Craco Swivi Seat User manual

Owners Manual
Swivi Seat™ 3-in-1 Booster
Graco PD283577F 10/14

Feeding Booster
attached to chair
This product can be used in the following modes:
Toddler Booster
Infant Recline

Failure to follow these warnings and the
assembly instructions could result in serious injury or death.
•PLEASE SAVE OWNER’S
MANUAL FOR FUTURE USE.
•FOR YOUR CHILD’S SAFETY,
read the labels and the owner’s
manual before using product.
•BEFORE EACH USE. Inspect the
toddler booster for damaged
hardware, loose joints, missing
parts, or sharp edges.
•DO NOT USE toddler booster if
any parts are missing or broken.
•DO NOT substitute parts.
•FALL HAZARD Never move or
lift booster seat with child in it.
•ADULT ASSEMBLY REQUIRED.
•NEVER LEAVE CHILD
UNATTENDED. Always keep your
child in view in product.
•PREVENT SERIOUS INJURY OR
DEATH FROM SLIDING OUT,
FALLS, OR TIPPING OVER.
Always use seat belt. Secure your
child at all times with the
restraint system provided, either
in the reclining or upright
position.
The tray is not designed to hold
your child in the product. It is
recommended that the product
be used in the upright position
only by children capable of
sitting upright unassisted.
•NEVER allow a child to push
away from table.
•DO NOT FORCE TRAY
against child. Use only the two
adjustment positions. Be sure
both adjustment fingers are
engaged in armrest slots.
•STRANGULATION HAZARD:
Do not place product in any
location where there are cords,
such as window blind cords,
drapes, phone cords, etc.
•FOLLOW ASSEMBLY
INSTRUCTIONS CAREFULLY.
If you experience any difficulties,
please contact the Customer
Service Department.
•DISCONTINUE USING YOUR
TODDLER BOOSTER should it
become damaged or broken.
•PREVENT SERIOUS INJURY OR
DEATH. Do not use in motor
vehicles.
• DO NOT ADJUST the recline of
product with your child in it.
•ALWAYS USE booster straps to
attach feeding booster seat to
any chair. Always ensure straps
are pulled tightly.
•IF FEEDING BOOSTER SEAT
CANNOT be securely and safely
attached to the adult chair, do
not use feeding booster seat with
that chair.
•THIS FEEDING BOOSTER SEAT
is designed to be used by a child
up to 5 years of age and up to 50
lbs (22.7kg).
•USE ONLY Swivi Seat™
toddler booster accessories with
this product.

•ALWAYS SECURE CHILD IN
THE RESTRAINT UNTIL CHILD
IS ABLE to get in and out of the
feeding booster without help
(about 2 1/2 years old), the child
should be secured in the feeding
booster seat at all times by the
restraining system. The tray is not
designed to hold the child in the
chair.
•DO NOT USE the booster on a
stool, swivel chair, folding chair
or any other type of chair to
which this booster cannot be
firmly attached. The
recommended type of chair shall
be with four legs, a high
backrest, and a firm seat.
•Use the fully recline position
until infant can hold up head
without help (about 4 months
old).

Parts list
ALL MODELS
CERTAIN MODELS
This model may not include some features shown below. Check that
you have all the parts for this model BEFORE assembling your
product. If any parts are missing, call Customer Service.
No tools required.

Backrest
Insert seat back guides into seat
base.
1

Rotate seat back until it attaches
to base.
2
SNAP!

Seat Pad
1Pull waist straps through openings in
seat pad.
2Pull shoulder straps and crotch strap
through openings in seat pad.
3Wrap seat pad over the top of the
infant seat.
4Secure seat pad to front of infant seat
as shown.

Body Support (certain models)
1Place body support on top of the seat
pad.
2Pull waist straps through openings in
body support.
Pull shoulder straps through openings
in body support.
3

To Use Tray
1Squeeze release levers on each side of
tray, slide tray on seat, and snap into
side tray locks.
2
OR
SNAP!
To release squeeze release levers on
each side of tray and slide off.
To release push button on front of tray.

Tray Cover
1
Attach tray cover by pushing it down
on the tray.
To remove pull up on the back of the
tray.
2
SNAP!
Dishwasher safe.

To Recline Seat
Press button on front of seat and
push down or pull up to adjust.
1
2
WARNING DO NOT adjust the seat recline with
the child in it. Tray must be removed when the seat is in the fully
reclined position.
Tray must be removed when the
seat is in the reclined position.
There are 4 recline positions.

To Rotate Seat
Locate one of the handles on the
side of the booster and pull
towards the direction you want
to rotate the seat.
1
WARNING DO NOT adjust the seat with the
child in it.
2
OR
There are 3 positions.

To Secure Child
5 Point Harness
1 4
5
2
3
Use slide adjuster at shoulder and
waist for tighter adjustment.
WARNING Falling Hazard: Always use the seat belt.

3 Point Buckle
To convert to 3-pt harness.
6
7
10
8
9
Use slide adjuster at waist for
further adjustment.

When changing harness strap slots,
MAKE SURE harness straps are
going through same slots in seat
pad and seat back.
The harness straps must go into
slot that is even with or slightly
above the shoulders. Avoid
twisting straps.
11

Using as Toddler Booster
1
Remove seat back and pad from
seat base.
2
Disconnect seat back from base.

Attaching booster seat to chair
1
Turn infant/toddler feeding
booster seat over.
Unfasten clips.

Place feeding booster on a chair
with no armrests and that has a
back, ensuring that the straps are
hanging freely.
Make sure that there are no
extra seatpads or cushions on
the chair that you are using with
the booster.
3
4Wrap top straps around back of
seat and secure clip. Tighten by
pulling on the adjustment strap.
OR
SNAP!

Wrap bottom straps around base of
seat and secure clip under the seat.
Tighten by pulling on the loose straps.
CHECK to make sure feeding booster
is securely attached by moving from
side to side.
6Ensure the feeding booster is
attached correctly by pulling
up on it.
5
OR
SNAP!
