Crafstman 172.743240 User manual

CAUTION: Read, understand and follow all
Safety Rules and Operating Instructions in this
Manual before using this product.
Operator’s Manual
CHARGE BATTERY
BEFORE FIRST USE
Sears Brands Management Corporation,
Hoffman Estates, IL 60179
See the full line of Craftsman
®
products
at craftsman.com
•WARRANTY
• SAFETY
• UNPACKING
• DESCRIPTION
• ASSEMBLY
• OPERATION
• MAINTENANCE
• ESPAÑOL
Lithium-ION
24 -Volt 13-in.
Weedwacker
Cordless
Trimmer
Model No. 172.743240

Warranty……………………………..................................……………..Page 2
Safety Symbols……………………..................................……………..Page 3
Safety Instructions……………………..................................……….....Pages 4 - 10
Unpacking..……………………………..............................………….....Page 11
Description………………………………..................................………..Pages 12 - 14
Assembly and Adjustments………………………………......................Pages 14 - 20
Operation...................………………………..................................…...Pages 20 - 25
Maintenance..........……………………..................................………....Page 26
Accessories........................................................................................ Pages 26 - 27
Parts List.......……………………......................................………….....Pages 28 - 29
TABLE OF CONTENTS
SAVE THESE INSTRUCTIONS!
READ ALL INSTRUCTIONS!
2
WARNING: Some dust created by using power tools contains
chemicals known to the State of California to cause cancer and birth defects
or other reproductive harm.
!
CRAFTSMAN®THREE YEAR FULL WARRANTY
FOR THREE YEARS from the date of purchase this power tool is warranted
against any defects in material or workmanship. A supplied battery pack
or charger is warranted against such defects for one year from the purchase
date. A defective product will be replaced free of charge.
For warranty coverage details to obtain free replacement,
visit the web site: www.craftsman.com
This warranty does not cover the cutting-line which is an expendable part that
can wear out from normal use within the warranty period. This warranty is void
if this product is ever used while providing commercial services or if rented to
another person. This warranty gives you specific legal rights, and you may
also have other rights which vary from state to state.
Sears Brands Management Corporation,
Hoffman Estates, IL 60179
SAFETY SYMBOLS
3
The purpose of safety symbols is to attract your attention to possible
dangers. The safety symbols and the explanations with them deserve your
careful attention and understanding. The symbol warnings do not, by
themselves, eliminate any danger. The instructions and warnings they give
are no substitutes for proper accident prevention measures.
WARNING: Be sure to read and understand all safety instructions in this
manual, including all safety alert symbols such as “DANGER,”
“WARNING,” and “CAUTION” before using this cordless trimmer. Failure to
follow all instructions listed in this manual may result in electric shock, fire and/or
serious personal injury.
SYMBOL SIGNAL MEANING
SAFETY ALERT SYMBOL: Indicates DANGER, WARNING, OR
CAUTION. May be used in conjunction with other symbols or pictographs.
DANGER: Indicates a hazardous situation which, if not avoided, will
result in death or serious injury. This signal word is to be limited to the most
extreme situations. Always follow the safety precautions to reduce the risk of
fire, electric shock, and personal injury.
WARNING: Indicates a hazardous situation which, if not avoided, could
result in death or serious injury. Always follow the safety precautions to
reduce the risk of fire, electric shock, and personal injury.
CAUTION: Indicates a hazardous situation which, if not avoided, could
result in minor or moderate injury.
Damage Prevention and Information Messages
These inform the user of important information and/or instructions that could
lead to equipment or other property damage if they are not followed. Each
message is preceded by the word “NOTE,” as in the example below:
NOTE: Equipment and/or property damage may result if these instructions
are not followed.
WARNING: To ensure safety and reliability, all repairs
should be performed by a qualified service technician.
WARNING: The operation of any power tools can
result in foreign objects being thrown into your eyes,
which can result in severe eye damage. Before beginning
power tool operation, always wear safety goggles or
safety glasses with side shield and a full face shield when needed. We
recommend a Wide Vision Safety Mask for use over eyeglasses or standard
safety glasses with side shields. Always use eye protection which is marked
to comply with ANSI Z87.1 shields.

SAFETY INSTRUCTIONS
4
WARNING: if correctly used, this cordless trimmer is an easy to
handle and efficient tool; if used improperly or without the due precautions
it could become a dangerous tool. For pleasant and safe work, ALWAYS
strictly comply with the safety rules that are contained in this manual.
!
WARNING: BE SURE to read and understand all instructions in this
manual before using this cordless trimmer. Failure to follow all instructions
listed below may result in electric shock, fire and/or serious personal injury.
!
WARNING: The operation of any trimmer can result in FOREIGN
OBJECTS BEING THROWN, which can result in personal injury or property
damage. ALWAYS use proper safety equipment.
!
WARNING: To avoid mistakes that could cause serious injury, DO NOT
install battery pack into this trimmer until the following instructions have
been read and understood.
!
PERSONAL SAFETY
WORK AREA SAFETY
1. ALWAYS avoid dangerous conditions. DO NOT use in wet or damp areas or
expose to rain.
2. DO NOT operate in the presence of flammable liquids, gases, or dust.
Power tools create sparks which may ignite dust or fumes.
3. ALWAYS keep bystanders and visitors at a safe distance while operating
a trimmer. NEVER allow children near the tool. Flying objects can injure
anyone in the area.
4. CHILDPROOF your tools with padlocks and master switches. Lock tools away
when not in use. This trimmer is not a toy.
5. DO NOT use trimmer at night. ALWAYS make sure you have adequate lighting.
6. BEFORE using the trimmer, remove any stones, sticks, debris or objects that
could be entangled in or thrown by the trimmer.
1. KNOW your tool. Read the operator’s manual carefully. Learn the cordless trimmer’s
applications and limitations, as well as the specific potential hazards related to this tool.
2. STAY ALERT, watch what you are doing and use common sense when operating
this tool.
3. DO NOT use tool while tired or under the influence of drugs, alcohol or medication.
A moment of inattention while operating this tool may result in serious personal injury.
4. DRESS properly. Wear rubber gloves and substantial rubber soled footwear when
working outdoors. DO NOT operate lawn and garden tools when barefoot or wearing
open sandals. Wear long pants and long sleeves to protect your legs and arms.
Trimmers can pick up objects such as rocks and send them flying at fast speeds.
DO NOT wear loose clothing or jewelry. Keep your hair, clothing, and gloves away
from moving parts. Loose clothing or long hair can be caught in moving parts.
SAFETY INSTRUCTIONS cont.
5
WARNING: BE SURE to read and understand all instructions before
operating this tool. Failure to follow all instructions listed below may
result in electric shock, fire and/or serious personal injury.
!
TOOL USE AND CARE SAFETY
WARNING: BE SURE to read and understand all instructions before
operating this cordless trimmer. Failure to follow all instructions listed
below may result in shock, fire and/or serious personal injury.
!
ELECTRICAL SAFETY
PERSONAL SAFETY cont.
5. USE SAFETY EQUIPMENT. Always wear safety goggles or safety glasses with
side shields or full face shield, proper work shoes with rubber non-slip soles,
heavy-duty non-slip rubber gloves and dust mask or respirator and hearing
protection. Hard hat should be used for appropriate conditions.
6. DO NOT overreach. Keep proper footing and balance at all times. Proper footing
and balance enables better control of the tool in unexpected situations.
1. DO NOT use the tool if switch does not turn it “On” or “Off”. Any tool that
cannot be controlled with the switch is dangerous and must be repaired.
2. DISCONNECT the battery before making any adjustments, changing cutting
line, or storing the tool. Such preventive safety measures reduce the risk of
starting the tool accidentally.
3. Avoid Unintentional Starting. Do not insert battery with finger on switch.
Be sure switch is off when inserting battery
4. STORE idle tools out of the reach of children and other untrained persons.
Children MUST NOT operate the tool. Tools are dangerous in the hands of
untrained users.
5. Maintain Trimmer With Care. Keep line cutter sharp and clean for best performance
and to reduce the risk of injury. Follow instructions for lubricating and changing
accessories. Inspect appliance cord periodically, and if damaged, have it repaired by
an authorized service facility. Inspect extension cords periodically and replace if
damaged. Keep handles dry, clean, and free from oil and grease.
6. CHECK for misalignment or binding of moving parts, breakage of parts, and
any other condition that may affect the tool's operation. If damaged, have the tool
serviced before using. Many accidents are caused by poorly maintained tools.
7. USE ONLY cutting line that is recommended for this trimmer. Cutting line that
may be suitable for one trimmer may become hazardous when used on another
trimmer.
A battery operated tool with integral batteries or a separate battery pack must
be recharged only with the specified charging stand for the battery pack. A
charger that may be suitable for one type of battery may create a risk of fire
when used with another battery.
1. Use battery operated tool only with specifically designated battery pack.
Use of any other batteries may create a risk of fire.
2. Use battery pack only with charging stand listed.
MODEL CHARGING STAND BATTERY PACK
71-74324
CGT244LU-23 (WA3733) CGT244LU-44 (WA3526) 71-28131

SAFETY INSTRUCTIONS cont.
6
SERVICE SAFETY
1. If any part of this trimmer is missing or should break, bend, or fail in any
way; or should any component fail to perform properly: SHUT OFF the
power switch and remove the trimmer plug from the power source and have the
missing, damaged or failed parts replaced BEFORE resuming operation.
2.
Tool service must be performed only by a qualified service dealer. Service or
maintenance performed by unqualified personnel could result in a risk of injury.
SAFETY RULES FOR CORDLESS TRIMMERS
1. KNOW your cordless trimmer. Read operator’s manual carefully. Learn the
applications and limitations, as well as the specific potential hazards related to this
tool. Following this rule will reduce the risk of electric shock, fire or serious injury
2. CAUTION: DO NOT have the battery pack installed in the trimmer when not in use.
3. DO NOT use trimmer without adequate lighting. ALWAYS make sure that you can
see what you are trimming and edging.
4. Use trimmer ONLY when grass and weeds are dry.
5. ALWAYS remove objects such as stones, sticks, and debris from the
trimming/edging path that could become entangled in, or thrown by, the trimmer.
6. ALWAYS hold the trimmer by both the main rear handle and the auxiliary handle
for greater control and balance. NEVER reach under the safety guard.
7. USE RIGHT TRIMMER. Do not use trimmer for any job except that for
which it is intended.
8. DO NOT grasp or touch the exposed cutting line when picking up or holding the
trimmer.
ELECTRICAL SAFETY cont.
3. Do not abuse the cord on the charger. Never carry the charger by its power
cord. Never pull the power cord to remove the charger from the power outlet.
Damage to the cord or charger could occur and create an electric shock hazard.
Keep cord away from heat, oil, sharp edges or moving parts. Replace damaged
cords immediately. Damaged cords increase the risk of electric shock.
The label on your tool may include the following symbols.
V.....................................................................Volts
A....................................................................Amps
Hz..................................................................Hertz
W....................................................................Watts
min................................................................Minutes
..................................................................Alternating current
................................................................Direct current
n
o
...................................................................No-load speed
..................................................................Class II construction, Double Insulated
RPM...............................................................Revolutions per minute
SPM...............................................................Strokes per minute
OPM...............................................................Orbits per minute
..................................................................Indicates danger, warning or caution.
It means attention! Your safety is involved.
.................................................................Arrows show direction objects will be
thrown by trimmer line rotation.
!
................................................................Indoor use only
SAFETY INSTRUCTIONS cont.
7
9. DO NOT FORCE the trimmer. Do not try to cut more than what the trimmer is
designed for. It will do a better job with less chance of injury when used at the
rate for which it is designed.
10.
KEEP the handle dry, clean and free of oil and grease. Use a clean cloth when
cleaning. DO NOT use solvents, brake fluids, gasoline, or other petroleum
products to clean the trimmer. They can damage plastic parts.
11. NEVER, for any reason, touch the cutting line or other moving parts during use.
12. When changing cutting line spool be careful of the line cutter on the guard.
Cutter is sharp and can cause injury (see page 17, Fig. 5a)
13.
DO NOT use this product without the guard being fitted.
14. KEEP guard in place and in good working order. Keep guard positioned
between you and cutting line. Keep hands and feet away from cutting line.
15.
ALWAYS store the trimmer indoors with battery pack removed when not in use. It
should be stored in a dry place, high up or locked in a place that is out of the
reach of children.
16. Cordless tools do not have to be plugged into an electrical outlet; therefore,
they are always in operating condition when the battery pack is installed.
Be aware of possible hazards when not using your battery operated tool or
when changing accessories. Following this rule will reduce the risk of electric
shock, fire, or serious personal injury.
17. Do not place battery tools or their batteries near fire or heat. This will reduce
the risk of explosion and possible injury.
18.
Do not crush, drop or damage battery pack. Never use a battery pack or
charger that has been dropped or received a sharp blow. A damaged battery
pack is subject to explosion. Properly dispose of a dropped or damaged battery pack
immediately.
19. Exercise care in handling batteries in order not to short the battery with conducting
materials such as rings, bracelets, and keys. The battery or conductor may overheat
and cause burns.
20. Do not open or mutilate the batteries. Released electrolyte is corrosive and may
cause damage to the eyes or skin. It may be toxic if sallowed To reduce the risk of
personal injury, never use any cordless product in the presence of open flame.
If exposed, flush with water immediately.
21. Do not charge battery in a damp or wet location. Following this rule will reduce
the risk of electric shock.
22. For best results, your battery should be charged in a location where the
temperature is more than 50°F but less than 80°F. Do not store battery outside or
in vehicles.
23. Under extreme usage or temperature conditions, battery leakage may occur.
If liquid comes in contact with your skin, wash immediately with soap and
water,
then neutralize with lemon juice or vinegar. If liquid gets into your eyes,
flush them with clean water for at least 10 minutes, then seek immediate
medical attention. Following this rule will reduce the risk of serious personal
injury.
24. ALWAYS use only 0.065 inch (1.65 mm) spiral twisted cutting line with this
trimmer. Use of any other cutting line may create a hazardous situation.
Do not use heavier lines than recommended in this manual.
25. ALWAYS keep ventilation openings clear of debris.
SAFETY RULES FOR CORDLESS TRIMMERS cont.

SAFETY INSTRUCTIONS cont.
8
WARNING: NEVER reach under the trimmer (cutting line area) until
trimmer has completely stopped. The trimmer's cutting line will continue to
rotate for a few seconds after it is switched off.
!
WARNING: READ AND UNDERSTAND ALL INSTRUCTIONS. Failure
to follow all instructions listed below may result in electric shock, fire
and / or serious personal injury.
!
SAFETY RULES FOR CORDLESS TRIMMERS cont.
WARNING: Some dust particles created by lawn and garden tools
contain chemicals known to the State of California to cause cancer, birth
defects or other reproductive harm. Some examples of these chemicals are:
• Compounds in fertilizers, herbicides, pesticides, and insecticides.
• Arsenic and chromium from chemically treated lumber.
!
!
Your risk from these exposures varies, depending upon how often you do
this type of work. To reduce your exposure to these chemicals:
• Work in a well-ventilated area
• Work with approved safety equipment, such as those dust masks
that are specially designed to filter out microscopic particles.
SAFETY RULES FOR BATTERY CHARGER
26. BEFORE using the trimmer, remove any stones, sticks, debris or objects that
could be entangled in or thrown by the trimmer.
27. NYLON CUTTING LINE Keep face, hands and feet clear of rotating nylon line at
all times.
28. THE ROTATING LINE PERFORMS A CUTTING FUNCTION. Use care when
trimming around screens and flowers and other objects that you DO NOT want
damaged or cut.
29. KEEP ALL BYSTANDERS AWAY at a safe distance from the work area,
especially children.
30. MAKE SURE that other persons and pets are at least 100 feet away.
IMPORTANT WARNING:
When this tool is being used as a trimmer or edger, stones and other
objects can be thrown out at high speed by the line. The tool and guard are
designed to help reduce the danger. However, the following special
precautions should be taken.
TO REDUCE THE RISK of rebound or ricochet injury, always work away
from any solid objects such as walls, steps, large stones, landscape bricks,
timbers, trees, etc. Use extreme care when working close to solid objects
and when necessary edge or trim by hand.
NOTE: Before using battery charger, read all instructions and cautionary
markings in this manual, on battery charger and, battery pack, and trimmer
using battery pack, to prevent misuse of the products and possible injury
or damage.
SAFETY INSTRUCTIONS cont.
9
CAUTION: USE ONLY the specifically designated battery charger
that was supplied with this trimmer when charging the battery pack. The
use of any other battery charger could damage the battery pack, and
create a hazardous condition.
!
CAUTION: To reduce the risk of electric shock or damage to the
battery charger and battery pack, charge only the specifically designated
battery pack that was included with this trimmer and charger. Charging
other types of battery packs may cause them to burst, causing personal
injury and damage.
!
SAFETY RULES FOR BATTERY CHARGER cont.
1. Do not use the battery charger outdoors or expose to wet or damp
conditions. Water entering charging stand will increase the risk of electric shock.
2. Use of an attachment with this battery charger that is not recommended
may result in a risk of fire, electric shock, or injury to persons.
3. Do not abuse the cord on the battery charger. Never carry the charger by its
power cord. Never pull the power cord to remove the charger from the power
outlet. Damage to the cord or charger could occur and create an electric shock
hazard. Keep cord away from heat, oil, sharp edges or moving parts. Replace
damaged cords immediately. Damaged cords increase the risk of electric shock.
4. Make sure cord is located so that it will not be stepped on, tripped over,
come in contact with sharp edges or moving parts, heat, oil, or otherwise
subjected to damage or stress. This will reduce the risk of accidental falls, which
could cause injury, and damage to the cord which could result in electric shock.
5. Keep cord and charger away from heat to prevent damage to housing or
internal parts.
6. Do not let gasoline, oils, petroleum-based products, etc. come in contact
with plastic parts. They contain chemicals which can damage, weaken or destroy
plastic.
7. An extension cord should not be used unless absolutely necessary. Use of
improper extension cord could result in a risk of fire and electric shock. If an
extension cord must be used, make sure: a) That pins on plug of extension cord
are the same number, size and shape as those on the charger, b) That extension
cord is properly wired and in good electrical condition, and c) That you use a
proper extension cord. ONLY use cords listed by Underwriters Laboratories (UL).
Other extension cords can cause a drop in line voltage, resulting in a loss of power
and overheating of charging stand. An AWG (American Wire Gauge) size of at
least 14-gauge is recommended for an extension cord of 25-ft. or less in length.
Use 12-gauge for an extension cord of 50-ft. Extension cords100-ft. or longer
are not recommended.
8. INSPECT tool cords for damage. Do not operate charger with a damaged
cord, which could cause shorting and electric shock. Have damaged tool
cords repaired at a qualified service dealer.
9. Do not operate charger if it has received a sharp blow, been dropped, or
other wise damaged in any way. Take it to an qualified service dealer for
electrical check to determine if the charger is in good working order.

SAFETY INSTRUCTIONS cont.
10
10. Do not disassemble charger. Take it to a qualified service dealer
when service or repair is required. Incorrect reassembly may result in a risk of
electric shock or fire.
11. Disconnect charger from the power supply when not in use. This will reduce
the risk of electric shock or damage if metal items should fall into the opening in
the charger. It also will help prevent damage during a power surge.
12. Risk of electric shock. Do not touch un-insulated portion of output connector
or un-insulated battery terminal.
13. Save these instructions. Refer to them frequently and use them to instruct
others who may use this tool. If you loan someone this tool, also loan them these
instructions to prevent misuse of the product and possible injury.
1. ALWAYS wear safety glasses or eye shields when using this tool. Everyday
eyeglasses have only impact-resistant lenses; they are NOT safety glasses.
2.
PROTECT your lungs. Wear a face mask, dust mask or respirator if the operation is
dusty.
3. PROTECT your hearing. Wear appropriate personal hearing protection during
use. Under some conditions noise from this product may contribute to hearing loss.
4. ALL VISITORS AND BYSTANDERS MUST wear the same safety equipment that
the operator of the tool wears.
5. ALWAYS check the tool for damaged parts. Before further use of the tool, a
guard
or other part that is damaged should be carefully checked to determine if it
will operate properly and perform its intended function. Check for misalignment or
binding of moving parts, breakage of parts, and any other condition that may affect
the tool’s operation. A guard or other part that is damaged should be properly
repaired or replaced at a qualified service center.
6. SAVE THESE INSTRUCTIONS. Refer to them frequently and
use them to instruct others who may use this tool. If someone borrows this
tool, make sure they have these instructions also.
This device complies with Part 15 of the FCC Rules. Operation is
subject to the following two conditions: (1) this device may not cause
harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation
SAFETY RULES FOR BATTERY CHARGER cont.
ADDITIONAL RULES FOR SAFE OPERATION
WARNING: BE SURE to read and understand all instructions. Failure
to follow all instructions listed below may result in electric shock, fire \
and / or serious personal injury.
!
UNPACKING (Fig. 1)
11
WARNING: If any part of the trimmer is missing or damaged, do not
install the battery pack into the trimmer until the damaged part is repaired
or replaced.
!
1. The trimmer comes assembled except for the guard, edge guide wheels,
which must be attached.
2. Remove the trimmer, safety guard, edge guide wheels, box containing
the battery pack and charger from the carton and inspect your trimmer.
3. Do not discard box or packing material until all parts are examined.
Fig. 1
Battery Charger
Battery Pack
Safety Guard
Trimmer
Auxiliary Handle
Edge Guide Wheels

DESCRIPTION cont.
13
KNOW YOUR CORDLESS TRIMMER cont. (Fig. 2)
Fig. 2
DESCRIPTION
12
KNOW YOUR CORDLESS TRIMMER (Fig. 2)
NOTE: Before attempting to use this product, familiarize yourself with all
operating features and safety rules.
Safety Guard
Edge Guide
Wheels
Cutting Line
Trimmer Head
Motor
Housing
Air
Vents
Trimmer Head 5-position
Adjustment Button
Top Black Locking Collar
for Adjusting Length of Shaft
Adjustable Telescopic
Top Shaft also Rotates
180
° for Edging
24-Volt
Battery Pack
Trigger
Switch
Trigger
Switch
Handle
Safety “On” Button
Auxiliary Handle
Bottom Black Locking Collar
for Rotating Top Shaft 180
°
Quick Release
Auxiliary Bracket
Spool Holder
Safety, performance and dependability have been given top priority in the design of
this product, making it easy to maintain and operate.
This Cordless Trimmer has the following features:
1. 13-inch Cutting Path
2. 2 in 1: Trimmer and In-Line Edger with Two Wheels The cutting face can be
changed from horizontal to vertical. (i.e. For cutting edges). Pull Handle rotation
locking mechanism and turn the top of the shaft 180ºcounter-clockwise.
(The head will only move in one direction) The motor head will swivel through
180º- Release the collar and the shaft will lock-confirm secure before use!
3. 24 Volt Cordless / 7800 RPM (no-load speed) for efficient trimming and edging.
4. 24.0 Volt, 2.0Ah Lithium Battery Pack (No. CGT244LU-44) 71-28131
recharges in 3 hours under normal use.
5. Charger (No. CGT244LU-23) has 1 LED light. Connect the battery charger to
the power supply and the green light will
illuminate. Slide the battery pack into the
charger base to make the connections and the red light will illuminate to show
charging has started. The red light will switch to green, which means the battery is
full, and charging is completed. Then press the battery pack release button and
remove your battery pack. Your battery pack is now ready for use.
6. Ergonomically Designed Rear Handle for maximum control and gripping
comfort with reduced operator fatigue.
7. Four finger Trigger Switch with Safety “On” Button. Safety On button must
be depressed to operate trigger switch.
8. 5-Position Trimmer Head easily adjusts to the desired working angle for
optimum operator control in all trimming and edging applications. From trimming
around hard-to-reach flower beds and shrubs, to deck supports, fences and
stairways, to edging sidewalks, driveways and landscaping.
9. Edge Guide Wheels provides a cutting guide for protecting flowers, plants,
screens and fences from being cut by trimmer line.
10. Adjustable Telescopic Shaft allows adjustments from 17 to 28 inches from
your ideal working height. Comfortably fits users that are 4 1/2 to 6 1/2 feet.
11.
Lightweight and Ergonomically Designed for easy use, handling comfort and
efficient trimming and edging.
12.
Automatic Line Feed when line becomes worn, the hub will automatically feed
and trim a new length of line.
13.
Quick Release Auxiliary Handle for easy adjustment of auxiliary handle.
14.
Spoon Holder on the auxiliary handle for convenient installment of 1pc spare spool.
When the line is running out during trimming, you can replace the spool immediately.
15. Your trimmer uses: 0.065 inch diameter twisted line. Use Craftsman 71-85937
automatic feed replacement spool and line. It’s factory wound for maximum
reliability.

DESCRIPTION cont.
14
ASSEMBLY & ADJUSTMENTS
The battery pack for this tool has been shipped in a low charge condition to prevent
possible problems.
Cutting Path
Speed
Rating
Line Diameter
Line Feed Mechanism
Power Head Tilt
Adjust Height of Shaft
Charger
Charge Time in Normal Use
Charger Number
Battery Pack Number
SPECIFICATIONS
CHARGING THE LITHIUM-ION BATTERY PACK (Fig. 3 and 3a)
1. Charge battery pack only with the charger that was supplied with this trimmer.
2. Make sure power supply to the charger is normal household voltage, 120 volts,
60 Hz, AC-only.
3. Connect the battery charger to the power supply and the green light will illuminate
showing charger is operating.
4. Slide the battery pack into the charger base to make the connections and the red
light will illuminate to show charging has started. The red light will stay lit until the
battery is fully charged.
ASSEMBLY & ADJUSTMENTS cont.
15
NOTE: Within the warranty period, if the charger LED lights do not operate
properly, or the charger does not charge the battery pack, return the
charger and battery pack to your nearest Sears Store or other Craftsman
outlet for free replacement.
NOTE: A hot battery pack only occurs when prolonged continuous use of
your trimmer causes the batteries to become hot. It does not occur with
typical use. Within the warranty period, if the battery pack becomes hot
with typical use, return the charger and battery pack to your nearest Sears
store or other Craftsman outlet for free replacement.
CHARGING THE LITHIUM-ION BATTERY PACK cont. (Fig. 3 and 3a)
CHARGING A HOT BATTERY PACK
7.
The battery pack will become slightly warm to the touch while charging. This is
normal and does not indicate a problem.
8.
Do not place the charger in an area of extreme heat or cold. It will work best at
normal room temperature.
9.
When battery pack becomes fully charged, unplug battery charger from power
supply and remove the battery pack.
When using your tool continuously, the batteries in your battery pack will become
hot. You should let a hot battery pack cool down for approximately 30 minutes before
attempting to recharge.
13 inches
7800 RPM
24.0 Volt
0.065-inch twisted line
Automatic
5 positions
From 17 to 28 inches
120V, 60Hz AC
3 hours
CGT244LU-23
CGT244LU-44 retail number 71-28131
NOTE: The battery pack will not reach full charge capacity on the first few
charges. The break-in period requires 4 to 5 charging cycles, where the
battery pack is completely discharged (no motor sound or tool motion) and
then fully recharged. During the break-in period the battery pack needs to
charge 3 or more hours continuously. The green LED light on the charger
will come on in 3 hours, this is normal. Continue to leave the battery pack
charging for a total of 3 hours or more. After the break-in period, a full
recharge is indicated on the charger when the green LED light is lit.
5. The red light will switch to green, which means the battery is full, and charging is
completed. A discharged battery at normal room temperature will take
approximately 3 hours to reach full charge. When charging is completed, unplug
the charger and remove the batter pack.
6. After normal use, 3 hours charging time is required to fully recharge the battery
pack. If battery pack has not been charged for two or more months or completely
discharged, then it should be charged continuously for 3 or more hours.
Fig. 3 Fig. 3a

ASSEMBLY & ADJUSTMENTS cont.
16
INSTALLING THE LITHIUM-ION BATTERY PACK (Fig. 4)
Insert the battery pack into grass trimmer’s battery port. A simple
push and slight pressure will be sufficient.
CAUTION: When inserting batteries into this product, the proper
polarity or direction must be observed. Reverse insertion of batteries can
result in leakage or explosion. (Applies to product employing more than
one separately replaceable primary battery.)
!
WARNING: This Cordless Trimmer is always in operating condition
when the battery pack is installed. Therefore, the Safety On Button should
always be in the released position locking the power off, when the tool is
not in use or you are carrying it at your side. The trigger switch will not
turn the trimmer ON until the Safety On Button is depressed.
!
WARNING: To avoid injury, ALWAYS remove the battery from the
trimmer BEFORE installing parts, cleaning the trimmer, making any
adjustments or storing the trimmer
!
Fig. 4
ASSEMBLY & ADJUSTMENTS cont.
17
INSTALLING THE SAFETY GUARD (Figs. 5 and 5a)
INSTALLING THE EDGE GUIDE
WHEELS (Fig. 6)
1. Remove the battery pack from the trimmer.
2. Turn the trimmer’s motor housing head over to provide access to underside base
of the head by the cutting line spool.
3. Locate the single screw in the base of the head and remove the screw.
4. Insert the edge of the safety guard into the slot along the back of the trimmer’s
head,
carefullly lining the screw hole in the guard up with the screw hole in the
trimmer head.
5. Insert screw and securely attach the safety guard (see Figs. 5 and 5a).
Your trimmer comes with a set of Edge
Guide Wheels that is handy for use as a
cutting guide. It can be used to help keep
the cutting line away from items you
don’t want cut, such as flowers, or
damaged, such as fences or screens.
Each end of the wheel assembly guide
is secured in its position on the motor
housing with two screws, included, see
Fig. 6. Check Edge Guide Wheels to
make sure they are properly located
and secure.
NOTE: THE SAFETY GUARD MUST BE ATTACHED to the trimmer head
before use.
NOTE: Safety Guard will only fit one way.
Fig. 5a
Line
Cutter
Fig. 5
Fig. 6

18
ASSEMBLY & ADJUSTMENTS cont.
19
WARNING: To avoid injury, ALWAYS remove the battery from the
trimmer BEFORE installing parts or cleaning the trimmer or making any
adjustments.
!
WARNING: BEFORE
connecting the battery pack to your
trimmer, BE SURE you are not
pressing in on the trigger switch.
Failure to do so could result in
accidental start-up, which may
cause serious personal injury.
!
ADJUSTING THE CUTTING ANGLE (Fig. 9)
Your trimmer has a 5-position tilting head that easily adjusts to the desired working
angle for optimum operator control and comfort. To adjust the trimmer head angle.
1. Remove the battery pack from the trimmer.
2. Press the red trimmer head adjustment
button on the motor housing (see Fig. 9).
3. Move the trimmer head to one of the five
different angles and release the button.
Head will click into position. Easily
readjust the angle to a more efficient
position as needed.
ADJUSTING THE HEIGHT (Figs. 8 and 8a)
The Trimmer’s Telescopic
Shaft Comes in the Collapsed
Position
1. To raise the telescopic shaft,
twist top collar
(counterclockwise) to
unlock, and pull (extend)
top of shaft up, to desired
height.
2. Twist top collar (clockwise)
to lock top shaft in place.
3. To lower or collapse the
shaft simply reverse the
above steps, 1 and 2.
Fig. 9
WARNING: If any part of the trimmer is missing or damaged, do not
install the battery pack until the damaged part is repaired or replaced.
!
Trimmer Head
Adjustment
Button
1
2
3
4
5
ASSEMBLY & ADJUSTMENTS cont.
WARNING: To avoid injury, adjust the auxiliary handle for maximum
control and balance. DO NOT overreach when operating the trimmer.
ALWAYS KEEP proper balance for better control of the tool in unexpected
situations.
!
1. To release the auxiliary handle, unlock/open the Quick Release Auxiliary Bracket .
(see Fig. 7)
2. The auxiliary bracket can be opened and closed, the auxiliary handle itself can be
moved forward or backward into 5 different locked positions. (see Fig. 7a)
3. When the handle is in desired position, lock the
Quick Release Auxiliary Bracket .
Fig. 7
NOTE: THE AUXILIARY HANDLE HAS BEEN ALREADY ATTACHED to the
trimmer, but you need to adjust it to your desired position before use.
Quick Release
Auxiliary Bracket
Auxiliary Handle
Fig. 7a
ADJUSTING THE AUXILIARY HANDLE (Fig. 7 and 7a)
Fig. 8
Top
Collar
Bottom
Collar
Fig. 8a
Top
Collar
Bottom
Collar

ASSEMBLY & ADJUSTMENTS cont.
20
OPERATION
Your edger / trimmer has an extended
length (4-finger) ON / OFF trigger switch
and a safety ON button, both of which
have to be depressed to turn the
trimmer on. The trigger switch will not
depress until the safety ON button
is depressed.
Turning Trimmer ON
1. Install battery pack, and using your
thumb, press in on the safety ON button.
2. While continuing to hold in the
safety button, squeeze the trigger
switch. Now the trimmer will come on.
3. Once the trimmer is on, you can release the safety button and the trimmer will
remain on as long as you continue to squeeze the extended length trigger switch.
Turning Trimmer OFF
1. Release the trigger switch to turn trimmer OFF.
2. Allow at least 5 seconds for the cutting spool (line) to stop rotating.
TURNING TRIMMER ON AND OFF
(Fig. 12)
TO USE TRIMMER FOR EDGING:
ROTATE REAR HANDLE AND UPPER SHAFT 180°
(Figs. 10, 11, 11a and 11b)
1. Remove the battery pack from the trimmer.
2. Pull bottom collar down and rotate top shaft,
rear handle (and auxiliary handle) 180°
3. Release bottom collar to lock shaft in place.
Fig. 11
Fig. 12
Fig. 11b
Fig. 10
Pull
bottom
collar
down
Use as
edger
Use as
trimmer
OPERATION cont.
21
When trimming, cut from left to right for cutting efficiency; this throws the clippings
away from the operator (Fig. 13).
To edge, rotate the shaft 180° (See Page 20, Figs. 11 and 11a). Place edge guide
wheels and trimmer head above the surface you are going to edge, as shown in Fig. 14.
WARNING: To avoid injury, DO NOT carry the trimmer with your
finger on the trigger switch.
!
WARNING: The operation of any trimmer can result in FOREIGN
OBJECTS BEING THROWN, which can result in personal injury or property
damage. ALWAYS use proper safety equipment.
!
NOTE: ALWAYS keep the air vents on the trimmer’s head (motor housing)
free of obstructions when operating the trimmer.
TRIMMING AND EDGING (Figs. 13 and 14)
Fig. 11a
Rotate
top shaft,
release
bottom
collar
to lock
Fig. 13
Use as a
trimmer
Mask
Gloves
Use as a
edger
Fig. 14

OPERATION cont.
24
OPERATING TIPS
1. Before each use make sure the protective safety guard is tightly installed.
Tighten the guard screw, but DO NOT over tighten.
2. Be sure to check the auxiliary handle before each use, to make sure it is firmly
tightened.
3. Before trimming, inspect the area for string, wire, branches, rocks, toys, or
other objects that could be entangled in or thrown by the cutting line.
4. Stand with the cutting head tipped down at an angle in front, guiding the trimmer
in a semi-circular motion around you.
5. Cut from left to right whenever possible. Cutting to the right improves the unit’s
cutting efficiency. Clippings are thrown away from the operator.
6. To produce a smoothly trimmed area, move the trimmer in and out of the area
being cut with constant speed and height.
7. Use only the tip of the cutting line to do the trimming, especially near walls and
fences. Trimming with the side of the cutting line may overload the motor, wear
out the line faster, and break the line more often.
8. DO NOT rest the trimmer spool on the ground while you are trimming. This will
cause spool wear.
9. When cutting vegetation that is over 6 inches in height, work from top to bottom
in small increments to avoid premature line wear or engine drag.
10. If the trimmer is not cutting correctly, the auto feed may not be operating
correctly, or the spool may be empty. Remove the spool and identify the problem.
See page 22, AUTOMATIC LINE FEED SYSTEM and page 23, REPLACE
CUTTING LINE and FILLING SPOOL WITH CUTTING LINE.
CAUTION: Before you begin trimming, only use the appropriate type
of cutting line.
!
25
MAINTENANCE
ACCESSORIES
WARNING: To avoid injury, ALWAYS turn trimmer off and disconnect
the battery from the trimmer BEFORE installing parts or cleaning the
trimmer or making any adjustments.
!
WARNING: To avoid damage or electric shock, DO NOT use strong
solvents or detergents on the plastic housing or plastic components.
Certain household cleaners may damage plastic and may also cause a
shock hazard.
!
WARNING: The use of attachments or accessories that are not
recommended for this tool might be dangerous and could result in serious
injury. Do not attempt to use fishing line or other lines that are not
recommended.
!
CLEANING
Wipe the outside of the trimmer with a dry, soft cloth. DO NOT hose down or wash
the trimmer with water. Scrape the guard and spool area to remove dried clippings
and mud. Brush or blow dust, debris and grass clippings out of the air vents. Keep
the vents free of obstruction.
CUTTING LINE
Replace the cutting line ONLY with 0.065 inch (1.65 mm) twisted (helical or spiral)
shaped, not round, line for auto feed. Craftsman Professional 0.065-in. replacement
trimmer line, 71-85911, in packs of 240ft., is recommended.
SPOOL
Replace the spool with a new pre-wound spool (Craftsman Automatic Feed Spool
item number 71-85937). Line and spools are available at Sears Stores or other
Craftsman outlets.
BATTERY PACKS
Replacement battery packs (71-28131) are available for purchase at Sears stores and
other Craftsman outlets, Sears Service Centers, and through the craftsman.com
web site.
WARNING: To avoid injury, ALWAYS remove the battery from the
trimmer BEFORE installing parts or cleaning the trimmer or making any
adjustments.
!

ACCESSORIES
26
WARNING: Upon removal, cover the battery pack’s terminals with
heavy-duty adhesive tape. Do not attempt to destroy or disassemble
battery pack or remove any of its components. LITHIUM-ION batteries
must be recycled or disposed of properly. Also, never touch both terminals
with metal objects and / or body parts as short circuit may result. Keep
away from children. Failure to comply with these warnings could result in
fire and / or serious injury.
!
BATTERY CARE
BATTERY PACK REMOVAL AND PREPARATION
FOR RECYCLING
The battery pack for this tool is equipped with lithium-ion rechargeable batteries.
Length of service from each charging will depend on the type of work you are doing.
The batteries in this tool have been designed to provide maximum trouble-free life.
However, like all batteries, they will eventually wear out. DO NOT disassemble battery
pack and attempt to replace the batteries. Handling of these batteries, especially
when wearing rings and jewelry, could result in a serious burn.
To obtain the longest possible battery life, we suggest the following:
1. Remove the battery pack from the charger once it is fully charged and ready for use.
For battery storage longer than 30 days:
• Store the battery pack where the temperature is more than 40°F but less
than 105°F.
• Store battery packs in a fully charged condition.
• Charge the battery every 2 months during storage.
• A battery pack will slowly loose its charge over time, it may need to be charged
before use.
To preserve natural resources, please recycle or dispose
of batteries properly.
This product contains lithium-ion batteries. Local, state
or federal laws may prohibit disposal of lithium-ion
batteries in ordinary trash.
Consult your local waste authority for information regarding
available recycling and / or disposal options.
CONTAINS LITHIUM-ION BATTERIES
MUST BE RECYCLED OR DISPOSED OF PROPERLY.
27
PARTS LIST
The model number will be found on the nameplate of the Trimmer. Always mention the model number when requesting parts and service for your tool.
To order parts, call 1-800-469-4663
24-Volt 13-in.Weedwacker® Cordless Trimmer Model No. 172.74324

28
PARTS LIST
The model number will be found on the nameplate of the Trimmer. Always mention the model number when requesting parts and service for your tool.
To order parts, call 1-800-469-4663
29
NOTES
24-Volt 13-in.Weedwacker® Cordless Trimmer Model No. 172.74324
CGT244LU-1 CGT244LU-2 CGT244LU-3 CGT244LU-4 CGT244LU-9 CGT244LU-12 CGT244LU-13 CGT244LU-14 CGT244LU-16 CGT244LU-17 CGT244LU-18 CGT244LU-21 CGT244LU-22 CGT244LU-23 CGT244LU-30 CGT244LU-31 CGT244LU-32 CGT244LU-33 CGT244LU-35 CGT244LU-36 CGT244LU-38 CGT244LU-39 CGT244LU-40 CGT244LU-41
1 2 3 4 9
12 13 14 16 17 18 21 22 23 30 31 32 33 35 36 38 39 40 41
Self Tapping Screw Cutting Blade Guard Nut Self Tapping Screw Self Tapping Screw Screw Swivel Cover Nut Compression Spring Lock Button Clamping Plate Screw Washer Assembly Charger Coiled Cable Telescope Tube Locking Ring Screw Switch Left/Right Handle Power Supply Board Compression Spring Linkage Button
1 1 1 2 7
18
1 1 2 1 1 1 4 1 1 1 1 1 1 1 1 1 1 1
Parts No. Part Description Qty.
Position No.
CGT244LU-42 CGT244LU-43 CGT244LU-44
(71-28131)
CGT244LU-45 CGT244LU-46 CGT244LU-47 CGT244LU-48 CGT244LU-49 CGT244LU-50 CGT244LU-51 CGT244LU-52 CGT244LU-53 CGT244LU-54 CGT244LU-101 CGT244LU-102 CGT244LU-103 CGT244LU-105 CGT244LU-107 CGT244LU-111 CGT244LU-112
42 43 44 45 46 47 48 49 50 51 52 53 54
101 102 103 105 107
111
112
Compression Spring Switch Button Battery Pack(Li-ion) Cutting Head Cover Nut Rivet Cutting Head Line Feeder Assembly Compression Spring Spool & Line Fixing Block Connect Sheath Dc Motor Guard Assembly Roller Set Left /Right Housing Assembly Auxiliary Handle Assemby Motor Assembly Roller Bracket & Spindle
1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 2 1
Parts No. Part Description Qty.
Position No.
