Cotell IH2510E User manual

IH2510E-A-WM-BT
1
Installation Guide
IH2510E with Bluetooth Option (Wall-Mount)

IH2510E-A-WM-BT
2
IH2510E-A-WM Infotainment Connectivity Panel Accessories
HDMI Cable
User guide
Screws
Brackets
IH2500E-M-WM FEATURES
Wall-mount
Ergonomic design with stylish outlook
High quality casing
Dual universal power sockets (110VAC or 220VAC)
+5V universal charger
AV + S-interface
HDMI
VGA + Audio

IH2510E-A-WM-BT
3
IH2510E-A-WM DIAGRAM
ITEM
FEATURE
DESCRIPTION
1
Audio & Video
Audio & Video input
2
HDMI
HDMI input
4
VGA
VGA input
6
Universal Power Socket
Universal power supply(110VAV or 220VAC)
7
+5V USB charger
+5V charger
8
Universal Power Socket
Universal power supply(110VAV or 220VAC)
IH2510E-A-WM MEASUREMENT
12 3 4 5 6 7

IH2510E-A-WM-BT
4
BRACKET DIAGRAM
（in mm）
INSTALLATION PROCEDURE
Remove the bracket; Create depression in the wall according to the size of the junction box (in mm).

IH2510E-A-WM-BT
5
1.Fasten the bottom of the junction box to the wall
2. Place the universal power cord through the junction box
3.Insert all the cables through the Junction box and ensure that they are securely fastened.
Connect the other end of the cables to the relevant connections (Power, Internet & TV outlets)

IH2510E-A-WM-BT
6
4.Place the IH2510E-A-WM core into the junction box and fasten the 4 screws provided. Clip in the
upper faceplate.
5. Test all function to ensure they are workable.
OPERATION
General
1. Turn the TV to Appropriate HDMI channel using the TV remote control
2. Plug in the device to any of the penal input, the TV will auto select the right channel for the
input
3. The TV will recognize the last device plugged-in
Note: Input Selection
The IH2500B Infotainment connectivity panel will not instruct the TV to switch its input port. If the
connectivity panel is connected on port “HDMI2”, then the user will have to manually select the
“HDMI2” input via the TV remote control.
However some Hospitality TV models now have the capacity to automatically “detect” when a live
AV feed is connected to a port on the TV, and subsequently these models will automatically sense
when the user connects a device to the panel and an activeAV connection is fed to the TV from the
panel. With such models no manual selection is necessary, however a manual override is still
possible.

IH2510E-A-WM-BT
7
Bluetooth
1. Switch on Bluetooth function on Panel
2. Switch on Bluetooth service on personal Smartphone / Media Device
3. Search for Bluetooth devices from SmartPhone / Media Device control interface
4. Connect to “Bluetooth TV” (or similar) Audio device.
5. If prompted for access code or PIN, input the 4-digit number displayed on the TV (0000)
6. Play music from SmartPhone / Media Device music player
7. Adjust volume using TV or in-room Entertainment System control.

IH2510E-A-WM-BT
8
IMPORTANT SAFETY INSTRUCTIONS
WHEN USING YOUR INFOTAINMENT CONNECTIVITY PANEL, BASIC SAFETY PRECAUTIONS SHOULD
ALWAYS BE FOLLOWED TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK AND INJURY TO
PERSONS. INCLUDING THE FOLLOWINGS:
1. READ AND UNDERSTAND ALL INSTRUCTIONS IN THIS MANUAL.
2. FOLLOW ALL WARNINGS AND INSTRUCTIONS MARKED ON THE PRODUCT.
3. DO NOT USE LIQUID CLEANER ORAEROSOL. USEA DAMP CLOTH FOR CLEANING.
4. NEVER FORCEFULLY PUSH OBJECTS OF ANY KIND INTO THIS PRODUCTAS THEY MAY TOUCH
DANGEROUS VOLTAGE POINTS OR SHORT OUT PARTS THAT COULD RESULT INA RISK OF FIRE
OR ELECTRIC SHOCK. NEVER SPILL LIQUID OF ANY KIND ON THE PRODUCT.
5. TO REDUCE THE RISK OF ELECTRIC SHOCK DO NOT DISASSEMBLE THIS PRODUCT. CALL
QUALIFIED SERVICE MEN WHEN SOME SERVICE OR REPAIR WORK IS REQUIRED. OPENING OR
REMOVING COVERS MAY EXPOSE YOU TO DANGEROUS VOLTAGES OR OTHER RISKS.
INCORRECT REASSEMBLE CAN CAUSE ELECTRIC SHOCK WHEN THE APPLIANCE IS
SUBSEQUENTLY USED.
6. UNPLUG THIS PRODUCT FROM THE WALLOUTLETAND REFER SERVICING TO QUALIFIED
SERVICE PERSONNEL UNDER THE FOLLOWING CONDITIONS:
- WHEN THE POWER SUPPLY CORD OR PLUG IS DAMAGED OR FRAYED
- LIQUID HAS BEEN SPILLED INTO THE PRODUCT.
7. IF THE PRODUCT DOES NOT OPERATE NORMALLY BY FOLLOWING THE OPERATING
INSTRUCTIONS. ADJUST ONLY THOSE CONTROLS THAT ARE COVERED BY THE OPERATING
INSTRUCTIONS BECAUSE IMPROPER ADJUSTMENT OF OTHER CONTROLS MAY RESULT IN
DAMAGE AND WILL OFTEN REQUIRE EXTENSIVE WORK BYA QUALIFIED TECHNICIAN TO
RESTORE THE PRODUCT TO NORMAL OPERATION.
- IF THE PRODUCT HAS BEEN DROPPED
- THE PRODUCT EXHIBITA DISTINCT CHANGE IN PERFORMANCE.
8. AVOID USING A INFOTAINMENT CONNECTIVITY PANEL DURING AN ELECTRICAL STORM. THERE
MAY BEA REMOTE RISK OF ELECTRIC SHOCK FROM LIGHTING.

IH2510E-A-WM-BT
9
WARRANTY EXCLUSIONS
This warranty does not cover, or may be voided by, the followings:
1. Any damage resulting from abuse or misuse (i.e. liquid spills, abuse, or customer’s modification
( warranty label broken) on the Infotainment connectivity panel.
2. Any damage caused by failure to follow operating or installation instructions provided with the
Infotainment connectivity panel
3. New faceplates or damage to the faceplate or discoloration of the Infotainment connectivity
panel.
4. Any damage resulting from improper connection of the Infotainment connectivity panel to other
equipment.
5. A Infotainment connectivity panel used in a harsh or corrosive environment.
6. Cords & connectors
7. Force majeure.
8. Damages in transit.
9. Any damage resulting from unauthorized modification or repair of the Infotainment connectivity
panel.
COTELL PRODUCT SUPPORT
If you need technical assistance with this product, please contact COTELL INTERNATIONAL
LIMITED :
Telephone : [phone]
Fax : [phone]
Email : [e-mail]
Website: www.cotell.cn
Please contact us should the above operating instructions do not match the actual product.
