COZY HEDV253A and User manual

HI-EFFICIENT DIRECT VENT
WALL FURNACE
Prices and specifications subject
to change without notice.
All prices are F.O.B. factory.
Page 1
MODEL NUMBERS
HEDV253A- NAT. GAS
HEDV403A- NAT. GAS
HEDV254A - L.P. GAS
HEDV404A - L.P. GAS
Mr. Contractor, we only sell parts through our wholesalers, but the prices listed are for your convenience. For prompt parts
service, contact the wholesaler from which you purchased your Cozy heater. NOTE: Parts & schematic drawings on current
models are shown atwww.cozyheaters.com.
44
40
3
2
42
29
1
4
45
46
30
31
32
33
34
35
39
38 41 23
22 43
36
37
28
24
21
20 15
14
1719
18
16
12 13
11
9
10
27
7
6
8
526
25
47
48

Page 2 SEPTEMBER 2007
HOWTOPROPERLYORDERPARTS: In addition to part description and part number, please give model number, serial
number, and type of gas used. This information can be found on the rating plate that is attached to heater.
REF. PART LIST PART LIST PART LIST PART LIST
PART DESCRIPTION NO. NO. PRIC
E
NO. PRICE NO. PRICE NO. PRICE
Cabinet 1 18020 126.00$ 18020 126.00$ 18520 152.00$ 18520 152.00$
Circulating Blower 2 72501 162.00$ 72501 162.00$ 72500 240.80$ 72500 240.80$
Limit Switch 3 72671 9.60$ 72671 9.60$ 72670 9.60$ 72670 9.60$
FrontHeatShield 4 18100 13.30$ 18100 13.30$ 18595 28.20$ 18595 28.20$
Tubular Heat Exchanger 5 72531 166.00$ 72531 166.00$ 72530 133.10$ 72530 133.10$
CabinetBase Assembl
y
6 18120 19.10$ 18120 19.10$ 18620 23.20$ 18620 23.20$
Leg Leveler (4 Per) 7 80009 1.60$ 80009 1.60$ 80009 1.60$ 80009 1.60$
Draft Inducer Gasket 8 72565 6.40$ 72565 6.40$ 72565 6.40$ 72565 6.40$
DraftInducerMounting Plate Gasket 9 72563 2.10$ 72563 2.10$ 72563 2.10$ 72563 2.10$
DraftInducer 10 72506 166.00$ 72506 166.00$ 72506 166.00$ 72506 166.00$
SightGlass Frame 11 18185 1.90$ 18185 1.90$ 18185 1.90$ 18185 1.90$
SightGlass 12 70150 1.30$ 70150 1.30$ 70150 1.30$ 70150 1.30$
SightGlass Gasket 13 72564 2.10$ 72564 2.10$ 72564 2.10$ 72564 2.10$
Ignitor 14 64009 23.50$ 64009 23.50$ 64009 23.50$ 64009 23.50$
Ignitor Cable 15 64210 17.50$ 64210 17.50$ 64210 17.50$ 64210 17.50$
Burner Orifice (Requires 2) 16 *95251 3.60$ *95258 3.60$ *72156 3.60$ *72139 3.60$
Manifold 18 72640 19.70$ 72640 19.70$ 72640 19.70$ 72640 19.70$
Burner BoxAssembl
y
19 18150 35.30$ 18150 35.30$ 18150 35.30$ 18150 35.30$
Burner BoxTop Gasket 20 72567 4.30$ 72567 4.30$ 72567 4.30$ 72567 4.30$
Burner BoxTop 21 18165 4.20$ 18165 4.20$ 18165 4.20$ 18165 4.20$
Gas Valve 22 64590 76.50$ 64591 76.50$ 64590 76.50$ 64591 76.50$
Gas Valve SupportBracket 23 18180 4.20$ 18180 4.20$ 18180 4.20$ 18180 4.20$
Burner BoxMounting Gasket 24 72566 5.30$ 72566 5.30$ 72566 5.30$ 72566 5.30$
Transformer 25 78069 24.70$ 78069 24.70$ 78069 24.70$ 78069 24.70$
CircuitBoard 26 64625 223.70$ 64625 223.70$ 64625 223.70$ 64625 223.70$
Wiring Harness 27 72675 12.80$ 72675 12.80$ 72675 12.80$ 72675 12.80$
Pressure Switch 28 72517 17.00$ 72517 17.00$ 72518 17.00$ 72518 17.00$
Casing Back 29 18090 22.90$ 18090 22.90$ 18590 28.60$ 18590 28.60$
A
ir Intake Hose 30 72611 10.30$ 72611 10.30$ 72611 10.30$ 72611 10.30$
2"Hose Clamp (4 Per) 31 72593 1.80$ 72593 1.80$ 72593 1.80$ 72593 1.80$
Vent Cap Assembl
y
32 18250 56.20$ 18250 56.20$ 18650 55.30$ 18650 55.30$
Vent Cap Gasket 33 72608 2.00$ 72608 2.00$ 72608 2.00$ 72608 2.00$
Collection BoxAssembl
y
34 18225 157.00$ 18225 157.00$ 18225 157.00$ 18225 157.00$
Collection BoxGasket 35 72607 1.30$ 72607 1.30$ 72607 1.30$ 72607 1.30$
Collection BoxCap 36 72587 1.60$ 72587 1.60$ 72587 1.60$ 72587 1.60$
Vent Exhaust Tube 37 72610 181.80$ 72610 181.80$ 72610 181.80$ 72610 181.80$
Trim KitBracket(Requires 4) 38 18320 8.90$ 18320 8.90$ 18320 8.90$ 18320 8.90$
Wall Mounting Bracket(Requires 4) 39 18315 1.90$ 18315 1.90$ 18315 1.90$ 18315 1.90$
Trim Kit,Left Side Panel 40 18310 13.70$ 18310 13.70$ 18310 13.70$ 18310 13.70$
Trim Kit,Right Side Panel 41 18305 13.70$ 18305 13.70$ 18305 13.70$ 18305 13.70$
Trim KitTop 42 18300 13.30$ 18300 13.30$ 18700 15.00$ 18700 15.00$
HEDVWire Bracket 43 18190 2.30$ 18190 2.30$ 18190 2.30$ 18190 2.30$
Liner,LeftSide 44 18110 9.40$ 18110 9.40$ 18610 8.20$ 18610 8.20$
Liner Top 45 18075 14.60$ 18075 14.60$ N/A N/A N/A N/A
Thermostat, 24 Volt 46 78355 21.00$ 78355 21.00$ 78355 21.00$ 78355 21.00$
Draft Inducer Mounting Plate 47 18200 22.30$ 18200 22.30$ 18200 22.30$ 18200 22.30$
ThermostatWire 20' N/A 74518 1.40$ 74518 1.40$ 74518 1.40$ 74518 1.40$
PowerCord N/A 64205 5.90$ 64205 5.90$ 64205 5.90$ 64205 5.90$
Condensate Kit N/A 18900 81.90$ 18900 81.90$ 18900 81.90$ 18900 81.90$
HEDV403
A
HEDV404
A
HEDV253
A
HEDV254
A
Mr. Contractor, we onlysell parts through our wholesalers,but the prices listed above are for your convenience. For
promptparts service,contactthe wholesaler from which you purchased your Cozyheater. NOTE: Parts & schematic
drawings on currentmodels are shown atwww.cozyheaters.com.
