Owner's Manual
ICRIIFTSMAN°I
ROTARY LAWN MOWER
7.0 Horsepower
Power-propelled
21" Rear discharge
Model No.
917.378780
CAUTION:
Read and follow all
Safety Rulesand Instructions
beforeoperatingthis equipment
Sears, Roebuck and Co., Hoffman Estates, IL 60179 U.S.A.
Visit ourCraftsman website:www,sears.com/craftsman

Warranty ............................................... 2
Safety Rules ...................................... 2-4
Assembly /Pre-Operation .................... 5
Operation ........................................... 6-9
Maintenance Schedule ...................... 10
Maintenance ................................. 10-13
Product Specifications ........................ 11
Service and Adjustments .............. 13-15
Storage ......................................... 15-16
Troubleshooting ........................... 16-17
Repair Parts .................................. 35-43
Sears Service ...................... Back Cover
LIMITED TWO YEAR WARRANTY ON CRAFTSMAN POWER MOWER
For two years from date of purchase, when this Craftsman Lawn Mower is maintained,
lubricated, and tuned up according to the operating and maintenance instructions in
the owner's manual, Sears will repair free of charge any defect in material or workman-
ship.
If this Craftsman Lawn Mower is used for commercial or rental purposes, this warranty
applies for only 90 days from the date of purchase.
This Warranty does not cover:
• Expendable items which become worn during normal use, such as rotary mower
blades, blade adapters, belts, air cleaners and spark plug.
• Repairs necessary because of operator abuse or negligence, including bent
crankshafts and the failure to maintain the equipment according to the instructions
contained in the owner's manual.
Warranty service is available by returning the Craftsman power mower to the nearest
Sears Service Center/Department in the United States. This warranty applies only
while this product is used in the United States.
This Warranty gives you specific legal rights, and you may also have other rights which
vary from state to state.
Sears, Roebuck and Co., D/817 WA, Hoffman Estates, Ulinois 60179
IMPORTANT: This cutting machine is capable of amputating hands and feet and
throwing objects. Failure to observe the following safety instructionscould result in
serious injury or death.
ALook for this symbol to point out
important safety precautions. It means
CAUTION!!! BECOMEALERT!!I YOUR
SAFETY IS INVOLVED.
ACAUTION: Always disconnect spark
plug wire and place wire where it cannot
contact spark plug in order to prevent
accidental starting when setting up,
transporting, adjusting or making repairs.
AWARNING: Engine exhaust, some of
its constituents, and certain vehicle
components contain or emit chemicals
known to the State of California to cause
cancer and birthdefects or other repro-
ductive harm.
_I_WARNING: Battery posts, terminals and
related accessories contain lead and
lead compounds, chemicals known to the
State of California to cause cancer and
birthdefects or other reproductive harm.
Wash hands after handling.
2
A CAUTION: Muffler and other engine
parts become extremely hot during
operation and remain hot after engine
has stopped. To avoid severe burns on
contact, stay away from these areas.

I.GENERAL OPERATION
• Read,understand,andfollow all
instructions on the machine and in the
manual(s) before starting. Be thor-
oughly familiar with the controls and
the proper use of the machine before
starting.
• Do not put hands or feet near or under
rotating parts. Keep clear of the
discharge opening at all times.
•Only allow responsible individuals,
who are familiar with the instructions, to
operate the machine.
• Clear the area of objects such as
rocks, toys, wire, bones, sticks, etc.,
which could be picked up and thrown
by the blade.
•Be sure the area is clear of other
people before mowing. Stop machine if
anyone enters the area.
• Do not operate the mower when
barefoot or wearing open sandals.
Always wear substantial foot wear.
• Do not pull mower backwards unless
absolutely necessary. Always look
down and behind before and while
moving backwards.
• Do not operate the mower without
proper guards, plates, grass catcher or
other safety protective devices in place.
• See manufacturer's instructions for
proper operation and installation of
accessories. Only use accessories
approved by the manufacturer.
• Stop the blade(s) when crossing gravel
drives, walks, or roads.
• Stop the engine (motor) whenever you
leave the equipment, before cleaning
the mower or unclogging the chute.
• Shut the engine (motor) off and wait
until the blade comes to complete stop
before removing grass catcher.
• Mow only in daylight or good artificial
light.
• Do not operate the machine while
under the influence of alcohol or drugs.
• Never operate machine in wet grass.
Always be sure of your footing: keep a
firm hold on the handle and walk;
never run.
• Disengage the self-propelled mecha-
nism or drive clutch on mowers so
equipped before starting the engine
(motor).
• If the equipment should start to vibrate
abnormally, stop the engine (motor)
and check immediately for the cause.
Vibration is generally a warning of
trouble.
• Always wear safety goggles or safety
glasses with side shields when
operating mower.
II. SLOPE OPERATION
Slopes are a major factor related to slip
and fall accidents which can result in
severe injury. All slopes require extra
caution. If you feel uneasy on a slope, do
not mow it.
DO:
• Mow across the face of slopes: never
up and down. Exercise extreme caution
when changing direction on slopes.
• Remove obstacles such as rocks, tree
limbs, etc.
• Watch for holes, ruts, or bumps. Tall
grass can hide obstacles.
DO NOT:
• Do not trim near drop-offs, ditches or
embankments. The operator could lose
footing or balance.
• Do not trim excessively steep slopes.
• Do not mow on wet grass. Reduced
footing could cause slipping.
Ill. CHILDREN
Tragic accidents can occur if the operator
is not alert to the presence of children.
Children are often attracted to the
machine and the mowing activity. Never
assume that children will remain where
you last saw them.
• Keep children out of the trimming area
and under the watchful care of another
responsible adult.
• Be alert and turn machine off if children
enter the area.
• Before and while walking backwards,
look behind and down for small
children.
• Never allow children to operate the
machine.
• Use extra care when approaching blind
corners, shrubs, trees, or other objects
that may obscure vision.
IV. SERVICE
• Use extra care in handling gasoline
and other fuels. They are flammable
and vapors are explosive.
-Use only an approved container.
- Never remove gas cap or add fuel
with the engine running. Allow
engine to cool before refueling. Do
not smoke.
- Never refuel the machine indoors.
- Never store the machine or fuel
container inside where there is an
open flame, such as a water heater.
3

•Never run a machine inside a closed •
area.
• Never make adjustments or repairs
with the engine (motor) running. °
Disconnect the spark plug wire, and
keep the wire away from the plug to
prevent accidental starting. •
• Keep nuts and bolts, especially blade
attachment bolts, tight and keep
equipment in good condition.
• Never tamper with safety devices.
Check their proper operation regularly.
• Keep machine free of grass, leaves, or
other debris build-up. Clean oil or fuel °
spillage. Allow machine to cool before
storing.
Stop and inspect the equipment if you
strike an object. Repair, if necessary,
before restarting.
Never attempt to make wheel height
adjustments while the engine (motor) is
running.
Grass catcher components are subject
to wear, damage, and deterioration,
which could expose moving parts or
allow objects to be thrown. Frequently
check components and replace with
manufacturer's recommended parts,
when necessary.
Mower blades are sharp and can cut.
Wrap the blade(s) or wear gloves, and
use extra caution when servicing them.
Do not change the engine governor
setting or overspeed the engine.
These accessories were available when this lawn mower was produced. They are not
shipped with your mower. They are also available at most Sears retail outlets and service
centers. Most Sears stores can also order repair parts for you, when you provide the model
number of your lawn mower. Some of these accessories may not apply to your lawn mower.
LAWN MOWER PERFORMANCE
CLIPPING DEFLECTOR
FOR REAR DISCHARGE LAWN MOWERS
GRASS CATCHERS
FOR
REAR DISCHARGE
LAWN MOWERS
MULCHER KITS
GRASS CATCHERS
FOR
SIDE DISCHARGE
LAWN MOWERS
LAWN MOWER MAINTENANCE
MUFFLERS AIR FILTERS
BELTS BLADES BLADE ADAPTERS WHEELS
STABILIZER
GAS CANS
SPARK PLUGS
ENGINE OIL
4

Read these instructions and this manual
in its entirety before you attempt to
assemble or operate your new lawn
mower.
IMPORTANT: This lawn mower is
shipped WITHOUT OIL OR GASOLINE in
the engine.
Your new lawn mower has been as-
sembled at the factory with the exception
of those parts left unassembled for
shipping purposes. All parts such as nuts,
washers, bolts, etc., necessary to com-
plete the assembly have been placed in
the parts bag. To ensure safe and proper
operation of your lawn mower, all parts
and hardware you assemble must be
tightened securely. Use the correct tools
as necessary to ensure proper tightness.
TO REMOVE LAWN MOWER FROM
CARTON
1. Remove loose parts included with
mower.
2. Cut down two end corners of carton
and lay end panel down flat.
3. Remove all packing materials except
padding between upper and lower
handle and padding holding operator
presence control bar to upper handle.
4. Roll lawn mower out of carton and
check carton thorougly for additional
loose parts.
HOWTO SET UPYOUR LAWN
MOWER
TO UNFOLD HANDLE
IMPORTANT: Unfold handle carefully so
as not to pinch or damage control cables.
1. Raise handles until lower handle
section locks into place in mowing
position.
2. Remove protective padding, raise
upper handle section into place on
lower handle and tighten both handle
knobs.
3. Remove handle padding holding
operator presence control bar to
upper handle.
Your lawn mower handle can be adjusted
for your mowing comfort. Refer to "AD-
JUST HANDLE" in the Service and
Adjustments section of this manual.
Operator I
control bar
Upper handl UP
LIFT
UI
Mowing
position
Lower handle
TO INSTALL ATrACHMENTS
Your lawn mower was shipped ready to
be used as a mulcher. To convert to
bagging, see "TO CONVERT MOWER" in
the Operation section of this manual).
5

KNOW YOUR LAWN MOWER
READ THIS OWNER'S MANUAL AND ALL SAFETY RULES BEFORE OPERATING
YOUR LAWN MOWER. Compare the illustrations with your lawn mower to familiarize
yourself with the location of various controls and adjustments. Save this manual for
future reference.
These symbols may appear on your lawn mower or in literature supplied with the
product. Learn and understand their meaning.
CAUTION ENGINE ENGINE FAST SLOW CHOKE FUEL OIL DANGER, KEEP HANDS
OR WARNING ON OFF AND FEET AWAY
Throttle Operator presence control bar
Drive control lever
Starter
handle Handle knob
oil cap with dipstick
Grass catcher Muffler
Housing
cover
Primer adjuster (on each wheel)
IMPORTANT: This lawn mower is shipped WITHOUT OIL OR GASOLINE in the engine.
MEETS CPSC SAFETY REQUIREMENTS
Sears rotary walk-behind power lawn mowers conform to the safety standards of the
American National Standards Institute and the U.S. Consumer Product Safety Commis-
sion. The blade turns when the engine is running.
Operator presence control bar -must
be held down to the handle to start the
engine. Release to stop the engine.
Starter handle - used for starting the
engine.
Primer- pumps additional fuel from the
carburetor to the cylinder for use when
starting a cold engine.
Drive control lever -used to engage
power-propelled forward motion of lawn
mower.
Throttle control - used for starting the
engine and allows you to select either
FAST or SLOW engine speed.
6

The operation of any lawn
mower can result in foreign
objects thrown into the
eyes, which can result in
severe eye damage.
Always wear safety glasses or eye
shields while operating your lawn mower
or performing any adjustments or repairs.
We recommend standard safety glasses
or a wide vision safety mask worn over
spectacles.
HOWTO USE YOUR LAWN MOWER
ENGINE SPEED
The engine speed is controlled by a
throttle control located on the side of the
upper handle. FAST position is for
starting, normal cutting, trimming and
better grass bagging. SLOW position is
for light cutting, trimming and fuel
economy.
DRIVE CONTROL
•Self-propelling is controlled by holding
the operator presence control bar down
to the handle and pushing the drive
control lever forward until it clicks; then
releasing the lever.
•Forward motion will stop when the
operator presence control bar is
released. To stop forward motion
without stopping engine, release the
operator presence control bar slightly
until the drive control disengages. Hold
operator presence control bar down
against handle to continue mowing
without self-propelling.
•To keep drive control engaged when
turning corners, push down on handle
and lift front wheels off ground while
turning lawn mower.
Operator )resence control bar Drive
control
FAST
SLOW
III I|I
II #
/ I I
ENGINE ZONE CONTROL
ACAUTION: Federal regulations require
an engine control to be installed on this
lawn mower in order to minimize the risk
of blade contact injury. Do not under any
circumstances attempt to defeat the
function of the operator control. The blade
turns when the engine is running.
•Your lawn mower is equipped with an
operator presence control bar which
requires the operator to be positioned
behind the lawn mower handle to start
and operate the lawn mower.
TO ENGAGE
DRIVE CONTROL
DRIVE
CONTROL
DISENGAGED
TO ADJUST cu'n'ING HEIGHT
Raise wheels for low cut and lower
wheels for high cut, adjust cutting height
to suit your requirements. Medium
position is best for most lawns.
•To change cutting height, squeeze
adjuster lever toward wheel. Move
wheel up or down to suit your require-
ments. Be sure all wheels are in the
same setting.
NOTE: Adjuster is properly positioned
when plate tab inserts into hole in lever.
Also, 9-position adjusters (if so equipped)
allow lever to be positioned between the
plate tabs.
RAISE WHEELS FOR LOW CUT Lever
7

TOCONVERTMOWER
Your lawn mower was shipped ready to be
used as a mulcher. To convert to bagging:
•Lift rear door of the lawn mower and place
the grass catcher frame hooks onto the
door pivot pins.
• To convert to mulching operation, remove
grass catcher and close rear door.
ACAUTION: Do not run your lawn mower
without rear door closed, clipping
deflector or approved grass catcher in
place. Never attempt to operate the lawn
mower with the rear door removed or
propped open.
Pivot pins Rear Grass
catcher
handle
Catcher frame hool__
TO EMPTY GRASS CATCHER
1. Lift up on grass catcher using the
frame handle.
2. Remove grass catcher with clippings
from under lawn mower handle.
3. Empty clippings from bag using both
frame handle and bag handle.
NOTE: Do not drag the bag when
emptying; it will cause unnecessary wear.
Grass
catcher
frame
handle
Bag
handle
2. Remove oil dipstick from oil fill spout.
Make sure that rim of spout is clean.
3. You receive a container of oil with the
unit. Slowly pour 3/4 (15 oz.) of the oil
from the container down the oil fill
spout into the engine.
4. Wait one minute to allow oil to settle.
Insert and tighten dipstick, then
remove it to check oil level.
5. Continue adding small amounts of oil
and rechecking the dipstick until it
reads full. DO NOT overfill, or engine
will smoke on starfup.
6. Always be sure to retighten oil dipstick
before starting engine.
•Check oil level before each use. Add
oil if needed. Fill to full line on dipstick.
• Change the oil after every 25 hours of
operation or each season. You may
need to change the oil more often
under dusty, dirty conditions.
ADD GASOLINE
•Fillfuel tank to bottom of tank filler
neck. Do not overfill. Use fresh, clean,
re.gular unleaded gasoline with a
ram=mum of 87 octane. Do not mix oil
with gasoline. Purchase fuel in
quantities that can be used within 30
Adays to assure fuel freshness.
CAUTION: Wipe off any spilled oil or
fuel. Do not store, spill or use gasoline
near an open flame.
ACAUTION: Alcohol blended fuels
(called gasohol or using ethanol or
methanol) can attract moisture which
leads to separation and formation of
acids during storage. Acidic gas can
damage the fuel system of an engine
while in storage. To avoid engine
problems, the fuel system should be
emptied before storage of 30 days or
longer. Drain the gas tank, start the
engine and let it run until the fuel lines
and carburetor are empty. Use fresh fuel
next season. See Storage Instructions for
additional information. Never use engine
or carburetor cleaner products in the fuel
tank or permanent damage may occur.
BEFORE STARTING ENGINE
ADD OIL
Your lawnmower is shipped without oil in
the engine. For type and grade of oil to
use, see "ENGINE" in the Maintenance
section of this manual.
A CAUTION: DO NOT overfill engine with
oil, or it will smoke on startup.
1. Be sure lawnmower is level and area
around oil fill is clean.
oline filler
cap
8
oil cap

TO START ENGINE
NOTE: Due to protective coatings on the
engine, a small amount of smoke may be
present during the initial use of the
product and should be considered
normal.
1. To start a cold engine, push primer
three (3) times before trying to start.
Use a firm push. This step is not
usually necessary when starting an
engine which has already run for a
few minutes.
2. Move throttle control lever to FAST
position.
3. Hold operator presence control bar
down to the handle and pul! starter
handle quickly. Do not allow starter
rope to snap back.
TO STOP ENGINE
• To stop engine, release operator
presence control bar.
NOTE: In cooler weather it may be
necessary to repeat priming steps. In
warmer weather over priming may cause
flooding and engine will not start. If you
do flood engine, wait a few minutes
before attempting to start and do not
repeat priming steps.
MOWING TIPS
• Under certain conditions, such as very
tall grass, it may be necessary to raise
the height of cut to reduce pushing
effort and to keep from overloading the
engine and leaving clumps of grass
clippings. It may also be necessary to
reduce ground speed and/or run the
mower over the area a second time.
• For extremely heavy cutting, reduce
the width of cut by overlapping
previously cut path and mow slowly.
• For better grass bagging and most
cutting conditions, the engine speed
should be set in the FAST position.
• Pores in cloth grass catchers can
become filled with dirt and dust with
use and catchers will collect less
grass. To prevent this, regularly hose
catcher off with water and let dry
before using.
• Keep top of engine around starter
clear and clean of grass clippings and
chaff. This will help engine air flow and
extend engine life.
MULCHING MOWING TIPS
IMPORTANT: For best performance,
keep mower housing free of built-up
grass and trash. See "CLEANING" in the
Maintenance section of this manual.
•The special mulching blade will recut
the grass clippings many times and
reduce them in size so that as they fall
onto the lawn they will disperse into the
grass and not be noticed. Also, the
mulched grass will biodegrade quickly
to provide nutrients for the lawn.
Always mulch with your highest engine
(blade) speed as this will provide the
best recutting action of the blades.
•Avoid cutting your lawn when it is wet.
Wet grass tends to form clumps and
interferes with the mulching action. The
best time to mow your lawn is the early
afternoon. At this time the grass has
dried and the newly cut area will not be
exposed to the direct sun.
•For best results, adjust the lawn mower
cutting height so that the lawn mower
cuts off only the top one-third of the
grass blades. If the lawn is overgrown it
will be necessary to raise the height of
cut to reduce pushing effort and to keep
from overloading the engine and
leaving clumps of mulched grass. For
extremely heavy grass, reduce your
width of cut by overlapping previously
cut path and mow slowly.
MAXI_
• Certain types of grass and grass
conditions may require that an area be
mulched a second time to completely
hide the clippings. When doing a
second cut, mow across or perpendicu-
lar to the first cut path.
• Change your cutting pattern from week
to week. Mow north to south one week
then change to east to west the next
week. This will help prevent matting
and graining of the lawn.
9

MAINTENANCE SCHEDULE ._
FILLINDATES _*"/'9..-_.,_I
REGULAR SERVICE
Check for Loose Fasteners I,f
Clean/Inspect Grass Catcher
(If Equipped) If If
Clean Lawn Mower t/M
O Clean Under Drive Cover
Power-Propelled Mowers)
Check drive belt,/pulleys
RE Power-Propelled Mowers)
Check/Sharpen/Replace Blade
Lubrication Chart
Clean Battery/Recharge
Electric Start Mowerst
ECheck Engine Oil Level
N Change Engine Oil
GClean Air Filter
I Inspect Muffler
N clean or Replace Spark Plug
EReplace Air Filter Paper Cartridge
v'
v'
RV,OE
i/
$
i/
_4
1_1,2
V'2
V°2
1 - Change more often when operating under aheaWload or in high ambient temperatures.
2 - Service more often when operating in dirty or dusty condilions,
3-Replace blades more often when mowing in sar_y soil.
4-Charge 48 hours at end of season,
GENERAL RECOMMENDATIONS
The warranty on this lawn mower does
not cover items that have been subjected
to operator abuse or negligence. To
receive full value from the warranty,
operator must maintain mower as
instructed in this manual, Some adjust-
ments will need to be made pedodically
to properly maintain your unit,
All adjustments in the Service and
Adjustments section of this manual
should be checked at least once each
season.
• Once a year, replace the spark plug,
clean or replace air filter element and
check blade for wear. Anew spark
plug and clean/new air filter element
assure proper air-fuel mixture and help
your engine run better and last longer.
•Follow the maintenance schedule in
this manual.
BEFORE EACH USE
1. Check engine oil level.
2. Check for loose fasteners.
LUBRICATION
Keep unit well lubricated (See "LUBRI-
CATION CHART").
LUBRICATION CHART
eadl_.._ (_) Wheel
juster (on
ch wheel)
_, ;lineoil
l/
I\
t-- -- JRear door
hinge
(!) Handle bracket mounting pins
(_) Spray lubricant
(_) See "ENGINE" in Maintenance section.
10
IMPORTANT: Do not oil or grease
plastic wheel bearings. Viscous
lubricants will attract dust and dirtthat
will shorten the life of the self-lubricat-
ing bearings. If you feel they must be
lubricated, use only a dry, powdered
graphite type lubricant sparingly.

PRODUCT SPECIFICATIONS
Serial number:
Date of purchase:
Gasoline capacity /type: 1.6 quarts (unleaded regular)
Oil type (APi-SF-SJ): SAE 30 (above 32°F); SAE 5W-30 (below 32°F)
Oil capacity: 20 ounces
Spark plug (gap: .020") Champion RC12YC
Blade bolt torque: 35-40 ft. Ibs.
The model and serial numbers will be found on a decal on the rear of the mower
housing. Record both serial number and date of purchase in space provided above
LAWN MOWER
Always observe safety rules when perform-
ing any maintenance.
TIRES
•Keep tires free of gasoline, oil, or insect
control chemicals which can harm rubber.
•Avoid stumps, stones, deep ruts, sharp
objects and other hazards that may cause
tire damage.
BLADE CARE
For best results, mower blade must be
kept sharp. Replace bent or damaged
blades.
TO REMOVE BLADE
1. Disconnect spark plug wire from spark
plug and place wire where it cannot
come in contact with spark plug.
2. Turn lawn mower on its side. Make
sure air filter and carburetor are up.
3. Use a wood block between blade and
mower housing to prevent blade from
turning when removing blade bolt.
NOTE: Protect your hands with gloves
and/or wrap blade with heavy cloth.
4. Remove blade bolt by turning counter-
clockwise.
5. Remove blade and attaching hard-
ware (bolt, lock washer and hardened
washer).
NOTE: Remove the blade adapter and
check the key inside hub of blade
adapter. The key must be in good condi-
tion to work properly. Replace adapter if
damaged.
TO REPLACE BLADE
1. Position the blade adapter on the
engine crankshaft. Be sure key in
adapter and crankshaft keyway are
aligned.
2. Position blade on the blade adapter
aligning the two (2) holes in the blade
with the raised lugs on the adapter.
3. Be sure the trailing edge of blade
(opposite sharp edge) is up toward
the engine.
4. Install the blade bolt with the lock
washer and hardened washer into
blade adapter and crankshaft.
5. Use block of wood between blade and
lawn mower housing and tighten the
blade bolt, turning clockwise.
• The recommended tightening torque is
35-40 ft. Ibs.
IMPORTANT: Blade bolt is grade 8 heat
treated.
TO SHARPEN BLADE
NOTE: We do not recommend sharpen-
ing blade - but if you do, be sure the
blade is balanced.
Care should be taken to keep the blade
balanced. An unbalanced blade will
cause eventual damage to lawn mower
or engine.
•The blade can be sharpened with a file
or on a grinding wheel. Do not attempt
to sharpen while on the mower.
•To check blade balance, drive a nail
into a beam or wall. Leave about one
inch of the straight nail exposed. Place
center hole of blade over the head of
the nail. If blade is balanced, it should
remain in a horizontal position. If either
end of the blade moves downward,
sharpen the heavy end until the blade
is balanced.
Crankshaft
Blade
11
Blade shaft
bolt washer Trailing edge Blade adapter

GRASS CATCHER
•The grass catcher may be hosed with
water, but must be dry when used.
• Check your grass catcher often for
damage or deterioration. Through
normal use it will wear. If catcher needs
replacing, replace only with a manufac-
turer approved replacement catcher.
Give the lawn mower model number
when ordering.
DRIVE WHEELS
Check front drive wheels each time
before you mow to be sure they move
freely.
The whee[s not turning freely means
trash, grass cuttings, etc. are in the drive
wheel area and must be cleaned to free
drive wheels.
If necessary to clean the drive wheels, be
sure to clean both front wheels.
1. Remove hubcaps, hairpin cotters and
washers.
2. Remove wheels from wheel adjusters.
3. Remove any trash or grass cuttings
from inside the dust cover, pinion and/
or drive wheel gear teeth.
4. Put wheels back in place.
NOTE: If after cleaning, the drive wheels
do not turn freely, contact a Sears or other
qualified service center.
GEAR CASE
•To keep your drive system working
properly, the gear case and area
around the drive should be kept clean
and free of trash build-up. Clean under
the drive cover twice a season.
• The gear case is filled with lubricant to
the proper level at the factory. The only
time the lubricant needs attention is if
service has been performed on the
gear case.
•If lubricant is required, use only Texaco
Starplex Premium 1 Grease, Part No.
750369. Do not substitute.
SAE VISCOSITY GRADES
0 3O 8O
-20 .10 0 t0 20 40
TEMPERATURE RANGE ANTICIPATED BEFORE NEXT OIL CHANGE
NOTE: Although multi-viscosity oils
(5W30, 10W30 etc.) improve starting in
cold weather, these multi-viscosity oils
will result in increased oil consumption
when used above 32°R Check your
engine oil level more frequently to avoid
possible engine damage from running
low on oil.
Change the oil after every 25 hours of
operation or at least once a year if the
lawn mower is not used for 25 hours in
one year.
Check the crankcase oil level before
starting the engine and after each five (5)
hours of continuous use. Tighten oil plug
securely each time you check the oil
level.
TO CHANGE ENGINE OIL
NOTE: Before tipping lawn mower to
drain oil, drain fuel tank by running
engine until fuel tank is empty,
1. Disconnect spark plug wire from spark
plug and place wire where it cannot
come in contact with spark plug.
2. Remove engine oil cap; lay aside on a
clean surface.
3. Tip lawn mower on its side as shown
and drain oil into a suitable container.
Rock lawn mower back and forth to
remove any oil trapped inside of
engine.
4. Wipe off any spilled oil from lawn
mower or side of engine.
5, Fill engine with oil. (See "ADD OIL" in
the Operation section of this manual).
6. Reconnect spark plug wire to spark
plug.
ENGINE
LUBRICATION
Use only high quality detergent oil rated
with API service classification SF-SJ.
Select the oil's SAE viscosity grade
according to your expected operating
temperature.
Container
12

AIR FILTER
Your engine will not run properly using a
dirty air filter. Clean the foam pre-cleaner
after every 25 hours of operation or every
season. Replace paper cartridge every
100 hours of operation or every season,
whichever occurs first. Service air
cleaner more often under dusty condi-
tions.
1. Loosen screws and remove cover.
2. Carefully remove cartridge.
3. Clean by gently tapping on a flat
surface. If very dirty, replace cartridge.
_LCAUTION: Petroleum solvents, such
as kerosene, are not to be used to clean
cartridge. They may cause deterioration of
the cartridge. Do not oil cartridge. Do not
use pressurized air to clean or dry
cartridge.
4. Install cartridge, then replace cover.
ge
Base
MUFFLER
Inspect and replace corroded muffler as it
could create a fire hazard and/or dam-
age.
SPARK PLUG
Replace spark plugs at the beginning of
each mowing season or after every 100
hours of operation, whichever occurs first.
Spark plug type and gap setting are
shown in "PRODUCT SPECIFICATIONS"
in Maintenance section of this manual.
CLEANING
IMPORTANT: For best performance,
keep mower housing free of built-up
grass and trash. Clean the underside of
your mower after each use.
_,CAUTION: Disconnect spark plug wire
from spark plug and place wire where it
cannot come in contact with the spark
plug.
•Clean the underside of your lawn
mower by scraping to remove build-up
of grass and trash.
• Clean engine often to keep trash from
accumulating. A clogged engine runs
hotter and shortens engine life.
• Keep finished surfaces and wheels free
of all gasoline, oil, etc.
• We do not recommend using a garden
hose to clean lawn mower unless the
electrical system, muffler, air filter and
carburetor are covered to keep water
out. Water in engine can result in
shortened engine life.
CLEAN UNDER DRIVE COVER
Clean under drive cover at least twice a
season. Scrape underside of cover with
putty knife or similar tool to remove any
build-up of trash or grass on underside of
drive cover.
_I=WARNING: To avoid serious injury,
before performing any service or adjust-
ments:
1. Release control bar and stop engine.
2. Make sure the blade and all moving
parts have completely stopped.
3. Disconnect spark plug wire from spark
plug and place where it cannot come
in contact with plug.
LAWN MOWER
TO ADJUST CUTTING HEIGHT
See "TO ADJUST CUTTING HEIGHT" in
the Operation section of this manual.
REAR DEFLECTOR
The rear deflector, attached between the
rear wheels of your mower, is provided to
minimize the possibility that objects will
be thrown out of the rear of the mower
into the operator's mowing position. If the
deflector becomes damaged, it should be
replaced.
13

TO REMOVE DRIVE BELT
1. Remove drive cover. Remove belt
from gearcase pulley by pushing
down on pulley and rolling belt off it.
2. Turn lawn mower on its side with air
filter and carburetor up.
3. Remove blade.
4. Remove debris shield.
5. Remove belt from engine pulley on
crankshaft.
TO REPLACE DRIVE BELT
1. Install new belt on engine pulley.
2. Reinstall debris shield and blade.
3. Return mower to upright position.
4. Install new belt on geamase pulley.
5. Reinstall drive cover.
NOTE; Always use factory approved belt
to assure fit and long life.
Drive
cover Belt .4
I
I
TO ADJUST HANDLE
The handle can be mounted in a high or
tow position. The mounting holes in the
bottom of lower handle are off center for
raising or lowering the handle.
1. Remove upper handle and all parts
attached to lower handle.
2. Remove hairpin cotters from lower
handle bracket mounting pin.
3. Squeeze lower handle in to remove it
from mounting pins.
4. Turn lower handle over to raise or
lower handle.
5. Squeeze lower handle in and position
holes onto mounting pins on handle
bracket.
6. Reassemble upper handle and all
parts removed from lower handle.
Hairpin
Mowing
Mounting-
pin LOW POSITION HIGH POSITIO
TO ASSEMBLE GRASS CATCHER
1. Put grass catcher frame into grass bag
with rigid part of bag on the bottom.
Make sure the frame handle is outside
of the bag top.
2. Slip vinyl bindings over frame.
NOTE: If vinyl bindings are too stiff, hold
them in warm water for a few minutes. If
bag gets wet, let it dry before using.
_CAUTION: Do not run your lawn
mower without clipping deflector or
approved grass catcher in place. Never
attempt to operate the lawn mower with
the rear door removed or propped open.
Catcher
frame
handle
FralT
openin
14

ENGINE
ENGINE SPEED
Your engine speed has been factory set.
Do not attempt to increase engine speed
or it may result in personal injury. If you
believe that the engine is running too fast
or too slow, take your lawn mower to a
Sears or other qualified service center for
repair and adjustment.
CARBURETOR
Your carburetor is not adjustable. If your
engine does not operate properly due to
suspected carburetor problems, take your
lawn mower to a Sears or other qualified
service center for repair and/or adjust-
ment.
IMPORTANT: Never tamper with the
engine governor, which is factory set for
proper engine speed. Overspeeding the
engine above the factory high speed
setting can be dangerous. If you think the
engine-governed high speed needs
adjusting, contact aSears or other
qualified service center, which has proper
equipment and experience to make any
necessary adjustments.
Immediately prepare your lawn mower for
storage at the end of the season or if the
unit will not be used for 30 days or more.
LAWN MOWER
When lawn mower is to be stored for a
period of time, clean it thoroughly, remove
all dirt, grease, leaves, etc. Store in a
clean, dry area.
1. Clean entire lawn mower (See
=CLEANING" in the Maintenance
section of this manual).
2. Lubricate as shown in the Mainte-
nance section of this manual.
3. Be sure that all nuts, bolts, screws,
and pins are securely fastened.
Inspect moving parts for damage,
breakage and wear. Replace if
necessary.
4. Touch up all rusted or chipped paint
surfaces; sand lightly before painting.
HANDLE
You can fold your lawn mower handle for
storage.
1. Squeeze the bottom ends of the lower
handle toward each other until the
lower handle clears the handle
bracket, then move handle forward.
2. Loosen upper handle mounting bolts
enough to allow upper handle to be
folded back.
IMPORTANT: When folding the handle
for storage or transportation, be sure to
fold the handle as shown or you may
damage the control cables.
• When setting up your handle from the
storage position, the lower handle will
automatically lock into the mowing
position.
SQUEEZE
TO FOLD
Operator
control bar
Upper
Lower
FOLD
3ACKWARD
Mowing
position
15

ENGINE
FUEL SYSTEM
IMPORTANT: It is important to prevent
gum deposits from forming in essential
fuel system parts such as carburetor, fuel
filter, fuel hose, or tank during storage.
Also, alcohol blended fuels (called
gasohol or using ethanol or methanol)
can attract moisture which leads to
separation and formation of acids during
storage. Acidic gas can damage the fuel
system of an engine while in storage.
1. Drain the fuel tank.
2. Start the engine and let it run until the
fuel lines and carburetor are empty.
•Never use engine or carburetor cleaner
products in the fuel tank or permanent
damage may occur.
•Use fresh fuel next season.
NOTE: Fuel stabilizer is an acceptable
alternative in minimizing the formation of
fuel gum deposits during storage. Add
stabilizer to gasoline in fuel tank or
storage container. Always follow the mix
ratio found on stabilizer container. Run
engine at least 10 minutes after adding
stabilizer to allow the stabilizer to reach
the carburetor. Do not drain the gas tank
and carburetor if using fuel stabilizer.
ENGINE OIL
Drain oil (with engine warm) and replace
with clean engine oil, (See "ENGINE" in
the Maintenance section of this manual).
CYLINDER
1. Remove spark plug.
2. Pour one ounce (29 ml) of oil through
spark plug hole into cylinder.
3. Pull starter handle slowly a few times
to distribute oil.
4. Replace with new spark plug.
OTHER
• Do not store gasoline from one season
to another.
• Replace your gasoline can if your can
starts to rust. Rust and/or dirt in your
gasoline will cause problems.
• If possible, store your unit indoors and
cover it to protect it from dust and dirt.
• Cover your unit with a suitable protec-
tive cover that does not retain moisture.
Do not use plastic. Plastic cannot
breathe, which allows condensation to
form and will cause your unit to rust.
IMPORTANT: Never cover mower while
engine and exhaust areas are still warm.
A CAUTION: Never store the lawn mower
with gasoline in the tank inside a building
where fumes may reach an open flame or
spark. Allow the engine to cool before
storing in any enclosure.
TROUBLESHOOTING -See appropriate section in manual unless directed
to a Sears Service Center.
PROBLEM CAUSE
Does not start 1. Dirty air filter.
2. Out of fuel.
3. Stale fuel.
4. Water in fuel,
5. Spark plug wire is
disconnected.
6. Bad spark plug,
7. Loose blade or broken
blade adapter.
8. Control bar in released
position.
9. Control bar defective.
10. Fuel valve lever (if so
equipped) in OFF position.
11 .Weak battery (if equipped).
12. Disconnected battery
connector (if equipped).
CORRECTION
1. Clean/replace air filter.
2. Fill fuel tank.
3. Drain tank and refill with
fresh, clean fuel.
4. Drain fuel tank and
carburetor and refill tank
with fresh gasoline.
5. Connect wire to plug.
61 Replace spark plug.
Tighten blade bolt or
replace blade adapter.
8. Depress control bar to
handle.
9. Replace control bar.
10.Turn fuel valve lever
to the ON position.
:11.Charge battery.
12.Connect battery to engine.
16

TROUBLESHOOTING -See appropriate section in manual unless directed
to a Sears Service Center,
PROBLEM CAUSE
Loss of power 1. Rear of lawn mower
Poor cut -
uneven
Excessive
vibration
Starter rope
hard to pull
CORRECTION
1. Set to "Higher Cut"
position.
.
3.
4.
5.
6.
1.
2.
3.
housing or cutting blade
dragging in heavy grass.
2. Cutting too much grass.
3. Dirty air filter.
4. Buildup of grass, leaves,
and trash under mower.
5. Too much oil in engine.
6. Walking speed too fast.
1. Worn, bent or loose blade.
2. Wheel heights uneven.
3. Buildup of grass, leaves
and trash under mower.
1. Worn, bent or loose blade.
2. Bent engine crankshaft.
1. Engine flywheel brake is on
when control bar is released.
2. Bent engine crankshaft.
3. Blade adapter broken.
4. Blade dragging in grass.
Cutting height too low.
Lift on blade worn off.
Catcher not venting air.
Grass is too high or wheel
height is too low.
2. Rear of lawn mower
housing or cutting blade
dragging in grass.
3. Grass catcher too full.
4. Handle height position not
rightfor you.
1. Belt wear.
2. Belt off of pulley.
3. Drive cable worn or broken.
4. Dirt in drive pinions.
Set to "Higher Cut"
position.
Clean/replace air filter.
Clean underside of mower
housing.
Check oil level.
Cut at slower walking speed.
Replace blade. 13ghten
blade bolt.
Set all wheels at same
height.
Clean underside of
mower housing.
1. Replace blade. "13ghten
blade bolt.
2. Contact a Sears or other
qualified service center.
1. Depress control bar to
upper handle before
pulling starter rope.
2. Contact a Sears or other
qualified service center.
3. Replace blade adapter.
4. Move lawn mower to cut
grass or to hard surface.
.
2.
13.
1.
2.
Grass catcher 1. Raise cutting height.
notfilling 2. Replace blade.
(If so equipped) 3. Clean grass catcher.
Hard to push 1. Raise cutting height.
.
4.
Loss of drive
or slowing of
drive speed
Raise rear of lawn mower
housing one (1) setting
higher.
Empty grass catcher.
Adjust handle height to suit.
1. Check/replace drive belt.
2. Check/reinstall drive belt.
3. Replace drive cable.
4. Clean drive pinions.
17

Garantfa ........................................................ 18
Reglas de Seguddad ............................... 18-20
Montaje /Pre-Operaci6n .............................. 21
Operaci6n ................................................ 22-25
Mantenimiento ......................................... 26-29
Programa de Mantenimiento ......................... 26
Especificaciones del Producto ..................... 27
Servicio y Adjustes ................................. 29-31
Almacenamiento ...................................... 31-32
Identificaci6n de problemas .................... 32-33
Servicio Sears ......................................... 35-43
Orden de Partes ............................ Contratapa
GARANT{A LIMITADA DE DOS AI_IOS PARA LA SEGADORA A MOTOR CRAFTSMAN
Por dos (2) afios, a partir de la fecha de compra, cuando esta Segadora Craftsman se
mantenga, lubrique y afine seg0n las instrucciones para la operaci6n y el mantenimiento en el
manual del duefio, Sears reparar& gratis todo defecto en el material y la mano de obra.
Si la Segadora Craftsman se usa para fines comerciales o de arriendo, esta garant|a s61ose
aplica per noventa (90) dias a partir de la fecha de compra.
Esta Garantfa no eubre:
•Artfculos que se desgastan durante el uso normal tales como las cuchillas segadoras
rotatorias, los adaptadores de la cuchilla, las correas, los filtros de aire y las bujfas.
• Reparaciones necesarias debido al abuso o ala negligencia del operador, incluyendose a los
cigL_efialesdoblados y ala falta de mantenimiento del equipo seglJn las instrucciones que se
incluyen en el manual del duefio.
EL SERVlClO DE GARANT[A ESTA DISPONIBLE al devolver la segadora a motor Craftsman al
centro/departmento de servicio Sears mas cercano en los Estadoe Unidos. Esta garantfa se
aplica solamente mientras el producto este en uso en los Estados Unidos.
Esta Garantfa le otorga derechos legales especfficos, y puede que tambi_n tenga otros
derechos que varian de estado a estado.
SEARS, ROEBUCK AND CO., D/817WA, HOFFMAN ESTATES, IL 60179 USA
IMPORTANTE: Esta maquina cortadaora es capaz de amputar las manos y los manos y los
pies y de lanzar objetos. Si no so observan las instruccionesde seguddad siguientesso pueden
producirlesiones graves o la muerte.
_kBusque este simbolo que sefiala las
precauciones de seguridad de importancia.
Quiere decir - IIIATENCl6NI!!IIIESTE
ALERTO!!! SU SEGURIDAD ESTA
COMPROMETIDA.
_IL.DVERTENClA: Siempre desconocte el
alambre de la bujfay p6ngalo donde no pueda
entrar en contacto con la bujfa, para evitar el
arranque por accidente, durante la
preparaci6n, el transporte, el ajuste o cuando
se haGen reparaciones.
_.DVERTENClA: Los bornes, terminales y
accesorios relativos de la baterfa contienen
plomo o compuestos de plomo, productos
quimicos conocidos en el Estado de California
como causa de crinGery defectos al
nacimiento u otros dafios reproductivos. Laver
las manoa despuds de manlpularlos.
,APRECAUCI(_N: El lubo de escape del
motor, algunos de sus constituyentesy
algunos componentes del vehfculo contienen
o desprenden productos quimicos conocidos
en el Estado de California como causa de
crinGery defectos al nacimiento u otros dafios
reproductivos.
APRECAUCI6N: El silenciadory otras
piezas del motor Uegan a sre extremadamente
calientes durante la operaci6n y siguen siendo
calientes daspu6s de quo el motor haya
parado. Pare evitar quemaduras severas,
permanezca lejos de astas dreas.
18

I. OPERACION
•Antes de empezar, debe familiafizarse
completamente con los controles y el uso
correcto de la maquina. Para esto, debe leer
y comprender todas las instrucciones que
aparecen en la maquina yen los manuales
de operaci6n.
•No ponga las manos o los pies cerca o
debajo de las partes rotatorias. Mantengase
siempre lejos de la abertura de la descarga.
•Permita que solamente las personas
responsables que est_n famUiarizadas con
las instruccionesoperen la m_quina.
•Despeje el _rea de objetos tales como
piedras, juguetes, alambres, huesos, palos,
etc. que pueden ser recogidos y lanzados
por las cuchillas.
• AsegOrese que el _rea no se hallen
personas, antes de segar. Pare la m&quina
si alguien entra en el drea.
•No opera la maquina sin zapatos o con
sandalias abiertas. P6ngase siempre
zapatos s61idos.
•No tire de la segadom hacia atr&s a menos
que sea absolutamente necesario. Mire
siempre hacia abajo y hacia detr&s antes y
mientras que se mueve hacia atr&s.
•No opere la segadora sin los respectivos
resguardos, las placas, el recogedor de
cdsped u otros aditamentos dise ados pare
su protecci6n y seguridad.
•Refi_rase alas instruccionesdel fabdcante
para el funcionamiento e instalaci6n de
accesorios. Use t_nicamente accesorios
aprobados per el fabricante.
•Detenga la cuchilla o las cuchillas cuando
cruce por calzadas, calles o caminos de
grava.
•Parar el motor cada vez que se abandona el
aparato, antes de limpiar la segadora o de
remover residuosdel tubo.
•Apagar el motor yesperar hasta que las
cuchillas est_n completamente paradas
antes de remover el receptor de hierba.
•Segar solamente con luz del dfa o con una
buena luz artificial.
•No opere la mdquina bajo la influencia del
alcohol o de las drogas.
•Nunca opere la maquina cuando la hierba
estd mojada. Asegt_resesiempre de tener
buena tracci6n en sus pies; mantenga el
mango firmemente y camine; nunca corm.
• Desconectar el mecanismo de propulsi6n
aut6noma o el embrague de transmisi6n en
las segadoras que Io tienen antes de poner
en marcha el motor.
•Si el equipo empezara a vibrar de una
manera anormal, pare el motor y revise de
inmediato para averiguar la causa.
Generalmente la vibraci6n suele indicar que
existe alguna averia.
•Siempre use gafas de seguridad o anteojos
con protecci6n lateral cuando opere la
segadora.
II. OPERACION SOBRE LAS CUESTAS
Los accidentes ocurren con mds frecuencia
en las cuestas. Estos accidentes ocurren
debido a resbaladas o caidas, las cuales
pueden resultar en graves lesiones. Operar la
recortadora en cuestas requiere mayor
concentraci6n. Si se siente inseguro en una
cuesta, no la recorte,
HACER:
•Puede recortar a tray, s de la superficie de
la cuesta, nunca hacia arriba y hacia abajo.
Proceda con extrema precauci6n cuando
cambie de direcei6n en las cuestas.
•Renueva todos los objetos extrafios, tales
como guijarros, ramas, etc.
•Debe prestar atenci6n ahoyos, baches o
protuberancias. Recuerde que la hierba alta
puede esconder obstdculos.
NO HACER:
•No recorte cerca de pendientes, zanjas o
terraplenes. El operador puede perder la
tracci6n en los pies o el equilibrio.
•No recorte cuestas demasiado inclinadas.
•No recorte en hierba mojada. La reducci6n
en la tracci6n de la pisada puede causar
resbalones.
II1.NII_IOS
Se pueden preducir accidentes trdgicos si el
operador no presta atenci6n a la presencia de
los nifios. A menudo, los nifios se sienten
atrafdos pot la mdquina y por la actividad de la
siega. Nunca suponga que los nifios van a
permanecer en el mismo lugar donde los vio
pot t_ltimavez.
•Mantenga a los nifios alejados del drea de la
siega y bajo el cuidado estricto de otra
persona adulta responsable.
•Estd alerta y apague la mdquina si hay
nifios que entran al drea.
•Antes y cuando este retrocediendo, mire
hacia atrds y hacia abajo para verificar si
hay nifios pequefios.
•Nunca permita que los nifios operen la
mdquina.
•Tenga un cuidado extra cuando se acerque
a esquinas donde no hay visibilidad,alos
arbustos, drboles u otros objetos que
pueden interferir con su Ifnea de visi6n.
IV. SERVICIO
•Tenga cuidado extra al manejar la gasolina
y los demds combustibles. Son inflamables
ylos gases son explosivos.
- Use solamente un envase aprebado.
- Nunca remueva la tapa del dep6sito de
gasolina o agregue combustible con el
motor funcionando. Permita que el motor
se enffie antes de volver a pone
combustible. No fume.
- Nunca vuelva a poner combustible en la
mdquina en recintos cerrados.
- Nunca almacene la mdquina o el envase
del combustible dentro de algdn lugar en
donde haya una llama expuesta, tal como
la del calentador de agua.
19

•Nunca haga funcionar una m_quina dentro
de un drea cerrada.
•Nunca haga ajustes o reparaciones
mientras el motor est_ en marcha.
Desconecte el cable de la bujfa, y
mant6ngalo a cierta distancia de _sta para
prevenir un arranque accidental.
• Mantenga las tuercas y los pemos,
especialmente los pernos del accesorio de
la cuchilla, apretados y mantenga el equipo
en buenas condiciones.
• Nunca manipule de forma indebida los
dispositivos de seguridad. Controle
regularmente su funcionamiento correcto.
• Mantenga la m&quina libre de hierba, hojas
u otras acumulaciones de desperdicio.
Limpie los derrames de aceite o combus-
tible. Permita que la m_.quina se enfr/e antes
de almacenada.
•Pare e inspeccione el equipo si le pega a un
objeto. Repdrelo, si es necesario, antes de
hacerlo arrancar.
• En ningl3n caso hay que regular la altura de
las ruedas mientras el motor esta en
marcha.
• Los componentes del receptor de la hierba
van sujetos a desgaste, daSos y deterioro,
que pueden exponer las pades en
movimiento o permitir que objetos sean
disparados. Controlar frecuentemente y
cuando sea necesado sustituir con partes
aconsejadas por el fabricante.
• Las cuchillas de la segadora est&n afiladas
y pueden cortar. Cubdr las hojas o llevar
guantes, y utilizar precauciones especiales
cuando se efecttia mantenimiento sobre ]as
mismas.
• No cambie el ajuste del regulador del motor
ni exceda su velocidad.
Estos accesoriosestaban disponibles cuande se produjo la segadora.No son facilitados junto al
cortacesped. Estdndispooiblesen la mayodade lastiendasde Sears yen loscentrosde servicio.La
mayorfade las_endas Searstambidnpueden mander a pedir partesde repuestoparausted,siles
proporcionael nt_rnerodel modelode susegadora.Algunosde estosaccesoriostalvez no se apliquena
su segadera.
RENDIMIENTO DE LA SEGADORA
DESVIADOR DE RECORTES
PARA SEGADORAS CON DESCARGA TRASERA
RECOREDOR
PAPA
SEGAOORAS
CON DI=SCARGA
TPASEPA
JUEGOS PARA LA ACOLCHADORA
RECOREDOR
PARA
SEGADOPAS
CON OESCARGA
LATERAL
MANTENIMIENTO DE LA SEGADORA
SILENCIADORES
CORREAS CUCHILLAS
FILTROS DE AIRE
ADAPTADORES
DE CUCHILLA RUEDAS
ESTABILIZADORE_S
ENVASES
DE GASOLINA
BUJ|AS
ACEITE
DEL MOTOR
2O
