Operating Guide
Remote Camera Controller
Model No. AW-RP150G

Connecting the Unit to AW-UE70/AW-UN70/AW-
HE35/AW-HE38/AW-HE40/AW-HN38/AW-HN40
Series Cameras 3
Connection Example 3
Connections 5
Compatible Functions List 6
Menu (when AW-UE70/AW-UN70/AW-HE35/AW-
HE38/AW-HE40/AW-HN38/AW-HN40 is connected) 8
Remote Controller Menu List 8
PAINT 10
SCENE 10
SHUTTER 10
CHROMA 11
GAIN 11
WHITE BALANCE 12
GAMMA 12
DRS 13
DTL 13
COLOR CORRE 14
DNR 15
CONTRAST 16
FUNCTION 17
USER ASSIGN 17
CAMERA INFO 17
PTZ INFO1 17
PTZ INFO2 17
HOUSING INFO 18
CROP 18
MAINTENANCE 19
CAMERA MENU OP 19
RP SETTING 19
FILES 19
RP INIT 19
RP VERSION 19
GPI TALLY 19
GPIO CAM SEL 19
GPO CAM.G 19
GPI PMEM 19
GPI PMEM.G 19
SYSTEM 20
CAMERA 20
CONNECT SETTING 20
MANUAL IP SET 20
AUTO IP SET 20
RP IP SET 20
TRACKING 20
PMEM /TMEM 21
PMEM LIST 21
PMEM DIRECT 21
PMEM STORE 21
PMEM DEL 21
TMEM 21
SETTING 21
- 2 -
Table of Contents

Connecting the Unit to AW-UE70/AW-UN70/
AW-HE35/AW-HE38/AW-HE40/AW-HN38/AW-HN40 Series
Cameras
Connection Example
Serial connection with AW-UE70/AW-UN70
AW-UE70/AW-UN70
<RS-422> connector
Suppliead
AC adapter Switching hub or injector
with PoE+ support
LAN cable (straight cable)
LAN cable (straight cable)
IP connection with AW-UE70/
AW-UN70
AW-UE70/AW-UN70
Supplied
AC adapter
<LAN ACT/LINK>
connector
Switching hub
with PoE+ support
LAN cable (straight cable)
LAN cable (straight cable)
- 3 -
Connecting the Unit to AW-UE70/AW-UN70/AW-HE35/AW-HE38/AW-HE40/AW-HN38/AW-HN40 Series Cameras

Serial connection with AW-HE35/AW-HE38/
AW-HE40/AW-HN38/AW-HN40
AW-HE35/AW-HE38/AW-HE40/
AW-HN38/AW-HN40
<RS-422> connector
Suppliead
AC adapter
LAN cable (straight cable)
LAN cable (straight cable)
Switching hub or injector
with PoE+ support
IP connection with AW-HE35/
AW-HE38/AW-HE40/AW-HN38/
AW-HN40
AW-HE35/AW-HE38/AW-HE40/
AW-HN38/AW-HN40
Supplied
AC adapter
<LAN ACT/LINK>
connector
Switching hub
with PoE+ support
LAN cable (straight cable)
LAN cable (straight cable)
- 4 -
Connecting the Unit to AW-UE70/AW-UN70/AW-HE35/AW-HE38/AW-HE40/AW-HN38/AW-HN40 Series Cameras

Connections
Set the connection setting to “Serial” or “LAN” in the [CONNECT SETTING] menu.
1
CAM01 : AW-UE70 1 / 1
TRACKING
CAMERA RP
IP SET
CONNECT
SETTING MANUAL IP SET AUTO IP SET
23 4 5
6
1
2
3
4
5
1 11
CAM SEL
1DATA SAVE NO?
CNNCT MD
Serial DATA LOAD NO?
CAM1
Serial CAM3CAM2 CAM4
CAM5 CAM7CAM6 CAM8
CAM9 CAM11CAM10 CAM12
CAM13 CAM15CAM14 CAM16
NON NONNON NON
NON NONNON NON
NON NONNON NON
NONNON NON
When connecting, observe the following points.
Serial connection
Connect the <SERIAL CONT 1 to 5> connector on this unit to the <RS-422> connector on the AW-UE70/AW-UN70/AW-
HE35/AW-HE38/AW-HE40/AW-HN38/AW-HN40 using a LAN cable (sold separately).
Use a straight cable (category 5e or higher; up to 1000 m (3280 ft) in length) for the LAN cable.
Do not connect a cable for PoE+ power supply to the <SERIAL CONT 1 to 5> connector of this unit.
LAN connection
Connect the <IP CONT> connector on this unit to the <LAN ACT/LINK> connector on the AW-UE70/AW-UN70/AW-
HE35/AW-HE38/AW-HE40/AW-HN38/AW-HN40 using a LAN cable (sold separately).
Use a straight cable (category 5e or higher; up to 100 m (328.0 ft) in length) for the LAN cable (STP).
Configure the camera IP address and port number settings of the connection destinations in [SYSTEM] menu as well.
This unit can be powered using PoE+. Use a switching hub with PoE+ support.
For details on switching hubs and PoE+ injectors that have been verified to support PoE+, consult with your dealer.
- 5 -
Connecting the Unit to AW-UE70/AW-UN70/AW-HE35/AW-HE38/AW-HE40/AW-HN38/AW-HN40 Series Cameras

Compatible Functions List
When the unit is used in conjunction with an AW-UE70/AW-UN70 Series 4K Integrated Camera or AW-HE35/AW-HE38/AW-HE40/AW-
HN38/AW-HN40 Series HD Integrated Camera, there will be functions that are limited or disabled for some of the unit’s buttons, dials, and
other controls. Be sure to refer to the following table.
POWER ALARM
BARS
ABBAWB
ATWVARA/3200K
SHUTTER
ON
SHUTTER
SYNC
SCENE
ON/OFF
B/5600K
AUTO
IRIS
WHITE BAL
R/B GAIN
R/B PED M.PED
SPEED
TELE
ZOOM
WIDE
AUTO
OTAF
LOW HI
F1 F2 F3 F4
ENABLE
ENABLE
SD CARD
PAINT USER 1
FUNCTION
MAINTENANCE USER 3
PMEM/TMEM USER 4
SYSTEM USER 5
SELECT
USER 6
USER 2
ENABLEENABLE
SPEEDFOCUS
LOW HI
SPEED
CAMERA / GROUP SELECTION
CAMERA GROUP
PAN
TILT
LOW HI
1 2 3 4 5
6 7 8 9 10
1
11
2
12
3
13
4
14
5
15
6
16
7
17
8
18
9
19
10
20
11-20
User button section
Focus, zoom
and iris section
Camera selection section Pan and
tilt section
Color adjustment section Menu operation section
Control panel Buttons, dials
✓:
Enabled
×:
Disabled
Remarks
Menu operation section
[F1], [F2], [F3], [F4] dials ✓
[PAINT] button ✓
[FUNCTION] button ✓
[MAINTENANCE] button ✓
[PMEM/TMEM] button ✓
[SYSTEM] button ✓
[PICTURE] button ✓
[ENABLE] button ✓
Cursor movement buttons ✓
Camera selection
section
[SELECT] button ✓
[CAMERA / GROUP SELECTION 1 to 10]
buttons
✓
Pan and tilt section
PAN/TILT lever ✓
ZOOM/FOCUS rocker ✓
[SPEED] dial ✓
[ENABLE] button ✓
- 6 -
Connecting the Unit to AW-UE70/AW-UN70/AW-HE35/AW-HE38/AW-HE40/AW-HN38/AW-HN40 Series Cameras

Control panel Buttons, dials
✓:
Enabled
×:
Disabled
Remarks
Focus, zoom and iris
section
[FOCUS] dial ✓
[(FOCUS) AUTO] button ✓
[OTAF] button ✓
[(FOCUS) SPEED] dial ✓
[ZOOM] button ✓
[(ZOOM) SPEED] button ✓
[IRIS] dial ✓
[(IRIS) AUTO] button ✓
[ENABLE] button ✓
Color adjustment
section
[BARS] button ✓
[AWB] button ✓
[ABB] button ✓
[WHITE BAL, A/3200K, B/5600K,
ATW/VAR] buttons
✓
[SHUTTER ON] button ✓
[SHUTTER SYNC] button ✓
[SCENE ON/OFF] button × Fixed to ON. (Function is intended for future
expansion.)
[M.PED] dial ✓
[R/B GAIN] dials ✓
[R/B PED] dials ✓
[ENABLE] button ✓
User button section [USER 1] to [USER 6] buttons ✓
- 7 -
Connecting the Unit to AW-UE70/AW-UN70/AW-HE35/AW-HE38/AW-HE40/AW-HN38/AW-HN40 Series Cameras

Menu (when AW-UE70/AW-UN70/AW-HE35/AW-HE38/AW-
HE40/AW-HN38/AW-HN40 is connected)
Remote Controller Menu List
When an AW-UE70/AW-UN70 4K Integrated Camera or AW-HE35/AW-HE38/AW-HE40/AW-HN38/AW-HN40 HD Integrated Camera is
connected, the menu will be as follows. The setting values will vary depending on the connected model. Depending on the model,
unsupported functions will be displayed as [-].
NOTE
To perform menu operations, upgrade the system version of the unit to 1.10-00-0.00 or later.
For details on menu operations, refer to the following sections in the Operating Instructions.
“Basic operations for the menus”
PAINT
SCENE “SCENE” (see page 10)
SHUTTER “SHUTTER” (see page 10)
CHROMA “CHROMA” (see page 11)
GAIN “GAIN” (see page 11)
WHITE BALANCE “WHITE BALANCE” (see page 12)
GAMMA “GAMMA” (see page 12)
DRS “DRS” (see page 13)
DTL “DTL” (see page 13)
COLOR CORRE “COLOR CORRE” (see page 14)
DNR “DNR” (see page 15)
CONTRAST “CONTRAST” (see page 16)
FUNCTION
USER ASSIGN Refer to the following section in the Operating Instructions.
“FUNCTION”
CAMERA INFO “CAMERA INFO” (see page 17)
PTZ INFO1 Refer to the following section in the Operating Instructions.
“FUNCTION”
PTZ INFO2
HOUSING INFO
CROP “CROP” (see page 18)
MAINTENANCE
CAMERA MENU OP Refer to the following section in the Operating Instructions.
“MAINTENANCE”
RP SETTING
FILES
RP INIT
RP VERSION
GPI TALLY
GPIO CAM SEL
GPO CAM.G
GPI PMEM
GPI PMEM.G
SYSTEM
CAMERA Refer to the following section in the Operating Instructions.
“SYSTEM”
CONNECT SETTING
MANUAL IP SET
AUTO IP SET
RP IP SET
TRACKING
- 8 -
Menu (when AW-UE70/AW-UN70/AW-HE35/AW-HE38/AW-HE40/AW-HN38/AW-HN40 is connected)

PMEM/TMEM
PMEM LIST Refer to the following section in the Operating Instructions.
“PMEM/TMEM”
PMEM DIRECT
PMEM STORE
PMEM DEL
TMEM
SETTING
- 9 -
Menu (when AW-UE70/AW-UN70/AW-HE35/AW-HE38/AW-HE40/AW-HN38/AW-HN40 is connected)

PAINT
SCENE
1
SCENE
CAM01 : AW-UE70 1 / 2
SCENE
SCENE1
DRSGAMMA DTL COLOR
CORRE
WHITE
BALANCE
DNR
SHUTTER CHROMA GAIN
2 3 4 5
6 7 8 9 10
1
1 1
Item Setting details
SCENE Switches the shooting mode that matches the shooting situation.
SHUTTER
1
SCENE
CAM01 : AW-UE70 1 / 2
DRSGAMMA DTL COLOR
CORRE
WHITE
BALANCE
DNR
SHUTTER CHROMA GAIN
23 4 5
6 7 8 9 10
1
1 1
MODE
OFF
SPEED
-
Item Setting details
MODE Selects the shutter mode for the camera.
SPEED Selects the shutter speed for the camera.
- 10 -
Menu (when AW-UE70/AW-UN70/AW-HE35/AW-HE38/AW-HE40/AW-HN38/AW-HN40 is connected)

CHROMA
1
SCENE
CAM01 : AW-UE70 1 / 2
DRSGAMMA DTL COLOR
CORRE
WHITE
BALANCE
DNR
SHUTTER CHROMA GAIN
234 5
6 7 8 9 10
1
1 1
LEVEL
+2
Item Setting details
LEVEL Sets the color intensity of images.
GAIN
1
SCENE
CAM01 : AW-UE70 1 / 2
DRSGAMMA DTL COLOR
CORRE
WHITE
BALANCE
DNR
SHUTTER CHROMA GAIN
2 3 45
6 7 8 9 10
1
1 1
AUTO 24 dB
AGC MAXGAIN
Item Setting details
GAIN Adjusts the gain of images.
AGC MAX When “AUTO” is selected as the [GAIN] setting, the maximum gain-up amount can be set.
- 11 -
Menu (when AW-UE70/AW-UN70/AW-HE35/AW-HE38/AW-HE40/AW-HN38/AW-HN40 is connected)

WHITE BALANCE
1
SCENE
CAM01 : AW-UE70 1 / 2
DRSGAMMA DTL COLOR
CORRE
WHITE
BALANCE
DNR
SHUTTER CHROMA GAIN
2 3 4 5
6 7 8 9 10
1
1 1
COLOR TMP R GAIN B GAINMODE
ATW - - -
Item Setting details
MODE Sets the white balance mode.
COLOR TMP This allows you to specify the color temperature between 2000K and 15000K.
R GAIN Adjusts the gain of the R channel.
B GAIN Adjusts the gain of the B channel.
GAMMA
1
SCENE
CAM01 : AW-UE70 1 / 2
DRSGAMMA DTL COLOR
CORRE
WHITE
BALANCE
DNR
SHUTTER CHROMA GAIN
2 3 4 5
67 8 9 10
1
1 1
LEVELTYPE
MID
NORMAL
Item Setting details
TYPE Selects the type of gamma curve.
LEVEL Adjusts the gamma correction level.
This is enabled when [TYPE] is “NORMAL”.
- 12 -
Menu (when AW-UE70/AW-UN70/AW-HE35/AW-HE38/AW-HE40/AW-HN38/AW-HN40 is connected)

DRS
1
SCENE
CAM01 : AW-UE70 1 / 2
DRSGAMMA DTL COLOR
CORRE
WHITE
BALANCE
DNR
SHUTTER CHROMA GAIN
2 3 4 5
678 9 10
1
1 1
DRS
OFF
Item Setting details
DRS Sets the DRS function which performs correction when video with high light/dark contrast is displayed.
DTL
1
SCENE
CAM01 : AW-UE70 1 / 2
DRSGAMMA DTL COLOR
CORRE
WHITE
BALANCE
DNR
SHUTTER CHROMA GAIN
2 3 4 5
6 7 89 10
1
1 1
DTL H LEVEL L LEVEL F.TONE
LOW OFF 18 9
Item Setting details
DTL Adjusts the image contour (i.e., image sharpness).
H LEVEL Adjusts the contour correction level when [DTL] is set to “HIGH”.
L LEVEL Adjusts the contour correction level when [DTL] is set to “LOW”.
F.TONE Sets flesh tone mode to make the skin of subjects appear smoother and more attractive.
- 13 -
Menu (when AW-UE70/AW-UN70/AW-HE35/AW-HE38/AW-HE40/AW-HN38/AW-HN40 is connected)

COLOR CORRE
1
SCENE
CAM01 : AW-UE70 1 / 2
DRSGAMMA DTL COLOR
CORRE
WHITE
BALANCE
DNR
SHUTTER CHROMA GAIN
2 3 4 5
6 7 8 910
1
2
3
4
5
1 2
TYPE
CORRECT
SAT B
SAT B_M
g
_M
g
SAT M
g
_R
SAT
PHS B
PHS B_M
g
_M
g
PHS M
g
_R
PHASE
SAT B_B_M
g
PHS B_B_M
g
SAT M
g
PHS M
g
SAT R PHS R
NORMAL
B
0 0
0
0
0
0
0
0
0
0
0
0
0
0
1
SCENE
CAM01 : AW-UE70 1 / 2
DRSGAMMA DTL COLOR
CORRE
WHITE
BALANCE
DNR
SHUTTER CHROMA GAIN
2 3 4 5
6 7 8 910
6
7
8
9
10
2 2
SAT Yl_G_G
SAT G_C
y
SAT C
y
_C
y
_B
PHSYl_G_G
PHSG_C
y
PHS C
y
_C
y
_B
SAT G PHS G
SAT C
y
PHS C
y
SAT C
y
_B_B PHS C
y
_B_B
0
0
0
0
0
0
0
0
0
0
SATYl PHS Yl SAT Yl_Yl_GPHSYl_Yl_G
00 0 0
SATR_R_Yl PHSR_R_Yl SATR_Yl_Yl PHSR_Yl_Yl
00 0 0
0
0
Item Setting details
TYPE Selects the type of color matrix.
CORRECT Adjusts the saturation and hue.
SAT Adjusts the saturation for each color.
PHASE Adjusts the hue for each color.
SAT B Adjusts blue saturation.
PHS B Adjusts blue hue.
SAT B_B_Mg Adjusts the color saturation with a 3:1 blue to magenta ratio.
PHS B_B_Mg Adjusts the hue with a 3:1 blue to magenta ratio.
SAT B_Mg_Mg Adjusts the color saturation with a 1:3 blue to magenta ratio.
PHS B_Mg_Mg Adjusts the hue with a 1:3 blue to magenta ratio.
SAT Mg Adjusts magenta saturation.
PHS Mg Adjusts magenta hue.
SAT Mg_R Adjusts the saturation of the color between magenta and red.
PHS Mg_R Adjusts the hue of the color between magenta and red.
SAT R Adjusts red saturation.
PHS R Adjusts red hue.
SAT R_R_Yl Adjusts the color saturation with a 3:1 red to yellow ratio.
PHS R_R_Yl Adjusts the hue with a 3:1 red to yellow ratio.
- 14 -
Menu (when AW-UE70/AW-UN70/AW-HE35/AW-HE38/AW-HE40/AW-HN38/AW-HN40 is connected)

Item Setting details
SAT R_Yl_Yl Adjusts the color saturation with a 1:3 red to yellow ratio.
PHS R_Yl_Yl Adjusts the hue with a 1:3 red to yellow ratio.
SAT Yl Adjusts yellow saturation.
PHS Yl Adjusts yellow hue.
SAT Yl_Yl_G Adjusts the color saturation with a 3:1 yellow to green ratio.
PHS Yl_Yl_G Adjusts the hue with a 3:1 yellow to green ratio.
SAT Yl_G_G Adjusts the color saturation with a 1:3 yellow to green ratio.
PHS Yl_G_G Adjusts the hue with a 1:3 yellow to green ratio.
SAT G Adjusts green saturation.
PHS G Adjusts green hue.
SAT G_Cy Adjusts the saturation of the color between green and cyan.
PHS G_Cy Adjusts the hue of the color between green and cyan.
SAT Cy Adjusts cyan saturation.
PHS Cy Adjusts cyan hue.
SAT Cy_Cy_B Adjusts the color saturation with a 3:1 cyan to blue ratio.
PHS Cy_Cy_B Adjusts the hue with a 3:1 cyan to blue ratio.
SAT Cy_B_B Adjusts the color saturation with a 1:3 cyan to blue ratio.
PHS Cy_B_B Adjusts the hue with a 1:3 cyan to blue ratio.
DNR
1
SCENE
CAM01 : AW-UE70 1 / 2
DRSGAMMA DTL COLOR
CORRE
WHITE
BALANCE
DNR
SHUTTER CHROMA GAIN
2 3 4 5
6 7 8 9 10
1
1 1
DNR
LOW
Item Setting details
DNR Sets the level of the digital noise reduction effect for outputting bright, clear images without noise even at
night and in other low-brightness environments.
- 15 -
Menu (when AW-UE70/AW-UN70/AW-HE35/AW-HE38/AW-HE40/AW-HN38/AW-HN40 is connected)

CONTRAST
CAM01 : AW-UE70 2 / 2
1
2
1 1
MODE
AUTO
LEVEL
FRM MIX
AUTO DAY MID
A.F.M MAX DAY/NIGHT NIGHT.D LV
11
0 dB
0
CONT
RAST
Item Setting details
MODE Selects AUTO/MANUAL for image brightness (contrast) control.
LEVEL Sets the convergence level for adjusting image brightness. This is enabled when [MODE] is “AUTO”.
FRM MIX Selects for frame addition (gain-up using sensor storage) amount.
A.F.M MAX Sets the maximum amount of frame addition for when “AUTO” is selected in [MODE] or “AUTO” is selected in
[FRM MIX].
DAY/NIGHT Switches between standard shooting (day mode) and night-vision shooting (night mode: shooting with
infrared light).
NIGHT.D LV Adjusts the level for switching from Night mode to Day mode when [DAY/NIGHT] is “AUTO”.
- 16 -
Menu (when AW-UE70/AW-UN70/AW-HE35/AW-HE38/AW-HE40/AW-HN38/AW-HN40 is connected)

FUNCTION
USER ASSIGN
For details on operations and settings, refer to the following sections in the Operating Instructions.
“USER ASSIGN”
NOTE
When the unit is connected with the AW-UE70/AW-UN70 series, you can assign the image stabilization mode (“I.S.” or “I.S.EXT”)
to a user button. When the function is assigned, the operation is as follows.
I.S.:
OFF and MODE1 selection
I.S.EXT:
OFF and MODE2 selection
CAMERA INFO
1
CAM01 : AW-UE70 1 / 1
CROP
HOUSING
INFO
USER
ASSING
CAMERA
INFO
PTZ
INFO1
PTZ
INF02
23 4 5
6
1
2
3
4
5
1 1
ND OPT
D.ZOOM D.ZM MAX D.EXT
I.S.
OSD STAT
OFF OFF
AUDIO
HDR
OFF OFF
BK LIGHT
OFF -
OFF
×16
OFF
OFF
-
GENLOCK
TYPE2
BARS TYP
Item Setting details
ND Sets the ND filter.
OPT Switches between the normal shooting mode and night mode.
D.ZOOM Sets the digital zoom function to ON/OFF.
D.ZM MAX Sets the maximum digital zoom magnification.
D.EXT Selects the digital extender function.
I.S. Selects the image stabilization mode.
BARS TYP Changes the type of color bar to display.
OSD STAT Sets ON/OFF for status display during AWB execution.
AUDIO Sets the audio input signal from the device connected to the audio input connector to ON/OFF.
GENLOCK Adjusts the horizontal phase during genlock.
HDR Adjusts the effect of the high dynamic range mode.
BK LIGHT Sets the backlight correction function to ON/OFF.
PTZ INFO1
For details on operations and settings, refer to the following sections in the Operating Instructions.
“PTZ INFO1”
PTZ INFO2
For details on operations and settings, refer to the following sections in the Operating Instructions.
“PTZ INFO2”
- 17 -
Menu (when AW-UE70/AW-UN70/AW-HE35/AW-HE38/AW-HE40/AW-HN38/AW-HN40 is connected)

HOUSING INFO
For details on operations and settings, refer to the following sections in the Operating Instructions.
“HOUSING INFO”
CROP
This functions only with cameras that support the crop function. It will not operate with the AW-UE70/AW-UN70/AW-HE35/AW-HE38/AW-
HE40/AW-HN38/AW-HN40.
- 18 -
Menu (when AW-UE70/AW-UN70/AW-HE35/AW-HE38/AW-HE40/AW-HN38/AW-HN40 is connected)

MAINTENANCE
CAMERA MENU OP
For details on operations and settings, refer to the following sections in the Operating Instructions.
“CAMERA MENU OP”
RP SETTING
For details on operations and settings, refer to the following sections in the Operating Instructions.
“RP SETTING”
FILES
For details on operations and settings, refer to the following sections in the Operating Instructions.
“FILES”
RP INIT
For details on operations and settings, refer to the following sections in the Operating Instructions.
“RP INIT”
RP VERSION
For details on operations and settings, refer to the following sections in the Operating Instructions.
“RP VERSION”
GPI TALLY
For details on operations and settings, refer to the following sections in the Operating Instructions.
“GPI TALLY”
GPIO CAM SEL
For details on operations and settings, refer to the following sections in the Operating Instructions.
“GPIO CAM SEL”
GPO CAM.G
For details on operations and settings, refer to the following sections in the Operating Instructions.
“GPO CAM.G”
GPI PMEM
For details on operations and settings, refer to the following sections in the Operating Instructions.
“GPI PMEM”
GPI PMEM.G
For details on operations and settings, refer to the following sections in the Operating Instructions.
“GPI PMEM.G”
- 19 -
Menu (when AW-UE70/AW-UN70/AW-HE35/AW-HE38/AW-HE40/AW-HN38/AW-HN40 is connected)

SYSTEM
CAMERA
For details on operations and settings, refer to the following sections in the Operating Instructions.
“CAMERA”
CONNECT SETTING
For details on operations and settings, refer to the following sections in the Operating Instructions.
“CONNECT SETTING”
MANUAL IP SET
For details on operations and settings, refer to the following sections in the Operating Instructions.
“MANUAL IP SET”
AUTO IP SET
For details on operations and settings, refer to the following sections in the Operating Instructions.
“AUTO IP SET”
RP IP SET
For details on operations and settings, refer to the following sections in the Operating Instructions.
“RP IP SET”
TRACKING
For details on operations and settings, refer to the following sections in the Operating Instructions.
“TRACKING”
- 20 -
Menu (when AW-UE70/AW-UN70/AW-HE35/AW-HE38/AW-HE40/AW-HN38/AW-HN40 is connected)
