Core Innovations CLT146401 User manual

CORE
INNOVATIONSTM
14.1” Laptop with Windows™ 10 S
CLT146401
User Manual

2
1. This laptop works best in non-tropical areas below 6560 feet (2000
meters).
2. Protect your device from impact from bumps and falls.
3. Do not use this device for extended periods of time in environments that
are either too cold, too hot, too humid or too dusty. Do not expose the
device to direct sunlight.
4. Avoid using this device in strong magnetic and static environments as
much as possible.
5. If the device comes into contact with water or any other liquid, power
it off immediately and wait for it to dry completely before turning it on
again.
6. Do not clean the device with any cleaning products containing
chemicals, to avoid damage caused by corrosion and dampness. When
cleaning is necessary, use a dry, soft cloth.
7. The company shall not be held responsible for the loss or deletion of
material inside the device caused by abnormal software and hardware
operation, maintenance or any other accidents.
8. Please regularly back up important data and files to avoid loss.
9. Please do not disassemble the device by yourself; doing so will void the
warranty.
Read Before Use

3
Unit at a Glance
1. Power Button: Turn your device on or off. Use to set your device to
Sleep or to wake it from Sleep.
2. Front Camera: Take photos and videos.
3. Touchpad: Use the touchpad to move your cursor.
25
6
6
1
4
3
14
11
12
13
14
79
8
10
FRONT TOP
BOTTOM
LEFT RIGHT

4
4. Keyboard: Use the keyboard for typing.
5. Indicators:
1 - The first light from the left indicates that the Power is on.
2 - The middle light indicates that Caps Lock is on.
3 - The third is the Num Lock indicator. When this light is on, you may
use the secondary keys on your keyboard.
6. Microphone: Transmits audio signals.
7. Charging Indicator: Red light illuminates when connected to a power
adapter.
8. Charging Port: 12V/2A charger.
9. USB Input: Connect external USB devices.
10. Mini-HDMI®Output: Connect your laptop to a monitor, TV or
other HDMI®-enabled device.
11. USB Input: Connect external USB devices.
12. Headphone Jack: Transmit audio signals to speakers or headphones.
13. Micro SD Card Slot: Built-in memory card reader slot that supports
Micro SD format up to 64GB.
14. Speakers: Built-in 2x1W speakers allow you to playback sound without
connecting external devices.
Unit at a Glance (Continued)
Fully charge your laptop for at least six hours before initial use. Use the
included wall charger. The battery indicator will confirm that your device is
charging.
Turn your laptop on by pressing and holding the power key for two seconds.
Once the screen is loaded, connect to your Wi-Fi®network. To wake the
screen from sleep, press the power key and the lock screen should appear.
Next, press the upwards arrow key () and log in. Sign in if your laptop
requires a password to log in.
Getting Started
Use your information to create a user account. You can use this
account to create, modify or remove other accounts on this
device.

5
Windows™ 10 S Start Menu
You will see many applications fixed on the Start menu. These apps are
displayed in the form of magnets, allowing you to easily visit programs at the
click of a button. You will need to log in to your Microsoft™ account before
the applications can fully run.
Learn more about Windows™ 10 S at:
https://www.microsoft.com/en-us/windows/s-mode
Interface Introduction

6
Microsoft™-Verified Security
With Windows™ 10 in S mode, your favorite applications, such as Office,
Evernote and Spotify are available from the Microsoft™ Store where they’re
Microsoft™-verified for security. Feel secure when you’re online. Microsoft
Edge™, your default browser, gives you more protection against phishing
and socially-engineered malware than Chrome or Firefox.
Switching out of S Mode
Windows™ 10 in S mode is designed for security and performance,
exclusively running apps from the Microsoft™ Store. If you want to install an
app that isn’t available in the Microsoft™ Store, you’ll need to switch out of
S mode.
Note: Switching out of S mode is one-way. If you make the switch, you won’t
be able to go back to Windows™ 10 in S mode. You may switch back only if
a software upgrade is made available. We recommend that you back up all
your files onto an external hard drive before switching OS. Switching out of S
mode is free of charge.
To switch out of S Mode, follow these steps:
1. Make sure you are logged into the Microsoft™ Store.
Windows™ 10 in S Mode

7
2. In the Microsoft™ Store, search for “Switch out of S Mode.”
3. Click on the Get button. Once the software has downloaded, click on the
Install button and follow the onscreen instructions to complete the setup.
Windows™ 10 in S Mode (Continued)

8
In addition to the applications already fixed on the Start Menu, all other apps
can be accessed from your laptop’s homepage. To add multiple apps to the
Start Menu:
1. Right click on the app icon you wish to pin to the Start Menu
2. Select Pin to Start
Conversely, if you want to remove an app from the Start Menu:
1. Right click on the app icon
2. Select Unpin from Start
Applications Introduction

9
The Menu bar is located within your Windows™ Start Menu, found at the
bottom of your screen.
Menu Bar
You can download more apps from the Microsoft™ Store found on
the Windows™ Start Menu.
Note: You need a Microsoft™ account to be able to download apps. You can
create an account by logging on to https://account.microsoft.com/account
Once you’ve created an account, go to the Microsoft™ Store app on
your laptop and sign in by clicking the icon.
Downloading Apps
PC: Allows you to set up, lock and
sign out
Documents: Opens the Documents
folder in your laptop
Pictures: Opens the Pictures folder
in your laptop
Settings: Setup and customize your
device
Power: Sleep, shutdown or restart
your device

10
You can see notifications on the Action Center.
The Search Bar can be found in your Start Menu. Use it to find documents
or files stored in your device. You can also use the Search Bar to search for
anything on the Web when an Internet connection has been setup.
Search

11
Here are some things Cortana™ can do for you:
 Give you reminders based on time, places, or people.
 Track packages, teams, interests, and flights.
 Send emails and texts.
 Manage your calendar and keep you up to date.
 Create and manage lists.
 Find facts, files, places, and info.
 Open any app on your system.
Note: Cortana™ is only available in certain countries/regions, and some
Cortana™ features might not be available everywhere.
What is Cortana™?
Cortana™ is your virtual assistant. She’ll help you get things done. The more
you use Cortana™, the more personalized your experience will be.
To get started, type a question in the search box, or select the microphone
and talk to Cortana™. (If you would like to talk to Cortana™, make sure your
mic is enabled.)
You can also set Cortana™ to respond to "Hey Cortana™" from the Settings
Menu by clicking on Start > Cortana™ > Settings > Cortana & Search
Settings.
Cortana™

12
Multitasking allows you to use multiple desktops to organize your files and
documents more efficiently.
1. Click the Task View button next to the search bar, or press Alt+Tab on
your keyboard to switch between or view apps.
2. To use two or more apps at a time, grab the top of an app window and
drag it to the side. Then choose another app and it’ll automatically snap
into place.
3. Create different desktops for home and work by selecting Task View >
New Desktop, and then opening the apps you want to use.
Multitasking
Clicking on the Power Button gives
you access to the Sleep, Restart, and
Shutdown operations. Briefly press
the Power Button on your keyboard to
enter Sleep Mode.
Basic Operations

13
The Action Center allows you to view and manage your accumulated
notifications. It also gives you quick access to commonly customized
settings.
To open the Action Center, click on the Windows Key ( ) on your keyboard
while pressing the letter A.
Action Center
Bluetooth: Turn Bluetooth®on or off.
Network: Connect to a Wi-Fi®network.
Location: Enable or disable location settings.
Nightlight: Shift your display to reduce blue light and emit warmer colors to
help you get a better night’s sleep.
Settings: Access all device settings.
Connect: Connect to a wireless display or audio device.
Battery Saver: Activate to save battery.
Airplane Mode: Select to activate airplane mode.

14 14
You can view your battery status at the lower right corner of the Lock Screen
or the lower right corner of Desktop Taskbar.
Battery

15
Connecting to Devices
You can connect your laptop to different devices with a USB cable or
wirelessly via Bluetooth®/Wi-Fi®.
Pair with a Bluetooth®Device
1. Turn on your Bluetooth®device to make it discoverable.
2. Open the Action Center. Click and hold “Bluetooth”. Select “Go To
Settings”.
3. Wait for your laptop to search for Bluetooth®devices. When the
Bluetooth®device appears, follow the on-screen instructions to finish
pairing.
Setup a Printer or Scanner
Click “All Settings” in the Action Center > Devices.
Available printers and scanners on your Wi-Fi®network will be listed. If you
do not see your printer, click "The printer that I want isn't listed" and follow
the prompts.
Project to a Second Screen
Connect your laptop to a TV or monitor via HDMI®to watch movies, work
with multiple apps, share presentations and more.
Connect to a Wireless Display
1. Open the Action Center and click "Connect".
2. Your laptop will search for wireless display and audio devices.
3. Choose the wireless device you wish to connect to and follow the on-
screen instructions.

16
Create Tiles
Pin your favorite apps and websites to the Start Screen.
Personalizing Your Laptop
To pin an app:
Click and hold the desired app, then select "Pin to Taskbar".
To pin a website (Microsoft™ Edge Browser only):
Go to the website using the installed Micrisoft™ Edge Browser. Click (...) on
the right hand side. Select "Pin to Start".
Customize Your Tiles
Customize your Start Screen by changing around the tiles any way you like.
To move a tile: Click and drag to where you want it.
To resize a tile: Click and hold a tile, select "Resize" (...), and choose the
size you want for the tile.
To unpin a tile from Start: Click and hold a tile. Select "Unpin from
Start" (...), then "Remove the Tile".

17
Personalizing Your Laptop (Continued)
Background and Color
You can also customize the Start Screen colors and background. At the
Start Screen, open the Action Center and click "All Settings", then select
"Personalization".
Personalize Your Lock Screen
Open the Action Center, and click "All Settings". Select Personalization >
Lock screen > Configure your options.
Personalize Your Desktop
To customize your desktop, go to your desktop and open the Action
Center. Click “Personalization”. You may now change the theme, desktop
background, colors and more.
Notifications and Actions
Notifications should appear in the top right corner of the screen. To hide
notifications, open the Action Center > All Settings > System > Notifications
and Actions.
Lock-Screen Notifications: To edit app notifications on the lock screen,
open All Settings in the Action Center. Select "Personalization", then "Lock
Screen".
Choose apps to show a quick status.

18
Wi-Fi®can only be used when the device connects to a Wi-Fi®Access Point
(AP) or a free, unsecured Wi-Fi®hotspot.
NOTE: This laptop supports 2.4GHz Wi-Fi®networks only.
Turn On Wi-Fi®
Within the Action Center menu, select the "Network" icon.
Under "Network & Internet Settings", switch on Wi-Fi® to scan for available
networks.
Your laptop will list the networks it finds. Click a network to connect.
When connected, the wireless indicator appears on the status bar. The white
lines indicate connection strength.
Network

19
Turn Off Wi-Fi®
Under "Networks", click Wi-Fi® again. Turn off Wi-Fi®when you are not using
it to extend the life of your battery between charges.
Forget a Wi-Fi®Network
Click "All Settings" in the Action Center > Network and Internet > Wi-Fi®>
Manage Known Networks > then select the network you wish to delete and
click "Forget".
Connect to a Virtual Private Network (VPN).
This laptop has built-in support for VPN. You can also install third-party VPN
Software, if available in the Windows™ Store. To connect to a VPN, open the
Action Center and click "VPN". Select "Add a VPN connection" and enter a
VPN to connect.
Disconnect from a VPN
Toggle the VPN switch under the Action Center. Turn off VPN when not in
use to extend the life of your battery.
Network (Continued)

20
Choose whether you want to use a Microsoft™ account or a local account.
Microsoft™ Account
Use this account to sign into Windows™ and shop for apps in the
Windows™ Store. All your files are also saved to OneDrive™ by default,
allowing you to access them from any device.
Local Account
You can only use a local account on your laptop and cannot connect to the
cloud.
Manage Your Accounts
There are two ways you can manage your accounts:
1. Action Center
 Open the Action Center and click "All Settings".
 Click Accounts > Set Access for other Accounts.
2. Sign-in Options
 You can also create a PIN password to sign in to your laptop. To
access other sign-in options, go to "All Settings" in the Action Center.
Click "Accounts", then select "Sign-in Options" and follow the on-
screen instructions.
Change your Password
1. Open the Action Center > Tap "All Settings".
2. Click "Accounts" > "Sign-in Options".
3. Choose "User Accounts" from the search results.
4. Under "Password", select "Change" and follow the on-screen
instructions.
User Accounts
Lock or Sign Out
Your laptop will automatically lock when not in use for a while. You can
manually lock or sign out from the Start Screen by clicking the "More
Options" icon ( ) on the top left.
