Craftsman 3One 917.383640 User manual

®
0 EL U
oAssembly
- Operation
oCustomer
Responsibilities
° Service
oAdjustments
_oRepair Parts
Caution:
Read and Follow
all Safety Rules
and Instructions
Before Operating
This Equipment
917.383640 OWNER'S MANUAL
TM
:_'11 IIIIII ..................... 1! ...........................................

SAFETY RULES
PLUG TO PREVENTACCIDENTAL STARTING WHEN SETTING UP, TRANSPORTING, ADJUSTING OR MAKING
REPAIRS. IMPORTANT
SAFETY STANDARDS REQUIRE OPERATOR PRESENCE CONTROLS TO MINIMIZETHE RISK OF INJURY. YOUR UNIT IS EQUIPPED WITH
SUCH CONTROLS. DO NOT ATTEMPT TO DEFEAT THE FUNCTION OF THE OPERATOR PRESENCE CONTROLS UNDER ANY CIRCUM-
STANCES.
TRAINING:
• Read this operator's manual carefulIy. Become familiar with
the controls and know how to operate your mower properly.
Learn how to quickfy stop mower_
•Do not allow children to use your mower. Never allow aduffs
to use mower without proper instructions.
,Keep the area of operation clear of all persons, especially
small children and pets.
• Use mower only as the manufacturer intended and as de-
scribed inthis manual.
•Do not operate mower if ithas been dropped or damaged in
any manner. Always have damage repaired before using
your mower.
, Do not use accessory attachments that are not recommended
by the manufacturer. Use of such attachments may be
hazardous.
•The blade turns when the engine is running.
PREPARATION:
,, Always thoroughly check the area to be mowed and ctear it of
all stones, sticks, wires, bones, and other foreign objects.
These objects will be thrown by the blade and can cause
severe injury,
,, Always wear safety glasses or eye shields when starting and
while using your mower.
,, Dress properly. Do not operate mower when barefoot or
wearing open sandals. Wear only solid shoes with good
traction when mowing.
° Check fuel tank before starting engine. Do not fill gas tank
indoors, when the engine isrunning or when the engine ishot.
Allow the engine to cool for several minutes before filling the
gas tank. Clean off any spilled gasoline before starting the
engine.
,, Always make wheel height adjustments before starting your
mower. Never attempt to do this while the engine is running_
° Mow only in daylight or good artificial light.
OPERATION:
• Keep your eyes and mind on your mower and the area being
cut. Do not let other interests distract you.
• Do not mow wet or slippery grass. Never run while operating
your mower. Always be sure ofyour footing -keep a firm hold
on the handles and walk.
Do not put hands or feet near or under rotating parts. Keep
clear of the discharge opening at all times.
• Always stop the blade whenever you leave or are not using
you rmower, or before crossing driveways, walks, roads, and
any gravel-covered areas.
• Never direct discharge of material toward bystanders nor
allow anyone near the mower while you are operating it.
•Before cleaning, inspecting, or repairing your mower, stop
the engine and make absolutely sure the blade and all
moving parts have stopped. Then disconnect the spark plug
wire and keep it away from the spark plug to prevent
accidental starting.
• Do not continue to run your mower ifyou hit a foreign object.
Follow the procedure outlined above, then repair any dam-
age before restarting and operating you mower.
° Do not change the governor settings or overspeed the
engine. Engine damage or personal injury may result.
- Do not operate your mower if it vibrates abnormally. Exces-
sive vibration is an indication of damage; stop the engine,
safely check forthe cause of vibration and repair as required.
• Do not run the engine indoors. Exhaust fumes are danger-
ous.
,, Never cut grass by pulling the mower towards you. Mow
across the face of slopes, never up and clown or you might
lose your footing. Do not mow excessively steep slopes.
Use caution when operating the mower on uneven terrain or
when changing directions - maintain good footing.
• Never operate your mower without proper guards, plates,
grass catcher or other safety devices in place.
MAINTENANCE AND STORAGE:
', Check the blade and the engine mounting bolts often to be
sure they are tightened properly.
• Check all bolts, nuts and screws at frequent intervals for
proper tightness to be sure mower is in safe working condi-
tion.
,, Keep al! safety devices in place and working.
• To reduce fire hazard, keep the engine free of grass, leaves
or excessive grease and oil.
Q Check grass catcher often for deterioration and wear and
replace worn bags. Use only replacement bags that are
recommended by and comply with specifications of the
manufacturer of your mower.
- Always keep a sharp blade on your mower.
° Allow engine to coo! before storing in any enclosure.
• Never store mower with fuel in the tank inside a building
where fumes may reach an open flame or an ignition source
such as a hot water heater, space heater, clothes dryer, etc.
IS SYMBOL TO POINT OUT IMPORTANT SAFETY PRECAUTIONS.
IT MEANS -ATTENTION!!! BECOME ALERT!!! YOUR SAFETY IS INVOLVED.

....... i
CONGRATULATIONS on your purchase of a Sears
Craftsman Lawn Mower. It has been designed, engineered
and manufactured to give you the best possible de-
pendability and performance.
Should you experience any problems you cannot easily
remedy, please contact your nearest Sears Service Cen-
teriDepartmento Sears has competent, welt trained tech-
nicians and the proper tools to service or repair this unit.
Please read and retain this manual. The instructions will
enable you to assemble and maintain your lawn mower
properly. Always observe the "SAFETY RULES".
MODEL
NUMBER 917.383640
SERIAL
NUMBER
DATE OF
PURCHASE
THE MODEl_ AND SERIAL NUMBERS WILL BE
FOUND ON A DECAL ATTACHED TO THE REAR
OF THE LAWN MOWER HOUSING.
YOU SHOULD RECORD BOTH SERIAL NUMBER
AND DATE OF PURCHASE AND KEEP IN A SAFE
PLACE FOR FUTURE REFERENCE.
PRODUCT SPECIFICATIONS
HORSEPOWER: 3.8
DISPLACEMENT: 9.0 cu. in.
GASOLfNE CAPACITY: ! .5 quarts
(Unleaded)
OIL (20 oz. Capacity): SAE 30 (Above 32°F)
5W30 (Below 32°F)
SPARK PLUG (GAP .030 in.):
(0.76 ram) Champion
RJ19LM or
Sears _ 33312
or STD 361458
or STD 360950
VALVE CLEARANCE: Intake: .008 in.
Exhaust: .008 in.
SOLID STATE IGNITION
AIR GAP: .0125 in.
BLADE BOLT TORQUE: 35*40 ff.-lbs.
MAINTENANCE AGREEMENT
A Sears Maintenance Agreement is available on this product. Contact your nearest Sears store for details.
CUSTOMER RESPONSIB_UTJES
® Read and observe the safety rules.
= Follow a regular schedule in maintaining, caring for and using your lawn mower.
Follow the instructions under "Customer Responsibilities" and "Storage" sections of this Owne¢s Manual.
LiMiTED TWO YEAR WARRANTY ON CRAFTSMAN POWER MOWER
For two years from date of purchase, when this Craftsman Lawn Mower is maintained, lubricated, and tuned up
according to the operating and maintenance instructions in the owner's manual, Sears will repair free of charge any
defect in material or workmanship.
If this Craftsman Lawn Mower isused for commercial or rental purposes, this warranty applies for only 90 days from
the date of purchase.
This Warranty does not cover:
Expendable items which become worn during normal use, such as rotary mower blades, blade adapters, belts,
air cleaners and spark plug.
= Repairs necessary because of operator abuse or negligence, including bent crankshafts and the failure to
maintain the equipment according to the instructions contained in the owner's manual.
WARRANTY SERVICE IS AVAILABLE BY RETURNING THE CRAFTSMAN POWER MOWER TO THE NEAREST
SEARS SERVICE CENTER/DEPARTMENT IN THE UNITED STATES. THIS WARRANTY APPLIES ONLY WHILE
THIS PRODUCT tS tN USE IN THE UNITED STATES.
This Warranty gives you specific tegal rights, and you may also have other rights which vary from state to state.
SEARS, ROEBUCK AND CO., D/817 WA, HOFFMAN ESTATES, ILLINOIS 60179
3

....... i
TABLE OF
SAFETY RULES .................................................... 2
PRODUCT SPECiFICATiONS .............................. 3
CUSTOMER RESPONSIBILITIES ............. 3, 11-13
WARRANTY .......................................................... 3
LAWN MOWER ACCESSORIES .......................... 5
ASSEMBLY ........................................................... 6
OPERATION .......................................................... 7
CONTENTS
MAINTENANCE SCHEDULE .............................. 11
SERVICE AND ADJUSTMENTS ......................... 14
STORAGE ........................................................... 15
TROUBLESHOOTING ......................................... 21
REPAIR PARTS - LAWN MOWER ................ 16-17
REPAIR PARTS -ENGINE ............................ !8-20
PARTS ORDERING/SERVICE ........ BACK COVER
