SPECIFICATIONS WITHOUT NOTICE
1
SET UP
1. Remove all packing material and tape, as well as any protective plastic from the equipment.
2. Place the equipment in the desired position and height.
3. Install the four (4) legs onto the equipment.
4. Clean and dry the equipment thoroughly before using.
INSTALLATION:
The installation of this equipment must conform with local codes, or with the National Gas
Code, ANSIZ223.1/NFPA 54, or the
Natural Gas and Propane Installation Code, CSA B149.1, as applicable.
• The equipment and its individual shutoff valve must be disconnected from the gas supply piping
system during any pressure testing of that system at test pressures in excess of ½ psi (3.5 kPa).
• The equipment must be isolated from the gas supply piping system by closing its individual
manual shutoff valve during any pressure testing of the gas supply piping system at test pressures
equal to or less then ½ psi (3.5 kPa).
Clearance and positioning around the equipment:
• This equipment must be installed adjacent to non-combustible surfaces only with a minimum
spacing of 6” from all sides. This equipment must be a distance of 6” from other equipment. The
equipment must have the 4” legs installed and be placed on a noncombustible surface.
For an oven equipped with casters, the installation shall be made with a connector that complies
with the Standard for Connectors for Movable Gas Appliances, ANSI Z21.69/CSA 6.16 and a
quick-disconnect device that complies with the Standard for Quick-Disconnect Devices for Use with
Gas Fuel, ANSI Z21.4/CSA 6.9. When installing the oven with casters and quick-disconnect hose,
adequate means must be provided to limit the movement of the oven without depending on the
connector and the quick disconnect device or its associated piping to limit the oven movement.
Restraining means may be attached to the vertical portion of the base frame in the rear of the oven.
Air Supply and ventilation:
• The area in front and around the equipment must be kept clear to avoid any obstruction of the flow
of combustion and ventilation air.
• Adequate clearance must be maintained at all times in front of and at the sides of the equipment
for servicing and proper ventilation.
Gas connection:
Prior to connecting gas supply, check the incoming line pressure. The oven can only withstand a
maximum pressure of ½ PSI (14” WC). If the line pressure is beyond this limit, a step down
regulator before this machine will be required.

USRESTAURANT® RESERVES THE RIGHT TO CHANGE SPECIFICATIONS WITHOUT NOTICE
2
Electrical connection:
Your oven is supplied for connection to a 115 volt, single phase grounded circuit. The electric motor,
oven lights, indicator lights and control circuits are connected through a electric supply cord found
at the rear of the oven.
Warning:
This appliance is equipped with a three-prong (grounding) plug for your protection against shock
hazard and should be plugged directly into a properly grounded three-prong receptacle. DO NOT
cut or otherwise remove the grounding prong from this plug.
Before making any connections to these units, check the rating plate to assure that the voltage and
phase of the oven is compatible with the electrical supply. When installing, all ovens must be
electrically grounded in accordance with local codes, or in the absence of local codes, with the
National Electrical Code, ANSI/NFPA 70 (in Canada - CSA Std. C22.2). Wiring diagrams are
located in the control compartment area of the oven. Standard wiring schematics are also provided
with this manual.
GAS CONVERSION
Please check the rating plate for the gas type to be connected for operation. If the available gas is
different from the gas type specified on the rating plate. A gas conversion procedure should be
performed by a qualified technician. It is recommended that a trained gas service technician with
the necessary tools, instruments and skills perform the conversion.
To convert the gas, following steps must be completed:
1. Remove all gas burner orifices and install the provided conversion kits
2. Change the Honeywell control valve. VR8205m2831 is for propane gas. VR8205A2800 is for
natural gas use.
Castor Installation
• Castors are available as an option for both the single and double oven sections.
• The castors is with threading bolt. Fasten the bolt to the leg hole in the center tightly.
NOTE: The casters with locking brakes are best mounted on the front side of the oven for easier
access.
• Align the leg plate holes in each leg with those in the corners of the oven bottom and secure using
the provided bolts. Tighten all bolts firmly. Repeat this procedure for all legs.
NOTE: If you plan to use casters and flexible fuel gas connectors, a fixed restraint of the proper
length must be incorporated to secure the oven to a non-movable surface to eliminate strain on the
connector. If the oven is removed from its normal position, the restraint must then be reattached
when returned.
For stacking unit, please use a stacking bracket and connect two pieces with screw and install the
stacking chimney assembly.

USRESTAURANT® RESERVES THE RIGHT TO CHANGE SPECIFICATIONS WITHOUT NOTICE
3
Exhaust System
The appliances must be positioned in suitable areas for the discharge of the combustion products
in respect to how much is prescribed by the installation’s norms. These appliances are not
designed to be connected to an evacuation duct for the discharge of combustible products.
These appliances must discharge the combustible products into appropriate hoods, or similar
devices, connected to a flue of proven efficiency, or they may be connected directly to an outdoor
vent.
If such an arrangement is not possible, the unit may be connected to an air exhaust system that
leads directly outdoors, having a capacity no lower than required; see the technical data table, plus
the air exchange necessary, in order to make operators comfortable.
Warnings
Always supervise the appliance while being used and never let it run while empty.
The appliances do not require special adjustment assistance from specialized personnel if the
adjustments are carried out by the user during the use of the appliance.
Use only the accessories recommended by the manufacturer.
During the initial uses of the appliance, an acrid or burning smell may be detected. This will
disappear after two or three uses.
After use, the areas are hot for a certain amount of time (residual heat). Avoid resting your hands
on them and allowing children to get too close.
These are very important regulations; if they are neglected, the appliance may not perform properly
or the user may be placed at risk.
The appliance is strictly for professional use and must be used by qualified personnel.
The installation, start-up and maintenance of the appliance must be carried out by qualified
personnel.
All installation works must be carried out according to the law in force. The manufacturer is not
responsible for damages due to an incorrect installation, bad maintenance or incorrect use.
Lighting, Relighting, and Shutdown Instructions
To light the oven, just switch the power switch at the top left corner of the control panel to the “ON”
position. (The oven is equipped with a direct hot surface ignition system. There is no pilot to light.)
If the burners fail to ignite within four seconds, the oven will automatically shut off the gas, wait five
minutes to allow the gas that was released to dissipate, and try to light the burners again. If the
burners still fail to ignite after three such attempts, the oven will stop trying, even though the power
switch is in the “ON” position. To continue to attempt to light the burners, turn the power switch
“OFF” and then “ON” again.
To shutdown the oven, switch the power switch to the “OFF“ position. For a complete shutdown,
also open the control panel and turn the manual shut-off valve to the “OFF” position.

USRESTAURANT® RESERVES THE RIGHT TO CHANGE SPECIFICATIONS WITHOUT NOTICE
4
Operations
Turn the oven ON and set the cooking temperature. Two additional controls are used to control the
fan (as described below).
The timer is a reminder of cooking process done. The timer does not control the temperature of the
oven.
To cook, do the following:
Turn the oven main power switch ON.
Choose the fan speed using the Fan Speed switch. The appropriate fan speed (HI or LOW)
depends on the type of food to be cooked.
Switch the Fan Mode switch to COOK. The fan will run continuously when the oven doors are
closed (the fan works independently of the gas system). (If this switch is turned to COOL, the only
Power Switch:
Main power supply to this oven
Fan Mode:
In COOK mode, the fan runs
continuously with the exception of
door being open. In COOL mode, the
fan runs continuously even if the
doors are open. This is to cool down
the unit with the door open
Cook Timer:
Turn knob to set cooking time. A buzzer
would beep when pre-set time is up.
Turn the knob to OFF to disable the
buzzer. The timer just acts as a
reminder and it is independent of the
oven control
Power Indicator:
It illuminates when the power is
switched to ON position.
HEAT-ON Indicator:
The HEAT-ON indicator will be on
when the burners are working
HI/LOW Fan Speed:
To choose fan speed (HI or LOW) to
cook different types of food.
Cook Temperature Control:
Turn the knob to desired temperature.
When the pre-set temperature is
reached, the HEAT ON indicator will be
off. The indicator would cycle on-off
Oven Interior Light Switch:
The light is controlled independently.

USRESTAURANT® RESERVES THE RIGHT TO CHANGE SPECIFICATIONS WITHOUT NOTICE
5
difference is that the fan will continue to rotate when the oven doors are open.)
Set the cooking temperature by turning the Cook Temperature Control until the indicator mark on
the knob is pointed to desired cooking temperature. The HEAT ON indicator will be on when the
burners are on and will remain on while the oven is heated.
Wait until the HEAT ON indicator cycles on and off for three times, the pre-set temperature has
been reached. Open the oven doors, load the product into the oven, and close the doors.
You can use the Cook Timer as a reminder of cooking process. If yes, turn the Cook Timer knob
until the indicator mark points to the desired cooking time (up to 55 minutes). The timer knob will
rotate counterclockwise as the timer runs down, indicating how much time remains. You can turn
the knob while cooking to increase or decrease the remaining time. When the timer runs out, a
buzzer will sound for a short time, and then turn itself off. (To immediately silence the buzzer, turn
the Cook Timer knob to the OFF position.) The timer is a reminder to you; the timer does not control
the oven.
If you open the oven doors, the burners and fan will shut off until the doors are closed. However,
the timer will continue running even if the doors are open.
For ovens that are equipped with an oven interior light, to turn on the light, press and hold the
switch located at the bottom of the control panel.
When the load has finish cooking, you can rapidly cool the load by opening the oven doors (which
will shut off the burners) and switching the Fan Mode to COOL (which will cause the fan to run even
though the doors are open). For the most rapid cooling, also switch the Fan Speed switch to HI.
After cooking is done, turn the Cook Temperature Control to the lowest setting (fully
counterclockwise) and switch the Power Switch to OFF.
CLEANING - NOTE: To maintain cleanliness and increase service life, this item should be cleaned
daily. Do not water jet to spray water directly on the unit, if liquid enters the electrical compartment it
may cause a short circuit or electrical shock.
Before cleaning or attempting to move this item always turn off, unplug and let the unit to cool down
completely.
Wipe the entire unit with a clean soft cloth until it is completely dry.
To avoid damage to the unit, do not use abrasive cleaners or scouring pads.
If soap or chemical cleaners are used, be sure they are completely rinsed away with clean water
immediately after cleaning. Chemical residue could damage or corrode the surfaces of the unit.
To avoid serious injury or damage, never attempt to repair or replace a damaged power cord
yourself. Contact a professional technician for repair service.
MAINTENANCE:
• A qualified service company should check the unit for safe and efficient operation on an annual
basis.
• Gas piping shall be a certain size and installed to provide a supply of gas sufficient to meet the full
gas input of the equipment.
• A manual shut off valve should be installed upstream from the manifold within 4 ft. (1.2m) of the
equipment and in a position where it can be reached in the event of an emergency.
• Check entire gas piping system for leaks every so often. Using a gas leak detector or soapy water
solution is recommended.
• Install equipment under efficient exhaust hood with flameproof filters with a distance of no less
than 4 feet between the top of the equipment and the filters or any other combustible materials.

USRESTAURANT® RESERVES THE RIGHT TO CHANGE SPECIFICATIONS WITHOUT NOTICE
6
Trouble shooting
Problem
Possible cause
Solution
No Heat
Ignitor defective
Call authorized Service center
No Heat
Power switch on control panel
is off
Set the control panel to COOK
No Heat
Doors are open
Close doors
No Heat
Door micro switch defective
Call authorized service center
No Heat
Gas valve to oven may be in
the cleared position
Turn gas valve on
Oven has not reached
proper
The oven has not reached
Wait for oven to reach pre-heat
temperature
pre-heat temperature
temperature
Oven has not reached
proper
Internal problem with main
Call authorized service center
temperature
temperature control
Convection fan does not
run
Oven has no electrical power
Check electrical supply
Convection fan does not
run
Circuit breaker tripped
Reset the breaker
Convection fan does not
run
Doors are open
Close doors
Convection fan does not
run
Door Micro-switch defective
Call authorized service center
Food Browns unevenly
Improper heating temperature
Pre-heat until desired
temperature is reached
Food Browns unevenly
Baking pan dark or glass
Lower oven temp by 25°F
Food dries before
browning
Oven temp too high
Lower oven temp
Food dries before
browning
Oven door opened too much
Stop opening oven door so
much
Oven cycles 3 times and
locks itself out
Flame sensor defective
Call authorized service center

USRESTAURANT® RESERVES THE RIGHT TO CHANGE SPECIFICATIONS WITHOUT NOTICE
7
Wiring diagram and Parts
θT1--Gas igniter
θT2--Flame sensor
IC2--Gas controller
YV--Combination valve

USRESTAURANT® RESERVES THE RIGHT TO CHANGE SPECIFICATIONS WITHOUT NOTICE
8
No.
Description
1
Side board
2
Wiring grid
3
Rack support
4
Left door assembly
5
Right door assembly
6
Front bottom plate
7
Burner assembly
8
Combustion cavity top board
9
Castor with leg
10
Control panel
11
Combination valve
12
Gas venturi pipe
13
Insulation cover for illuminator
14
Cavity side board
15
Cavity rear board
16
Motor support
17
Baffle plate
18
Motor
19
Back board
20
Cavity top board
21
Chimney cover
22
Top cover
23
Flue channel
No.
Description
1
Steel panel
2
Buzzer

USRESTAURANT® RESERVES THE RIGHT TO CHANGE SPECIFICATIONS WITHOUT NOTICE
9
3
Rock switch
4
Gas ignition controller
5
Transformer A
6
Transformer B
7
Hinge
8
Terminal
9
Thermostat
10
Timer
11
Control panel side
Product Specification Sheet
MODEL
STYLE(Manual)
Volts
Frequency
Total B.T.U. per Hour
CC-100
Gas convection oven
120V
60HZ
54,000
