CRAFTSMAN
19.2 Volt Cordless Drill
Model No. 113450
Repair Sheet

CRAFTSMAN 3/8 INCH, 19.2 VOLT CORDLESS DRILL-DRIVER
MODEL NUMBER 113450
The model number will be found on a label attached to the motor housing. Always mention the model number
in all correspondence regarding your 3/8 INCH CORDLESS DRILL-DRIVER or when ordering repair parts.
PARTS LIST
KEY PART
NO. NUMBER DESCRIPTION QTY.
1 616478003 Screw (Special) ...................................................................... 1
2 6903304 Chuck .................................................................................... 1
3 Item No. 911375 Battery Pack (1310715).......................................................... 1
4 Item No. 911041 Charger (1425301) ................................................................. 1
5 3063626 11315 Combo Kit Carrying Case – Not Shown ..................... 1
9021110 11348 Combo Kit Tool Bag – Not Shown .............................. 1
1
2
4
3
®
6
14
12
10
8
2

3
CRAFTSMAN 3/8 INCH, 19.2 VOLT CORDLESS DRILL-DRIVER – MODEL NUMBER 113450
1
1
2
3
4
4
5
6
7
8
9
10 11
12
14
13
15
16
17
18
19
20
21
20
20
20
20
20
22
22

The model number will be found on a label attached to the motor housing. Always mention the model number in all correspondence regarding your
3/8 INCH CORDLESS DRILL-DRIVER or when ordering repair parts.
PARTS LIST
KEY NO. PART NO. DESCRIPTION QTY.
1 983343001 Housing Assembly .........................................................................................................................1
2 3000909 Top Level ........................................................................................................................................1
3 540352003 Gear Change Button ......................................................................................................................1
4 6620311 Screw (M3.5 x 20 mm) ...................................................................................................................4
5 6359801 Mounting Plate ...............................................................................................................................1
6 6399201 Spring Plate....................................................................................................................................2
7 5434601 Spring Holder .................................................................................................................................1
8 4011801 Clutch Cap .....................................................................................................................................1
9 5437201 Sleeve.............................................................................................................................................1
10 6843401 Spring.............................................................................................................................................1
11 6711101 Washer ...........................................................................................................................................2
12 6838001 Clutch Washer................................................................................................................................1
13 6721901 Steel Ball ........................................................................................................................................6
14 6833802 Pin ..................................................................................................................................................6
15 983342001 Motor w/Gear Train and Clutch......................................................................................................1
16 2701239 Switch Assembly............................................................................................................................1
17 540340006 Forward-Reverse Actuator.............................................................................................................1
18 3048003 Rear Level ......................................................................................................................................1
19 9002724 Wrist Strap .....................................................................................................................................1
20 6620805 Screw (M4 x 16 mm) ....................................................................................................................10
21 6622306 Screw (M3.5 x 11 mm) ...................................................................................................................1
22 630206007 Bit Clip............................................................................................................................................2
983000001 Operator's Manual
2-26-13
(REV:03)
CRAFTSMAN 3/8 INCH, 19.2 VOLT CORDLESS DRILL-DRIVER – MODEL NUMBER 113450
4

WIRING DIAGRAM
CRAFTSMAN 3/8 INCH, 19.2 VOLT CORDLESS DRILL-DRIVER – MODEL NUMBER 113450
RED LEAD
BLACK LEAD
5
