Cooper Security EXP-PSU User manual

Page ii
© Cooper Security Ltd. 2011
IN NO EVENT WILL COOPER BE LIABLE FOR ANY SPECIAL, CONSEQUENTIAL , OR INDIRECT LOSS OR DAMAGE,
INCIDENTAL DAMAGES, STATUTORY DAMAGES, EXEMPLARY DAMAGES, LOSS OF PROFITS, LOSS OF REVENUE, LOSS
OF ANTICIPATED SAVINGS, LOSS OF BUSINESS OR OPPORTUNTIY, LOSS OF GOODWILL OR INJURY TO REPUTATION,
LIQUIDATED DAMAGES OR LOSS OF USE, EVEN IF INFORMED OF THE POSSIBILITY OF SUCH DAMAGES. COOPER‟S
LIABILITY FOR DAMAGES ARISING OUT OF OR RELATED TO A PRODUCT SHALL IN NO CASE EXCEED THE PURCHASE
PRICE OF THE PRODUCT FROM WHICH THE CLAIM ARISES. TO THE EXTENT PERMITTED BY APPLICABLE LAW, THESE
LIMITATIONS AND EXCLUSIONS WILL APPLY WHETHER COOPER‟S LIABILITY ARISES FROM BREACH OF CONTRACT,
BREACH OF WARRANTY, TORT (INCLUDING BUT NOT LIMITED TO NEGLIGENCE), STRICT LIABILITY, BY OPERATION
OF LAW, OR OTHERWISE.
Every effort has been made to ensure that the contents of this book are correct. The contents
of this book are subject to change without notice.
Printed and published in the U.K.
This manual applies to the EXP-PSU with version 2 software.
For Your Safety
This book contains several passages alerting you to potential problems or hazards. Each of
these are marked by the words Note, Caution or WARNING.:
Note:
Describes conditions that may affect the proper functioning of the
equipment (but will not damage the equipment).
Caution:
Describes actions that will physically damage the equipment and
prevent its proper function.
WARNING:
Describes actions that are hazardous to health, or cause injury or
death.
Please pay particular attention to these marked passages.
www.coopersecurity.co.uk
Product Support (UK) Tel: [phone].
Available between:
08: 30 and 17:00 Monday to Friday.
Product Support Fax: [phone]
email: [e-mail]
Part Number 12071708 7/7/11

Page iii
CONTENTS
1. Introduction ..................................... 1
About this Guide ............................... 1
2. Before You Begin .............................. 1
Preparation ......................................... 1
Siting the EXP-PSU ........................... 1
Guided Tour ........................................ 1
Opening the Case ............................. 1
Power Availability ................................. 3
Bus Cabling Requirements ........................... 4
Cable Type....................................... 4
Cable Segregation............................. 4
Voltage Drop .................................... 4
Connecting A Remote Power Supply .... 4
3. Installation....................................... 6
Caution: Static Electricity................... 6
Step 1. Fit the Case.............................. 6
Fitting ............................................. 6
Installing the Lid/Back Tamper ........... 6
Step 2. Run Bus Cable .......................... 6
Step 3. Connect EXP-PSU to the Bus....... 6
Addressing the EXP-PSU .................... 7
Step 4. Connect to Mains ...................... 7
Mains Cabling................................... 7
Step 5. Connect Wired Zones................. 7
Four Wire Closed Circuit Connections .. 7
Fully Supervised Loop Connections...... 7
Step 6. Connect Wired Outputs .............. 8
Remote Loudspeaker (Optional).......... 8
Wired Outputs .................................. 8
Step 7. Fit a Plug-By Communicator ....... 9
Step 8. Fit and Connect Battery ............. 9
Step 9. Initial Power-Up ..........................10
Step 10. Re-fit The Lid.........................10
4. Maintenance ................................... 11
5. Technical Specification ................... 11
General..............................................11
Capacities ..........................................11
Power Supply......................................11
EN50131-6 ratings...........................11
Electromagnetic Compatibility ...............12
Outputs .............................................12
Fuses.................................................12
Electrical Safety ..................................12
Compliance Statements .......................12
Compatible Equipment .........................12

EXP-PSU
Page iv
This page is intentionally blank.

EXP-PSU
Page 1
1. Introduction
The EXP-PSU is a remote power supply
intended for use in wired/wirefree alarm
systems controlled by the i-onEX range of
control units.
The power supply comprises a steel case
containing a pcb (printed circuit board) and
space for backup batteries.
The pcb holds the power supply circuits and
provides two sets of terminals for a bus
connection.
The pcb also provides a range of connectors
for outputs, plug-by communicators, and up
to 10 FSL (Fully Supervised Loop) or five
CC (Closed Circuit) zones.
The EXP-PSU provides monitoring
messages to the control unit over the
system bus. These messages include
Remote PSU Fault, Remote AC Fail, Remote
Battery Fail, and Remote Low Output
Voltage.
The EXP-PSU is designed and approved to
be used as part of a Security Grade 2 or 3
system.
About this Guide
This guide shows the simple procedure
required to physically install the EXP-PSU,
connect it to the bus, zones and outputs for
an i-onEX alarm system.
When you have completed the physical
installation please consult the i-onEX
Engineering Guide for details of providing a
bus address for the unit.
2. Before You Begin
Preparation
Before installation you should carry out a
survey of the site. You need to know how
many and what kind of detectors will be
connected to the EXP-PSU.
Siting the EXP-PSU
WARNING Ensure that the fixings are
strong enough to support the weight of the
EXP-PSU, its lid and two 17Ah lead acid
batteries. The total weight of the EXP-PSU
plus batteries can be up to 18kg.
Do site the unit:
Close to the equipment it is powering.
Upright, batteries at the bottom.
Within a protected area.
Do NOT site the unit:
In the entry or exit zones, or outside
the area covered by the alarm system.
Next to electronic equipment,
particularly computers, photocopiers or
other radio equipment, CAT 5 data lines
or industrial mains equipment.
Guided Tour
CAUTION: The printed circuit board for the
EXP-PSU has been tested for
Electromagnetic Compatibility (EMC).
However, when handling the pcb you must
take the standard precautions for handling
static sensitive devices.
Opening the Case
To gain access to the interior of the EXP-
PSU undo the screw at the bottom of the
lid. Slide the lid vertically up, then swing
the bottom of the lid out before moving the
lid down and away from the case.
Figure 1 Opening the EXP-PSU.
WARNING: When connected to the mains
with power applied mains voltages are
present on the shrouded heads of the
terminal screws of the mains connector.

EXP-PSU
Page 2
1. Case back.
2. Cable entry holes for
loudspeakers and communicators.
3. Fixing holes.
4. Plastic PCB tray.
5. Printed circuit board (PCB).
6. Cable entry holes for detector
and keypad wiring.
7. Hole for back tamper fitting..
8. Space for batteries (two off).
9.Fused mains terminal block
10. Mains cable anchor point.
11. Cable entry hole for mains.
Figure 2 EXP-PSU
1. Bus connector IN (from control
unit).
2. Bus connector OUT (to portion
of bus powered by EXP-PSU).
3. Comms fuse fail LED.
4. Plug-by communicator
connector (1 of 2).
5. Tamper switch connector.
6. Aux 1 power connector.
7. Aux 1 power fuse.
8. Aux 1 fuse fail LED.
9. Zone connector.
10. Aux 2 connector.
11. Outputs (transistorised).
12. I-RC01 connector.
13.Aux 2 fuse fail LED.
14. Aux 2 fuse.
15. Kick Start pins.
16. Battery 1 connector.
17. Battery 2 connector.
18. AC in connector.
19. Bus address display.
20. Sounder.
21. Loudspeaker connector.
22. Bus Addressing button.
23. Engineering keypad connector.
24. Bus OUT fuse fail LED.
25. RS485 terminator.
26. Status LEDs (from the top):
MF = Mains Fail
LB = Low Battery
12V = 12V Fault
DIAG = See page 10
Figure 3 EXP-PSU Printed Circuit Board
0V
-LS+
AC IN
12V
AUX-2
0V A B
BUS IN
0V 12v A B
BUS OUT
OP3 OP2 OP1
Z6 Z7 Z8 Z9 Z10Z1 Z2 Z3 Z4 Z5
OP4
1
3
5
4
6
7
8
11
3
8
3
10
9
2
0V
-LS+
AC IN
1 2V
AUX-2
0V A B
BUS IN
0V 12v A B
BUS OUT
OP3 OP2 OP1
Z6 Z7 Z8 Z9 Z10Z1 Z2 Z3 Z4 Z5
OP4
118
17
16
15
14
13
12
910 11
2122232425 26 20 19
2
4
3
5
6
7
8

EXP-PSU
Page 3
Power Availability
Before connecting any devices to the EXP-
PSU, you must make sure that the unit can
provide sufficient current to power the
portion of the system it is connected to
during a mains failure for the time required
to meet the appropriate standard.
EN50131-1 Grade 3 requires 30 hours
provided that the control unit is fitted with
an ATS4 communicator capable of
transmitting a mains fail signal.
Note: When calculating the average load
during the standby time period you must
allow for at least two periods in alarm. To
take the worst case these two periods of
alarm should each be 15 minutes long, the
maximum permitted in EN50131-1 section
8.6.
PD6662 Grade 3, under the same
conditions, reduces the standby time
requirement to 12 hours.
The amount of current available from the
EXP-PSU depends on the size of battery
fitted and its health. The current taken by
the power supply‟s pcb, is given in
Technical Specifications –EN50131-6
Ratings on page 11.
The following calculation shows a simplified
example: in an alarm system with an EXP-
PSU which is connected to five i-kp01
keypads, and 40 wired PIRs and a wired
siren, the portion of the system powered by
the EXP-PSU takes the following total
quiescent current:
Device
Current
EXP-PSU PCB
50mA
40 x PIRs at 15mA each
600mA
3 x (wired expanders)
60mA
5 x i-kp01 at 30mA each
(backlights off)
150mA
Siren (quiescent)
25mA
Total
885mA
During an alarm, these figures become:
Device
Current
EXP-PSU PCB
100mA
40 x PIRs at 15mA each
600mA
3 x (wired expander)
60mA
5 x i-kp01 at 60mA each
(backlights off)
300mA
Siren (in alarm)
400mA
Total
1460mA
The total amp hours required =
(0.885 A x 29.5h) + (1.46A x 0.5h) =
26.83Ah
Note that this example assumes that the
communicator has its own power supply.
Two new, fully charged, 17Ah batteries can
provide the charge required by the portion
of the system in the example and would
meet the EN50131-1 Grade 3
requirements.
A single new, fully charged, charged 17A
battery can provide the charge required by
the example system for PD6662 Grade 3
requirements.
Note: All current drawn from the 12V Aux
terminals must be included in the overall
calculation.
CAUTION: Ensure that the system does not
demand more than the maximum current
available from the EXP-PSU during an
alarm, see page 11.

EXP-PSU
Page 4
Bus Cabling Requirements
Cable Type
In general, the EXP-PSU requires standard
7/0.2 un-screened four core alarm cable for
wiring the bus.
For maximum performance in harsh
environments use twisted pair screened
cable with a characteristic impedance of
100-120ohms eg: Belden 8132 or other
cable designed for RS485.
Use one pair for data lines A and B. Use the
other pair for 12V and 0V. For optimum
performance the voltage at the keypads
and expanders should be greater than 12V.
Screened cable may prove necessary if the
installation site has equipment that
produces high levels of R.F. (Radio
Frequencies). For example, welding
equipment is known to produce a large
amount of radio interference. If screened
cable is required, you should keep to the
following guidelines:
1. Avoid earth loops by connecting the
screen on the cable to mains earth at
the control unit but not at the keypad,
expander or EXP-PSU.
2. The continuity of the cable screen is
most important and screens MUST be
continuous along the full length of the
cable.
3. Where the cable enters any metal
enclosure, ensure the screen is isolated
from the case.
Cable Segregation
Segregate the bus cabling from any other
wiring, such as mains supply cables,
telephone cables, computer network cables
and R.F. cables. Use cable ties to keep
cables separated.
Keep the bus cable clear of cables supplying
sounders, extension loudspeakers or any
other high current devices.
Voltage Drop
In order for the system to work correctly,
the voltage at each device must NOT drop
below 10.5V even when running on the
standby battery. Cooper Security
recommend that the voltage at each device
should stay above 12V.
Standard 7/0.2 alarm cable has a
resistance of 8 Ohms per 100m per core.
The voltage drop is calculated using the
following formula: V Drop = Current drawn
x cable length x 0.08 x 2.
Table 1 on the next page shows the voltage
drop against the current drawn and cable
length.
The shaded area shows where the voltage
drop would cause the bus voltage to fall
from 13.8V to below 12.0V when using a
single core.
Reducing Voltage Drop - Method 1:
Double up the supply connections (12V and
0V), which will halve the resistance on each
core and therefore halve the voltage drop.
When using Table 1 to calculate the
expected voltage drop, simply divide the
voltage drop for a single core by two.
Reducing Voltage Drop - Method 2:
Supply the detection devices from the Aux
output on separate cores. This is the
preferred method of reducing voltage drop
as detectors generally operate at lower
voltages (9.5V). When using this method,
the network cable must have two spare
cores.
Connecting A Remote Power Supply
Figure 4 shows the recommended method
of connecting the EXP-PSU power supply.
The bus cable from the control unit
terminates on the EXP-PSU Bus In
connector and a new cable starts from the
EXP-PSU Bus Out connector. See page 6 for
more details.

EXP-PSU
Page 5
Table 1. Voltage Drop
Current
Drawn
Cable Length (Standard 7/0.2 alarm cable)
10m
20m
30m
40m
50m
60m
70m
80m
90m
100m
60mA
0.10V
0.19V
0.29V
0.38V
0.48V
0.58V
0.67V
0.77V
0.86V
0.96V
80mA
0.13V
0.26V
0.38V
0.51V
0.64V
0.79V
0.90V
1.02V
1.15V
1.28V
100mA
0.16V
0.32V
0.48V
0.64V
0.80V
0.96V
1.12V
1.28V
1.44V
1.60V
120mA
0.19V
0.38V
0.58V
0.79V
0.96V
1.15V
1.34V
1.54V
1.74V
1.92V
140mA
0.22V
0.45V
0.67V
0.90V
1.12V
1.34V
1.57V
1.79V
2.02V
2.24V
160mA
0.26V
0.51V
0.77V
1.02V
1.28V
1.54V
1.79V
2.05V
2.30V
2.56V
180mA
0.29V
0.58V
0.86V
1.15V
1.44V
1.73V
2.02V
2.30V
2.59V
2.88V
200mA
0.32V
0.64V
0.96V
1.28V
1.60V
1.92V
2.24V
2.56V
2.88V
3.20V
220mA
0.35V
0.70V
1.06V
1.41V
1.76V
2.11V
2.46V
2.82V
3.17V
3.52V
240mA
0.38V
0.79V
1.15V
1.54V
1.92V
2.30V
2.69V
3.07V
3.46V
3.84V
260mA
0.42V
0.83V
1.25V
1.66V
2.08V
2.50V
2.91V
3.33V
3.74V
4.16V
280mA
0.45V
0.90V
1.34V
1.79V
2.24V
2.69V
3.14V
3.58V
4.03V
4.48V
300mA
0.48V
0.96V
1.44V
1.92V
2.40V
2.88V
3.36V
3.84V
4.32V
4.80V
320mA
0.51V
1.02V
1.55V
2.05V
2.56V
3.07V
3.58V
4.10V
4.61V
5.12V
340mA
0.54V
1.09V
1.63V
2.18V
2.72V
3.26V
3.81V
4.35V
4.90V
5.44V
360mA
0.58V
1.15V
1.73V
2.30V
2.88V
3.46V
4.03V
4.61V
5.18V
5.76V
380mA
0.61V
1.22V
1.82V
2.43V
3.04V
3.65V
4.26V
4.86V
5.47V
6.08V
400mA
0.64V
1.28V
1.92V
2.56V
3.20V
3.84V
4.48V
5.12V
5.76V
6.40V
Figure 4. Connecting Remote Power Supply Units

EXP-PSU
Page 6
3. Installation
Note: The installation steps listed below
assume that you have already decided on
the required location for the EXP-PSU.
Caution: Static Electricity
Like many other electronic products, the
EXP-PSU contains components that are
sensitive to static electricity. Try not handle
the PCB directly. If you must handle the
PCB, take the standard precautions against
damage by static electricity.
Step 1. Fit the Case
Fitting
To prevent access to the inside of the EXP-
PSU through the holes in the rear of the
case you must mount the unit on a wall or
other flat surface.
Locate and mark the position of the case.
Mark the position where the lid/back
tamper bracket touches the wall.
Fit the tamper shroud at the position where
the lid/back tamper touches the wall, see
Figure 5.
Figure 5 Fitting Tamper Shroud.
Mount the case vertically, as shown in
Figure 2. Use all three fixing holes. Use
No14/M6 screws at least 50mm long,
inserted into wall anchors appropriate for
the type of wall. Figure 2 shows the fixing
holes and cable entries.
WARNING Ensure that the fixings are
strong enough to support the weight of the
EXP-PSU, its lid and two 17Ah lead acid
batteries. The total weight of the EXP-PSU
plus batteries can be up to 18kg.
Protect the unit from dust and drilling
debris when drilling the fixing holes.
Installing the Lid/Back Tamper
Fit and connect the combined lid/back
tamper (provided). Ensure that the switch
is oriented as shown in Figure 6.
Figure 6 Lid/Back Tamper
Item 5 in Figure 3 shows the connector for
the lid/back tamper.
Note that to be approved at Security Grade
3 you must fit the lid/back tamper.
Step 2. Run Bus Cable
Please read “Bus Cabling Requirements on
page 4.
Step 3. Connect EXP-
PSU to the Bus
The EXP-PSU provides two bus connectors
(items 1 and 2 on Figure 3).
Figure 7 Bus Wiring EXP-PSU
Use the BUS IN connector to terminate the
bus cable from the part of the system that
is being powered by the control unit (or
other remote power supplies).
CAUTION DO NOT connect the 12V line of
the bus to BUS IN.
Use the BUS OUT connector to terminate
the bus cable to the portion of the system
being supplied by the EXP-PSU.
0V
+12V
B
0V
From control unit Bus In
Bus Out
To rest of system
A
B
A

EXP-PSU
Page 7
Addressing the EXP-PSU
The control unit assigns addresses to all
devices connected to the bus. You must
start this process off once the EXP-PSU is
connected, during the system power up.
See i-on160EX Engineering Guide for
instructions.
Step 4. Connect to Mains
WARNING: ENSURE THAT THE MAINS
SUPPLY IS DISCONNECTED AND ISOLATED
BEFORE MAKING ANY MAINS
CONNECTIONS. All mains electrical
connections must be carried out by a
qualified electrician and must comply with
the current local regulations (e.g. IEE).
Mains Cabling
Note: To avoid mains interference, the
mains cable must enter the EXP-PSU
through its own cable entry hole ( 9 in Fig
2) and must not be mixed with other
cables.
Mains Connection
Figure 8 shows the mains connection.
Connect to a suitable supply using a double
pole disconnect device in accordance with
EN60950-1.
Caution: Do not apply power at this
point.
Anchor the mains cable with a strain-relief
tie. There is a eye located near the mains
cable entry hole for this purpose.
Figure 8 Mains Connection
Step 5. Connect Wired
Zones
The EXP-PSU can be used for either four
wire Closed Circuit (CC) detectors, or two
wire Fully Supervised Loop (FSL) detectors.
Four Wire Closed Circuit Connections
Figure 9 shows the wiring for CCL zones on
the EXP-PSU.
Figure 9 EXP-PSU CCL Zone Wiring
Fully Supervised Loop Connections
Figure 10 shows the wiring connections for
FSL zones on the EXP-PSU. Note that the
resistance values shown are examples.
Figure 10 FSL Zone Wiring –EXP-PSU
The allowed values for Alarm Contact/End
of Line are: 4k7/2k2. 1k0/1k0, 2k2/2k2, or
4k7/4k7.
Note: Use the same pair of values for ALL
FSL wired circuits on the EXP-PSU.
When programming select the FSL resistor
values for the EXP-PSU in Installer Menu –
Detectors Devices –Wired Expanders - Edit Expander.
If you wish to connect two or more
detectors to a FSL zone, Figure 11 shows
the connections required.
L N
T500mA 250V
230V ~50Hz 350mA

EXP-PSU
Page 8
Figure 11 Wiring Two Detectors per Zone
FSL.
Figure 12 shows an example of wiring
double doors with two door contacts to one
FSL zone. Each door contact is a reed
switch, connected between the outer
terminals. The inner (shaded) terminal is
not connected, and provides a spare
terminal.
Figure 12 Example: Wiring Two Door
Contacts to One FSL Zone.
Figure 13 shows an example of wiring a
trouble/masking output using the “3-
resistor method”. Note that you must use
2k2 and 4k7 resistors as shown. Other
values will not work (See System Options –
Masking in the i-on160EX Engineering
Guide).
Figure 13 Example: Wiring a
Trouble/Masking Zone, 3 Resistor Method.
Step 6. Connect Wired
Outputs
Remote Loudspeaker (Optional)
If you wish to add a 16 Ohm wired
Loudspeaker unit, then connect it as shown
in Figures 14. Do not connect another
loudspeaker in parallel.
Figure 14 Connecting Wired Peripherals
Note: Loudspeakers are not warning
devices as described by EN50131-4.
Although loudspeakers may mimic alarm
tones, they also give alert tones and other
progress tones when setting and unsetting
the alarm system.
During normal operation any loudspeakers
connected to the EXP-PSU repeat setting
and entry tones for the partition that the
unit is allocated to. During an alarm the
loudspeakers repeat alarm tones.
Each 16 Ohm loudspeaker draws up to
280mA in operation. If there is more than
one loudspeaker connected to the EXP-PSU
then the +12V line on the Bus Out
connector may not be able to supply
sufficient current during an alarm.
Wired Outputs
The EXP-PSU provides connections for up to
four transistor driven outputs. By default
the outputs are 0V when active, +12V
when inactive. If you wish to reverse the
polarity of these outputs see Changing the
Polarity of a Wired Output in the i-onEX Engineering
Guide. Figure 15 shows an example of using
an expander output to drive an LED.
Figure 15 Using EXP-PSU Wired Outputs.
If required you can connect an i-rc01 relay
card to the pins immediately above the
output terminals (see 12 in Figure 3) or
directly to the output terminals. The i-rc01
provides four voltage free outputs that
mimic OP1 to OP4.
Zone1 2K2 EOL
4K7
Alarm contacts Alarm contacts
Tampercontacts Tamper contacts
Max 10 devicesper circuit (notrecommended)
2K2 EOL
Spare
ContactsContacts
4K7 Black
Red
Blue
To zone 
contacts Yellow
Zone 1 2K2 EOL
4K7
2K2
Alarm contacts
Trouble contacts Tamper contacts
+LS
-LS
-LS +

EXP-PSU
Page 9
Step 7. Fit a Plug-By
Communicator
The EXP-PSU can be connected to a
separate communicator or speech dialler
(for example, the Scantronic 8400, 660,
RedCare GSM or RedCare Dual Com).
Figure 16 shows the connections provided
by the communications wiring harness.
Each output pin of the communications
connector on the EXP-PSU follows the state
of the corresponding pin on the control
unit. These EXP-PSU communication
outputs cannot be programmed
independently of the control unit
communication outputs. Note that the
output types shown in Figure 16 are the
Factory default types. See the i-onEX
Security System Engineering Guide for
details on how to change the defaults on
the control unit (and, in consequence, on
the EXP-PSU).
Figure 16 Plug-By Communicator Wiring
Note: Comms O/P4 will be active when the
system is unset. This is normal.
To fit a communicator, follow the
instructions below.
Caution: Follow the instructions in the order
shown, or you may damage the EXP-
PSU and/or communicator.
1. Disconnect mains power from the EXP-
PSU, remove the case lid, and
disconnect the battery (if the system
has already been installed).
2. Make any necessary connections from
the communicator to the communication
wiring harness. The default is a 12V
positive voltage when the output is
inactive.
Refer to the next section if you are
using a dual-path communicator.
3. Plug the Communication Wiring Harness
onto the communications connector on
the main PCB.
If the system has already been installed:
4. Re-connect the battery.
5. Fit the case lid.
6. Apply mains power.
7. Test communicator operation.
Note: You will need to speak to the ARC in
order to confirm that the communicator has
worked correctly.
Line Monitoring for a Dual-Path
Communicator
If a standalone dual-path (landline and
mobile) communication device, such as a
RedCARE GSM, is connected to the plug-by
connector, you need to do the following to
obtain correct line fault reporting that
complies with BSIA Form No.175, April
2005:
1. Reprogram one of the plug by outputs
to type “ATS Test” and wire that output
to the ATS Test input of the
communicator.
2. Wire the Line Fault output of the
communicator to the Line Fault input of
the plug-by connector. The
communicator must provide +12Vdc to
indicate a line fault (for example, if the
Line Fault output at the communicator
uses a relay, connect the common
terminal of the relay to +12Vdc and the
normally-open terminal to the Line Fault
input of the plug-by connector).
The control unit will generate an "ATE L.F.
Single" alert if only one of the networks is
not available, or "ATE L.F. All" if both
networks are not available.
Step 8. Fit and Connect
Battery
Fit either one to two 17Ah Lead Acid
batteries into the battery compartment in

EXP-PSU
Page 10
the bottom of the EXP-PSU. Use batteries
whose case material has a minimum rating
of UL94V-2 in order to comply with
EN60950 (this standard applies because of
the energy content of 17Ah batteries).
See Figure 17. See page 3 for example
calculations of battery requirements.
WARNING 17Ah lead acid batteries
weigh 6kg each. Do NOT drop.
Connect the battery leads, red to the
positive, black to the negative terminals of
the battery. Connect the other ends of the
leads to either BATT1 or BATT2 (16 and 17
on Figure 3).
If you are fitting only one battery then
connect it to BATT1 (the lower set of pins)
and disable alerts on BATT2 (see the i-onEX
Range Engineering Guide).
Figure 17 Fitting the Batteries
Note: Connecting the batteries without
mains power will not start the system. (See
“Programming Before Installation” in the i-
on160EX Engineering Guide.)
Step 9. Initial Power-Up
Please see the i-onEX Security System
Engineering Guide for an explanation of bus
addressing.
When you apply power to the unit you may
notice the DIAG LED flashing (see 26 on
Figure 3). The LED gives one, two, three or
four flashes a second. Each of these
sequences has the following meaning.
No. Flashes
Meaning
One
Communication with control
unit over bus is OK
Two
No communication over the
bus in the last 10 seconds.
Three
No bus address allocated to
EXP-PSU
Four
No poll request received
from control unit in the last
minute.
The other status LEDs on the pcb (26 in
Figure 3) have the following meaning:
MF
Red=No mains AC.
LB
Amber = Absent or faulty
battery
12V
Red=12V fault
When glowing the following LEDs indicate
possible short circuits in the cabling.
Comms fuse
fail (3 in
Figure 3)
Red=communication outputs
failed. See Note 1
Aux 1 fuse
fail (8 in
Figure 3)
Red=Aux 1 fuse blown. See
Note 2
Aux 2 fuse
fail (13 in
Figure 3)
Red=Aux 2 fuse blown. See
Note 2
Bus OUT
fuse fail (24
in Figure 3)
Red=The output power on
the bus has failed. See Note
1
Notes:
1. These outputs are protected by
polyswitches, which will reset themselves
when the short is removed.
2. These outputs are protected by F-1A
20mm fuses which must be replaced once
the short is removed.
Step 10. Re-fit The Lid
Assemble and close the EXP-PSU:
a) Fit the lid of the EXP-PSU into the
back of the case (see Fig 18).
b) Fit and tighten the lid fixing screw.
Figure 18 Replacing the EXP-PSU lid.

EXP-PSU
Page 11
4. Maintenance
The EXP-PSU should be inspected at least
once per year. At each inspection:
Check the unit for obvious signs of
damage to the case or its lid.
Check the action of the back tamper.
Check the condition of the standby
battery.
Check the cabling to EXP-PSU
expander(s) for signs of damage or
wear.
Test any sounders.
Note that if you wish to find the location of
any keypad or expander you can employ
the Test –Locate Bus Device option in the
Installer Menu. Use this option to make a
selected bus device give a continuous tone
from its sounder. Once you have found the
bus device you can silence the tone by
opening the case and so activating the
device‟s tamper.
5. Technical
Specification
General
Product name
EXP-PSU.
Product
Description
External PSU with wired
zones and plug by
communicator connection.
Manufacturer
Cooper Security Ltd.
Environmental
Class II.
Operating
temperature
Tested -10 to +55°C.
Humidity
0 to 93% RH, non-
condensing.
Case material
Steel.
Dimensions:
Size:
427 x 400 x 101, mm HxWxD.
Weight:
6 kg (without stand-by
batteries).
Capacities
Zones
10 max
Outputs
16 plug-by communicator
outputs, plus 4 open
collector transistor outputs
Loudspeakers
1 output, minimum
impedance 16 Ohms
Power Supply
This product complies with the requirements of
EN50131-6 Type A power supply at Grade 3 and
environmental class 2.
Power supply type
A
Mains power supply
requirements
230VAC +10%/-15%,
350mA max, 50Hz.
Total power supply
capacity:
3.0A
(of which 1.5A is
used for battery
recharge and 1.5A is
available for
powering the
system).
Aux 1 12V supply*:
1A max
Aux 2 12V supply*:
1A max
Comms power
supply*:
400mA max
12V Expander Bus
OUT*:
400mA max
LS connectors
280mA in alarm.
*Note: The ratings given here represent the
maximum current that can be drawn before
triggering over-current protection.
EN50131-6 ratings
The EXP-PSU provides space for two 17Ah
batteries, giving a total of 34Ah charge.
Under EN50131-1 for Security Grade 3
installations the required battery standby
time is 30 hours, provided the system is
fitted with an ATS4 communicator capable
of transmitting a mains fail signal
This means that all the devices powered by
those backup batteries, within the EXP-
PSU, including the EXP-PSU itself, should
together draw no more in total than an
average of 1.1A over a 30 hour standby
time. Note that for Security Grade 3 the i-
on160EX or EXP-PSU must use a plug-by
communicator, which may have its own
power supply.
Under PD6662, battery standby time
requirements for Security Grade 3 drop to
12 hours, provided the system is fitted with
an ATS4 communicator capable of
transmitting a mains fail signal.
For Security Grade 2 the required battery
standby time is 12 hours. However, the
total average current available over 12
hours from the EXP-PSU batteries is limited
by the power supply to 1.5A. (The current
is limited to 1.5A because when mains is
present the 3.0A power supply reserves
2x750mA to recharge batteries, leaving
1.5A available to supply the system.)

EXP-PSU
Page 12
To meet Security Grade 2 the control unit
can be fitted with a plug-on communicator,
for example the i-sd02.
The table below shows the current
consumption of the EXP-PSU itself and each
device that can be fitted to it.
EXP-PSU power
requirement:
50mA quiescent.
100mA max
Keypad power
requirement:
30mA (backlight off)
45mA (backlight on)
65mA (backlight on)
60mA in alarm
Wired Expander
requirement
20mA max quiescent.
300mA in alarm if
sounder connected.
Radio Expander
requirement
40mA max quiescent
320mA in alarm if
sounder connected.
Battery charging
requirement:
750mA per battery
(recharge within 24
hrs)
Plug-by
Communicator pins
require:
5mA each when
active.
10 FSL zones
5mA
5 CCL zones
7mA
12V Bus output
voltage range :
10±0.5V to 13.8V
Aux 1 & 2 12V
output voltage
range:
10±0.5V to 13.8V
Max p-to-p ripple
voltage:
0.5V
Standby Battery:
12V, 17Ah sealed
lead acid, 2 off (not
supplied).
„Low battery‟ fault
at:
< 12V
Aux power output
fault at:
< 9V
Deep discharge
protection at:
10±0.5V
Standby time:
See “Power
Availabillity” on page
3.
Electromagnetic
Compatibility
Immunity
Conforms to EN50130-4.
Emissions
Conforms to EN61000-6-3.
Outputs
O/P 1 - 4
Open collector transistor,
+12VDC when inactive, 0V
when active. 500mA max.
Plug-by O/P
1-16
Open collector transistor
+12VDC when inactive, 0V
when active, 50mA max.
LS
(loudspeaker)
Min impedance 16 Ohm per
output, current
consumption = 280mA in
alarm.
Fuses
The EXP-PSU has a replaceable T500mA
mains fuse.
The Aux 1 and Aux 2 outputs are protected
by separate F-1A 20mm fuse.
Electrical Safety
Conforms to EN60950-1.
Compliance Statements
The EXP-PSU is a type B ACE (as defined in
EN50131-3 clause 8.7).
The EXP-PSU is compliant with EN50130-5
environmental class II.
The EXP-PSU is suitable for use in systems
designed to comply with PD 6662: 2004 at
grade 3.
When installed correctly the EXP-PSU is
capable of compliance with EN50131 at
Grade 3.
If the installer selects a non-compliant
configuration then they must remove or
adjust compliance labelling
Compatible Equipment
i-on160EX 160 zone expandable
control panel
i-on30EX (available end of 2011)
30 zone expandable
control panel
i-rc01 Relay Card
KEY-ENG Engineering keypad.
xcelw Wired PIR
xcelwpt Pet tolerant wired PIR
