Corally SKETER C-00191 Setup guide

QUICK START
USER GUIDE
Download the latest version of the manual as well as other languages from www.corally.com.
Téléchargez la dernière version du manuel ainsi que d’autres langues sur www.corally.com.
Download de laatste versie van de handleiding en andere talen van www.corally.com.
Laden Sie die neueste Version der Anleitung sowie weitere Sprachen von www.corally.com herunter.
C-00191 Manual - Revised : 2021-09-21

2
INTRODUCTION
READ FIRST
Thank you for purchasing a Team Corally car. This manual describes the instructions for using the model and the electronic compo-
nents. You will also nd some tips on how to maintain your RC model so that you can enjoy it for years to come. You have purchased
one of the most efcient models available on the market that has been designed by a team of professionals. You will also benet from
the best after-sales support. All Team Corally models guarantee a high quality of manufacture and performance that guarantees you a
high satisfaction of use and services provided by the Team Corally. Always take the time to read the instructions carefully in order to
follow all the procedures to use your RC model safely for you and for other people and property in the area. This will allow you to take
full advantage of all the performance of your RC model.
Please also check the website www. corally.com/Downloads/ to check if you have the latest version of this instruction manual. (Ver-
sion: see bottom cover of this manual)
If you have any questions about the model and its components, you can send a message to [e-mail]
We also recommend that you get help from an experienced model maker or your dealer.
You will nd all the references of the spare parts on the website www.corally.com
TERM OF USE
The user is responsible for the use of your model. The user assumes all risks associated with the use of the model. This model is not
intended for use by children under 14 years of age without the supervision of a responsible adult who is familiar with the dangers of
using a RC model. Team Corally / JSP Group Intl bvba, its manufacturers, distributors and resellers cannot control the use and load
of the model and therefore cannot be held responsible for any damage to property and damage caused to persons resulting from the
use of this product. You must accept these conditions and consider yourself fully responsible for the use of this product. If not, do not
use this product.
Due to the continuous development of our products, the exact specications of the kit may vary. If you have a problem with your new
kit, please contact the store where you purchased it, indicating the part number(s).
Team Corally / JSP Group Intl bvba reserves the right to change any specication without notice. All rights reserved.
This owner’s manual is designed for use with your vehicle and contains the instructions you will need to operate and maintain your
vehicle.
- We know you want to start driving immediately after unpacking, but it is very important that you take the time to read this manual
carefully, even if you are an experienced R/C driver.
- Read carefully and follow all instructions in this manual. Failure to comply with the instructions will be considered as abuse and/or
negligence which may result in the cancellation of the warranty.
- Your vehicle is designed to operate on uneven terrain. However, dust, sand, water and carpet bres can get into your car’s work-
spaces and can damage your vehicle if they are not removed quickly. We do not guarantee any warranty on your vehicle against
damage caused by external elements such as sand, dirt or water. Users are responsible for the maintenance and safe operation of
this vehicle.
- This product is not a toy. It is not suitable for users under 14 years of age, unless they are supervised by adults.
- Never attempt to disassemble electronic components. These have been carefully calibrated at the factory.
- Only improve your car with parts made for your car. If you upgrade performance, replace the entire system (such as the motor, in-
verter, battery, etc.) so that all components are properly adapted. Any malfunction resulting from a custom modication will void your
warranty.
- Before driving your vehicle, please read this manual in its entirety and examine your vehicle and radio control system for any defects.
- For better performance, some adjustments may be necessary.
- This vehicle requires a battery (included in the car or in the packaging). Make sure the vehicle’s battery is sufciently charged before
driving, otherwise you may lose control of the vehicle.
- The radio transmitter requires 4 AA batteries (not included)
- Always remove or disconnect the battery from the vehicle to the inverter when not in use.
- Please drive your car in a spacious place. Never drive your car on the street or in trafc. Public places are subject to specic legisla-
tion by country, city, municipality, please comply with the legislation for the use of RC models in your region.
- This product is fully assembled in the factory. We accept no liability for damage and/or accidents resulting from custom modica-
tions and/or malfunctions.
SAFETY PRECAUTIONS
For your safety, always use wear gloves and goggles when assembling and maintaining your model.
Always take all necessary precautions when handling products (silicone oil, grease, thread lock, cyanolyte glue, fuel) for the operation
of the model. (Refer to the manufacturer’s instructions)
For your safety, to keep the warranty and obtain the best performance, always use original CORALLY genuine parts.
Contains: LEAD (CAS 7439-92-1) ANTIMONY (CAS 7440-36-0)
WARNING: This product contains a chemical known to the state of California to cause cancer and birth defects or other reproductive
harm.
CAUTION: CANCER HAZARD
Contains lead, a listed carcinogen. Lead is harmful if ingested. Wash thoroughly after using.
DO NOT use product while eating, drinking or smoking.

3
USE PRECAUTIONS
Failure to operate your model in a safe and responsible manner may result in injury to yourself, others or damage to property around
you.
• Do not use your model on public roads or in areas where you may encounter pedestrians or riders.
• Do not operate in a congested area or in crowds.
• Do not operate in areas where loud noises can disturb others, such as hospitals and residential areas.
• Do not operate your model with obstructed line of sight, at night or near water.
• Your model is radio controlled, it is subject to possible radio interference. Radio interference can cause
loss of control of your model. Be careful.
• Take care not to injure yourself while using tools to adjust or upgrade your model.
• Since the model contains small parts, keep out of reach of children while assembling and/or disassem-
bling your model.
• If your model becomes stuck against an object, release the throttle and retrieve it by hand
• Do not continue to apply the throttle when your model is stuck. This may damage the motor and/or ESC/
Receiver unit.
• Turn OFF your model and don’t use it if it runs erratically. Please do not use your model again until the
problem has been solved.
• Keep the wheels of the model off the ground when checking the operation of the radio equipment.
• When learning to operate your model, go to an area that has no obstacles that can damage your model.
• Before and after each use, check all the screws on the model.
• To maintain the best performance, check that all moving parts move freely.
Take all necessary precautions before, during and after using your model. You are responsible for the safe assembly, mainte-
nance and use of your model.
In case of any questions, contact your local reseller or contact Team Corally support for assistance.
LIPO BATTERY SAFETY PRECAUTIONS
• Follow and respect the manufacturer’s instructions for use
• It is important to check that your ESC is set to LIPO if you are using a LIPO battery. Failure to comply with this instruction will result
in increased battery discharge and may cause re and damage to persons and property.
• When charging or storing LiPo batteries always use LiPo Safety Bag (Flame retardant).
• Always respect the maximum rate and voltage specied by the battery manufacturer.
• Charge the LIPO battery outdoors or in a ventilated area away from ammable objects and surfaces.
• NEVER leave your LiPo battery unattended while charging.
• If the battery swells during charging, stop charging immediately and disconnect the battery from the charger. Leave the battery
outside for a few hours and observe. Then recycle the battery according to the instructions of your country/region. Never dispose of
a LIPO battery with domestic waste.
• Before recycling your defective battery, it must be neutralized. Take a plastic container, ll it with water and add a lot of salt until the
water becomes opaque. Place the LIPO battery in the water and leave for 24 hours. Check with a voltmeter that the voltage is 0.0V.
Then recycle the battery according to local regulations.
• Never charge a damaged or inated battery.
• Never discharge the battery cells below 3.2V.
• Always use the appropriate balancer/charger when charging your LiPo battery pack.
• When the battery is empty, check the temperature of the battery before charging it.
If the battery is very hot, wait until it cools before charging it.
• Never charge a very hot battery as this may cause an explosion or re.
• When the battery is empty, recharge it immediately. Do not store an empty battery, the battery will continue to discharge, it will fall
below the minimum voltage and become unusable.

4
WARRANTY
If material defects or manufacturing faults should arise in a product distributed or manufactured by
Team Corally / JSP Group Intl bvba, and purchased by a consumer, we Team Corally / JSP Group Intl bvba acknowl-
edge the obligation to correct those faults or defects within the limitations described below. This manufacturers warranty
is in addition to, and does not affect, the legal or contractual rights of the consumer which arise from the purchase of
such products. Team Corally / JSP Group Intl bvba guarantees the consumer that its products are free from material,
manufacturing, and construction faults, as determined by the general state of knowledge and technology valid at the
time of manufacturing. The fault responsible for causing the damage must be proven to have been present in the prod-
uct at this time. Claims for compensation arising from consequential damage or product liability will not be considered
valid unless they fall under peremptory provisions of the law. If material defects or manufacturing faults should arise in
a product distributed or manufactured by Team Corally / JSP Group Intl bvba in the European community (EC) and pur-
chased by a consumer, then Team Corally / JSP Group Intl bvba undertakes to correct those defects within the limita-
tions described below. This manufacturer’s declaration does not affect the consumer’s legal or contractual rights regard-
ing defects arising from the purchase contract between the consumer and the dealer or reseller. Extend of the Warranty
If a claim is made under warranty, we take at our discretion to repair or replace the defective goods. We will not consider
supplementary claims, especially for reimbursement of costs relating to the defect (e;g. installation / removal costs) and
compensation for consequent damages unless they are allowed by statute. This does not affect claims on legal regula-
tions, especially according to the product liability law.
Provisions of the Warranty
The purchaser is required to make the warranty claim in writing, and must enclose original proof of purchase (e.g.
invoice, receipt, delivery note) and the appropriate warranty card. He must send the defective goods to our local rep-
resentatives or directly to Team Corally / JSP Group Intl bvba, Geelseweg 80, 2250 Olen, Belgium at his own risk and
cost.
The purchaser should state the material defect or manufacturing fault, or symptoms of the fault, as accurate as possible,
so that we can check if our warranty obligation is applicable. The goods are transported from the consumer to us, and
from us to the consumer, entirely at the risk and cost of the consumer.
Invalidation of the Warranty
The consumer cannot make a claim under warranty when the fault is affecting the use of the product arising from natural
wear, competition use, or improper use (including installation) or external forces. The consumer’s adherence to the
building and operating instructions relevant to the model, including the installation, operation, use of, and maintenance
of, model-related components cannot be supervised by Team Corally / JSP Group Intl bvba. Therefore Team Corally /
JSP Group Intl bvba is in no way liable for loss, damage, or costs resulting from improper use, or behaviour in any way
connected to the above described provisions. Unless otherwise required by law, Team Corally / JSP Group Intl bvba is
in no way whatever liable to provide compensation for damages arising from the improper use of the model (including
personal injury, death, damage to buildings, loss of turnover, loss of business, or interruption of business, or any other
direct, or indirectly caused, consequential damage).
Duration of Validity
The claim period is 24 months from the date of purchase of the product by the consumer from a dealer in the European
Community (EC) counted from the date of purchase. The claim period is 12 months from the date of purchase of the
product by the consumer from a dealer outside the European Community (EC) counted from the date of purchase. If
a defect arises after the end of the claim period, or if evidence or documents required according to this declaration in
order to make the claim valid are not presented until after this period, then the consumer forfeits any rights or claims
from this declaration. The guarantee period is not prolonged by the granting of any claims within the framework of this
warranty, especially in the case of repair or replacement. The guarantee period also does not restart in such cases.
Warranty Expiration
If we do not acknowledge the validity of a claim based on this declaration within the claim period, all claims based on
this declaration will expire after six months from the time of registering the claim; however this cannot occur prior to the
end of the claim period.
For any support, contact us at support.corally.com

5
KIT CONTENT (Depends on the selected model)
REQUIRED FOR OPERATION (Not included)
Transmitter User Guide
4x AA Batteries
for the Transmitter
1.5mm
2.0mm
3.0mm
Hex Drivers
Cross Wrench
4S - 14.8V LiPo Battery
Silicone Oil
(for maintenance)
Charger
RTR Model (Chassis with Body)
- Check the corally.com website download section and make sure you have the latest version of this manual
(see date on the cover of the manual)
- Vistez le site web corally.com section téléchargement et controlez que vous avez la dernière version de ce manuel (voir date sur la couverture du manuel)
- Überprüfen Sie die Website corally.com im Download-Bereich und stellen Sie sicher, dass Sie die neueste Version dieses Handbuchs haben
(siehe Datum auf dem Umschlag des Handbuchs).
- Kijk op de corally.com website in de download sectie en zorg ervoor dat u de laatste versie van deze handleiding heeft (zie datum op de omslag van de handleiding)
DOWNLOAD - TELECHARGER - DOWNLOAD - DOWNLOAD

6
Front Differential
CAR COMPONENTS
Steering Servo
Speed Controller (ESC)
Brushless Motor
Battery compartment
Receiver Box
Steering Link
Steering Block
Suspension Arm
Anti-Roll Bar
Rear Suspension Arm
Rear Upright
Camber Link
Wheel Axle
Rear Shock Absorber
Power Switch
Anti-Roll Bar
Front Shock Absorber
Rear Differential
Centre Differential

7
QUICK START GUIDE
1.5V - AA BATTERY
INSTALL 4x AA BATTERY
TURN ON THE TRANSMITTER (Always First)
READ THE INSTRUCTIONS
MAKE SURE THAT ALL SCREWS AND NUTS ARE
TIGHTENED PROPERLY.
CHARGE THE BATTERY
INSTALL THE BATTERY
WHEN FINISHING
CHECK THE FUNCTIONS CHECK THE RADIO SYSTEM RANGE
Move away from the max. distance you will drive the vehicle.
Check that the vehicle responds properly to the controls.
If not, reduce the distance or change the driving location.
DRIVE SLOWLY TO BEGIN
1.5V - AA BATTERY 1.5V - AA BATTERY 1.5V - AA BATTERY
CHARGER
BATTERY
BATTERY
BATTERY
ON
OFF
CONNECT THE BATTERY TO THE ESC
SWITCH ON THE ESC
CLEAN AND MAINTAIN YOUR VEHICLE
CHARGER
BATTERY
ON
OFF
CHARGE THE BATTERY

8
SILICONE
OIL
50%
WAIT TIGHTEN TIGHTEN
FULLY
5min
FILL MOVE
UP
3-4x
SLOWLY
MOVE
UP
FRONT REAR
SILICONE OIL SPRING TENSION SILICONE OIL SPRING TENSION SHOCK PISTON
OFF-ROAD 600CPS 4mm 600CPS 0mm 6 Holes Ø1.4mm
BASHING 700CPS 4mm 600CPS 0mm 6 Holes Ø1.4mm
FACTORY 600CPS 4mm 600CPS 0mm 6 Holes Ø1.4mm
SPRING TENSION
SHOCK ABSORBER MAINTENANCE
Remove the shock absorbers from the car. (4x) Remove the shock cap. Drain the oil from the shock absorber.
It may be necessary to replace the silicone oil in the shock absorbers every 40 runs.
It depends on how you drive and the type of terrain you drive on.
FILL THE SHOCK ABSORBERS WITH NEW SILICONE OIL ALWAYS USE SILICONE OIL, NEVER USE ANY OTHER TYPES OF OIL.
.www. corally.com/Chemicals/Silicone-Oils/
• Pull the Shock shaft
down.
• Fill the shock body with
silicone oil.
• Front : 450cps
Rear : 400cps
• Move the piston up&down
(3-4x) to release the air
bubbles in the silicone
oil.
• Pull the Shock shaft
down.
• Install the shock absorb-
er vertically and let it sit
for a few minutes until
the bubbles rise to the
surface.
• Install the silicone mem-
brane in the shock cap.
• Tighten slightly the
shock cap on the shock
body.
• A little oil will flow out of
the shock absorber.
• Gently move the piston
in upper position.
• The excess will flow out
of the shock absorber.
• Allow the piston in the
upper position.
• Tighten the cap fully but
not too much otherwise
the membrane will be
deformed.

9
APPLY
SILICONE OIL
Place all small parts on a screwdriver (Ø3mm)
and push them into the shock body. All parts
will be properly aligned.
Shock Piston - 6x1.4
Shock Piston - 8x1.2
C-00180-768 Shock Piston
Set content (8PCS)
C-00180-134-1
Shock Absorber “Ready Build” - Long - No Spring - 1 pc
600 CPS Oil Filled
C-00180-133
C-00180-189
C-00180-768
C-00180-190
C-00180-192
C-00180-136
C-00180-138
C-00180-029
C-00180-770
C-00180-149
C-00180-078
C-00180-188
C-00180-188
C-00180-191
C-00180-286 - SOFT
C-00180-164
C-00180-134
C-00180-287 - MEDIUM (Factory)
C-00180-288 - HARD
C-31001-25
SHOCK ABSORBER - EXPLODED VIEW
Do not overtighten the Shock Cap to
prevent deformation of the silicone
Shock Bladder.

10
FRONT DIFF CENTRE DIFF REAR DIFF
OFF-ROAD 20.000CPS 50.000CPS 10.000CPS
FACTORY 20.000CPS 100.000CPS 20.000CPS
Use the correct grade of silicone oil according to the operation.
Use only Silicone Oil, never use any other types of oil.
Perform the same maintenance operations for the centre and rear differentials.
DIFFERENTIAL MAINTENANCE
• 1. Remove the skid plate under the chassis.
• 2. Remove the front bumper.
• 3. Remove the 2 shock absorbers fixing screws.
Rotate the shock absorbers upwards
• 4. Loosen the anti-roll bar ball.
Remove the 2 upper fixing screws from the
differential cover.
• 5. Extract the differential.
• 6. Unscrew the differential.
• 7 Drain the silicone oil from the differential.
• 8 Fill with new silicone oil but not fully.
(75% capacity max.)
SILICONE OIL
It may be necessary to replace the silicone oil every 50 runs. It depends on how you drive and the type of terrain you drive on.
www. corally.com/Chemicals/Silicone-Oils/
75%
CAPACITY MAX.

11
C-00180-687
Diff Assembly - Front / Rear -
43T Bevel Gear - 1 set
C-00180-685-1
Centre Diff Assembly - Alu /
Steel - 52T Main Gear - 1 set
C-00180-154-X
C-3611-3-08-16-05 C-00180-205
C-00180-607
C-00180-183-1
C-00180-183-1
C-00180-182
C-00180-686
C-00180-684
C-00180-154-X
C-00180-182
C-00180-205
C-00180-686
C-3002-30-10 (x4)
C-3002-30-10 (x4)
C-3611-3-08-16-05
C-00180-179 (set)
C-00180-153-X
C-00180-153-X
C-00180-178
C-00180-182
C-00180-182
C-00180-205
C-00180-205
C-00180-179 (set)
C-00180-183
C-00180-184
C-00180-098
C-3611-3-08-16-05
C-3611-3-08-16-05
C-3002-30-12 (4pcs)
FRONT & REAR DIFFERENTIAL - EXPLODED VIEW
CENTRE DIFFERENTIAL - EXPLODED VIEW

12
GEAR RATIO
GEAR MESH ADJUSTMENT
PAPER STRIP 1x8cm
MOTOR PINION MOD1.0
www.corally.com/Pinions-Gears/Pinions-MOD1/
+TORQUE +SPEED
OK Factory fitted Usable but not recommended Not recommended, at your own risk
GEAR RATIO : 3.31
High-performance 13T tooth pinion gear, manufactured from special steel for toughness and durability with precise tolerances and assures
unparalleled concentricity. Created on a special gear machine, all pinions feature ultra-precise tooth shaping and ultra-true running for
vibration-free operation. Each pinion is marked with the tooth number for easy and quick identification.
• Special hardened steel
• CNC cut teeth for perfect teeth shape and concentricity
• Module MOD1
• fits all cars with MOD1 gears (1/8 Scale)
• for 5.0mm motor shafts
NOTE : The speed indicated in the table is a theoretical speed for information purposes.
The real speed varies according to the type of terrain, electronic equipment, atmospheric conditions and other driving parameters.
1. Loosen the screws.
2. Insert the paper strip.
3. Push the motor against the spur gear.
4. Turn the spur gear to run the paper through
the teeth.
Stop when the paper is in the middle.
Make sure that the motor pinion is against
the spur gear.
5. Tighten the fixing screws and extract the
paper strip.
If the gear mesh is not correct, you wear out the spur gear prematurely, the transmission will make noise, give unnecessary load on the
motor (higher consumption, heating of the transmission).
Km/h Mph Km/h Mph Km/h Mph Km/h Mph Km/h Mph Km/h Mph
Km/h Mph Km/h Mph
Gear 11T Pinion 12T Pinion 13T Pinion 14T Pinion 15T Pinion 16T Pinion
17T Pinion 18T Pinion
52T 15,66 14,33 13,24 12,28 11,49 10,76
8,95 8,45
4S 56 32 61 38 66 41 71 44 76 47 81 51
73 46 78 48
6S 71 44 78 48 84 52 91 56 97 60 104 64 110 68 117 72

13
FRONT DRIVE TRAIN - EXPLODED VIEW
C-00180-117-1
C-00180-117-1
C-00180-009
C-00180-009
C-00180-123-1
C-00180-123-1
C-00180-009-1
C-00180-009-1
C-00180-011
C-00180-011
C-00180-329
C-00180-329
C-00180-122
C-00180-122
C-00180-555
C-00180-555
C-00180-150
C-00180-150
C-00180-360
C-00180-360
C-00180-012 (x2)
M4x10
C-00180-149
C-00180-089
C-3003-30-16
C-00180-051
C-3003-30-20
C-3003-30-16
C-00180-419
C-00180-322 (x2)
C-00180-033 (set)
C-00180-033 (set)
C-00180-055 (set)C-3004-50-05
C-00180-155-X
C-3611-3-08-16-05 (x2)
C-00180-156
C-00180-687
M4x10
C-00180-149
C-00180-089
C-3101-30 (x4)
C-3101-30 (x2)
C-3101-30 (x2)
C-00180-231
C-00180-197
C-00180-220
C-3003-25-10
C-00180-033 (set)
C-00180-051
C-00180-419
C-3003-30-10 (x2)
C-3003-25-18
C-00180-219 (x2)
C-00180-048
C-00180-658 (x2)
C-00180-703 (set)
C-00180-703 (set)
C-00180-703 (set)
C-00180-698 (set)
C-00180-698 (set)
C-00180-698 (set)
C-00180-652
C-00180-149 (x2)
C-00180-045
C-00180-148
C-00180-692
C-3101-40-6
C-3003-30-20
C-3003-30-14 (x2)
C-3003-30-12 (x2)
C-3003-30-14 (x2)
C-3003-30-16 (x2)
C-3003-30-20 (x2)
C-3003-30-10 (x2)
C-3003-30-10 (x4)
C-3003-30-10 (x4)
C-3003-30-08 (x2)
C-3003-30-08 (x2)
LED light
(not included)
LED light
(not included)
C-3003-30-10 (x3)
C-3101-30 (x2)
C-3003-30-12 (x4)
C-00180-110
C-3201-60
C-3201-60
C-3201-60
C-3201-60
C-00180-207
C-00180-207
C-3003-30-10
C-3003-30-10
C-3004-40-04
C-3004-40-04
C-3004-30-03
C-3004-30-03
C-3004-30-03
C-3003-30-12 (2x)
C-3003-30-12 (2x)
C-3611-3-08-16-05 (x2)
C-3611-3-08-16-05 (x2)
The bumper of this model allows the installation of
LED lighting (not included)

14
C-3003-30-10 (x2)
C-3003-30-16
C-3003-30-25
C-3003-30-20
C-3003-30-16
C-3003-30-25
C-3003-30-30 (x2)
C-3003-25-18
C-3003-30-20
C-3003-30-14 (x2)
C-3003-30-14 (x2)
C-3003-30-14 (x2)
C-3003-30-18 (x2)
C-3003-30-16 (x2)
C-3003-30-16 (x2)
C-3003-30-12 (x2)
C-3003-25-04 (x2)
C-3003-25-04 (x2)
C-3003-25-04
C-3003-25-04
C-3003-30-20
C-3003-30-16
C-3003-30-16
C-3003-30-16 (x2)
C-3003-30-12 (x2)
C-3003-30-18
C-3003-25-10 (x2)
C-00180-148
C-00180-658
C-00180-658
C-00180-651
C-00180-033
DIN913•M3x3 (x2)
C-00180-220
DIN913•M3x3
C-00180-197
C-00180-693
C-00180-693
DIN913•M3x3
C-00180-231
C-00180-033
C-00180-418
C-00180-052
C-00180-635
C-00180-322
C-00180-687
C-00180-156
C-3101-30 (x4)
C-3101-40
C-3101-40
C-3101-40
C-00180-556
C-00180-369-1
C-3611-3-08-16-05 (x2)
C-00180-329
C-00180-122
C-00180-061
C-00180-297
C-00180-654 (x2)
C-00180-552
C-00180-653 (set)
C-00180-653 (set)
C-00180-656
C-00180-293
C-00180-556
C-00180-170
C-3101-30
C-3101-40
C-3101-30
C-3101-30 (x4)
C-00180-230
C-00180-008
C-00180-127
C-00180-370-X
C-00180-369-1
C-00180-010
C-00180-010
C-00180-149
C-00180-089
C-00180-418
C-00180-052
C-00180-059
C-00180-033
C-00180-149
C-00180-059 (set)
C-3101-30
C-3101-30
C-3101-40
C-3101-30
C-3611-3-08-16-05 (x2)
C-3611-3-05-11-04 (x2)
C-00180-155-X
DIN913
M5x5
C-00180-089
C-00180-149
C-00180-370-X
C-00180-020
C-00180-149
C-00180-170
C-00180-055
C-00180-293
C-3611-3-08-16-05 (x2)
C-00180-329
C-00180-008
C-00180-122
DIN913•M4x4
C-00180-055
C-00180-127
C-3004-40-04
C-3003-30-25
C-3002-40-20 (x2)
C-3002-40-16 (x2)
C-3002-30-12
C-3003-30-16
C-3003-30-16
C-3003-30-20 (x2)
C-3003-40-08
C-3003-40-08
C-3213-30-5
C-3213-30-5 (x4)
C-00180-230
REAR DRIVE TRAIN - EXPLODED VIEW

15
C-3101-30 (x4)
C-3101-30 (x4)
C-3101-30 (x4)
C-3101-30 (x2)
C-3101-30 (x2)
C-3101-30 (x2)
C-3101-30
C-3101-30 (x4)
C-3101-40 C-00180-305
C-00180-305
C-3101-40
C-3101-40
C-3101-40
C-3101-40
C-3101-30
C-3101-30
C-3101-40
C-3003-30-14 (x2)
C-3003-30-06 (x2)
C-3003-30-12 (x2)
C-3002-30-08 (x2)
C-3003-40-22
C-3003-40-22 (x2)
C-3003-30-30 (x2)
C-3003-30-16 (x4)
C-3003-30-14 (x2)
C-3003-30-18
C-3003-30-10 (x5)
C-3003-30-10 (x4)
C-3002-30-06 (x4)
C-3003-25-10 (x3)
C-3003-25-10 (x2)
C-3003-40-20
C-3002-30-16 (x2) C-3002-30-06 (x4)
C-3002-30-10 (x4)
C-3002-30-10 (x4)
C-3003-40-16 (x2)
C-00180-305
C-00180-305
C-3003-30-06 (x4)
C-3002-40-20 (x4)
C-3002-30-12 C-3002-40-10 (x6)
C-3002-40-12 (x4)
C-3002-40-12 (x4)
C-3002-40-10
C-3002-40-10 (x2)
C-3002-30-10 (x4)
C-3003-30-08 (x2)
C-3003-30-06 (x2)
C-00180-175
C-00180-150 (x2)
C-3213-30-5
C-3213-30-5 (x4)
C-3213-30-5 (x4)
C-3003-30-10 (x2)
C-3003-30-16
(x2)
C-3003-30-08
(x2)
C-3003-30-16 (x4)
C-00180-662
C-00180-669
C-00180-663
C-00180-646 (set)
C-00180-171
C-00180-716 (set)
C-00180-643 (set)
C-00180-643 (set)
C-00180-716 (set)
C-00180-716 (set)
C-00180-716 (set)
C-00180-685
C-00180-023
C-00180-714
C-00180-634
C-00180-645
C-00180-646 (set)
C-00180-646 (set)
C-00180-551
C-00180-636 (set)
C-00180-216
C-00180-145
C-00180-191
C-00180-715
C-00180-637
C-00180-562
C-00180-018
Receiver
C-00180-372
Servo
C-00180-149
C-00180-129
C-00180-044
C-00180-044
C-00180-661
C-00180-662
C-00180-662
C-00180-662
C-00180-664 (set)
C-00180-660 (set)
C-00180-660 (set)
C-00180-665 (set)
C-00180-660 (set)
C-00180-640
C-00180-655
C-00180-639
C-00180-145
C-00180-206 (x2)
C-00180-831
C-00180-529
C-00180-036 (set)
C-00180-036
(set)
C-3004-40-04
C-00180-147
C-72713
C-54054
C-54012
FRONT
REAR
C-3213-40-5 (x4)
C-3104-40 (x2)
C-3611-3-06-10-03 (x2)
C-3611-3-06-10-03 (x2)
M4x10mm DIN7991
#C-3002-40-10
M4x12mm DIN7991
#C-3002-40-12
M4x16mm DIN7991
#C-3002-40-16
M4x20mm DIN7991
#C-3002-40-20
M3x12mm DIN7991
#C-3002-30-12
C-00180-636 (set)
CHASSIS - EXPLODED VIEW
CHASSIS - SCREWS DESCRIPTION

16
C-00180-010
Suspension Arm - Lower - Rear
- Composite - 1 pc
C-00180-011
Suspension Arm - Upper - Front
- Composite - 1 pc
C-00180-012
Suspension Arm - Lower - Front
- Composite - 1 pc
C-00180-008
Hub - Rear - Composite - 1 pc
C-00180-009-1
HD Steering Block - Pillow Ball
Cup (2) - Front - Composite - 1 Set
C-00180-170
Ball - 6.8mm - Steel - 2 pcs
C-00180-127
Hinge Pin - Outer - Steel - 2 pcs
C-00180-048
Bushings Set - 0 Deg -
Composite - 1 Set
C-00180-055
Suspension Arm Shim - Com-
posite - 1 Set
C-00180-089
Anti-Roll Bar Ball Cups - Com-
posite - 4 pcs
C-00180-109
Caster Clips Set - 1 to 4.5mm
- 1 Set
C-00180-020
Gearbox Brace Mount A - Rear -
Composite - 1 pc
C-00180-018
Centre Diff Bulkhead - Compos-
ite - 1 Set
C-00180-023
Motor Mount Centre Diff Insert -
Composite - 1 pc
C-00180-033
Gearbox Case Set - Composite
- 1 Set
C-00180-036
Steering Bellcrank - Parts A-B-C
- Composite - 1 Set
C-00180-044
Ball Joint 6mm - Composite -
2 pcs
C-00180-045
Bumper Spacer - Front - 1 pc
C-00180-051
Suspension Arm Mount - Front -
Composite - 1 Set
C-00180-052
Suspension Arm Mount - Rear -
Composite - 1 Set
C-00180-117-1
Pivot Ball Adjusting Nut - w/
O-Ring - Aluminum - 1 Set
C-00180-123-1
Pivot Ball - Steel - 4 pcs
C-00180-329
Wheel Hex Adapter - Wide RTR
- Aluminium - 2 pcs
C-00180-230
Wheel Nut - Aluminium -
Ribbed - 4 pcs
C-00180-122
Pin 2.5x17mm - Steel - 10 pcs
C-00180-129
Turnbuckle - M3 - 35mm -
Steel - 2 pcs
C-00180-145
Servo Saver Shaft w/ Nut -
Aluminium - 1 pc
C-00180-147
Servo Saver Post - Steel - 2 pcs
C-00180-148
Shock Screw - Steel - 4 pcs
C-00180-149
Ball - 5.8mm - Steel - 4 pcs
C-00180-150
Ball Shouldered - 6.8mm - Steel
- 4 pcs
C-00180-171
Threaded Ball - 6mm - Steel -
2 pcs
C-00180-175-2
Steering Rack - Aluminium
7075 - 1 pc
C-00180-831
Steering Rack - Dual Stiffener -
Aluminum - 1 pc
C-00180-191
O-Ring - Silicone - 9x12mm
- 5 pcs
SPARE PARTS

17
C-00180-197
Anti-Roll Bar - 2.4mm - Front
- 1 pc
C-00180-200
Anti-Roll Bar - 2.4mm - Rear
- 1 pc
C-00180-220
Ball End 5.8mm - for Anti Roll
Bar - Steel - 4 pcs
C-00180-219
Suspension Arm Pivot Pin -
Upper - Front - Steel - 2 pcs
C-00180-231
Collar - for Anti-roll Bar - Alu-
minium - 1 pc
C-00180-293
Ball 6.8mm - Steel - 4 pcs
C-00180-556
Camber Links Rear - Buggy -
Composite - 2 pcs
C-00180-635
Shock Tower - 5mm - Alumini-
um - Rear - 1 pc
C-00180-529
Suspension Arm Mount - Upper
- Front - Aluminium - 1 Pc
C-00180-322
Suspension Arm Pivot Pin - Low-
er Inner - Fr/Re - Steel - 2 pcs
C-00180-370-X
PRO Drive Axle - Short - Rear -
Swiss Spring Steel - 2 pcs
C-00180-369-1
Universal Drive Shaft - Buggy -
Rear - 1 pc
C-00180-552
Rear Bumper w / Skid Plate -
Composite - 1 pc
C-00180-297
Rear Bumper Weelie-Bar -
Composite - 1 pc
C-00180-206
Steering Rack Bushing - Steel
- 2 pcs
C-00180-216
Servo Saver Spring - 1 pc
C-00180-207
Steering Block Arms - Alumini-
um - 2 pcs
C-00180-360
Universal Joint Drive Shaft -
Buggy - Front - 1 pc
C-00180-372
Servo Arm - Steering - Alu -
1 pc
C-00180-551
Front Bumper w / Skid Plate -
Composite - 1 pc
C-00180-555
Steering Links - Buggy - Com-
posite - 2 pcs
C-00180-562
Centre Diff Support Spacer -
4mm - Composite - 1 pc
C-00180-634
Motor Mount - Aluminium - 1 pc
C-00180-655
Centre Diff. Cover - RTR - Com-
posite - 1 pc
C-00180-636
Chassis Brace - MT - Front /
Rear - Composite
C-00180-643
Side Guards - Left-Right - Com-
posite - Set
C-00180-646
Battery - ESC Holder Plate - RX
Box Cover - Composite - 1 Set
C-00180-004-1
Battery Strap - Hook & Loop
- 2 pcs
C-00180-645
Chassis - MT-Short - RTR -
Aluminium - 1 pc
C-00180-637
Upper Plate - Front - Compos-
ite - 1 pc
C-00180-640
Centre Diff. Plate - Composite
- 1 pc
C-00180-652
Shock Tower - 5mm - Alumini-
um - Front - 1 pc
C-00180-651
Wheelie bar support A - RTR -
Composite - 1 pc
C-00180-418
Suspension Arm Mount - XTR -
Rear - 7075 Aluminum - 1 Set
C-00180-419
Suspension Arm Mount - XTR -
Front - 7075 Aluminum - 1 Set
SPARE PARTS

18
C-00180-614
Body Clip Retainer w/ Body clip
- Black - 6 pcs
C-00180-653
Wheelie Bar Upper & Lower
Arms - Composite - Set
C-00180-656
Wheelie bar Wheel - RTR -
Composite - 1 pc
C-00180-654
Wheelie bar Wheel Axle - RTR -
Steel - 2 pcs
C-00180-660
Switch Holder - Torox 135 - 180
Switch - Tube 12mm - 1 Set
C-00180-662
Shock Tower Brace Holder -
Tube 12mm - Composite - 1 set
C-00180-663
Shock Tower Brace - Front - MT
- Aluminum - Black - 1 pc
C-00180-669
Shock Tower Brace - Rear -
Aluminum - Black - 1 pc
C-00180-693
Body Post - Rear - RTR - Com-
posite - 2 pcs
C-00180-692
Body Post - Front - RTR - Com-
posite - 2 pcs
C-00180-632
MT Tires Glued on Rims -
2 pcs
C-54054
Electric Motor – Kuron 725 –
Brushless - Sensorless
C-54012
Speed Controller - TOROX 135 -
Brushless - 2-4S
C-52022
Digital Servo - CRHV-7225-MG
- High Voltage - Core Motor -
Metal Gear – 25 Kg Torque
C-00180-639
Gear Box Brace Mount - Rear -
Composite - 1 pc
C-00180-664
Chassis Tube - Front - 130mm -
Aluminum - Black - 1 Set
C-00180-665
Chassis Tube - Rear - 110mm -
Aluminum - Black - 1 Set
C-00180-623
Painted Body - MT SKETER XP
4S - RTR - 1 pc
Check the availability of spare parts on the website www.corally.com
Visualisez la disponibilité des pièces de rechange sur le site web www.coally.com
Sehen Sie sich die Verfügbarkeit von Ersatzteilen auf der Website www.corally.com an.
Controleer de beschikbaarheid van reserveonderdelen op de website www.corally.com
C-00180-698
Bumper MT - Front - w/ LED
Holder - Composite - 1 pc
C-00180-703
Bumper Holder / Absorber -
Front - Composite - 1 pc
C-00180-716
Centre Roll Cage - Composite
- 1 set
C-00180-305
Center Roll Cage Pin - Steel -
2 pcs
C-72713
M1.0 Pinion - Hardened Steel -
13 Teeth - Shaft Dia. 5mm
SPARE PARTS
S
P
A
R
E
P
A
R
T
S
A
V
A
I
L
A
B
L
E
O
N
w
w
w
.
c
o
r
a
l
l
y
.
c
o
m
Click !

19
C-00180-178
Diff. Bevel Gear 43T - Steel -
1 pc
C-00180-179
Planetary Diff. Gears - Steel -
1 Set
C-00180-156
Bevel Pinion 13T - Steel - 1 pc
C-00180-182
O-Ring - Silicone - 5x8mm -
5 pcs
C-00180-098
Diff Case - FR-RE - Composite
- 1 pc
C-00180-183
Diff. Gasket - 4 pcs
C-00180-184
Gear Diff. Pin - Steel - 2 pcs
C-00180-205
Diff. Outdrive Pin - 2x11,8mm -
Steel - 4 pcs
C-00180-153-X
PRO Diff. Outdrive Cup - Swiss
Spring Steel - 2 pcs
C-00180-179
Planetary Diff. Gears - Steel -
1 Set
C-00180-182
O-Ring - Silicone - 5x8mm -
5 pcs
C-00180-183-1
Central Diff. Gasket - 4 pcs
C-00180-715
Drive Shaft - Center - Front -
85.5mm - Steel - 1 pc
C-00180-714
Drive Shaft - Center - Rear -
110mm - Steel - 1 pc
C-00180-154-X
PRO Centre Diff. Outdrive Cup -
Swiss Spring Steel - 2 pcs
C-00180-607
Spur Gear 52T - Steel - 1 pc
C-00180-685-1
Centre Diff Assembly - Alu /
Steel - 52T Main Gear - 1 set
100K Oil Filled
C-00180-155-X
PRO Pinion Outdrive Cup -
Swiss Spring Steel - 2 pcs
C-00180-687
Diff Assembly - Front / Rear -
43T Bevel Gear - 1 set
20K Oil Filled
C-00180-686
Diff Case - Centre - Aluminium.
- 1 pc
For use with Diff Pin C-00180-684
C-00180-684
Gear Diff Pin - 3.5x29.8mm -
for C-00180-686 - Steel - 4 pcs
For use with C-00180-686
SPARE PARTS
FRONT & REAR DIFFERENTIAL - SPARE PARTS
CENTRE DIFFERENTIAL - SPARE PARTS

20
C-00180-138
Shock Cap - Lower - Composite
- 2 pcs
C-00180-029
Shock Spring Cup - Composite
- 4 pcs
C-00180-164
Shock Shaft - 66mm - Rear -
Steel - 2 pcs
C-00180-133
Shock Cap - Aluminium - Hard
Anodised - 2 pcs
C-00180-134
Shock Body - Rear - Aluminium
- Hard Anodised - 1 pc
C-00180-136
Shock Collar - Aluminium -
Hard Anodised - 2 pcs
C-00180-078
Shock Body Insert - Washer -
Composite - 1 set
C-00180-191
O-Ring - Silicone - 9x12mm
- 5 pcs
C-00180-768
Shock Piston Heavy Duty -
4mm thick - 1 Set
Holes: 8x1.2mm
Holes: 6x1.4mm
C-00180-287
Shock Spring - Medium - Rear
- 2 pcs
C-00180-286
Shock Spring - Soft - Rear
- 2 pcs
C-00180-288
Shock Spring - Hard - Rear
- 2 pcs
C-00180-189
Shock Bladders - Silicone -
4 pcs
C-00180-190
Shock Washer - 2.5x6x0.5mm -
Steel - 10 pcs
C-00180-188
O-Ring - Silicone - 4x8mm -
5 pcs
C-00180-192
O-Ring - Silicone -
16.2x19.8mm - 5 pcs
C-00180-134-1
Shock Absorber “Ready Build” -
Long - 1 pc
600Cps Oil Filled
C-00180-658
Shock Cap Cover - RTR - Com-
posite - 2 pcs
C-00180-770
HD Shock End - Short - Com-
posite - 4 pcs
SPARE PARTS
SHOCK ABSORBER - SPARE PARTS
