COOLWHIP T4 User manual

YOUR INSTALLATION INSTRUCTIONS

T4/T5/T6 FLAT PACK FURNITURE
INSTALLATION INSTRUCTIONS

Please ensure you briefly read over this instruction
manual before attempting to assemble and fit your
units. Once you have an understanding of the process,
please then read and follow each page step by step,
failure to do this can result in mistakes and the process
taking much longer.
STOP & READ

CONTENTS
3-7 Overview
8-17 T Trimming
18-30 Pre assembly
31-45 Wardrobe assembly
46-48 Soft close drawer assembly
49-53 Fridge pod assembly
54-56 Fitting the table leg and rail
57-59 Above unit shelf/ locker assembly
60-62 Fitting guide

Read instructions and
prepare work space and tools
T Trimming Hang all doors and fit catches
Upgraded Tambour doors Assemble
Fitting
THE PROCESS

T TRIMMING
•Mallet
•Stanley knife
•Curved Stanley knife
•Mitre shears
TOOLS

Staring the Trim
Trimming corners
Ending the join
Removing Trim from hinge holes
Tips and hints
Do not t trim cupboard parts
QUICK OVERVIEW

STARTING THE TRIM
Cut the trim square before
starting every piece
Ensure the lip is on the surface
denoted by the piece sticker
Start and finish on the
black line

CORNERS
Keep the Trim tight
to avoid gaps
Use the inside of the mallet
to trim door apertures*
*ensure you use masking tape

Remove the inner trim to
avoid bobbled corners
CORNERS

ENDING THE TRIM
Mark and cut the Trim a few
(mm) past the start point Butt the two Trims together Mallet the join flush.

Where there is no join simply cut the
edge straight with a Stanley
ENDING THE TRIM

REMOVE THE HINGE
Remove the inner Trim from the hinge hole to allow the
hinge to sit flush. Failure to do this will result in bulging

TIPS AND HINTS
Always keep the trim taught
to avoid gaps and bobbles
Always hit down onto a surface, use
the edge of a bench if necessary
Heat the trim to stretch
and manipulate

TOOLS
•Drill Driver
•Stanley knife
•Cross head
Screw driver
HANGING DOORS

Place the correct door into the
correct aperture ensuring the
door is orientated correctly
Place the handle catch
into the hole
Using 16mm screws, fix the
back of the catch into place
ensuring the catch is straight
HANDLES

Fix the hinges to the door only
using 16mm screws and the
pilot holes provided
Clip on the cover plates Turn the adjustment all the
way to the rear before fixing
to the aperture
HINGES

Remove wide screws and
replace with 16mm screws to fit
the plate to the aperture
OVERLAY
ADJUSTMENT
HORIZONTAL
ADJUSTMENT
CLIP-ON
MOUNT
Once both hinges are fitted,
adjust the door to fit flush with
equal spacing
HINGES
(CONT.)

STRIKE PLATE
Mark out the width of the strike plate
on the door and the aperture parallel
to the catch using a Stanley knife
Remove the trim lip from the door and the
aperture allowing the strike plate to sit flush onto
the wood, then fit using 2 x 16mm screws*
*adjust before tightening

CHECK & MAKE SURE…
The doors sit flush and open and shut correctly
HANGING DOORS
Now follow the same process of hanging all the
doors before continuing to page 23
