Cotron BT-B01 User manual

User Manual
Bluetooth Stereo Receiver

1
Warning ................................................................................................1-3
Warning for FCC
This device complies with Part 15 of the FCC Rules. Operation is subject to
the following two conditions:
(1)This device may not cause harmful interference.
(2)This device must accept any interference received, including interference
that maycause undesired operation.
Any changes or modications (including the antennas) made to this device
that are not expressly approved by the manufacturer may void the user’s
authority to operate the equipment.
FCC RF Radiation Exposure Statement: This equipment complies with FCC
RF radiation exposure limits set forth for an uncontrolled environment. This
device and its antenna must not be co-located or operating in conjunction
with any other antenna or transmitter.
This equipment has been tested and found to comply with the limits for a
class B digital device,pursuant to part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation.
This equipment generates, uses and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no guarantee
that interference will not occur in a particular installation. If this equipment
does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try
to correct the interference by one or more of the following measures:
---Reorient or relocate the receiving antenna.
---Increase the separation between the equipment and receiver.
---Connect the equipment into an outlet on a circuit different from that to which
the receiver is connected.
---Consult the dealer or an experienced radio/TV technician for help.
Index

2
Please do not store the product in high temperature or humidity place for long time.
Chapter one
1.1 Product Introduction ..................................................... ....... .........4
1.2 Function Key Introduction ........................................................... 5
Chapter two
Operation Introduction
2.1 AV service
2.1.1 Turn-On ......................................................................... 6
2.1.2 Searching Available Bluetooth Device ....... .......... ......... 6
2.1.3 Paring ..................................................... .............. ........ 7
2.1.4 Connecting .................................................................... 8
2.1.5 Play Music ........................................ ................. ..... ...... 9
2.1.5.1 Music Play/Pause/Stop ........................................ ......... 9
2.1.5.2 Volume Control ........................................ ..................... 9
2.1.5.3 Song Switch ................................... .................... .......... 9
2.2 Mobile phone Hands-Fee
2.2.1 Paring with Mobile Phone .......... ............ ..................... 10
2.2.2 Answer coming call ..................................................... 10
2.2.3 Hang up ......... .................. ............................................ 10
2.2.4 Switching between Mobile and Music Player .............. 10
2.2.5 Last Call Redial ........................................................... 10
Chapter Three
Important message and Trouble Shooting ................................. 11
Chapter Four
Specication .......................................................................... 12-13

3
User Manual of Bluetooth Stereo Receiver
！
1. Please read the user manual before operate the BT-B01
2. Please keep the user manual for your reference anytime.
3. Please follow all the instruction in the usual manual
4. Please clean the BT-B01 with clothes rather than other Chemical liquid
Cleaner by spray or any means.
5. Do not use any accessory not included in the package avoid any damage
on the goods.
6. All the operation set-up should follow the user manual, and use the acce-
ssories included in the standard package.
7. Any problem happened on the Power adaptor, please consult to the Dealer
or distributor. Do not open the power adaptor by yourself.,
8. Please plug off the power adaptor for the power socket in the ashing light
ening day or not in use for long time period to protect the goods.
9. Do not open the product by yourself under and situation or drop any liquid
into the product to avoid short circuit.
10. Do not plug in the BT-B01 on the power socket under
electronics overloaded circumstance.
Warning
Please do not store the product in high temperature or humidity place for long time.
Important Operation Safety Notice

User Manual of Bluetooth Stereo Receiver
4
mini USB Connector (for Charging)
1.1 Product Introduction
Using state-of-the-art Bluetooth technology, it lets you have the
convenience to enjoy the music from computer or other source,
meanwhile, you can answer your phone call without miss.
1.2 Function Key Introduction
Volume up Previous Song Volume down Next Song
1. Product and Function Key Introduction

5
User Manual of Bluetooth Stereo Receiver
1. Product and Function Key Introduction
mini USB Connector (for Charging)
Earphone
Paly/Pause Hook Hole for hanging strap

User Manual of Bluetooth Stereo Receiver
6
2.1.3 Pairing
1. When BT-B01 ashing with Blue/Red LED, click on the “Pairing” as Photo(2)
1. Please plug in the Dongle to the USB port
2. Use BT-B01 pairing with your Bluetooth enable mobile phone rst if you
would like to have the hand-free function.
3. After pairing with your Bluetooth enable mobile phone, switch off your
BT-B01 then turn it on again to operate the below AV mode process.
4. After paring using the AV mode, please connect your BT-B01 with your
mobile phone again.Then, you can enjoy your music from your Bluetooth
enable device without missing any call.
2.1.1 Turn on the Power
Press Play/Pause Key till the LED light ashing Blue and Red,
entering Pairing mode.
2.1.2 Searching Bluetooth enable device
In the IVT operation software, select the “View” then click the “ Update”,
the IVT will show BT-B01 on the screen. If not, repeat the process above.
(1)
2. Operation Instruction
2.1 AV service

7
User Manual of Bluetooth Stereo Receiver
(2)
(3)
2.1.3 Pairing
1. When BT-B01 ashing with Blue/Red LED, click on the “Pairing” as Photo(2)
2. Enter Pin Code “ 0000” in the blank, and press “ Enter”
2. Operation Instruction
When you have paired successfully, the blue LED will ash slowly.
And the BT-B01 icon will show as photo (4). Attention : If you are not
pairing under the BT-B01 pairing status(Blue/Red Flashing),even you
get the same result as above, you did not get the pairing successfully.
Please switch of the Power of BT-B01 and re-do the pairing process.
3.
(4)

User Manual of Bluetooth Stereo Receiver
8
B
2.1.4 Connecting
2. Operation Instruction
1. Click twice on the icon BT-B01 in the Photo(5)
2. Click right button of your mouse on the Speaker Icon of photo (5)
executing the “Connecting” Selection.
3. If you are connecting successfully, the screen will show as photo (6)
(5)
(6)

9
User Manual of Bluetooth Stereo Receiver
2.1.5 Play Music
Under the Connecting Status, you are able to execute the Window Media
Player mode and play the music through the BT-B01. You can have Volume
Control , Forward / Backward and Pause/Stop/Play remote control function
from your BT-B01 to the Window Media Player.
2.1.5.1 Music Play/Pause/Stop
1. Press Play/Pause Key to get the music paused.
2. If you want to re-play the music, just press the Play/Pause key again.
3. Press the Play/Pause Key three seconds, you can get the music stop.
2.1.5.2 Volume Control
1. Press the Volume Up to increase the volume.
2. Press the Volume Down to decrease the volume..
2.1.5.3 Select Song
1. Press the “Forward” button for next song.
2. Press the “ Backward” button for previous song.
2. Operation Instruction

User Manual of Bluetooth Stereo Receiver
10
2.2.1 Pairing with your Bluetooth enable mobile phone
Please set up the connection between your Bluetooth enable mobile phone
with BT-B01. Then the BT-B01 will recognize your Bluetooth enable mobile
phone quickly when you want to use it.
1. Switch on the power of BT-B01 to let it enter the ashing Blue/Red LED
paring status.
2. Please refer to the user manual for paring with your Bluetooth enable
mobile phone. Please make sure the distance between your
Bluetooth enable mobile and BT-B01 is within 2 M.
3. After your Bluetooth enable mobile phone show BT-B01, please enter
the Pin Code “0000”
4. In the connecting status, the Blue LED will ash slowly.
2.2.2 Answer the Call
1. When the call is coming, the BT-B01 will have reminder sound.
2. Press lightly the Play/Pause Key to answer the phone.
2.2.3 Hang Up
Press Play/Pause key to hang up the line.
2.2.4 Switch between the Bluetooth enable mobile phone
and your Bluetooth enable music player.
1. When you play the music through the BT-B01, the coming call will have
reminder sound. Press lightly the Play/Pause key to answer your call.
2. Within 10 seconds after your end of the phone call, the BT-B01 will
connect your Bluetooth enable music player automatically.
2.2.5 Last Call re-dial
Press the “Backward” key over 5 seconds, the BT-B01 will re-dial
your last call number.
2. Operation Instruction
2.2 Mobile phone Hands-Fee

11
User Manual of Bluetooth Stereo Receiver
3. Important message and Trouble Shooting
1. Power Low
When the music play is not smooth or the LED turns red, the BT-B01 is in the
Power Low Status, please charge your battery immediately.
2. How to Charge
A. Plug in the USB cable to the BT-B01
B. Plug in the same USB cable above to the Computer.
C. It takes about 3.5 hours to get the battery charged.
3. Fail to connect with your mobile phone
A. Make sure you have switched on your power of mobile phone.
B. Make sure the Bluetooth function of your Mobile Phone is on.
C. Make sure your Bluetooth enable mobile phone is within 10 meter from the BT-B01
4. How to Maintain
A. Keep the BT-B01 dry, and in dry circumstance.
B. Keep the BT-B01 in clean and no dusty circumstance.
C. Do not store the BT-B01 in high temperature place, it will shorten the
battery life, electric device using time and deform the plastic parts.
D. Do not store the BT-B01 in low temperature place, when the temperature
comes up, the steam will cause short-circuit of the PCB.
E. Do not open the BT-B01 or you might damage it by poor skill.
F. Do not drop the BT-B01 or Strike on the BT-B01, it might damage the
PCB circuits inside.
G. Do not use any chemical liquid to clean the BT-B01.
H. Do not paint on the BT-B01, it might obstruct the products and
makes it mal-function.
5.New Battery : Please charge over 7 hours for the rst time charging.
6.For Battery :
A.Do not use un-authorized batteries.
B.Use the BT-B01 as user manual, it can let your have longer battery life.
C.Under different temperature, battery has different charging performance.
D.Do not use battery in other purpose.

User Manual of Bluetooth Stereo Receiver
12
4. Specication
Bluetooth Specication Version 1.2
Frequency 2.4GHz ISM Band
Transmission Rate 723 kbps
Receive Sensitivity -81 dBm
Maximum Output Power +4 dBm (Class 2)
Operating Voltage 5V
Operating Temperature -20~+75 ℃
Storage Temperature -40~+85 ℃
Antenna Impedance 50 ohm
Package Size 71mm(L)x31mm(W)x18(H)mm
Operating Range 10 meters
Standby Current 10mA
Operating Current 24mA
Battery Type Li-Polymer
Safety Excellent
Possibility of Leakage No
Design Flexibility High
Nominal Voltage(V) 3.7
Gravimetric Energy Density(Wh/kg) Highest(160-210)
Memory Effect No
Self Discharge(%/month) <5
Life Cycle >500
Environmental Friendliness Yes (No leakage, No Heavy Metals)
4.2 Battery Specicatoin
4.1 General Specication

13
User Manual of Bluetooth Stereo Receiver
4. Specication
Battery Model : AE5024386H
Volume Average Voltage Dimension Thickness
Typical Min Weight Length Width Gram
(mAh) (mAh) (±1) (±0.5) (±0.3)
420 400 3.7 38 24 5
V
Operating Temperature
Discharge: -20 C + 60 C
Charging: -0 C + 45 C
Storage: -20 C + 45 C (for less then 1 month)
-20 C + 35 C (for less then 6 month)
8.50

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions:
(1) This device may not cause harmful interference.
(2)This device must accept any interference received, including interference that may cause
undesired operation.
15.105 Federal Communications Commission (FCC) Requirements, Part 15
This equipment has been tested and found to comply with the limits for a class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference by one or more of the
following measures:
---Reorient or relocate the receiving antenna.
---Increase the separation between the equipment and receiver.
---Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
---Consult the dealer or an experienced radio/TV technician for help.
Any changes or modifications (including the antennas) made to this device that are not
expressly approved by the manufacturer may void the user's authority to operate the
equipment.
FCC RF Radiation Exposure Statement: This equipment complies with FCC RF radiation
exposure limits set forth for an uncontrolled environment. This device and its antenna must not
be co-located or operating in conjunction with any other antenna or transmitter.
