Copper Canyon Lighting HF-5009LCD User manual

Save These Instructions – For Household Use Only
Owner’s Manual
MODEL: HF-5009LCD
POWER: 120V, 60Hz WATTAGE: 1,200W
When using electrical appliances, basic safety precautions
should always be followed. Do not use the Copper Chef Power
AirFryer Plus until you have read this manual thoroughly.
Warranty Information Inside

23.2-Qt. Copper Chef Power AirFryer Plus | Model: HF-5009LCD 3.2-Qt. Copper Chef Power AirFryer Plus | Model: HF-5009LCD 3
Important Safeguards 4
Parts & Accessories 6
Using the Control Panel 8
Instructions for Use 10
Cooking Chart 12
Troubleshooting 13
Frequently Asked Questions 14
Warranty 15
CONGRATULATIONS
We all love fried food...
Crispy fried chicken, french fries, coconut shrimp,
chicken parmesan, spicy hot wings... the list goes
on and on. Those tasty delights have become part
of our everyday diet. Until now, it was impossible
to get that great, crispy-fried crunch and avor
without frying in deep fat or oil.
Good News!
The new Copper Chef Power AirFryer Plus has
changed everything. Our culinary design team has
perfected a cooking system that virtually eliminates
the oil from the process. Messy, unhealthy oil is
replaced with Turbo Cyclonic Air that surrounds your
food, cooking it to crisp and juicy perfection.
The Copper Chef Power AirFryer Plus...
Not only cooks your favorite fried foods but also
broils and bakes many other favorites like air-fried
burgers, calzones, and doughnuts. It couldn’t
be easier! You and your family will enjoy many
years of crispy, mouthwatering meals and snacks
with the Copper Chef Power AirFryer Plus.
BEFORE YOU BEGIN
The Copper Chef Power AirFryer Plus will provide
you many years of delicious family meals and
memories around the dinner table. But before you
begin, it's very important that you read this entire
manual, making certain that you are totally familiar
with this appliance's operation and precautions.
Copper Chef Power AirFryer Plus Table of Contents

43.2-Qt. Copper Chef Power AirFryer Plus | Model: HF-5009LCD 3.2-Qt. Copper Chef Power AirFryer Plus | Model: HF-5009LCD 5
1. READ AND FOLLOW all instructions carefully.
2. NEVER immerse the Main Unit Housing, which
contains electrical components and heating
elements, in water. Do not rinse under the tap.
3. THIS APPLIANCE IS NOT INTENDED FOR
use by persons with reduced physical, sensory,
or mental capabilities or lack of experience and
knowledge unless they are under the supervision
of a responsible person or have been given
proper instruction in using the appliance. This
appliance is not intended for use by children.
4. TO AVOID ELECTRICAL SHOCK, do not put
liquid of any kind into the Main Unit Housing
containing the electrical components.
5. THIS APPLIANCE HAS A POLARIZED PLUG
(one blade is wider than the other). To reduce
the risk of electric shock, this plug is intended
to t into a polarized outlet only one way. If the
plug does not t fully into the outlet, reverse the
plug. If it still does not t, contact a qualied
electrician. Do not attempt to modify the plug in
any way.
6. MAKE SURE the appliance is plugged into
a wall socket. Always make sure that the plug
is inserted into the wall socket properly.
7. DO NOT place the Unit on the stove top. Place
on a at, horizontal surface with adequate space
for air ow. Do not place other appliances within
5 in. of the Unit.
8. TO PREVENT food contact with the heating
elements, do not overll.
IMPORTANT SAFEGUARDS IMPORTANT SAFEGUARDS
9. DO NOT cover the Air Intake Vent or Hot Air Outlet
Vent while the Copper Chef Power AirFryer Plus is
operating. Doing so will prevent even cooking and
may damage the Unit or cause it to overheat.
10. NEVER pour oil or any other liquids into the
Outer Basket. Fire and personal injury could result.
11. WHILE COOKING, the internal temperature of
the Unit reaches several hundred degrees F. To
avoid personal injury, never place hands inside
the Unit unless it is thoroughly cooled down.
12. DO NOT use this Unit if the plug,
the power cord, or the appliance itself
is damaged in any way.
13. IF THE POWER CORD IS DAMAGED, you must
have it replaced by Tristar, its service agent,
or a similarly qualied person in order to avoid
hazard.
14. KEEP the appliance and its power cord out of
the reach of children when it is in operation or in
the cooling down process.
15. KEEP the power cord away from hot surfaces.
Do not plug in the power cord or operate
the Unit controls with wet hands.
16. NEVER connect this appliance to an external
timer switch or separate remote-control system.
17. NEVER use this appliance with an extension
cord of any kind.
18. DO NOT operate the appliance on or near
combustible materials, such as tablecloths,
paper towels, or curtains.
19. WHEN COOKING, do not place the appliance
against a wall or against other appliances. Leave
at least 5 in. free space on the back and sides
and above the appliance. Do not place anything
on top of the appliance.
20. DO NOT USE the Copper Chef Power AirFryer
Plus for any purpose other than described in this
manual.
WARNING
When using electrical appliances, always follow
these basic safety precautions.
PREVENT INJURIES! – CAREFULLY READ
ALL INSTRUCTIONS BEFORE USE!
21. NEVER operate the appliance unattended.
22. WHEN IN OPERATION, hot steam is released
through the Hot Air Outlet Vent. Keep your
hands and face at a safe distance from the Hot
Air Outlet Vent. Also avoid the hot steam and air
while removing the Outer Basket and Fry Tray
from the appliance.
23. THE UNIT’S OUTER SURFACES may become
hot during use.The Outer Basket and Fry Tray
will be hot. Wear oven mitts when handling hot
components or touching hot surfaces.
24. SHOULD THE UNIT EMIT BLACK SMOKE,
unplug immediately and wait for smoking to
stop. Allow the Unit to cool and wipe out excess
oil and grease from the Unit. Do not use any
cleaning agent.
• Always operate the appliance on
a horizontal surface that is level, stable,
and noncombustible.
• This appliance is intended for normal household
use only. It is not intended for use in commercial
or retail environments.
• If the Copper Chef Power AirFryer Plus is
used improperly or for professional or semi-
professional purposes or if it is not used
according to the instructions in the user manual,
the guarantee becomes invalid and Tristar will
not be held liable for damages.
• Always unplug the appliance after use.
• When the cooking time has completed, cooking
will stop and the fan will continue running for 10
secs. to cool down the Unit.
• Let the appliance cool down for approximately
30 mins. before handling, cleaning, or storing.
• The Copper Chef Power AirFryer Plus is
equipped with an internal microswitch that
automatically shuts down the fan and heating
element when the Outer Basket is removed.
CAUTION
Electric Power
The unit should be operated on a dedicated
electrical outlet. If the electrical outlet is being
used by other appliances, your Unit may not
operate properly.
Electromagnetic Fields
This unit complies with all standards regarding
electromagnetic elds. If handled properly and
according to the instructions in this user manual,
the Unit is safe to use based on scientic
evidence available today.
Overheating Protection
Should the inner temperature control system fail,
the overheating protection system will be
activated and the Unit will not function.
Should this happen, unplug the Unit. Allow time
for the Unit to cool completely before restarting
or storing.
Automatic Shut-Off
The Unit has a built-in shut-off device that
will automatically shut off the Unit when the
cooking time has completed. You can manually
switch off the Unit by pressing the Power
Button. The fan will continue running
for 10secs. to cool down the Unit.
SAVE THESE INSTRUCTIONS – FOR HOUSEHOLD USE ONLY

63.2-Qt. Copper Chef Power AirFryer Plus | Model: HF-5009LCD 3.2-Qt. Copper Chef Power AirFryer Plus | Model: HF-5009LCD 7
Parts & Accessories Parts & Accessories
1. FRY TRAY
2. OUTER BASKET
3. EASY-GRIP HANDLE
4. MAIN UNIT HOUSING
5. AIR INLET VENT
6. CONTROL PANEL
7. HOT AIR OUTLET VENT
8. POWER CABLE
6
4
5
7
8
NOTE: Unpack all listed contents
from the packaging. Contents vary
by model. Please remove any
clear or blue protective lm on
the components before use.
PRODUCT DIMENSIONS: 10.5 X 12.9 X 12.1 IN. | 26.6 X 32.7 X 30.7 CM
TOP VIEW FRONT VIEW BACK VIEW
IMPORTANT: Please make sure that your Copper Chef Power AirFryer Plus has been shipped with
the components that you ordered (some accessories may be sold separately). Check everything
carefully before use. If any part is missing or damaged, do not use this product. Contact Tristar using
the customer service number located on the back of this manual.
CAUTION: Unit may be hot. Be careful
not to touch the Unit while in use. Keep
the Unit away from other objects.
1
3
2

83.2-Qt. Copper Chef Power AirFryer Plus | Model: HF-5009LCD 3.2-Qt. Copper Chef Power AirFryer Plus | Model: HF-5009LCD 9
5
Using The Control Panel Using the Control Panel
1
4
6
32
1. Power Button
Once the Outer Basket and Fry Tray
are properly placed in the Main Unit
Housing, the LCD Panel will be illuminated.
Pressing the Power Button once will set
the Unit to a default cooking temperature
of 370° F and time of 15 mins. Pressing the
Power Button a second time will start the
cooking process. Pressing the Power Button
during the cooking cycle will turn the Unit off.
2. Temperature Control Buttons
The + and − symbols enable you to add
or decrease cooking temperature 10° F
at a time. Keeping a button held down
will rapidly change the temperature.
Temperature control range: 170° F–400° F.
3. Timer Control Buttons
The + and - symbols enable you to add
or decrease cooking time 1 min. at a time.
Keeping the Button held down will rapidly
change the time. Time control range:
1– 60 mins.
4. Time and Temperature Display
This display will keep track of the
temperature and remaining cook time.
5. Blue Fan Icon
The Blue Fan Icon will appear when the Unit
is turned on and will remain illuminated until
cooking cycle is complete.
Food Cook Times Temperature Time
French Fries 400° F (204° C) 18 mins.
Chicken 360° F (182° C) 20 mins.
Steak 400° F (204° C) 12 mins.
Fish 350° F (177° C) 10 mins.
Pre-Programmed Funcions6.
The Copper Chef Power
AirFryer has four pre-
programmed cooking
functions. Simply press one
of the preset functions to
set the pre-programmed
time and temperature.

10 3.2-Qt. Copper Chef Power AirFryer Plus | Model: HF-5009LCD 3.2-Qt. Copper Chef Power AirFryer Plus | Model: HF-5009LCD 11
Instructions for Use Instructions for Use
• Remove all the packaging material.
• Remove any stickers or labels from the Unit.
• Before initial use, wipe the inside and
outside of the Unit with a warm, moist cloth
and mild detergent. Handwash all cooking
accessories.
• Before cooking food, preheat the Copper
Chef Power AirFryer Plus for a few
minutes to allow the Unit to burn off the
manufacturer’s protective coating of oil.
Dampen a washcloth with warm, soapy
water and wipe the Unit clean after
the burn-in cycle.
• Place the Unit on a stable, horizontal,
and level surface. Do not place the Unit
on a surface that is not heat resistant.
Ensure that the Unit is used in an area
with good air circulation and away from
hot surfaces and any combustible materials.
Do not place on the stove top.
• Place the Fry Tray in the Outer Basket. Slide
the Outer Basket into the Unit. If the Basket
is placed properly, it will click into place. If
the Basket does not click into place, remove
the Basket from the Unit and slide it in again.
• The Copper Chef Power AirFryer Plus cooks
using hot air. Do not fill the Outer Basket
with oil or frying fat.
• Do not put anything on top of the Unit.
This disrupts the airflow and affects the
cooking results.
1. Plug the Unit into a grounded wall socket.
2. To preheat, push the Power Button.
3. Press the Temperature Increase or Decrease
Buttons to set the cooking temperature.
4. Press the Time Decrease Button to set the
preheat time to 3 mins. When the preheat
cycle nishes, carefully pull the Outer Basket
out of the Unit and place the ingredients
inside. NOTE: Never use the Outer Basket
without the Fry Tray.
5. Do not touch the Outer Basket directly
because the Outer Basket becomes very hot
during operation. Only hold the Outer Basket
by its handle.
6. Press the Power Button. Set the appropriate
time and temperature for the ingredients you
are cooking.
7. When the timer beeps ve times, the set
cooking time has elapsed. Pull the Outer
Basket out of the Unit and place it on a
heat-resistant surface.
8. If the food is fully cooked, use tongs to
remove food. CAUTION: Do not turn the
Outer Basket upside down because any
excess oil that has collected on the bottom
of the basket will leak onto the ingredients.
9. If the food is not fully cooked, simply slide
the Outer Basket back into the Unit
and add a few minutes to the cooking time.
10. The Unit is instantly ready for preparing
more food.
Using the Copper Chef Power AirFryer Plus
Before First Use
To ensure even cooking, some foods require
shaking during the cooking process. Remove
the Outer Basket from the Unit. Gently shake
the contents as needed and place the Basket
back in the Unit to continue cooking.
CAUTION: The Outer Basket will be hot.
Wear an oven mitt during this procedure.
1. Place the Outer Basket on
a heat-resistant surface.
2. Shake the ingredients in the Basket.
3. Return the Outer Basket to the Unit
to finish cooking.
Shaking
Tips
• Foods that are smaller in size usually require
a shorter cooking time than larger foods.
• Large quantities of food require a longer
cooking time than smaller quantities.
• Shaking food halfway through the cooking
process ensures that all the pieces are
fried evenly.
• Adding a bit of vegetable oil to fresh potatoes
is suggested for a crispier result. When adding
oil, do so just before cooking and add only a
teaspoon of oil onto the potatoes.
• Snacks normally cooked in an oven can also
be cooked in the Copper Chef Power AirFryer
Plus.
• Use premade dough to prepare filled
snacks quickly and easily. Premade dough
also requires a shorter cooking time than
homemade dough.
• You can use the Copper Chef Power
AirFryer Plus to reheat foods. Simply set the
temperature and time to however warm you
want your food.

12 3.2-Qt. Copper Chef Power AirFryer Plus | Model: HF-5009LCD 3.2-Qt. Copper Chef Power AirFryer Plus | Model: HF-5009LCD 13
Cooking Chart
FOOD ITEM QUANTITY SHAKE TEMP (°F) COOK TIME
Adjustable Range (Increments)
COMMENTS
Copper Chef Power AirFryer Plus
THIN FROZEN FRIES 1¼ cups YES 400° 15–16 mins. (1 min.) -
THICK FROZEN FRIES 1¼ cups YES 400° 15–20 mins. (1 min.) -
HOMEMADE FRIES 1¼ cups YES 400° 10–16 mins. (1 min.) Add ½ tbsp. oil
HOMEMADE POTATO WEDGES 1¼ cups YES 360° 18–22 mins. (1 min.) Add ½ tbsp. oil
HASH BROWNS 1 cup YES 360° 15–18 mins. (1 min.) -
STEAK ¼–1.1 lb 360° 8–12 mins. (1 min.) -
PORK CHOPS ¼–1.1 lb 360° 10–14 mins. (1 min.) -
HAMBURGER ¼–1.1 lb 360° 7–14 mins. (1 min.) -
SAUSAGE ROLL ¼– 1.1 lb 400° 13–15 mins. (1 min.) -
CHICKEN DRUMSTICK ¼–1.1 lb 360° 18–22 mins. (1 min.) -
CHICKEN BREAST ¼–1.1 lb 360° 10–15 mins. (1 min.) -
SPRING ROLLS ¼–¾ lb YES 400° 15–20 mins. (1 min.) Use oven-ready
FROZEN CHICKEN NUGGETS ¼–1.1 lb YES 400° 10–15 mins. (1 min.) Use oven-ready
FROZEN FISH STICKS ¼–1.1 lb 400° 6–10 mins. (1 min.) Use oven-ready
MOZZARELLA STICKS ¼– 1.1 lb 360° 8–10 mins. (1 min.) Use oven-ready
CAKE 1 ¼ cups 320° 20–25 mins. (1 min.) Use baking tin
QUICHE 1 ½ cups 360° 20–22 mins. (1 min.) Use baking tin/oven dish
MUFFINS 1 ¼ cups 400° 15–18 mins. (1 min.) Use baking tin
SWEET SNACKS 1 ½ cups 320° 20 mins. (1 min.) Use baking tin/oven dish
Keep in mind that these settings are guidelines. Since ingredients differ in origin, size,
shape, and brand, we cannot guarantee the best settings for your ingredients.
NOTE
Troubleshooting
Symptom Possible Cause Solution
The Copper Chef Power
AirFryer Plus does not work
The appliance is not plugged in. Plug Power Cable into wall socket.
You have not turned the Unit on
by setting the preparation time
and temperature.
Press the Power Button.
Select Time and Temperature. Press the
Power Button again and cooking will
begin.
The Unit is turned off. If you press the Power Button
while the Unit is cooking, you will trigger the Auto
Shut-Off mode.
Press the Power Button. Select a Time
and Temperature. Press the Power Button
again and cooking will begin.
Food is not cooked
The Outer Basket is overloaded. Use smaller batches for more even frying.
The temperature is set too low. Raise temperature and continue cooking.
Food is not fried evenly Some foods need to be shaken during
the cooking process. See Shaking in Instructions for Use, p. 11.
Outer Basket will not slide into Unit properly
Outer Basket is overloaded. Do not ll the Fry Basket above the
Maximum line.
Fry Tray is not placed in Outer Basket correctly. Gently push Fry Tray into Outer Basket
until it clicks.
White smoke coming from Unit
Too much oil is being used. Wipe down to remove excess oil.
Outer Basket has grease residue from previous
operation. Clean the Outer Basket after each use.
French fries are not fried evenly
Potato not prepped properly. Consult recipe for potato type & prep.
Fries are not cut evenly. Cut fries thinner or reshape fries.
Fries are too crowded. Spread fries out or cook smaller batch.
Potatoes not rinsed properly during preparation. Pat dry to remove excess starch.
Fries are not crispy Raw fries have too much water.
Dry potato sticks properly
before misting oil.
Cut sticks smaller.
Add a bit more oil.
Error
E1 - Broken circuit of the thermal sensor Call Customer Service at
1-973-287-5129
E2 - Short circuit of the thermal sensor

14 3.2-Qt. Copper Chef Power AirFryer Plus | Model: HF-5009LCD 3.2-Qt. Copper Chef Power AirFryer Plus | Model: HF-5009LCD 15
Frequently Asked Questions
1. Can I prepare foods other than fried dishes with my
Copper Chef Power AirFryer Plus?
You can prepare a variety of dishes, including steaks,
chops, burgers, and baked goods. See the Copper Chef
Power AirFryer Plus Recipe Guide.
2. Is the Copper Chef Power AirFryer Plus good for
making or reheating soups and sauces?
Never cook or reheat liquids in the Copper Chef Power
AirFryer Plus.
3. Is it possible to shut off the Unit at any time?
Pressing the Power Button during any cooking cycle will
cancel the cooking cycle and shut off the Copper Chef
Power AirFryer Plus.
4. What do I do if the Unit shuts off while cooking?
As a safety feature, the Copper Chef Power AirFryer Plus
has an Auto Shut-Off device that prevents damage from
overheating. Remove the Outer Basket and set it on a heat-
resistant surface. Allow the Unit to cool down. Remove the
Power Cable from the outlet. Once cool, plug the Power
Cable back into the socket. Restart with the Power Button.
5. Does the Unit need time to heat up?
If you are cooking from a cold start, add 3 mins. to
the cooking time.
6. Can I check the food during the cooking process?
Removing the Outer Basket during the cooking process will
pause the cooking cycle. During this time, you can shake
the contents in the Outer Basket if needed to ensure even
cooking. Returning the Outer Basket to the Unit will resume
the cooking cycle.
7. Is the Copper Chef Power AirFryer Plus dishwasher safe?
Only the Fry Tray is dishwasher safe. The Unit itself, which
contains the heating coil and electronics, should never be
submerged in liquid of any kind or cleaned with anything
more than a warm, moist cloth or nonabrasive sponge with
a small amount of mild detergent.
8. What happens if the Unit still does not work after I have
tried all the troubleshooting suggestions?
Never attempt a home repair. Contact Tristar and follow
the procedures set forth by the guarantee. Failure to do so
could render your warranty null and void.
Clean the Copper Chef Power AirFryer Plus after each use.
The Outer Basket and the Fry Tray are coated with a special
nonstick surface. Never use abrasive cleaning materials or
utensils on these surfaces.
1. Remove the Power Cable from the wall socket
and be certain the appliance is thoroughly cooled before
cleaning.
2. Wipe the outside of the appliance with a warm, moist cloth
and mild detergent.
3. Clean the Outer Basket and the Fry Tray with hot water, a
mild detergent, and a nonabrasive sponge.
NOTE: The Fry Tray is dishwasher safe.
TIP: Should the Fry Tray contain difcult-to-remove food
particles, soak in hot, soapy water for 10 mins.
4. Clean the inside of the appliance with hot water, a mild
detergent, and a nonabrasive sponge.
5. If necessary, remove unwanted food residue from
the heating element with a soft cleaning brush.
1. Unplug the appliance and let it cool down thoroughly.
2. Make sure all components are clean and dry.
3. Place the appliance in a clean, dry place.
Cleaning
Storage
60-Day Money-Back Guarantee
If you decide that you don’t love this product, your order is covered by our 60-Day
Money-Back Guarantee. You have 60 days from the day you receive your product to request
a replacement product or refund of the purchase price minus processing and handling fees.
To receive a refund or replacement, you must return the product to us at your expense.
To return the product, call customer service at 1-973-287-5129 and request a return
merchandise authorization number. Pack the product carefully and include in the package a
note with (1) your name, (2) mailing address, (3) phone number, (4) email address, (5) reason
for return, and (6) proof of purchase or order number, and (7) specify on the note whether
you are requesting a refund or replacement. Write the return merchandise authorization
number on the outside of the package.
Send the product to the following return address:
Copper Chef Power AirFryer Plus
Tristar Products
500 Returns Road
Wallingford, CT 06495

We are very proud of the design and quality of our
Copper Chef Power AirFryer Plus.
This product has been manufactured to the highest standards.
You can visit www.TristarCares.com to nd answers
to questions, read recipes and nd additional items to
compliment your Unit. Should you have any issues, our friendly
customer service staff is here to help you.
1-973-287-5129
Distributed by:
Tristar Products, Inc.
Faireld, NJ 07004
© 2018 Tristar Products, Inc.
Made in China
CCPAF-PLUS_3.2QT_IB_TP_ENG_V2_181026
