Craftsman 247.28981 User manual

Sears Brands Management Corp., Hoffman Estates, IL 60179 U.S.A.
Visit our website: www.craftsman.com
Operator’s Manual
LAWN TRACTOR
26 HP, 50” Tractor
Electric Start
PYT9000
Model No. 247.28981
IMPORTANT:
Read and follow all Safety
Rules and Instructions before
operating this equipment.
For answers to your questions about
this product, Call:
1-800-659-5917
Craftsman Tractor Help Line
5am - 5 pm, Mon - Sat
This product has a low emission engine which operates differently
from previously built engines. Before you start the engine, read and
understand this Operator’s Manual.
• Español, p. 62
Form No. 769-05600
(August 3, 2010)

34
PARTS LIST
Steering and Axle — Model No. 247.28981
3
13
32
16
2
7
1918
14
33
11
8
10
17
1
17
7
9
4
6
12
24
39
26
29
25
30
28
7
29
25
12
6
5
9
26
26
30
24
31
22
23
21 34
37
40
38
36
35
15
20
27
34
35
15

35
PARTS LIST
Ref.
No. Part No. Description
1710-04095 Hex Head Screw, 3/8-16:1.00
2710-0514 Hex Head Screw, 3/8-16:1.00
3710-0643 Hex Head Screw, 5/16-18:1.00
4711- 04998 LH Drag Link
5711-04999 RH Drag Link
6912-0240 Jam Nut, 7/16-20
7712-04065 Flangelock Nut, 3/8-16
8712-0459 Flangelock Nut, 7/16-20
9712-3004A Flangelock Nut, 5/16-18
10 717-1550F Steering Gear
11 717-1554 Steering Pinion Gear
12 923-0448A Ball Joint, 7/16-20
13 936-3004 Flat Washer, .406 X .875 X .105
14 736-3084 Flat Washer, .51 X 1.12 X .06:HT
15 731-05674 Bumper Cap
16 738-04263 Steering Shaft, .625 OD X 24.25 LG
17 738-04363 Shoulder Spacer, .385X 1.25 X .3025
18 741-04237B Hex Flange Bearing 5/8 PM
19 783-06043-0637 Steering Support Bracket
20 638-04022-0637 RH Axle Assembly
Ref.
No. Part No. Description
21 638-04028-0637 LH Axle Assembly
22 710-0395 Hex Head Screw, 5/16-18:2.25
23 710-0859 Hex Head Screw, 3/8-16:2.50
24 710-3180 Hex Head Screw, 5/16-18:1.75
25 912-0214 Hexlock Nut, 3/8-24
26 712-04063 Flangelock Nut, 5/16-18
27 714-0162 Cotter Pin, 5/32:1.25
28 719-04413A Pivot Bar Axle
29 748-04065-0637 Steering Block
30 748-04068 Spacer, .71 ID X .125 OD X .56LG
31 750-05280 Spacer, .385 X 1.00 X 1.5075
32 631-04415 Steering Wheel
33 731-06825 Steering Wheel Cap
34 634-04406-0961 Wheel Assembly
35 736-04228A Flat Washer, .781ID x 1.590OD
36 734-1731-0901 Tire
37 741-0990B Flange Bearing, .760ID
38 741-0516B Flange Bearing, .760 x 1.00 x 1.20LG
39 934-0255 Tubeless Air Valve
40 634-04405-4042 Rim Assembly
Steering and Axle — Model No. 247.28981

36
PARTS LIST
Hood and Dash — Model No. 247.28981
48
47
28
43
21 27
25
26
24
29
32
24
22
13
30
8
15
36
39
42
37
5
45
41
6
9
44
23
46
10
1
17 16
14
11
2
12
7
3
19
20
18
433
40
38
3533
34
2
31
24

37
PARTS LIST
Ref.
No. Part No. Description
1631-04353P Dash Lever
2710-04484 Taptite Screw, Lock Washer, 5/16-18:.750
3710-0599 Taptite Screw, Lock Washer, 1/4-20:0.500
4710-0895 Hi-Lo Screw, Lock Washer, 1/4-15:0.750
5710-0896 Screw, Lock Washer, 1/4-14:0.625
6710-1017 Screw, 1/4-14:0.625
7710 -1611B Taptite Screw, 5/16-18:0.750
8710-3217 Machine Screw, #8-32:0.375
9712-0142 Hex Nut, #8-32:GRA
10 714-04040 Bow-tie Cotter Pin
11 726-3046 Ratchet Clip:.250 DIA
12 731-07456 Dash
13 731-07550 Control Knob
14 732-04580 Extension Spring, .500 DIA X 2.733 LG
15 735-0271A Bumper
16 735-04076 Accessory Net
17 747-05280 Control Rod Latch
18 747-1196 Lever Rod
19 783-04285F-0637 RH Dash Support Plate
20 783-04323F-0637 LH Dash Support Plate
21 625-04124 Key (Set of 2)
22 683-04618-0691 Hood Assembly
23 710-04187 Hi-lo Screw, Lock Washer, 1/4-15:0.50
24 710-05108 Screw, Lock Washer, 1/4 DIA:.750
Ref.
No. Part No. Description
25 931-07457 Grill
26 731-07458 RH Lens
27 731-07459 LH Lens
28 931-07461 Hood Scoop
29 731-07467 Lower Grill
30 731-07469 LH Hood Scoop
31 731-07470 RH Hood Scoop
32 738-04091A Shoulder Screw, .43X.29:TT:5/16-18
33 710-0642 Taptite Screw, 1/4-20:0.750
34 747-05049 RH Tank Support Rod
35 747-05050 LH Tank Support Rod
36 751-0603A Fuel Cap
37 951-10573 Fuel Tank, 2.75 Gallons
38 689-00157 Guard Assembly
39 712-04065 Flangelock Nut, 3/8-16
40 738-0143 Shoulder Bolt, .496 x .336:3/8-16
41 946-04556 Throttle/Choke Control
42 735-04170 Fuel Tank Gasket
43 731-07495 P-Style Plen
44 725-04992 Switch Key Module
45 925-04036C Hour Meter
46 725-04258 PTO Switch
47 925-0963 Miniature Lamp, 12V
48 925-1649 Lamp Socket
Hood and Dash — Model No. 247.28981

38
PARTS LIST
Seat and Fender — Model No. 247.28981
33
38
20
25
22
18
17
40
21
18
23
27
24
18
31
39
12
6
15
1
4
9
13 8
14
16
7
2
5
3
11
26
28
19
30
10
36
32
37
29
34
2
35
A
A

39
PARTS LIST
Ref.
No. Part No. Description
1683-04223-0637 Lift Shaft Assembly
2712-04063 Flangelock Nut, 5/16-18
3712-04065 Flangelock Nut, 3/8-16
4914-0104 Cotter Pin, .072 DIA. X 1.13 LG
5714-04040 Bow-Tie Cotter Pin
6716-0106A E-Ring, .625 DIA. SHAFT
7720-04150 Handle Grip
8732-0874 Torsion Spring
9736-0105 Spring Washer, .401 X .870 X .063
10 738-0138A Shoulder Screw, .437 X .470:5/16-18
11 938-0380 Shoulder Bolt, .500 x .270:3/8-16
12 941-0225 Hex Flange Bearing
13 746-0968 Lift Cable, 16.16 LG
14 747-04962A Lift Handle
15 756-04331 Pulley Roller Cable
16 783-05546A-0637 Lift Arm
17 710-04482 Hex Head Flange, 3/8-16:.875
18 710-04484 Taptite Screw, Lock Washer, 5/16-18:.750
19 712-3004A Flangelock Nut, 5/16-18
20 725-0157 Cable Tie, 3/16 X .05 X 7.4
21 732-04561 Compression Spring, 1.71 X 3.735 X .238
Ref.
No. Part No. Description
22 732-04563 Compression Spring, .68 X 1.065 X .055
23 938-0296 Shoulder Screw, .437 X .268:5/16-18
24 783-06049-0691 Seat Mounting Bracket
25 783-06050 Seat Adjustment Lever
26 783-06088-0691 Seat Pivot Bracket
27 783-06448 Switch Retainer Clip
28 710-04187 Hi-Lo Screw, Lock Washer, 1/4-15:0.50
29 710-0451 Carriage Bolt, 5/16-18:.750
30 710-0599 Taptite Screw, Lock Washer, 1/4-20:0.500
31 710-0895 Hi-Lo Screw, Lock Washer, 1/4-15:0.750
32 731-05837 LH Fender Cover
33 731-06754 RH Fender Cover
34 736-3078 Flat Washer, .344 X 1.00 X .063 HDN
35 783-06118-0691 Fender
36 726-3046 Ratchet Clip
37 735-04137 LH Foot Pad
—735-04139 RH Foot Pad
38 757-04127 Seat
39 783-06181-0637 Lift Bracket
40 925-05013 Seat Switch
Seat and Fender — Model No. 247.28981

40
PARTS LIST
Drive and Rear Wheels — Model No. 247.28981
18
23
5
16
13
15
11
29
21
26
42
46
3
14
27
43
43
41
4
7
9
40
A
A
10
34 36
28
14
8
39
39 8
44
24
47
5
57
56
49
51
58
66
31
19
70
17
6
20
37
14
55
53
5
1
45
5
67
59
68
33
32
54
61
65
5
63
52
50
60
64
48
5
59
62
61
72
69
71
30
25
12
20
38
22
35
14
2

41
PARTS LIST
Ref.
No. Part No. Description
1918-0319 Hydro Transmission
2710-0176 Hex Head Screw, 5/16-18:2.75
3710-0227 Screw, Indented Washer, #8-18:0.500
4710-0351 Screw, #10-16:0.500
5710-04484 Taptite Screw, Indented Washer, 5/16-18:.750
6710-0653 Taptite Screw, Indented Washer, 1/4-20:0.375
7710-1007 Taptite Sems Screw, :3/8-16:1.500
8710-1325 Taptite Screw, Indented Washer, 1/4-20:1.625
9710 -3011 Hex Head Screw, 3/8-16:2.25
10 912-0240 Jam Nut, 7/16-20
11 912-0346 Jamlock Nut, 1/2-20
12 712-04063 Flangelock Nut, 5/16-18
13 912-0431 Flangelock Nut, 3/8-16
14 914-0111 Cotter Pin, 3/32:1.0
15 725-0157 Cable Tie. 3/16 X .05 X 7.4
16 725-04791A Jumper Harness
17 725-1644 Short Spring Switch
18 926-0154 Push Mount Cable Tie 7.5 LG
19 926-0320 Insulator Nut Plate
20 731-05299A Sleeve, .765 ID X 1.500 LG
21 731-06098 Hydro Fan
22 932-0209 Extension Spring, .48 OD X 2.03
23 732-04606 Extension Spring, .500 DIA X 12.6 LG
24 732-04624 Extension Spring, 1.00 DIA X 4.75
25 732-0716D Extension Spring, .59 OD X 4.00 LG
26 732-0729 Wire Ring
27 732-3118 Extension Spring, .375 OD X 1.44 LG
28 936-0264 Flat Washer, .330 X .630 X .0635
29 736-04263 Lock Washer
30 936-3008 Flat Washer, .344 X .750 X .120
31 736-3010 Flat Washer, .407 X .812 X .135
32 736-0430 Flat Washer, .50 x 1.59 x .062
33 731-2290A Hub Cap
34 738-04420 Shoulder Spacer, 1.375 X .380 X .183
35 747-04139 Brake Rod
36 747-04957A Footpedal Bypass Transmission Rod
Ref.
No. Part No. Description
37 747-04979 Hydro Control Rod
38 747-04991 Hydro Bypass Rod
39 750-04456 Spacer, 260 X .372 X 1.420 LG
40 954-04207 V-Belt, 4L X 78.9 POLY
41 756-04224 Flat Idler Pulley, 2.75 OD
42 756-04308 Input Pulley, 4.13 DIA
43 756-04325 V Idler Pulley, X 3.06
44 783-06027A Center Idler Bracket
45 783-06133-0637 Hydro Mounting Bracket
46 783-06260-0637 Belt Disengage Support Bracket
47 783-1019B Switch Actuator Bracket
48 647-04152A Brake Control Assembly
49 683-04488 Hydro Pedal Bracket Assembly
50 710-0604A Taptite Screw, Indented Washer, 5/16-18:0.625
51 711-05068 Clevis Pin, 5/16 X 3.985
52 712-04065 Flangelock Nut, 3/8-16
53 714-04040 Bow-Tie Cotter Pin
54 726-0214 Push Cap
55 732-04587 Extension Spring, .63 DIA X 4.95 LG
56 735-04118A Forward Pedal Pad
57 735-04135 Reverse Pedal Pad
58 735-04136 Brake Pedal Pad
59 736-0242 Bell Washer, .340 X .872 X .060
60 938-0380 Shoulder Bolt, .500 X .270:3/8-16
61 741-0495 Flange Bearing, .630 IDX .695 OD X .60
62 748-04203 Cruise Latch
63 783-05914 Pedal Support Bracket
64 783-05940 Pedal Support Bracket, 5/8
65 783-06059-0637 Drive Pedal Bracket
66 783-06103A-0637 Brake Pedal Bracket
67 634-0177-0961 Wheel Assembly
68 710-0627 Hex Head Screw, 5/16-24:.750
69 634-04369-4042 Rim Assembly
70 934-0255 Tubeless Air Valve
71 734-1873-0901 Tire
72 941-0490 Axle Hub
Drive and Rear Wheels — Model No. 247.28981

42
PARTS LIST
Engine Accessories — Model No. 247.28981
A
A
1
11
13
4
4
7
5
8
17
15 2
3
8
16
12
10
14
9
6

43
PARTS LIST
Ref.
No. Part No. Description
1683-04549-0637 Mulffler Shield Assembly
2710-0227 Screw, Indented Washer, #8-18:0.500
3710-04683 Taptite Screw, Indented Washer, 3/8-16:1.000
4710-0599 Taptite Screw, Indented Washer, 1/4-20:0.500
5710-1314A Socket Head Screw, 5/16-18:.750
6712-0271 Sems Nut, 1/4-20
7783-06378 Heat Shield
8721-0460 Exhaust Gasket
9725-0157 Cable Tie, 3/16 X .05 X 7.4
10 726-0205 Hose Clamp, .490 DIA.
11 728-04000 Rivet, .188 DIA X .300 L
12 751-3141-14 Oil Drain Extension Hose
13 751-0564B Muffler Deflector
14 751-10349 Fuel Hose
15 751-10353 Long Muffler Deflector
16 951-10517A Oil Drain
17 751-10542A Muffler Deflector
Engine Accessories — Model No. 247.28981

44
PARTS LIST
PTO and battery — Model No. 247.28981
18
6
17
22
11
21
20
9
7
5
2
4
1
10
16
19
23
13
10
14
12
3
8
15

45
PARTS LIST
Ref.
No. Part No. Description
1710-04379A Hex Head Screw, 7/16-20:3.50
2917-04174A Electric PTO Clutch
3725-0157 Cable Tie, 3/16 x .05 x 7.4
4936-0171 Lock Washer, 7/16
5736-0277 Flat Washer, 1.031 x 1.620 x .095
6725-05088 Battery
7756-0978B Electric PTO Engine Pulley
8710-04666 Hex Head Flange, 1/4-20:.75
9683-04469A-0691 Frame
10 710-04484 Taptite Screw, Indented Washer, 5/16-18:.750
11 710-0599 Taptite Screw, Indented Washer, 1/4-20:0.500
12 710-3005 Hex Head Screw, 3/8-16:1.25
13 712-04065 Flangelock Nut, 3/8-16
14 738-04058 Shoulder Spacer, .38 X 1.0 X .70
15 747-04121A Battery Holder Rod
16 783-0349-0637 Battery Tray
17 783-06089-0637 Seat Frame Bracket
18 712-0271 Sems Nut, 1/4-20
19 747-05195 Belt Keeper Rod
20 725-04363 Interlock Switch
21 738-04237A Shoulder Screw, #10-32:.500
22 725-04439 Solenoid, 12 V
23 712-04064 Flangelock Nut, 1/4-20
NS 925-04093 Wire Harness Assembly
PTO and battery — Model No. 247.28981

46
PARTS LIST
7
60
61
7
55
11
56
41
10 50
56
44
54
47 18
63
32
2
2
45 39
22
23
12
68
69
67
70
69
57 66
21
2
65
48
35
20
15
51
9
38
43 16 24
58
31
25
4
26
19
59
9
21
49
6
22
39
13
20
5
46
36
20
30
45
20
17
53 33
27
42
28
14
28
333
53
8
37
29
40
7
20
9
1
2
64
52
62
34
Deck — Model No. 247.28981

47
PARTS LIST
Ref.
No. Part No. Description
196606 Retainer Hook Bracket
2918-04825B Spindle Assembly
3683-0254B-4028 Deck Hanger Bracket Assembly
4983-04561-4028 Deck Assembly
5703-3279-4028 Deflector Chute Stop
6710-04095 Hex Head Screw, 3/8-16:1.00
7710-04484 Taptite Screw, Indented Washer, 5/16-18:.750
8710-0528 Hex Head Screw, 5/16-18:1.25
9710-0599 Taptite Screw, Indented Washer, 1/4-20:0.500
10 710-1008 Taptite Sems Screw, 3/8-16:1.875
11 710 -3011 Hex Head Screw, 3/8-16:2.25
12 710-3103 Hex Head Screw, 5/16-18:2.00
13 710-3178 Carriage Bolt, 3/8-16:0.75
14 711- 05078 Deck Support Rod
15 911-3314 Roller Pin
16 912-0206 Hex Nut, 1/2-13
17 712-0229 Push Nut, 3/8
18 912-0240 Jam Nut, 7/16-20
19 712-04063 Flangelock Nut, 5/16-18
20 712-04065 Flangelock Nut, 3/8-16
21 712-0417A Flange Nut, 5/8-18
22 912-0641 Hex Nut, M16-1.5 DIN 936
23 912-3010 Hex Nut, 5/16-18
24 712-3083 Hexlock Nut, 1/2-13
25 914-0111 Cotter Pin, 3/32:1.0
26 753-04070 Lynch Pin, .1875
27 714-04043 Bow-Tie Cotter Pin
28 914-0470 Cotter Pin, 1/8 X 1.25
29 917-04074 Deck Gear
30 921-04041 Water Nozzle Adaptor
31 731-05679 Front Roller
32 732-04649 Extension Spring, 1.0 OD X 6.10 LG
33 732-04652 Compression Spring, .535 OD X 1.751 LG
34 732-0934 Extension Spring, 1.15 OD X 5.99 LG
35 734-04155 Front Deck Wheel
Ref.
No. Part No. Description
36 734-0973 Rear Deck Wheel
37 936-0119 Lock Washer, 5/16
38 936-0179 Flat Washer, .531 X 1.25 X .100
39 736-0225 Lock Washer, 5/8
40 936-0275 Flat Washer, .344 X .688 X .065
41 936-0300 Flat Washer, .406 X .875 X .059
42 936-0314 Thrust Washer, .375X.70X.030
43 736-0317 Bell Washer, .63 X 1.25 X .18
44 736-3010 Flat Washer, .407X.812X.135
45 737-04003D Water Nozzle
46 938-0373 Shoulder Bolt, .496 X 1.525:3/8-16
47 738-04162A Shoulder Spacer, .8840 X .190
48 938-3056 Shoulder Bolt, .496 X 2.50:3/8-16
49 942-04053C 2-in-1 Cutting Blade
50 747-04530 Belt Keeper Rod
51 747-05067A Deck Lift Rod
52 732-04372 Torsion Spring
53 747-1116 Deck Release Handle Rod
54 750-3119 Spacer, .406 ID X 1.00 OD X .38
55 954-04240 V-Belt
56 756-04129B Idler Pulley, 4.25"DIA
57 750-1096 Spacer, .800 x 1.100 x 1.53 LG
58 783-04414A-4028 Center Deck Skirt
59 783-04415-4028 RH Deck Skirt
60 783-05280-4028 LH Belt Cover
61 783-05281-4028 RH Belt Cover
62 711-04565 Hinge Pin
63 783-06361-0637 Idler Bracket
64 783-05030 Chute Bracket
65 631-04070A Chute Deflector
66 756-04216 Deck Pulley, 5.39 DIA
67 937-3000 Lube Fitting
68 738-0976 Spindle Shaft, 4.1250 LG.
69 941-0919 Ball Bearing, .787ID X 1.85 ODX.551
70 748-0434 Spacer, .750 x 1.150 x .230 LG
Deck — Model No. 247.28981

8
252
10
9
11
3
2
1
250
22
1027
718
850
45
46
287
842
524
523
525
847
220
615
219
562
505
227
278
212
750
1024
943
965
415
20
1013
1017
12
4
15
742
552
616
552A
404
691
186A
512
#1
#2
Engine — Model No. 247.28981
PARTS LIST
48

387
240
385
53
654
187
601
703
118
276
1127
137
104
987
95
150
1128
105
1126
1124A
276
633
108
672
418
163
135
231
130
98
947
141
125
133
131
142
1124
975
217
1169
117
634
51
51A
51A
24
26
28
25
27
27
32
29
741
146
16
50
929
212
163
54
617
186
415
51A
51A
Engine — Model No. 247.28981
PARTS LIST
49

1070
75
332
74
216
209211
267
265
188
222
1090
579
802
310
801
1051
783
513
309
510
697
23
165
726
1005
695
544
803
668
73
668A
503
562
505
227
278
729
1054
851
334
635
333
501
526
1059
1119
474
729A
405A
789
Engine — Model No. 247.28981
PARTS LIST
50

337
635
13
798
42
192
1022
1100
1029
7
36
35
33
34
868
798
5A
883
1022
1100
1029
7
36
35
33
5
42
192
1023A
1023
1022
883
1022
1026
45
1026A
914
617
617
42
34
86842
914
918
850
850
Engine — Model No. 247.28981
PARTS LIST
51

573
163
304
967
445
306
307
865
447
703
431
305
305A
197
467
968
1040
306A
Engine — Model No. 247.28981
PARTS LIST
52
