COPLAR LTA-LG-01 User manual

- 1 -
O
Op pe er ra at to or r’ ’s sM Ma an nu ua al lo of f
L
Li in ne eT Tr ri im mm me er rA At tt ta ac ch hm me en nt t
Thank you for buying our Gardening tools
SAVE THIS MANUAL FOR FUTURE REFERENCE
LTA-LG-01

- 2 -
TABLE OF CONTENTS
Safety Rules 4-5
Description 6-7
Assembly 8
Operation 9
Maintenance 10-11
PDF created with FinePrint pdfFactory Pro trial version www.pdffactory.com

- 3 -

- 4 -
SAFETY RULES
SAVE THESE INSTRUCTIONS
GENERAL SAFETY RULES
1. For safe operation, read and understand al instructions before using the straight shaft trimmer
attachment. Follow all safety instructions. Failure to follow all safety instructions listed below, can
result in serious personal injury.
2. Do not allow children or untrained individuals to use this unit.
3. Wear safety glasses or goggles that are marked to comply with ANSI Z87.1 standards and hearing
protection when operating this unit.
4. Wear heavy long pants, boots, and gloves. Do not wear loose fitting clothing, short pants, jewelry of
any kind, or go barefoot.
5. Secure long hair so it is above shoulder level to prevent entanglement in any moving parts.
6. Keep all bystanders, children, and pets at least 50 ft (15 m) away.
7. Do not operate this unit when you are tired, ill or under the influence of alcohol, drugs, or
medication.
8. Do not operate in poorlighting.
9. Keep firm footing and balance. Do not overreach. Overreaching can result in loss of balance or
exposure to hot surfaces.
10. Keep all parts of your body away from any moving part.
11. When using the attachment on a trimmer with a gasoline engine, do not touch areas around the
muffler of cylinder of the power head, these parts get hot from operation. Failure to do so could
result in possible serious personal injury.
12. Always stop the engine and remove the spark plug wire or disconnect from power supply before
making any adjustments or repairs except for carburetor adjustments.
13. Inspect unit before each use for loose fasteners, damaged or missing parts. Correct before using the
straight shaft trimmer attachment. Failure to do so can cause serious injury.
14. Use only original manufacturer’s replacement parts. Failure to do so, may cause poor performance,
possible injury, and will void your warranty.
15. Do not, under any circumstance, use any attachment or accessory on this product which was not provided with
the product or identified as appropriate for use with this product in the Operator’s Manual.
16. Avoid dangerous environment. Do not use the attachment in damp or wet locations.
17. Do not use in rain.
18. Use the right attachment, do not use attachment for any job except that for which it is intended.
SPECIFIC SAFETY RULES FOR TRIMMER USE
1. Replace string head if cracked, chipped, or damaged in any way. Be sure the string head is properly
installed and securely fastened. Failure to do so can cause serious injury.
2. Make sure all deflectors and handles are properly and securely attached.
3. Use only the manufacturer’s replacement stringin the cutting head. Do not use any other cutting
attachment unless specifically noted in operator’s manual.
4. Never operate string trimmer without the grass deflector in place and in good condition.
5. Maintain a firm grip on both handles while trimming. Keep string head below waist bevel. Never cut
with the string head located over (30 in.) 76 cm or more above the ground.
WARNING:
Read and understand all instructions. Failure to follow all instructions listed below, may
result in electric shock, fire and/or serious personal injury.

- 5 -
SAFETY RULES
SAFETYRULES WHEN ATTACHMENT IS ATTACHED TO AN ELECTRIC POWERHEAD
1. When this attachment is being used with the
recommended electric power unit, refer to
“Electrical Safety Rules” in the electric power
unit’s Operator’s Manual, in addition to items
contained in this manual.
2. Make sure the cord is located so that it will not be
stepped on, tripped over, or otherwise subjected to
stepped on, tripped over, or otherwise subjected to
damage or stress. Keep cord clean of the working
area.
3. Do not abuse the power cord. Never carry the
product by the cord. Never yank the plug out of the
receptacle. Keep the cord away from heat, oil, and
sharp edges.
4. Inspect extension cords for deterioration, cuts, or
cracks in the insulation. Repair or replace the cords
if any defects appear.
WARNING:
Keep the extension cord clear of th
e
working area. Position the cord so that i
t
will not come in contact with the edge
r
attachment when in use. Failure to do so
can result in serious personal injury.
WARNING:
Check extension cords before each use.
If damaged replace them immediately.
Touching the damaged area could caus
e
serious injury due to electrical shock.

- 6 -
DESCRIPTION
Before using the Straight Shaft Trimmer Attachment, familiarize yourself with all operating features and
safety requirements.
PART LIST OF LINE TRIMMER ATTACHMENT
Item Description Item Description
1 Stringhead Ass'y 14 Blade & Shield Kit
2 Retainer-spool (L.H.Thread) 15 Pan head screw
3 Spool & string Ass'y 16 Blade-cut off
4 Spring-compression 17 Grass shield
5Housing & eyelet Ass'y 18 Cap head screw
6 Adapter-stringhead 19 Boom ass'y
7 Washer-flanged 20 Shaft-flexible
8 Gearhead & screw kit 21 Driveshaft housing ass'y
9 Gear head Ass'y 22 Dustproof cover
10 Hexagon head screw M5X12 23 Hanger
11 Flat- washer 24 Brush cutter kit warning label
12 Cap head screw M6X30 25 Decal warning label
13 Clampfor grass shield 26 Brand label
WARNING:
Do not allow familiarity with your tool to make you careless. Remember that a careless fraction of a second is
sufficient to inflict severe injury.

- 7 -
DESCRIPTION
Fi
g
.1

- 8 -
ASSEMBLY
JOINING THE POWER HEAD TO THE STRAIGHT SHFT TRIMMER TTACHENT
See Figure 2.
The straight shaft trimmer attachment connects to the power head by means of a coupler device.
1. Loosen the knob on the coupler of the power head shaft and remove the end cap from the
attachment shaft .
2. Push in the button located on the straight shaft trimmer attachment shaft. Align the button with the
guide recess on the power head coupler and slide the two shafts together. Rotate the straight shaft
trimmer attachment shaft until the button locks into the positioning hole.
NOTE:If the button does not release completely in the positioning hole, the shafts are not locked
into place. Slightly rotate from side to side to side until the button is locked into place.
3. Tighten the knob securely.
REMOVING THE ATTACHMENT FROM THE POWER HEAD
For removing or changing the attachment:
1. Loosen the knob.
2. Push in the button and twist the shafts to remove and separate ends.
TO ATTACH THE STRAIGHT SHAFT GRASS DEFLECTOR See Figure 3.
1. Remove the wing screw from the grass deflector.
2. Insert the tab on the mounting bracket in the slot on the grass deflector.
3. Align the screw hole in the mounting bracket with the screw hole in the grass deflector.
4. Insert the wing screw through the mounting bracket and
5. Tighten the wing screw securely.
WARNING:
N
ever attach or adjust any attachment while power head is running. Always Stop the unit and remove the spar
k
p
l
ug
wire or disconnect from the
po
wer s
upp
l
y
. Failure to heed this warni
ng
can cause serious
p
ersonal in
j
ur
y
.
WARNING:
Be certain the knob is fully tightened before operating equipment; check it periodically for tightness during use
to avoid serious in
j
ur
y
or
p
roduct dama
g
e.

- 9 -
OPERATION
OPERATING THE TRIMMER See Figure 4.
Hold the trimmer with the right hand on the rear handle and the left hand on the front handle. Keep a
firm grip with both hands while in operation. Trimmer should be held at a comfortable position with the
rear handle about hip height.
Cut tall grass from the top down. This will prevent grass from wrapping around the shaft and string head,
which may cause damage from overheating. If grass becomes wrapped around the string head, stop the
engine, remove the spark plug wire or disconnect from the power supply, and remove the grass.
NOTE:When the attachment is being used on a trimmer with a gasoline engine, always operate at full
throttle. Prolonged cutting at partial throttle will result in oil dripping from the muffler.
ADVANCING THE STRING
ADVANCING STRING USING THE LINE TAP ADVANCE SYSTEM
String advance is controlled by tapping string head on grass whilerunning engine at full throttle.
1 Run engine at full throttle.
2 Tap string head on ground to advance string. String advances each time the head is tapped.
3 Several taps may be required until string strikes the cut off blade.
4 Resume trimming.
NOTE:If the string is worn too short you short you may not be able to advance the string by tapping it
on the ground. If so, stop the engine, remove the spark plug wire or disconnect from the power supply,
and manually advance the string.
ADVANCING THE STRING MANUALLY
Push the spoolretainer down while pulling on string(s) to manually advance the string.
CUTTING TIPS See Figure 5.
1. Keepthe trimmer tilted toward the area being cut; this is the best cutting area.
2. Do not cut in dangerous cutting area.
3. Use thetip of string to do the cutting;do not force string head into uncut grass.
4. Wire and picket fences cause extra string wear, even breakage. Stone and brick walls, curbs, and wood may
wear string rapidly.
5. Avoid trees and shrubs. Tree bark , wood moldings, siding, and fence posts can easily be damaged by thestring.
GRASS DEFLECTOR LINE TRIMMING CUT-OFF BLADE See Figure 6.
This trimmer is equipped with a line trimming cut-off blade on the grass deflector. For best cutting,
advance string until it is trimmed to length by the cut-off blade. Advance string whenever you hear the
engine running faster than normal. This will maintain best performance and keep string long enough to
advance properly.

- 10 -
MAINTENANCE
You may make adjustments and repairs described in the maintenance section. For other repairs, have the
unit serviced by an authorized servicing dealer.
SPOOL REPLACEMENT LINE TAP ADVANCE SYSTEM
NEW PREWOUND SPOOL
See Figures 7 and 8.
If replacing string only, refer to “String Replacement ” later in this manual.
Use only .080 in (2.0 mm) diameter monofilament string.
Use the manufacturer’s replacement parks for best performance.
1 Stop the engine, disconnect the spark plug wire or disconnect from the power supply. Hold the string
head and unscrew the spoolretainer. Turn clockwise.
2Remove the empty spool from the string head. Use the spring from the empty spool if one is not
ovided with the new spool and string.
3To install the new spool, make sure the two strings are captured in the slots opposite each other on
the new spool. Make sure the ends of each string are extended approximately 6 in. (152 mm) beyond
each slot.
4Thread the strings into the eyelets in the sting head. Carefully push the spool the spool into the string
head (gently pull the strings to the outside if necessary). When the spool is positioned in the string
head, grasp the strings and pull sharply to release them from the slots in the spool.
5Push down and turn the spool counterclockwise until it no longer turns. Hold the spool down and
rotate clockwise a small amount. Release the spool. The spool should be locked down in string head.
If not, hold down and rotate until locked.
6Make sure the string head and the spoolretainer are installed o the shaft by turning the retainer
counterclockwise to tighten.
7Pull the strings again to rotate the spool into cutting position. Push the spoolretainer down while
pulling on string(s) to manually advance the string and to check for proper assembly of the string
head.
STRING REPLACEMENT
See Figures 9, 10, 11, and 12.
1 Stop the engine, disconnect the spark plug wire or disconnect from the power supply. Hold the string
head and unscrew the spool from the string head.
2 Remove the spool from the string head.
NOTE:Keep the spring attached to the spool. Remove any old string remaining on the spool.
3 Cut two pieces of string, each being approximately 9 ft. (2.7 m ) long.
4 Insert the first string into the anchor hole the upper part of the spool. Wind the first string around the
upper part of the spool counterclockwise, as shown by the arrows on the spool. Place string in the
slot on upper spool flange, leaving about 6 in. (152 mm ) extended beyond the slot. Do not overfill.
After winding the string, there should be at least 1/4 in. (6mm) between the wound string and the
outside edge of the spool.
5 Repeat above step with second string, using the bottom part of spool. Do not overfill.
6 Replace the spool and the spoolretainer. Refer to “Spool Replacement” earlier in this manual.
WARNING:
Use only original manufacturer’s replacement parts, accessories and attachments. Failure to do so may cause
poo
r
p
erformance
,po
ssible in
j
ur
y
and ma
y
void
you
r warrant
y
.

- 11 -
MAINTENANCE
STORING THE STRAIGHT SHAFT TRIMMER ATTACHMENT
Store the straight shaft trimmer attachment in a well ventilated place that is inaccessible to children.
Keep away from corrosive agents such as garden chemicals and deicing salts.
To remove the straight shaft trimmer attachment from the power head for storage:
1 Loosen the knob on the coupler device.
2 Push the button in, then twist the shafts to remove and separate the power head from the attachment.
For storing information: Please refer the Operator’s Manual of your power head.
ATTACHING THE STORAGE HANGER
See Figure 13.
There are two ways to hang your attachment for storage.
1. To use the hanger cap, push in the button and place the hanger cap over end of the straight shaft
trimmer attachment shaft. Slightly rotate the cap from side to side until the button into place.
2. The secondary hole in the straight shaft trimmer attachment shaft can be use for hanging purposes as
well.
