CopterX CX-CT6C User manual

CX-CT6C
2.4GHz 6 Channel
FHSS Technology
Digital Proportional
Radio System
www.copterx.com
Copyright © 2011 KY MODEL Company Limited.
INSTRUCTION MANUAL
INSTRUCTION MANUAL

01
MENU
1.
2.
3.
4.
5.1
5.2
5.3
5.4
6.
7.
8.
9.1.
9.2.
9.3.
9.4.
9.5.
9.6.
10.1.
10.2.
10.3.
10.4.
10.5.
10.6.
10.7.
10.8.
10.9.
10.10.
10.11.
11.1.
11.2.
11.3.
12.
Table of content
Introduction
Caution
Transmitter Chart
2.4G Binding
Heli. Connection Diagram (3 Servos CCPM)
Airplane Connection Diagram
V-Tail COnnection Diagram
DELTA-MIX Connection Diagram
CX-CT6C Basic Features
LED Displaying Board Function
Menu
System Menu
MODEL.SET
PLANE TYPE
STICK MODE
STICK ADJ
TRAINER
Function Menu (Heli.)
D/R
SUB. TRIM
TRAVEL
CH.REV
SWASH.MIX
GYRO.SENS
THRO.CURV
MONITOR
PIT.CURV
THRO.HOLD
Function Menu for Fixed Wing Plane
Function Menu for V-Tail
Function Menu for Delta Mix
Technology Data
1
2
2
3
3
4
5
6
6
7
7
8
9
10
12
12
13
13
14
16
17
18
18
19
19
20
20
21
21
22
22
23
23
CX-CT6C
2.4GHz 6 Channel FHSS Technology
Digital Proportional Radio System

1. Introduction
Thank you for purchasing the CopterX CX-CT6C digital proportional radio system. With advanced
micro processor control, large LCD display, glitch free FHSS 2.4GHz system, multiple model
memory, build-in program for helicopter, airplane, v-tail and delta wing. Make this one of the most
advance radio system in the market. Please keep this manual for future reference.
02
CX-CT6C
2. Caution
Please read this manual carefully and keep it for reference in the future.
Warning:
1. This product was designed only for radio controlled models;
2. The usage of this product should be approved by local relevant law or regulations;
3. We will not be responsible for the damages caused by unauthorized modification, adjustment or
replacement of parts of this product;
4. The manual may be altered without prior notice. Please contact us if you have any corrections or
clarifications that should be made in the manual.
Please pay more attention to the parts in this manual, which are marked with “Warning”
Before starting the transmitter, make sure the transmitter batteries are well loaded and with
enough power. And please check and confirm that the servos are all well and properly connected.
Please take off batteries from transmitter after flying and during the transportation.
Please check and have a test on control surfaces to confirm the transmitter handling of each part
prior to each takeoff.
Keep the radio system away from moisture, high temperature and strong vibration. Do not clean
the product with solvent.
Do not fly your models near airfield, schools, hospitals, residences, power transmission network,
communication facilities and other places that are forbidden for starting the transmitter. Please
stop flying your models with the radio on rainy or windy days, or at night.
Do not fly the models when you are tired, sick, intoxicated, or not in good spirit.
The antenna does not touch anything else when power switch is turned on.
Do not leave this product and its accessories within the reach of small children.
Please use this product according to your local relevant law or regulation, we are not responsible
for any incidents or damages.
2.4GHz 6 Channel FHSS Technology
Digital Proportional Radio System

3. Transmitter Chart
Antenna
03
CX-CT6C
2.4GHz 6 Channel FHSS Technology
Digital Proportional Radio System
Hover pitch Hover throttle
Digital trim
Digital trim
INCREASE
DECREASE
ENTER
Right stick
TH. Hold (Heli.)
CH 5 (Plane)
GYRO.SENS (Heli.)
CH 6 (Plane)
Digital trim
Digital trim
Power switch
LCD display
UP
DOWN
EXIT
Hook
Left stick
(Heli.) A/E/R DR
(Aile, Elev, Rudd)
IDLE switch
Charging jack
4. 2.4G Binding
The binding process: turn on the transmitter, then connect the power of receiver keeping the
receiver “BIND” button till the light turn on GREEN which means the binding is successful. After that,
it is unnecessary to bind again.
Caution: make sure the RX and TX is within one meter, and around 10 meters no similar device. If
the light flashing, showing the binding failure, please do again as above indication.

04
CX-CT6C
2.4GHz 6 Channel FHSS Technology
Digital Proportional Radio System
Servo 3
Servo 1
Servo 4
Gyro
Receiver
RUDD.
Remote Gain
Rudder
Electronic
Speed
Controller
Power
PITCH
ELEV.
AILE.
Motor
Servo 2
Switch to “HELIC” position and enter Helicopter mode.
5.1. Heli. Connection Diagram
(3 Servos CCPM)
(AILE.)
(PITCH)
(ELEV.)
Front

05
CX-CT6C
2.4GHz 6 Channel FHSS Technology
Digital Proportional Radio System
5.2. Airplane Connection Diagram
Switch to “plane” position and enter Airplane mode, not mix function, as for normal planes.
Receiver channel distribution:
CH1: Aileron
CH2: Elevator
CH3: Throttle
CH4: Rudder
CH5: Gear
CH6: Flap
AILE.
AILE.
ELEV.
RUDD.
Servo 3
Servo 1
Servo 4
Servo 5
Receiver
Gear
Flap
Electronic
Speed
Controller
Power
RUDD.
ELEV.
AILE.
Motor
Servo 2

06
CX-CT6C
2.4GHz 6 Channel FHSS Technology
Digital Proportional Radio System
5.3. V-Tail Connection Diagram
Switch to “V-Tail” position and enter V-Tail mode, elevator and Rudder is mixed, as for V-Tail planes.
Receiver channel distribution:
CH1: Aileron
CH2: Ruddervator (Tail)
CH3: Throttle
CH4: Ruddervator 2 (Tail)
CH5: Aileron2
5.4. DELTA-MIX Connection Diagram
Switch to “DELTA” position and enter DELTA-MIX mode, aileron and elevator is mixed, as for triangle
planes, tailless planes, discal planes.
Receiver channel distribution:
CH1: Eleron
CH2: Eleron 2
CH3: Throttle
CH4: Rudder

07
CX-CT6C
2.4GHz 6 Channel FHSS Technology
Digital Proportional Radio System
6. CX-CT6C Basic Features
1. Pitch neutral trim
2. Output standard 6 channel signal and support 2.4G sytem
3. Support 3D fly mode, normal fly, idle 1 fly and idle 2 fly (in the idle mode)
4. D/R for Aileron, elevator, rudder
5. Throttle hold function
6. Gyro sensitivity adjustment
7. Channel neutral position setting
8. Channel reverse and channel servo travel adjustment
9. Six models data memory
10. LED will blink with alarming when the voltage is low
NOTE: If “THRO HOLD” is shown on LCD when you turn on the power, please move “TH. HOLD”
switch to the position 0, otherwise, you can not properly enter power on interface.
NOTE: If “IDLE ON” is shown on LCD when you turn on the power, please move “IDLE” switch to the
position N, otherwise, you can not properly enter power on interface.
THRO HOLD
10.0V CT6C
SYS.
MENU
FUN.
MENU
TH. HOLD
IDLE ON
10.0V CT6C
SYS.
MENU
FUN.
MENU
IDLE
7. LED Displaying Board Function
“POWER” LED
The light keeps on with blue color in normal power-on condition. When
the voltage is below 4.0V, the light blinks with alarming. Now please exit
the operation and change new battery.

8. Menu
FUN. MENU
08
CX-CT6C
2.4GHz 6 Channel FHSS Technology
Digital Proportional Radio System
HELIC PLANE V-TAI DELTA
D/R
SUB.TRIM
TRAVEL
CH.REV
SWASH.MIX
D/R
SUB.TRIM
TRAVEL
CH.REV
MONITOR
GYRO.SENE
D/R
SUB.TRIM
TRAVEL
CH.REV
MONITOR
V-TAIL
D/R
SUB.TRIM
TRAVEL
CH.REV
MONITOR
DELTA-MIX
THRO.CURV
MONITOR
PIT.CURV
THRO.HOLD
SYS. MENU
HELIC PLANE V-TAI DELTA
MODEL.SET
PLANETYPE
STICKMODE
STICK ADJ
TRAINER
MODEL.SET
PLANETYPE
STICKMODE
STICK ADJ
TRAINER
MODEL.SET
PLANETYPE
STICKMODE
STICK ADJ
TRAINER
MODEL.SET
PLANETYPE
STICKMODE
STICK ADJ
TRAINER
1. MODEL.SET: Here you can set the parameter of the model, rename, save and format the corre-
sponding model parameter, and come back to the factory setting.
2. PLANETYPE: Four types of plane are selectable. Helicopter, fixed wing(plane), V-Tail and Delta.
3. STICKMODE: Operating stick selection: Mode 1 (right throttle), Mode 2 (left throttle), Mode 3 and
Mode 4.
4. STICK ADJ: Neutral position setting of 4 proportional channels controlled by the operating stick.
5. TRAINER: This menu can be used for simulator setting.

9.1. System Menu
09
CX-CT6C
2.4GHz 6 Channel FHSS Technology
Digital Proportional Radio System
10.0V CT6C
SYS.
MENU
FUN.
MENU
SYS.MENU
MODEL.SET
PLANE TYPE
STICK MODE
MODEL MOD0
RENAME
SAVE AS
RECOVER
MODEL MOD0
RENAME
RECOVER
SYS.MENU
STICK ADJ
TRAINER
MODEL.SET
PLANE TYPE
RENAME
0123456789
BCDEFGHIJ
KLMNOPQRST
UVWXYZ
A
MOD0
SAVE AS
MODEL MOD0
RENAME
SAVE AS
SYS.MENU
MODEL.SET
STICK MODE
PLANE TYPE
PLANE TYPE
HELIC PLANE
V-TAI DELTA
STICK MODE
STICK ADJ
TRAINER
STICK MODE
MODE 1
RU AI
EL TH
STICK MODE
MODE 2
RU AI
TH EL
STICK MODE
MODE 3
AI RU
EL TH
STICK MODE
MODE 4
AI RU
TH EL
SYS.MENU
TRAINER
STICK ADJ SYS.MENU
TRAINER
STICK ADJ
SYS.MENU
STICK ADJ
TRAINER
TRAINER
NORMAL
SYS.MENU
STICK ADJ
TRAINER
TRAINER
TRAINER
RECOVER

9.2. MODEL.SET
Recall Model
Operation:
1. Press “up” or “down” to select “SYS.MENU”, and press “ENTER” to come to the interface.
2. Press “ENTER” to come to “MODEL.SET” interface, and now the shadow area is the item that can
be set currently.
3. Press “INC” or “DEC” to select mode you expect. The default setting are Mod1, Mod2, Mod3,
Mod4, Mod5, Mod6.
4. Press “ENTER” to confirm when a model number is selected, otherwise your selection is invalid.
Remark: when your selection is successful, the model naming area in the main interface will show
the corresponding change.
Please note: All your settings have been saved in the current model number.
Rename model
Operation:
1. Press “up” or “down” to select “SYS.MENU”, and press “ENTER” to come to the interface.
2. Press “ENTER” to come to “MODEL.SET” interface, and now the shadow area is the item that can
be set currently.
3. Press “up” or “down” to select the setting function items, and press “ENTER” to come to
“RENAME”
4. Move the stick in left stick four directions to select letters or digits to rename your item. Press
“ENTER” to confirm when letters or digits are selected, otherwise your selection is invalid.
Caution: When cannot select letters to the left need redone “STICK ADJ”.
Remark: when the cursor is at ‘ or ’, press “ENTER” to quickly change the single letter of the
name.
ENTER
10
CX-CT6C
2.4GHz 6 Channel FHSS Technology
Digital Proportional Radio System
SYS.MENU
PLANE TYPE
STICK MODE
MODEL.SET MODEL
RENAME
SAVE AS
RECOVER
MOD0
ENTER
MODEL
SAVE AS
RECOVER
MOD0
RENAME RENAME
0123456789
BCDEFGHIJ
KLMNOPQRST
VWXYZ
A
UOD0
U

11
CX-CT6C
2.4GHz 6 Channel FHSS Technology
Digital Proportional Radio System
Save as model number
Operation:
1. Press “down“ to select “SYS.MENU”, and press “ENTER” to come to the interface.
2. Press “ENTER” to come to “MODEL.SET” interface, and now the shadow area is the item that can
be set currently.
3. Press “up” or “down” to select the setting item, and press “ENTER” to come to “SAVE AS”
4. Press “up” or “down” to select your model number to be saved. Press “ENTER” to confirm when
the number is selected. It can be saved again and again in different model number groups. Press
“EXIT” to leave the setting.
Remark: the data of the current model will copy to another memory slot, so please be careful.
ENTER
MODEL
RECOVER
MOD0
RENAME
SAVE AS
MODEL MOD0
RENAME
RECOVER
SAVE AS
Recover the factory data
Operation:
1. Press “down” to select “SYS.MENU”, and press “ENTER” to come to the interface.
2. Press “ENTER” to come to “MODEL.SET” interface, and now the shadow area is the item that can
be set currently.
3. Press “up” or “down” to select the setting item, and press “ENTER” to come to “RECOVER”
4. Press “ENTER” to recover the factory setting, and press “EXIT” to leave the menu.
Remark: This recovery will clear the data of the current model, please be careful.
ENTER
MODEL MOD0
RENAME
SAVE AS
RECOVER
MODEL MOD0
RENAME
SAVE AS
RECOVER

9.3. PLANE TYPE
9.4. STICK MODE
Plane type selection
Operation:
1. Press “down” to select “SYS.MENU”, and press “ENTER” to come to the interface.
2. Press “up” or “down” to select “PLANE TYPE”, and now the shadow area is the item that can be set
currently. Press “ENTER” to go to the next step.
3. Now comes out a dialing box, press “up” or “down” to select “HELIC”, “PLANE”, “V-TAIL” or “DELTA”.
And press “ENTER” to save the setting and leave the operation.
Stick mode selection
Operation:
1. Press “down” to select “SYS.MENU”, and press “ENTER” to come to the interface.
2. Press “up” or “down” to select “STICK MODE”, and now the shadow area is the item that can be set
currently. Press “ENTER” to og to the next step.
3. Press “up” or “down” to select “MODE 1” (right throttle), “MODE 2” (left throttle), “MODE 3”,
“MODE 4”. And press “ENTER” to save the selection and press “EXIT” to leave the operation.
Remark: This operation changes the distribution of 4 proportional channels. Please note: “AILE”,
“ELEV”, “THRO” and “RUDD” channels have been distributed now. When the stick model is changed,
the menu order controlled by the stick “AI” and “EL” is also changed. Please pay attention to the
difference.
ENTER
12
CX-CT6C
2.4GHz 6 Channel FHSS Technology
Digital Proportional Radio System
SYS.MENU
STICK MODE
MODEL.SET
PLANE TYPE
SYS.MENU
MODEL.SET
STICK MODE
PLANE TYPE
PLANE TYPE
PLANE
V-TAI DELTA
HELIC
STICK MODE
MODE 1
RU AI
EL TH
STICK MODE
MODE 2
RU AI
TH EL
STICK MODE
MODE 3
AI RU
EL TH
STICK MODE
MODE 4
AI RU
TH EL

9.5. STICK ADJ
Stick neutral position setting
Operation:
1. Press “ENTER” to come to “STICK ADJ” interface, and now the shadow area is the item that can be
set currently.
2. Before your operation, please be sure that the 4 proportional channels of the sticks are in the
neutral position and the 4 electronic trim buttons are also in the neutral position.
3. Press “ENTER” to enter, and now comes out a dialing box. Press “up” or “down” to select “NO” or
“YES”, and press “ENTER”. When you hear one “beep” sound, the neutral setting is successful.
4. Press “EXIT” to save and leave the setting.
ENTER
13
CX-CT6C
2.4GHz 6 Channel FHSS Technology
Digital Proportional Radio System
ENTER
SYS.MENU
TRAINER
STICK ADJ
SYS.MENU
TRAINER
STICK ADJ SYS.MENU
TRAINER
STICK ADJ
9.6. TRAINER
Trainer mode selection
Operation:
1. Press “down” to select “SYS.MENU”, and press “ENTER” to come to the interface.
2. Press “up” or “down” to select “NORMAL” or “TRAINER”.
NORMAL: normal fly, TRAINER: simulator software
NOTE
1. This function is for simulator operation in the computer, optional simulator
cable and software require.
2. Please do not connect “Trainer” interface at the back of the transmitter
to any electric equipment or other radio transmitters, or else, we are not
responsible for any damages.
3. This interface does not support training function, it is only for flying
simulation software.
ENTER
SYS.MENU
STICK ADJ
TRAINER
SYS.MENU
STICK ADJ
TRAINER
TRAINER
NORMAL
SYS.MENU
STICK ADJ
TRAINER
TRAINER
TRAINER
Simulating JACK

10.1. Function Menu (Heli.)
14
CX-CT6C
2.4GHz 6 Channel FHSS Technology
Digital Proportional Radio System
10.0V CT6C
SYS.
MENU
FUN.
MENU
FUN.MENU
D/R
SUB. TRIM
TRAVEL
FUN.MENU
CH.REV
SWASH.MIX
GYRO.SENE
FUN.MENU
THRO.CURV
MONITOR
PIT.CURV
FUN.MENU
THRO.HOLD
D/R
SUB. TRIM
TRAVEL
CH.REV
DR AILE0
H
I
O
L
0
0
100
100 DR ELEV0 H
I
O
L
0
0
100
100
DR RUDD0
H
I
O
L
0
0
100
100
SUB. TRIM
AILE
ELEV
THRO 0 0
0
TRAVEL
AILE
ELEV
THRO 100 100
100
100
100
100
REV.SW
CH
REV
NOR
TRAVEL
RUDD
GEAR
PITH 100 100
100
100
100
100
SUB. TRIM
RUDD
GEAR
PITH 0 0
0
123456

15
CX-CT6C
2.4GHz 6 Channel FHSS Technology
Digital Proportional Radio System
SWASH.MIX
GYRO.SENE
THRO.CURV
MONITOR
SWASH.MIX
AILE
PITH
ELEV -50 -50
-50
1
2
3
4
5
6
GYRO.SENS
POS0
POS1 100
-100
THRO.HOLD
THRO.HOLD
SW
VALUE
ON
THRO. CURV
NOR
I
O
L
0
0
0
PIT.CURV
PIT. CURV
NOR
I
O
L
0
0
0
THRO. CURV
IDLE0
I
O
L
0
100
100
THRO. CURV
IDLE1
I
O
L
0
100
100
PIT. CURV
IDLE0
I
O
L
0
0
0
PIT. CURV
IDLE1
I
O
L
0
0
0

10.2. D/R
16
CX-CT6C
2.4GHz 6 Channel FHSS Technology
Digital Proportional Radio System
D/R operation for AILE
Operation:
1. Press “up” to select “FUN.MENU”, and press “ENTER” to come to the interface.
2. Press “up” or “down” to select “D/R”, and now the shadow area is the item that can be set
currently. Press “ENTER” to go to the next step.
3. Press “A/E/R D/R” to select “AILE D/R”, and LCD shows the corresponding “AILE0” or “AILE1”
4. Press “up” or “down” to select “H” or “L”, and press “INC” or “DEC” to set the corresponding value
and dual band curve will change accordingly.
5. Set “AILE D/R” switch on the top of the transmitter. When “A/E/R D/R” is in “0” position, LCD
shows “AILE0”, and now you can set D/R value for “AILE0”. And when “A/E/R D/R” is in “1” position,
LCD shows “AILE1”, and now you can set D/R value for “AILE1”
6. After your setting, press “EXIT” to save the setting and leave the operation.
DR AILE0
H
I
O
L
0
0
100
45
A/E/R D/R
0
1
0
1
AILE DR SW
POS0/POS1
D/R operation for ELEV
Operation:
1. Press “up” to select “FUN.MENU”, and press “ENTER” to come to the interface.
2. Press “INC” or “DEC” to select “D/R”, and now the shadow area is the item that can be set
currently. Press “ENTER” to select “ELEV D/R”.
3. Move “up” or “down” button to select “H” or “L”, and press “INC” or “DEC” to set the corresponding
value and dual band curve will change accordingly.
4. Set “ELEV D/R” switch on the top of the transmitter. When “A/E/R D/R” is in “0” position, LCD
shows “ELEV0”, and now you can set D/R value for “ELEV0”. And when “A/E/R D/R” is in “1” position,
LCD shows “ELEV1”, and now you can set D/R value for “ELEV1”
5. After your setting, press “EXIT” to save the setting and leave the operation.
DR ELEV0
H
I
O
L
0
0
100
45
A/E/R D/R
0
1
0
1
ELEV DR SW
POS0/POS1

17
CX-CT6C
2.4GHz 6 Channel FHSS Technology
Digital Proportional Radio System
D/R operation for RUDD
Operation:
1. Press “up” to select “FUN.MENU”, and press “ENTER” to come to the interface.
2. Press “up” or “down” to select “D/R”, and now the shadow area is the item that can be set
currently. Press “ENTER” to go to the next step.
3. Press “up” or “down” to select “H” or “L”, and press “INC” or “DEC” to set the corresponding value
and dual band curve will change accordingly.
4. Set “RUDD D/R” switch on the top of the transmitter. When “A/E/R D/R” is in “0” position, LCD
shows “RUDD0”, and now you can set D/R value for “RUDD0”. And when “A/E/R D/R” is in “1”
position, LCD shows “RUDD1”, and now you can set D/R value for “RUDD1”
5. After your setting, press “EXIT” to save the setting and leave the operation.
Remark: There is no shortcut key on the surface of the transmitter, D/R data is only one group,
please be noted.
DR RUDD0
H
I
O
L
0
0
100
100
A/E/R D/R
0
1
0
1
AILE DR SW
POS0/POS1
10.3. SUB. TRIM
Channel neutral trim operation
Operation:
1. Press “up” to select “FUN.MENU”, and press “ENTER” to come to the interface.
2. Press “INC” or “DEC” to select “SUB TRIM”, and now the shadow area is the item that can be set
currently. Press “ENTER” to go to the next step.
3. Press “up” or “down” to select “AILE”, “ELEV”, “THRO”, “RUDD”, “GEAR”, “PITCH”.
4. Press “INC” or “DEC” to set the value of channel neutral trim.
5. After your setting, press “EXIT” to save the setting and leave the operation.
ENTER ENTER
FUN.MENU
TRAVEL
D/R
SUB. TRIM
SUB. TRIM
AILE
ELEV
THRO 0 0
0SUB. TRIM RUDD
GEAR
PITH 0 0
0

18
CX-CT6C
2.4GHz 6 Channel FHSS Technology
Digital Proportional Radio System
10.4. TRAVEL
Travel operation
Operation:
1. Press “up” to select “FUN.MENU”, and press “ENTER” to come to the interface.
2. Press “up” or “down” to select “TRAVEL”, and now the shadow area is the item that can be set
currently. Press “ENTER” to go to the next step.
3. Press “up” or “down” to select the channel you like to adjust, use Rudder stick to select the high
or low value.
4. Press “INC” or “DEC” to set the travel value.
5. After your setting, press ‘EXIT” to save the setting and leave the operation.
ENTER
FUN.MENU
D/R
SUB. TRIM
TRAVEL
TRAVEL
AILE
ELEV
THRO 100 100
100
100
100
100 STICK:
RUDD. RU
EL
10.5. CH.REV
Channel reverse operation
Operation:
1. Press “up” to select “FUN.MENU”, and press “ENTER” to come to the interface.
2. Press “up” or “down” to select “CH.REV”, and now the shadow area is the item that can be set
currently. Press “ENTER” to go to the next step.
3. Press “up” or “down” to select the channel.
4. Press “INC” to set the reverse mode and “DEC” to set normal mode.
5. After your setting, press “EXIT” to save the setting and leave the operation.
ENTER
FUN.MENU
SWASH.MIX
GYRO.SENE
REV.SW
CH
REV
NOR
123456 REV.SW CH
REV
NOR
123456CH.REV

19
CX-CT6C
2.4GHz 6 Channel FHSS Technology
Digital Proportional Radio System
10.6. SWASH.MIX
Swash mix (only for CCPM three servos 120° helicopter)
Operation:
1. Press “up” to select “FUN.MENU”, and press “ENTER” to come to the interface.
2. Press “up” or “down” to select “SWASH.MIX”, and now the shadow area is the item that can be set
currently. Press “ENTER” to go to the next step.
3. Press “up” or “down” to select “AILE”, “PITCH”, “ELEV”.
4. Press “INC” or “DEC” to set the value of each channel.
5. After your setting, press “EXIT” to save the setting and leave the operation.
ENTER
FUN.MENU
SWASH.MIX
GYRO.SENE
CH.REV
FUN.MENU
SWASH.MIX
GYRO.SENE
CH.REV
SWASH.MIX
AILE
PITH
ELEV -50 -50
-50
10.7. GYRO.SENS
Gyro sensitivity adjustment
Operation:
1. Press ‘up” to select “FUN.MENU”, and press “ENTER” to come to the interface.
2. Press “up” or “down” to select “GYRO.SENE”, and now the shadow area is the item that can be set
currently. Press “ENTER” to go to the next step.
3. Set “GYRO.SENS” switch on the top of the transmitter: When “GYRO.SENS” is in “0” position, LCD
shows “POS 0”, and now you can set the value for “POS 0” by “INC” or “DEC”. When “GYRO.SENS” is
in “1” position, LCD shows “POS 1”, and now you can set the value for “POS 1” by “INC” or “DEC”.
4. After your setting, press “EXIT” to save the setting and leave the operation.
ENTER
GYRO.SENS
0
1
0
1
GYRO.SENS
GYRO.SENS
POS0/POS1
POS0/POS1
GYRO.SENS
POS0/POS1
GYRO.SENS
POS0
POS1 100
-20
