Cooper Controls EG2 User manual

EG2
Ethernet Gateway
Installation guide

P2Document 9850-000224-00 EG2
Contents
Location & Mounting 3
Product Overview 4
Connections 5
Setup Instructions 5 - 7
!
WARNING HAZARDOUS VOLTAGES
DISCONNECT FROM SUPPLY
BEFORE REMOVING COVERS
NO USER SERVICEABLE PA RTS INSIDE
SERVICE BY QUALIFIED PERSONNEL ONLY
WARNING
To reduce the risk of fire or electric shock,
DO NOT expose this device to rain or moisture.
DO NOT energise unless the front cover is in place.
This device must be earthed.
Installation, programming and maintenance must be carried out by qualified personnel.
Cooper Controls cannot accept responsibility for repairs or modifications that are not
competently executed and in accordance with service or upgrade information.
CE compliant to all relevant standards
Introduction
Welcome
The Ethernet Gateway 2 provides connection between an iLight CAN network and an Ethernet
LAN. This allows a user to control and configure the iLight system using iCANsoft on a LAN
network PC rather than by connecting directly into the network.
The EG2 also facilitates connection to the internet when installed behind a firewall. This then
enables remote connection for controlling, programming and obtaining diagnostics of the
lighting control system. A web interface is provided for simple operation of the lighting system.
The EG2 also functions as a smartphone device host allowing control and programming of the
iLight network. Apps are available free of charge for Android and Apple devices.
Facilities are provided to allow a BMS or smart home system to interact with the iLight network.
This is achieved by simple character strings communicated via a UDP or TCP connection.

P3Document 9850-000224-00 EG2
Installation
Location
The EG2 should be installed in a dry ventilated location, where ambient conditions are
maintained within the requirements of the unit. The unit has ventilation slots on its sides to allow
convection cooling and in no circumstances should these be blocked.
Ambient atmosphere requirements
Temperature: +2°C to +40°C (+36°F to +104°F)
Humidity: 5% to 95% non-condensing
IP Rating: IP20
Dimensions Weight
159mm (w) x 90mm (h) x 58mm (d) 0.25Kg (0.55 lbs)
Mounting
Always mount in well ventilated location Allow
50mm (2”) above and below the unit if trunking
with a depth greater than 50mm (2”) is used.
Basic Schematic

P4Document 9850-000224-00 EG2
Ethernet LINK
LED on indicates the link
is connected at 100Mb
LED off indicates the link
is connected at 10Mb
Ethernet DATA
LED on indicates that
the Ethernet link is
established
LED flashes off briefly
when Ethernet traffic is
present
SD card DATA
LED flashing indicates
memory card is being
accessed
SD card INPUT
Indicates SD Memory
card location
iCAN DATA
Red flashing LED indicates
traffic being sent and/or
received
Red LED on indicates a
CANbus error
iCAN status
Green flashing LED indicates
normal operation
Product Overview
The label on the enclosure identifies the position of the status LEDS, switches & connectors.
iCANnet
iLight network
connection
(See P6 for
wiring details)
TIMECLOCK
N/A - Future use
RESET
Switch that resets
the device. Only
press this on direct
instruction from
Cooper Controls to
avoid data corruption
Ethernet INPUT
Indicates Ethernet
connector location
POWER
The Green Power LED will
double flash continuously
while EG2 is on.
iCAN IDENT
Switch that causes the EG2
to send a message on the
CAN BUS to identify itself

P5Document 9850-000224-00 EG2
Connections
Connecting the Supply
Power is to be supplied to the EG2 via an external regulated power supply in
the range of 9-36VDC 0.3A
Cooper Controls are able to provide a recommended power supply if required.
Catalogue Number: PSU-15-DIN (15VDC 0.67A)
Wire gauge for supply terminals
Terminal sizes:
iCANnet 5 x 1.5mm²
iCAN Network Connections
A removable 5 way connector screw
terminal plug is provided for the
connection of iCAN network cables.
The recommended cable to use for
iCANnet is: CAT5 FTP.
-V +V
Set Up Instructions
iCANnet
Connect the EG2 to the CAN network using the iCANnet connector. If the EG2 is at the
end of a network set the Term link to ON otherwise set to the OFF position.
Ethernet
Ethernet connection by RJ45 (568B). This should be connected to either an Ethernet Switch
or to a Wireless Router.

P6Document 9850-000224-00 EG2
Set Up Instructions
Configuration
iCAN Device Number
The EG2 is supplied with a iCANnet Device number with Segment number 255 and a
node number in the range 1-255. Both Segment and Node number can be changed using
iCANsoft.
Factory Default IP settings
IP Address 192.168.0.100•
Mask 255.255.255.0•
DHCP Off•
Note the EG2 default settings are to use
a fixed IP address of 192.168.0.100. Any
device used to communicate with the
EG2 will need to be located within the
192.168.0.x subnet.
Power up
The EG2 takes approximately 60 seconds to be ready for use once power is applied.
Wait for the Green CAN LED to flash slowly.
The Green Power LED will double flash continuously while EG2 is on.
If Ethernet is connected the Link and Data LEDs will indicate successful connection.
Setting the IP address
The factory set IP Address can be changed using the iCANnet connection or using a
computer connected directly to the Ethernet port.
Changing with iCANnet
Connect to the iCAN network a computer running iCANsoft using a Cooper Controls PC
Node. Search the network and load the EG2 into iCANsoft.
Go the Ethernet tab. Either the Default settings can be applied or other settings can be applied.
Select OK or Apply to download the changes to the EG2.

P7Document 9850-000224-00 EG2
Change IP address via the Ethernet port
EG2 is supplied from the factory without DHCP enabled; therefore, it is necessary that the
Ethernet port of the PC is set to the correct IP Address and Subnet Mask. For details of
setting the IP address of your computer consult information on line. This will depend on your
Operating System.
For example:
IP Address 192.168.0.99•
Subnet mask 255.255.255.0•
Gateway 192.168.0.1•
To connect the EG2 directly to the PC, it may be necessary to use a Crossover Cable,
however, most modern computers are able to connect directly to another Ethernet device
without a crossover cable.
The Ethernet port of your computer will need to configured to a compatible IP address.
Open iCANsoft. It will be required to set iCANsoft to communicate using the Ethernet Port.
This is done by selecting from the Tool bar Tools>Options>Network.
Select Ethernet Gateway and change the IP address to 192.168.0.100. Also ensure the ‘Use
Password’ check box is ticked. The detault password is Cooper123 (Case sentitive).
Select OK to confirm and set the
address.
iCANsoft can now be used to configure
any items connected on the network.
Set the IP address of the EG2 as
described in section above for
iCANsoft. The new IP address will
become valid when the EG2 is reset
or power to the device is removed and
re-instated.
Reset to factory defaults
Factory defaults may be reset by the following procedure:
Remove power from the board.
Press the CAN ID button and reapply power. Keep the button pressed until the CAN LED
flashes then stays on. At this point the Ethernet settings will have been restored to defaults.
After setting to factory defaults, the IP address of the device will revert to 192.168.0.100
