Craftsman 315.HD3000 Quick setup guide

Craftsman
1/2 In. Hammer Drill
Double Insulated
Model No. 315.HD3000
Repair Sheet

2
CRAFTSMAN 1/2 in. HAMMER DRILL – MODEL NUMBER 315.HD3000
2
5
6
4
3
1
See Note “A” on next page

3
CRAFTSMAN 1/2 in. HAMMER DRILL – MODEL NUMBER 315.HD3000
The model number will be found on a label attached to the motor housing. Always mention the model number in all correspondence regarding your
DRILL or when ordering repair parts.
PARTS LIST
KEY PART
NO. NUMBER DESCRIPTION QTY
1 039453001013 Auxiliary Handle Assembly................................................................................................1
2 039171001002 Depth Stop Rod ................................................................................................................1
3 039171001015 Chuck Key Strap...............................................................................................................1
4 039171001014 Chuck Key.........................................................................................................................1
5 039453001008 Logo Label ........................................................................................................................1
6 039453001009 Data Label.........................................................................................................................1
Not Shown:
990000686 Operator’s Manual
3-11-14
(Rev:01)
NOTE: The assembly shown represents an important part of the double insulated system. To avoid the possibility of alteration or damage to the
System, service should be performed by your nearest Sears repair center. Contact your nearest Sears retail store for service center information.

4
CRAFTSMAN 1/2 in. HAMMER DRILL – MODEL NUMBER 315.HD3000
1
3
4
5
6
11
10
9
8
7
5
16
17
18
2
15
14
1
14
6
12
13
WARNING: Improper repair of a double insulated tool can result in damage to the doulbe insulation system possibly causing electrical shock of
electrocution. Any repairs requiring disassembly of your tool requires safety testing and should only be performed by a Sears authorized
Service Center. For the service center nearest you call 1-800-932-3188.

5
CRAFTSMAN 1/2 in. HAMMER DRILL – MODEL NUMBER 315.HD3000
The model number will be found on a label attached to the motor housing. Always mention the model number in all correspondence regarding your
HAMMER DRILL or when ordering parts.
PARTS LIST
1 039453001004 Housing Assembly..............................................................................................................................................1
2 039140001070 Bend Relief .........................................................................................................................................................1
3 039453001023 Mode Shift Button ..............................................................................................................................................1
4 039740003029 Impact Plate .......................................................................................................................................................1
5 039803001020 Brush Assembly .................................................................................................................................................1
6 039740003024 Screw (M2.9 x 16 mm, Pan Hd.) ........................................................................................................................4
7 039740003019 Bearing Cover.....................................................................................................................................................1
8 039140001048 Ball Bearing (607-2Z)..........................................................................................................................................1
9 039740003015 Ball Bearing (608-2RZ) .......................................................................................................................................1
10 039803001004 Motor Assembly (Inc. Key Nos. 8-9)...................................................................................................................1
11 039740003001 Output Spindle Shaft and Gear Assembly .........................................................................................................1
12 039171001006 1/2 in. Chuck ......................................................................................................................................................1
13 039140001012 Chuck Screw (M6 x 25 mm, Special, Left Hand Threads) .................................................................................1
14 039453001012 Screw (4.2 x 16 mm, Torx Hd.) ...........................................................................................................................9
15 039803001013 Power Cord ........................................................................................................................................................1
16 039453001010 Switch Assembly................................................................................................................................................1
17 039140001067 Cord Clamp ........................................................................................................................................................1
18 039140001066 Screw (M4.2 x 14 mm, Pan Hd.) ........................................................................................................................2
KEY PART
NO. NUMBER DESCRIPTION QTY

6
CRAFTSMAN 1/2 in. HAMMER DRILL – MODEL NUMBER 315.HD3000
WIRING DIAGRAM
WHITE
WHITE
WHITE
BLACK
BLACK
BLACK
MOTOR
SWITCH
BRUSH
ASSEMBLY
BRUSH
ASSEMBLY
POWER
CORD
