Owner's Manual
JCRIIFTSMIIW _OWE R
ROTARY LAWN
4.25 Horsepower
22" Side Discharge
Model No.
917.387611
CAUTION:
Read and follow all
Safety Rules and Instructions
before operating this equipment
Sears, Roebuck and Co., Hoffman Estates, IL 60179 U.S.A.
Visit our Craftsman website: www.sears.com/craftsman

Warranty ................................................. 2
Safety Rules ........................................ 2-4
Assembly /Pre-Operation ...................... 5
Operation ............................................. 6-9
Maintenance Schedule ........................ 10
Maintenance .................................... 10-13
Product Specifications .......................... 11
Service and Adjustments ...................... 14
Storage ............................................ 15-16
Troubleshooting .............................. 16-17
Repair Parts ..................................... 34-39
Sears Service ......................... Back Cover
LIMITED TWO YEAR WARRANTY ON CRAFTSMAN POWER MOWER
For two years from date of purchase, when this Craftsman Lawn Mower is maintained,
lubricated, and tuned up according to the operating and maintenance instructions in
the owner's manual, Sears will repair free of charge any defect in material or workman-
ship.
If this Craftsman Lawn Mower is used for commercial or rental purposes, this warranty
applies for only 90 days from the date of purchase.
This Warranty does not cover:
•Expendable items which become worn during normal use, such as rotary mower
blades, blade adapters, belts, air cleaners and spark plug.
•Repairs necessary because of operator abuse or negligence, including bent
crankshafts and the failure to maintain the equipment according to the instructions
contained in the owner's manual.
Warranty service is available by returning the Craftsman power mower to the nearest
Sears Service Center/Department in the United States. This warranty applies only
while this product is used in the United States.
This Warranty gives you specific legal rights, and you may also have other rights which
vary from state to state.
SEARS, ROEBUCKAND CO., D/817 WA, HOFFMAN ESTATES, ILLINOIS 60179
IMPORTANT: This cutting machine is capable of amputating hands and feet and
throwing objects. Failure to observe the following safety instructions could result in
serious injury or death.
ALook for this symbol to point out
important safety precautions. It means
CAUTIONH! BECOMEALERT!!! YOUR
SAFETY IS INVOLVED.
AWARNING: In order to prevent
accidental starting when setting up,
transporting, adjusting or making repairs,
always disconnect spark plug wire and
place wire where it cannot contact spark
plug.
_kWARNING- Engine exhaust, some of
its constituents, and certain vehicle
components contain or emit chemicals
known to the State of California to cause
cancer and birth defects or other repro-
ductive harm.
AWARNING: Battery posts, terminals and
related accessories contain lead and
lead compounds, chemicals known to the
State of California to cause cancer and
birth defects or other reproductive harm.
Wash hands after handling.
_1,CAUTION: Muffler and other engine
2
parts become extremely hot during
operation and remain hot after engine
has stopped. To avoid severe burns on
contact, stay away from these areas.

I. GENERAL OPERATION
•Read, understand, and follow all
instructions on the machine and in the
manual(s) before starting. Be thor-
oughly familiar with the controls and
the proper use of the machine before
starting.
• Do not put hands or feet near or under
rotating parts. Keep clear of the
discharge opening at all times.
• Only allow responsible individuals,
who are familiar with the instructions, to
operate the machine.
• Clear the area of objects such as
rocks, toys, wire, bones, sticks, etc.,
which could be picked up and thrown
by the blade.
• Be sure the area is clear of other
people before mowing. Stop machine if
anyone enters the area.
• Do not operate the mower when
barefoot or wearing open sandals.
Always wear substantial foot wear.
• Do not pull mower backwards unless
absolutely necessary. Always look
down and behind before and while
moving backwards.
•Do not operate the mower without
proper guards, plates, grass catcher or
other safety protective devices in place.
• See manufacturer's instructions for
proper operation and installation of
accessories. Only use accessories
approved by the manufacturer.
•Stop the blade(s) when crossing gravel
drives, walks, or roads.
•Stop the engine (motor) whenever you
leave the equipment, before cleaning
the mower or unclogging the chute.
•Shut the engine (motor) off and wait
until the blade comes to complete stop
before removing grass catcher.
•Mow only in daylight or good artificial
light.
•Do not operate the machine while
under the influence of alcohol or drugs.
•Never operate machine in wet grass.
Always be sure of your footing: keep a
firm hold on the handle and walk; never
run,
•Disengage the self-propelled mecha-
nism or drive clutch on mowers so
equipped before starting the engine
(motor).
•If the equipment should start to vibrate
abnormally, stop the engine (motor)
and check immediately for the cause.
Vibration is generally a warning of
trouble.
• Always wear safety goggles or safety
glasses with side shields when operat-
ing mower.
II. SLOPE OPERATION
Slopes are a major factor related to slip
and fall accidents which can result in
severe injury. All slopes require extra
caution. If you feel uneasy on a slope, do
not mow it.
DO:
•Mow across the face of slopes: never
up and down. Exercise extreme caution
when changing direction on slopes.
• Remove obstacles such as rocks, tree
limbs, etc.
• Watch for holes, ruts, or bumps. Tall
grass can hide obstacles.
DO NOT:
•Do not trim near drop-offs, ditches or
embankments. The operator could lose
footing or balance.
• Do not trim excessively steep slopes.
• Do not mow on wet grass. Reduced
footing could cause slipping.
IlL CHILDREN
Tragic accidents can occur if the operator
is not alert to the presence of children.
Children are often attracted to the
machine and the mowing activity. Never
assume that children will remain where
you last saw them.
• Keep children out of the trimming area
and under the watchful care of another
responsible adult.
• Be alert and turn machine off if children
enter the area.
• Before and while walking backwards,
look behind and down for small
children.
• Never allow children to operate the
machine.
• Use extra care when approaching blind
corners, shrubs, trees, or other objects
that may obscure vision.
3

IV. SERVICE
•Use extra care in handling gasoline
and other fuels. They are flammable
and vapors are explosive.
-Use only an approved container.
- Never remove gas cap or add fuel
with the engine running. Allow
engine to cool before refueling. Do
not smoke.
-Never refuel the machine indoors.
- Never store the machine or fuel
container inside where there is an
open flame, such as a water heater.
• Never run a machine inside a closed
area.
• Never make adjustments or repairs
with the engine (motor) running.
Disconnect the spark plug wire, and
keep the wire away from the plug to
prevent accidental starting.
• Keep nuts and bolts, especially blade
attachment bolts, tight and keep
equipment in good condition.
•Never tamper with safety devices.
Check their proper operation regularly.
•Keep machine free of grass, leaves, or
other debris build-up. Clean oil or fuel
spillage. Allow machine to cool before
storing.
•Stop and inspect the equipment if you
strike an object. Repair, if necessary,
before restarting.
• Never attempt to make wheel height
adjustments while the engine (motor) is
running.
• Grass catcher components are subject
to wear, damage, and deterioration,
which could expose moving parts or
allow objects to be thrown. Frequently
check components and replace with
manufacturer's recommended parts,
when necessary.
• Mower blades are sharp and can cut.
Wrap the blade(s) or wear gloves, and
use extra caution when servicing them.
• Do not change the engine governor
setting or overspeed the engine.
These accessories were available when this lawn mower was produced. They are not
shipped with your mower. They are also available at most Sears retail outletsand service
centers. Most Sears stores can also order repair parts for you, when you provide the model
number of your lawn mower. Some of these accessories may not apply to your lawn mower.
LAWN MOWER PERFORMANCE
CLIPPING DEFLECTOR
FOR REAR DISCHARGE LAWN MOWERS
GRASS CATCHERS
FOR
REAR DISCHARGE
LAWN MOWERS
MULCHER KITS
GRASS CATCHERS
FOR
SIDE DISCHARGE
LAWN MOWERS
STABILIZER
GAS CANS
LAWN MOWER MAINTENANCE
MUFFLERS AIR FILTERS SPARK PLUGS
BELTS BLADES BLADE ADAPTERS WHEELS ENGINE OIL
4

Readtheseinstructionsandthis manual
in itsentirety before you attempt to
assemble or operate your new lawn
mower.
IMPORTANT: This lawn mower is shipped
WITHOUT OIL OR GASOLINE in the
engine.
Your new lawn mower has been as-
sembled at the factory with the exception
of those parts left unassembled for
shipping purposes. To ensure safe and
proper operation of your lawn mower, all
parts and hardware you assemble must
be tightened securely. Use the correct
tools as necessary to ensure proper
tightness. All parts such as nuts, wash-
ers, bolts, etc., necessary to complete the
assembly have been placed in the parts
bag.
TO REMOVE LAWN MOWER FROM
CARTON
1. Remove loose parts included with
mower.
2. Cut down two end comers of carton
and lay end panel down flat.
3. Remove all packing materials except
padding between upper and lower
handle and padding holding operator
presence control bar to upper handle.
4. Roll lawn mower out of carton and
check carton thoroughly for additional
loose parts.
HOW TO SET UP YOUR LAWN
MOWER
TO UNFOLD HANDLE
IMPORTANT: Unfold handle carefully so
as not to pinch or damage control cables.
1. Raise handles until lower handle
section locks into place in mowing
position.
2. Remove protective padding, raise
upper handle section into place on
lower handle and tighten both handle
knobs.
3. Remove handle padding holding
operator presence control bar to upper
handle.
Your lawn mower handle can be adjusted
for your mowing comfort. Refer to
"ADJUST HANDLE" in the Service and
Adjustments section of this manual.
Operator I
control bar
LIFT
UF
Mowing
position
Lower handle
TO INSTALL ATTACHMENTS
Your lawn mower was shipped ready to
be used as a mulcher. To convert mower
to bagging or discharging, see 'q-O
CONVERT MOWER" in the Operation
section of this manual.
5

KNOWYOUR LAWN MOWER
READ THIS OWNER'S MANUALAND ALL SAFETY RULES BEFORE OPERATING YOUR
LAWN MOWER. Compare the illustrations with your lawn mower to familiarize yourself with
the location of various controls and adjustments. Save this manual for future reference.
These symbols may appear on your lawn mower or in literature supplied with the
product, Learn and understand their meaning,
CAUTION ENGINE ENGINE FAST SLOW CHOKE FUEL OIL DANGER, KEEP HANDS
OR WARNING ON OFF AND FEET AWAY
presence control bar
Starter handle
Handle knob
cap
Air filter
Engine oil cap with
Primer
Muffler
Discharge
IMPORTANT: This lawn mower is shipped
WITHOUT OIL OR GASOLINE in the engine.
Wheel adjuster (on each wheel)
MEETS CPSC SAFETY REQUIREMENTS
Sears rotary walk-behind power lawn mowers conform to the safety standards of the
American National Standards Institute and the U,S. Consumer Product Safety Commis-
sion. The blade turns when the engine is running.
Operator presence control bar - must be
held down to the handle to start the engine,
Release to stop the engine.
Starter handle - used for starting the engine. 6
Primer - pumps additional fuel from the
carburetor to the cylinder for use when
starting a cold engine.

Theoperationof any lawn
mower can result in foreign
objects thrown into the
eyes, which can result in
severe eye damage.
Always wear safety glasses or eye
shields while operating your lawn mower
or performing any adjustments or repairs.
We recommend a standard safety
glasses or wide vision safety mask worn
over spectacles.
HOWTO USE YOUR LAWN MOWER
ENGINE SPEED
The engine speed was set at the factory
for optimum performance. Speed is not
adjustable.
ENGINE ZONE CONTROL
ACAUTION: Federal regulations require
an engine control to be installed on this
lawn mower in order to minimize the risk
of blade contact injury. Do not under any
circumstances attempt to defeat the
function of the operator control. The blade
turns when the engine is running.
•Your lawn mower is equipped with an
operator presence control bar which
requires the operator to be positioned
behind the lawn mower handle to start
and operate the lawn mower.
TO ADJUST CuI-rlNG HEIGHT
Raise wheels for low cut and lower
wheels for high cut, adjust cutting height
to suit your requirements. Medium
position is best for most lawns.
•To change cutting height, squeeze
adjuster lever toward wheel. Move
wheel up or down to suit your require-
ments. Be sure all wheels are in the
same setting.
NOTE: Adjuster is properly positioned
when plate tab inserts into hole in lever.
Also, 9-position adjusters (if so equipped)
allow lever to be positioned between the
plate tabs.
LOWER WHEELS FOR HIGH CUT
Plate
tab
TO CONVERT TO DISCHARGING
MOWER
Your mower is shipped ready to be used
as a mulcher. To convert to bagging or
discharging:
• Lift discharge guard and remove
mulcher plate.
•Mower can now be used for side
discharge or optional grass catcher can
be attached.
• To return to mulching operation, simply
reinstall mulcher plate as shown.
_I,CAUTION: Do not run your lawn
mower without discharge guard, ap-
proved grass catcher or mulcher plate in
place.
Discharge
Housing
opening
Mulch
Hinge rod
RAISE WHEELS FOR LOW CUT
7

BEFORE STARTING ENGINE
ADD OIL
Your lawnmower is shipped without oil in
the engine. For type and grade of oil to
use, see "ENGINE" in the Maintenance
section of this manual.
A CAUTION: DO NOT overfill engine with
oil, or it will smoke on startup.
1. Be sure lawnmower is level and area
around oil fill is clean.
2. Remove oil dipstick from oil fill spout.
Make sure that rim of spout is clean.
3. You receive a container of oil with the
unit. Slowly pour 3/4 (15 oz.) of the oil
from the container down the oil fill
spout into the engine.
4. Wait one minute to allow oil to settle.
Insert and tighten dipstick, then
remove it to check oil level.
5. Continue adding small amounts of oil
and rechecking the dipstick until it
reads full. DO NOT overfill, or engine
will smoke on startup.
6. Always be sure to retighten oil dipstick
before starting engine.
•Check oil level before each use. Add
oil if needed. Fill to full line on dipstick.
• Change the oil after every 25 hours of
operation or each season. You may
need to change the oil more often
under dusty, dirty conditions.
ADD GASOLINE
• Fill fuel tank to bottom of tank filler
neck. Do not overfill. Use fresh, clean,
regular unleaded gasoline with a
minimum of 87 octane. Do not mix oil
with gasoline. Purchase fuel in
quantities that can be used within 30
_i days to assure fuel freshness.
CAUTION: Wipe off any spilled oil or
fuel. Do not store, spill or use gasoline
near an open flame.
A CAUTION: Alcohol blended fuels
(called gasohol or using ethanol or
methanol) can attract moisture which
leads to separation and formation of
acids during storage. Acidic gas can
damage the fuel system of an engine
while in storage. To avoid engine
problems, the fuel system should be
emptied before storage of 30 days or
longer. Drain the gas tank, start the
engine and let it run until the fuel lines
and carburetor are empty. Use fresh fuel
next season. See Storage Instructions for
additional information. Never use engine
or carburetor cleaner products in the fuel
tank or permanent damage may occur.
Gasoline
fillercap
Engine
oil cap
TO START ENGINE
NOTE: Due to protective coatings on the
engine, a small amount of smoke may be
present during the initial use of the
product and should be considered
normal.
1. To start a cold engine, push primer
three (3) times before trying to start.
Use a firm push. This step is not
usually necessary when starting an
engine which has already run for a
few minutes.
2. Hold operator presence control bar
down to the handle and pull starter
handle quickly. Do not allow starter
rope to snap back.
TO STOP ENGINE
•To stop engine, release operator
presence control bar.
NOTE: In cooler weather it may be
necessary to repeat priming steps. In
warmer weather over priming may cause
flooding and engine will not start. If you
do flood engine, wait a few minutes
before attempting to start and do not
repeat priming steps.

MOWING TIPS
• Under certain conditions, such as very
tall grass, it may be necessary to raise
the height of cut to reduce pushing
effort and to keep from overloading the
engine and leaving clumps of grass
clippings. It may also be necessary to
reduce ground speed and/or run the
lawn mower over the area asecond
time.
•For extremely heavy cutting, reduce the
width of cut by overlapping previously
cut path and mow slowly.
•For better grass bagging and most
cutting conditions, the engine speed
should be set in the FAST position.
•For side discharge lawn mowers,
cutting in a counter-clockwise direction,
starting at the outside of the area to be
cut, spreads grass clippings more
evenly and puts less load on the
engine. To keep clippings off of
walkways, flower beds, etc., make the
first cuts in a clockwise direction.
•Pores in cloth grass catchers can
become filled with dirt and dust with
use and catchers will collect less grass.
To prevent this, regularly hose catcher
off with water and let dry before using.
•Keep top of engine around starter clear
and clean of grass clippings and chaff.
This will help engine air flow and
extend engine life.
MULCHING MOWING TIPS
IMPORTANT: For best performance, keep
mower housing free of built-up grass and
trash. See "CLEANING" in the Maintenance
section of this manual.
•The special mulching blade will recut the
grass clippings many times and reduce
them in size so that as they fall onto the
lawn they will disperse intothe grass and
not be noticed. Also, the mulched grass
will biodegrade quickly to provide nutrients
for the lawn. Always mulch with your
highest engine (blade) speed as this will
provide the best recutting action of the
blades.
• Avoid cutting your lawn when it is wet. Wet
grass tends to form clumps and interferes
with the mulching action. The best time to
mow your lawn is the early aftemoon. At
this time the grass has dried and the newly
cut area will not be exposed to the direct
sun.
• For best results, adjust the lawn mower
cutting height so that the lawn mower cuts
off onlythe top one-third of the grass
blades. If the lawn is overgrown it will be
necessary to raise the height of cut to
reduce pushing effort and to keep from
overloading the engine and leaving
clumps of mulched grass. For extremely
heavy grass, reduce your width of cut by
overlapping previously cut path and mow
slowly.
MAX 1/3
• Certain types of grass and grass condi-
tions may require that an area be mulched
a second time to completely hide the
clippings. When doing a second cut, mow
across or perpendicular to the firstcut path.
• Change your cutting pattern from week to
week. Mow north to south one week then
change to east to west the next week. This
will help prevent matting and graining of
the lawn.
9

,,..T..,.o.
FILL IN DATES
AS YOU COMPLETE /__d_ #f" SERVICE
REGULARSE.V,CE _I"_'_6_'_/_,_ _" DATES
Check for LooseFasteners !// li/
Clean/Inspect Grass Catcher
(If Equipped)
M Clean LawnMower
O Clean Under Drive CoverPower-PropelledMowers)
Check drivebelVpulleys
_Power-Propelled Mowers)
Check/Sharpen/Replace Blade
LubricationChart
Clean Battery/Recharge
ElectdcStart MowersI
ECheck EngineOil Level
NChange Engine Oil
GClean Air Filter
Inspect Muffler
N Clean or Replace Spark Plug
EReplace Air FitterPaper Cartridge
t/
1,/1_
V'=
V'2
1- Change more often when operating under a heavy load or in high ambient temperatures.
2 - Sen/ice more often when operating in dirty ordusty conditions.
3-Replace blades more often when mowing in sandy soil.
4" Charge 48 hours at end of season. LUBRICATION CHART
(_) Wheel adjuster
GENERAL RECOMMENDATIONS each wheel)
The warranty on this lawn mower does not
cover items that have been subjected to
operator abuse or negligence. To receive full
value from the warranty, operator must
maintain mower as instructed in this manual.
Some adjustments will need to be made
periodically to properly maintain your unit.
All adjustments in the Service and Adjust-
ments section of this manual should be
checked at least once each season.
•Once a year, replace the spark plug, clean
or replace air filter element and check
blade for wear. A new spark plug and
clean/new air filter element assure proper
air-fuel mixture and help your engine run
better and last longer.
• Follow the maintenance schedule in this
manual.
(_s(_) (D Brake
pring bracket
Discharge
guard hinge pin
_(_) Engine oil
(_) Handle bracket mounting pins
BEFORE EACH USE
•Check engine oil level.
• Check for loose fasteners.
LUBRICATION
Keep unitwell lubricated (See "LUBRICATION
CHART").
10
(_) Spray lubricant
(_) See "ENGINE" in Maintenance section.
IMPORTANT: Do not oil or grease
plastic wheel bearings. Viscous
lubricants will attract dust and dirt that
will shorten the life of the self-lubricat-
ing bearings. If you feel they must be
lubricated, use only a dry, powdered
graphite type lubricant sparingly.

PRODUCT SPECIFICATIONS
Serial Number:
Date of Purchase:
Gasoline Capacity /Type: 1.5 Quarts (Unleaded Regular)
Oil Type (API-SF-SJ): SAE 30 (above 32°1=); SAE 5W-30 (below 32°F)
Oil Capacity: 20 Ounces
Spark Plug (Gap: .030") Champion RJ19LM or J19LM
Blade Bolt Torque: 35-40 ft. Ibs.
The model and serial numbers will be found on adecal on the rear of the mower
housing. Record both serial number and date of purchase in space provided above.
LAWN MOWER
Always observe safety rules when perform-
ing any maintenance.
TIRES
•Keep tires free of gasoline, oil, or insect
control chemicals which can harm rubber.
•Avoid stumps, stones, deep ruts, sharp
objects and other hazards that may cause
tire damage.
BLADE CARE
For best results, mower blade must be
kept sharp. Replace bent or damaged
blades.
TO REMOVE BLADE
1. Disconnect spark plug wire from spark
plug and place wire where it cannot
come in contact with spark plug.
2. Turn lawn mower on its side. Make
sure air filter and carburetor are up.
3. Use a wood block between blade and
mower housing to prevent blade from
tuming when removing blade bolt.
NOTE: Protect your hands with gloves
and/or wrap blade with heavy cloth.
4. Remove blade bolt by turning counter-
clockwise.
5. Remove blade and attaching hard-
ware (bolt, lock washer and hardened
washer).
NOTE: Remove the blade adapter and
check the key inside hub of blade
adapter. The key must be in good condi-
tion to work properly. Replace adapter if
damaged.
(opposite sharp edge) is up toward
the engine.
4. Install the blade bolt with the lock
washer and hardened washer into
blade adapter and crankshaft.
5. Use block of wood between blade and
lawn mower housing and tighten the
blade bolt, turning clockwise.
• The recommended tightening torque is
35-40 ft. Ibs.
IMPORTANT: Blade bolt is grade 8 heat
treated.
TO SHARPEN BLADE
NOTE: We do not recommend sharpen-
ing blade - but if you do, be sure the
blade is balanced.
Care should be taken to keep the blade
balanced. An unbalanced blade will
cause eventual damage to lawn mower
or engine.
• The blade can be sharpened with a file
or on a grinding wheel. Do not attempt
to sharpen while on the mower.
• To check blade balance, drive a nail
into a beam or wall. Leave about one
inch of the straight nail exposed. Place
center hole of blade over the head of
the nail. If blade is balanced, it should
remain in a horizontal position. If either
end of the blade moves downward,
sharpen the heavy end until the blade
is balanced.
TO REPLACE BLADE Blade
1. Position the blade adapter on the
engine crankshaft. Be sure key in
adapter and crankshaft keyway are
aligned.
2. Position blade on the blade adapter
aligning the two (2) holes in the blade Blade
with the raised lugs on the adapter, bolt
3. Be sure the trailing edge of blade
Blade adapter Crankshaft
keyway
11
Crank
shaft
washer Trailingedge Blade adapter

GRASS CATCHER
(If purchased as an accessory)
•The grass catcher may be hosed with
water, but must be dry when used.
•Check your grass catcher often for
damage or deterioration. Through
normal use it will wear. If catcher
needs replacing, replace only with a
manufacturer approved replacement
catcher. Give the lawn mower model
number when ordering.
ENGINE
LUBRICATION
Use only high quality detergent oil rated
with API service classification SF-SJ.
Select the oil's SAE viscosity grade
according to your expected operating
temperature.
SAE VISCOSITY GRADES
-2O 0 3O
"30 -20 -10 0 tO 20 30 40
I1EMPIERATIJRE RANGE AN_CIPATED BEFORE NEXT OIL CHANGE
NOTE: Although multi-viscosity oils
(5W30, 10W30 etc.) improve starting in
cold weather, these multi-viscosity oils
will result in increased oil consumption
when used above 32°F. Check your
engine oil level more frequently to avoid
possible engine damage from running
low on oil.
Change the oil after every 25 hours of
operation orat least once a year if the
lawn mower is not used for 25 hours in
one year.
Check the crankcase oil level before
starting the engine and after each five (5)
hours of continuous use. Tighten oil plug
securely each time you check the oil
level.
TO CHANGE ENGINE OIL
NOTE: Before tipping lawn mower to
drain oil, drain fuel tank by running
engine until fuel tank is empty.
1. Disconnect spark plug wire from spark
plug and place wire where it cannot
come in contact with spark plug.
2. Remove engine oil cap; lay aside on
a clean surface.
3. Tip lawn mower on its side as shown
and drain oil into a suitable container.
Rock lawn mower back and forth to
remove any oil trapped inside of
engine.
4. Wipe off any spilled oil from lawn
mower or side of engine.
5. Fill engine with oil. (See "ADD OIL" in
the Operation section of this manual).
6. Reconnect spark plug wire to spark
plug.
3ontainer
12

AIR FILTER
Your engine will not run properly and may
be damaged by using a dirty air filter.
Replace the air filter every 100 hours of
operation or every season, whichever
occurs first. Service air cleaner more
often under dusty conditions. Do not
wash air filter.
TO CHANGE AIR FILTER
1. Remove the air filter by turning
clockwise to the stop and pull away
from collar.
2. Remove filter from inside of cover.
3. Clean the inside of the cover and the
collar to remove any dirt accumula-
tion.
4. Insert new filter into cover.
5. Put air filter cover and filter into collar
aligning the tab with the slot.
6. Push in on cover and turn counter-
clockwise to tighten.
lar TURN CLOCKWISE
TO
Clip REMOVE
\
Slot
Air filter
Air filter cover
TURN
COUNTER-
CLOCKWISE TO TIGHTEN
MUFFLER
Inspect and replace corroded muffler as it
could create a fire hazard and/or dam-
age.
SPARK PLUG
Replace spark plugs at the beginning of
each mowing season or after every 100
hours of operation, whichever occurs first.
Spark plug type and gap setting are
shown in "PRODUCT SPECIFICATIONS"
in Maintenance section of this manual.
CLEANING
IMPORTANT: For best performance, kiip
mower housing free of built-grass and
trash. Clean the underside of your mower
after each use.
ACAUTION: Disconnect spark plug wire
from spark plug and place wire where it
cannot come in contact with spark plug.
•Clean the underside of your lawn
mower by scraping to remove build-up
of grass and trash.
• Clean engine often to keep trash from
accumulating. A clogged engine runs
hotter and shortens engine life.
•Keep finished surfaces and wheels free
of all gasoline, oil, etc.
• We do not recommend using a garden
hose to clean lawn mower unless the
electrical system, muffler, air filter and
carburetor are covered to keep water
out. Water in engine can result in
shortened engine life.
13

AWARNING: To avoid serious injury,
before performing any service and
adjustments:
1. Release control bar and stop engine.
2. Make sure the blade and all moving
parts have completely stopped.
3. Disconnect spark plug wire from spark
plug and place where it cannot come
in contact with plug.
LAWN MOWER
TO ADJUST CU'FI'ING HEIGHT
See "TO ADJUST CU-i-I-ING HEIGHT" in
the Operation section of this manual.
REAR DEFLECTOR
The rear deflector, attached between the
rear wheels of your mower, is provided to
minimize the possibility that objects will
be thrown out of the rear of the mower into
the operator mowing position. If the
deflector becomes damaged, it should be
replaced.
SQUEEZE
TO ADJUST
_racket Hairpin
\
Lower
DISCHARGE GUARD
The discharge guard, attached to the
discharge opening of your lawn mower, is
provided to prevent the possibility of injury
resulting from objects being thrown out of
the discharge opening into the operator
mowing position. If the discharge guard
becomes damaged, it should be replaced.
TO ADJUST HANDLE
The handle can be mounted in a high or
low position. The mounting holes in the
bottom of lower handle are off center for
raising or lowering the handle.
1. Remove upper handle and all parts
attached to lower handle.
2. Remove hairpin cotters from lower
handle bracket mounting pin.
3. Squeeze lower handle in to remove it
from mounting pins.
4. Turn lower handle over to raise or
lower handle.
5. Squeeze lower handle in and position
holes onto mounting pins on handle
bracket.
6. Reassemble upper handle and all
parts removed from lower handle.
ROTATE
ENGINE
ENGINE SPEED
Your engine speed has been factory set.
Do not attempt to increase engine speed
or it may result in personal injury. If you
believe that engine is running too fast or
too slow, take your mower to a Sears or
other qualified service center for repair
and adjustment.
CARBURETOR
Your carburetor has a non-adjustable
fixed main jet for mixture control. If your
engine does not operate properly due to
suspected carburetor problems, take your
lawn mower to aSears or other qualified
service center for repair and/or adjust-
ment.
IMPORTANT: Never tamper with the
engine governor, which is factory set for
the proper engine speed. Overspeeding
the engine above the factory high speed
scan be dangerous. If you think the
engine-governed high speed needs
adjusting, contact a Sears or other
qualified service center, which has proper
equipment and experience to make any
necessary adjustments.
14

Immediatelyprepare your lawn mower for
storage at the end of the season or if the
unit will not be used for 30 days or more.
LAWN MOWER
When lawn mower is to be stored for a
period of time, clean it thoroughly, remove
all dirt, grease, leaves, etc. Store in a
clean, dry area.
1. Clean entire lawn mower (See
"CLEANING" in the Maintenance
section of this manual).
2. Lubricate as shown in the Mainte-
nance section of this manual.
3. Be sure that all nuts, bolts, screws,
and pins are securely fastened.
Inspect moving parts for damage,
breakage and wear. Replace if
necessary.
4. Touch up all rusted or chipped paint
surfaces; sand lightly before painting.
HANDLE
You can fold your lawn mower handle for
storage.
1. Squeeze the bottom ends of the lower
handle toward each other until the
lower handle clears the handle
bracket, then move handle forward.
2. Loosen upper handle mounting bolts
enough to allow upper handle to be
folded back.
IMPORTANT: When folding the handle
for storage or transportation, be sure to
fold the handle as shown or you may
damage the control cables.
•When setting up your handle from the
storage position, the lower handle will
automatically lock into the mowing
position.
SQUEEZE
TO FOLD
hanc
control bar
Upper
Lower
FOLD
BACK3NARD
Mowing
position
ENGINE
FUEL SYSTEM
IMPORTANT: It is important to prevent
gum deposits from forming in essential
fuel system parts such as carburetor, fuel
filter, fuel hose, or tank dudng storage.
Also, alcohol blended fuels (called
gasohol or using ethanol or methanol)
can attract moisture which leads to
separation and formation of acids during
storage. Acidic gas can damage the fuel
system of an engine while in storage.
1. Drain the fuel tank.
2. Start the engine and let it run until the
fuel lines and carburetor are empty.
•Never use engine or carburetor cleaner
products in the fuel tank or permanent
damage may occur.
•Use fresh fuel next season.
NOTE: Fuel stabilizer is an acceptable
alternative in minimizing the formation of
fuel gum deposits during storage. Add
stabilizer to gasoline in fuel tank or
storage container. Always follow the mix
ratio found on stabilizer container. Run
engine at least 10 minutes after adding
stabilizer to allow the stabilizer to reach
the carburetor. Do not drain the gas tank
and carburetor if using fuel stabilizer.
ENGINEOIL
Drain oil (with engine warm) and replace
with clean engine oil. (See "ENGINE" in
the Maintenance section of this manual).
15

CYLINDER
1. Remove spark plug.
2. Pour one ounce (29 ml) of oil through
spark plug hole into cylinder.
3. Pull starter handle slowly a few times
to distribute oil.
4. Replace with new spark plug.
OTHER
• Do not store gasoline from one season
to another.
• Replace your gasoline can if your can
starts to rust. Rust and/or dirt in your
gasoline will cause problems.
• If possible, store your unit indoors and
cover it to protect it from dust and dirt.
•Cover your unit with a suitable protec-
tive cover that does not retain moisture.
Do not use plastic. Plastic cannot
breathe, which allows condensation to
form and will cause your unit to rust.
IMPORTANT: Never cover mower while
engine and exhaust areas are still warm.
_I, CAUTION: Never store the lawn
mower with gasoline in the tank inside a
building where fumes may reach an open
flame or spark. Allow the engine to cool
before storing in any enclosure.
TROUBLESHOOTING -See appropriate section in manual unless directed
to a Sears Servic .=Center.
PROBLEM CAUSE CORRECTION
Does not start 1. Dirty air filter. 1. Clean/replace air filter.
,
3. Out of fuel. Stale fuel.
4. Water in fuel.
5. Spark plug wire is
disconnected.
6. Bad spark plug.
7. Loose blade or broken
blade adapter.
8. Control bar in released
position.
9. Control bar defective.
2. Fill fuel tank.
3. Drain tank and refill with
fresh, clean fuel.
4. Drain fuel tank and
carburetor and refill tank
with fresh gasoline.
5. Connect wire to plug.
6. Replace spark plug.
7. Tighten blade bolt or
replace blade adapter.
8. Depress control bar to
handle.
9. Replace control bar.
Loss of power
10.Fuel valve lever (if so
equipped) in OFF position.
11.Weak battery (if equipped).
12.Disconnected battery
connector (if equipped).
.
.
3.
4.
5.
6.
10.Turn fuel valve lever
to the ON position.
11 .Charge battery.
12. Connect battery to engine.
Rear of lawn mower
housing or cutting blade
dragging in heavy grass.
Cutting too much grass.
Dirty air filter.
Buildup of grass, leaves,
and trash under mower.
Too much oil in engine.
Walking speed too fast.
1. Set to "Higher Cut"
position.
2. Set to "Higher Cut"
position.
3. Clean/replace air filter.
4. Clean underside of mower
housing.
5. Check oil level.
6. Cut at slower walking speed.
16

TROUBLESHOOTING -See appropriate section in manual unless directed
to a Sears Service Center.
PROBLEM CAUSE CORRECTION
Poor cut- 1. Worn, bent or loose blade. 1. Replace blade. Tighten
uneven blade bolt.
2. Wheel heights uneven. 2. Set all wheels at same
height.
3. Buildup of grass, leaves 3. Clean underside of
and trash under mower, mower housing.
Excessive 1. Worn, bent or loose blade. 1. Replace blade. Tighten
vibration blade bolt.
2. Bent engine crankshaft. 2. Contact aSears or other
qualified service center.
Starter rope Engine flywheel brake is on
hard to pull when control bar is released.
.
2.
3.
4.
Bent engine crankshaft.
Blade adapter broken.
Blade dragging in grass.
1. Depress control bar to
upper handle before
pulling starter rope.
2. Contact a Sears or other
qualified service center.
3. Replace blade adapter.
4. Move lawn mower to cut
grass or to hard surface.
;Grass catcher 1. Cutting height too low. 1. Raise cutting height.
_otfilling 2. Lift on blade worn off. 2. Replace blade.
(If so equipped) 3. Catcher not venting air. 3. Clean grass catcher.
Hard to push 1. Raise cutting height.
1. Grass is too high or wheel
height is too low.
2. Rear of lawn mower
housing or cutting blade
dragging in grass.
3. Grass catcher too full.
4. Handle height position not
right for you.
2. Raise rear of lawn mower
housing one (1) setting
higher.
3. Empty grass catcher.
4. Adjust handle height to suit.
17

Garantfa ........................................................ 18
Reglas de Seguridad ............................... 16-19
Montaje /Operaci6n ...................................... 21
Operaci6n ................................................ 23-25
Mantenimiento ............................................... 26
Programa de Mantenimiento................... 26-29
Especificaciones del Producto ..................... 27
Servicio y Adjustes ....................................... 30
Almacenamiento ...................................... 31-32
Identificaci6n de problemas .................... 32-33
Partes de repuesto ................................. 34-39
Servicio Sears ................................ Contratapa
GARANTfA UMITADA DE DOS AltOS PARA LA SEGADORA AMOTOR CRAFTSMAN
Por dos (2) aSos, a parr de la fecha de compra, cuando esta Segadora Craftsman se mantenga,
lubrique y afine segt_n las instmcciones para la operaci6n y el mantenimiento en el manual del dueSo,
Sears reparar_ gratis tododefecto en el material y la mano de obra.
Si la Segadora Craftsman se usa para fines comerdales ode arfiendo, esta garanffa s_lo se aplica por
noventa (90) dfas a partir de la fesha de compra.
Esta Garantfa no cut)re:
•Artfcul_ que se desgastan duranteel uso normal tales como lascuchillassegaderas rotatorias, los
adaptadores de la cuchilla, las correas, los filtres de aire y las bujfas.
•Reparacioeesnecesariasdebidoal abusoo a la negligenciadel operador,locluy6ndosea los
cig0ehalesdeblados y a lafalta de mantenimientodel equiposeg0nles instruccionesque sa incluyen
enelmanualdel dueiSo.
EL SERVICIO DE GARANTIA ESTA DISPONIBLE al devolverlasegaderaa motorCraftsmanal Centro/
Departmentode ServicioSears rnescercanoen los EstadosUnidos.Esta garantfasa aplicasolamente
mientrasel productoeste en uso en los EstadosUnides.
Esta Garantfale otorgaderschos legalesespecfrv::os,y puedeque tambi_ntenga otresderschosque
vadan de estade aestado.
Sears, Roebuckand Co., D/8171NA,HoffrnanEstates,IL 60179 USA
IMPORTANTE: Esta maquina cortadaora es capaz de amputar las manos ylos manos ylos
pies yde lanzar objetos. Si no sa observan las instruccionesde seguridad siguientes se pueden
producir lesiones graves o la muerte.
_IBusque esto sfmbolo que se£1alalas
precauciones de seguridad de importancia.
Quiere deck - liiATENCION!!!iiiESTE
ALERTO!!! SU SEGURIDAD ESTA
COMPROMETIDA.
,_ADVERTENCIA: Siempre desconecte el
alambre de la bujfa y p6ngalo donde no pueda
entrar en contacto con la bujfa, para evitar el
arranque por accidente, durante la
preparaci6n, el transporte, el ajuste o cuando
se hacen reparaciones.
_,a, DVERTENCIA: Los bornes, terminales y
accesorios relativos de la baterfa contienen
plomo o cornpuestos de plomo, productos
quimloos conocidos en el Estado de California
como causa de c_ncer y defectos al
nacimiento u otros daSos reproductivos. Lavar
las rnanos despu_s de manipularlos.
_IPRECAUCI()N: El tubo de escape del
motor, algunos de sus constituyentes y
algunos componentes del vehfculo contienen
o desprenden productos qufrnicos conocidos
en el Estado de California como causa de
c_.ncery defectos al nacirnientou otros daSos
reproductivos.
_IPRECAUCI6N: El silenciador y otras
piezas del motor Ilegan asre extremadamente
calientes durante la operaei6n y siguen siendo
calientes despu_s de que el motor haya
parado. Para evitar quernaduras severas,
permanezca lejos de estas _.reas.
18

I. OPERACION
• Antes de empezar, debe familiarizarse
completamente con los controles y el uso
co]recto de la maquina. Para esto, debe leer
y comprender todas las instruccionesque
aparecen en la maquina yen los manuales
de operaci6n.
•No ponga las manos o los pies coma o
debajo de las partes rotatorias. Mant6ngase
siempre lejos de la abertura de la descarga.
• Permits que solamente las personas
responsables que est_n familiadzadas con
las instrucciones operen la m_lquina.
•Despeje el _rea de objetos tales como
piedras, juguetes, alambres, huesos, palos,
etc. que pueden ser recogidos y lanzados
por las cuchUlas.
•Aseg_rese que el drea no se hallen
personas, antes de segar. Pare la mdquina
si alguienentra en el drea.
•No opere la maquina sin zapatos o con
sandalias abiertas. P6ngase siempre
zapatos s61idos.
•No tire de la segadora hacia atr_s amenos
que sea absolutamente necesario. Mire
siempre hacia abajo y hacia detr._santes y
mientras que se mueve hacia atr_ls.
•No opere la segadora sin los respectivos
resguardos, las placas, el recogedor de
c_sped u otros aditamentos dise ados para
su protecci6n y seguridad.
• Refi_rase alas instrucciones del fabricante
pars el funeionamiento einstalaei6n de
accesorios. Use _nicamente accesonos
sprobados por el fabdcante.
•Detenga la cuchiUao las cuchillas cuando
cruce por ealzadas, calles o caminos de
grava.
• Parar el motor cada vez que se abandona
el aparato, antes de limpiar la segadora o de
remover residuos del tubo.
• Apagar el motor y esperar hasta que las
cuchillas est6n completamente paradas
antes de remover el receptor de hierba.
• Segar solamente con luz del d_a o con una
buena luz artificial.
• No opere la mdquina bajo la influencia del
alcohol o de las drogas.
• Nunca opere la maquina cuando la hierba
est6 mojada. Aseg_rese siempre de tener
buena tracci6n en sus pies; mantenga el
mango firmemente y camine; nunca corra.
• Desconectar el mecanismo de propulsi6n
aut6noma o el embrague de transmisi6n en
las segadoras que Io tienen antes de poner
en marcha el motor.
• Si el equipo empezara a vibrar de una
manera anormal, pare el motor y revise de
inmediato para averiguar la eausa.
Generalmente la vibraci6n suele indicar que
existe alguna averia.
• Siempre use gafas de seguridad o anteojos
con protecci6n lateral cuando opere la
segadora.
II. OPERACION SOBRE LAS CUESTAS
Los accidentes ocu]ren con mds frecuoncia
en las cuestas. Estos accidentes ocurren
debido a resbaladas o cafdas, las cuales
pueden resuitar en graves lesiones. Operar la
recortadora en cuestas requiere mayor
concentraci6n. Si se sionte inseguro en una
cuesta, no la recorte.
HACER:
• Puede recortar a tray,s de la superficie de
la cuesta, nunca hacia arriba y hacia abajo.
Proceda con extrema precauci6n cuando
cambie de direcci6n en las cuestas.
• Renueva todos los objetos extraSos, tales
como guijarros, ramas, etc.
• Debe prestar atenci6n a hoyos, baches o
protuberancias. Recuerde que la hierba alta
puede esconder obstdculos.
NO HACER:
•No recorte cerca de pendientes, zanjas o
terraplenes. El operador puede perder la
tracci6n en los pies o el equilibdo.
•No recorte cuestas demasiado inclinadas.
•No recorte en hierba mojada. La reducci6n
en la tracci6n de la pisada puede causar
resbalones.
II1.NIl;lOS
Se pueden producireccidentes trdgicossi el
operador no presta atenci6n ala presencia de
los niSos.A menudo, los niSosse sienten
atrafdos pot la mdquina y porla actividad de la
siega. Nunca suponga que los niSosvan a
permanecer en el mismo lugar donde los vio
pot dltima vez.
•Mantenga a los niSosalejados del drea de la
siega y bajo el cuidado estrictode otra
persona adulta responsable.
•Estd alerta y apague la m._quinasi hay
niSosque entran al drea.
•Antes y cuando este retrocediendo, mire
hacia atrds y hacia abajo para vedficar si
hay niSos pequeSos.
•Nunca permitaque los niSosoperen la
mdquina.
•Tonga un cuidado extra cuando se acerque
a esquinas donde no hay visibilidad,a los
arbustos, _,rboles u otros objetos que
pueden interferircon su linea de visi6n.
IV. SERVIClO
•Tenga cuidado extra al manejar la gasolina
y los demos combustibles. Son inflamables
y los gases son explosivos.
- Use solamente un envase aprobado.
-Nunca remueva la tapa del dep6sito de
gasolina o agregue combustiblecon el
motorfuncionando. Permita que el motor
se enfrle antes de volver a pone
combustible. No fume.
Nunca vuelva a poner combustible en la
mdquina en recintos cerrados.
Nunca almacene la mdquina o el envase
del combustible dentro de alglJnlugar en
donde haya una llama expuesta, tal como
la del calentador de agua.
19

•Nunca haga funcionar una mdquina dentro
de un drea cerrada.
•Nunca haga ajustes o repareciones
mientras el motor est_ en marcha.
Desconecte el cable de la bujfa, y
mant@ngaloa cierta distancia de 6sta para
prevenir un arranque accidental.
• Mantenga las tuercas y los pemos,
especialmente los pemos del accesono de
la cuchilla, apretados y mantenga el equipo
en buenas condiciones.
•Nunca manipule de forma indebida los
dispositivosde seguridad. Controle
regularmente su funcionamiento correcto.
•Mantenga la mdquina libre de hierba, hojas
u otras acumulaciones de desperdicio.
Limpie los derrames de aceite o combus-
tible. Permita que la mdquina se enfrfe antes
de almacenarla.
•Pare e inspeccione el equipo si le pega a un
objeto. Repdrelo, si es necesado, antes de
bacerlo arrancar.
•En ning0n caso hay que regular la altura de
las ruedas mientras el motor estd en
marcha.
•Los componentes del receptor de la hierba
van sujetos a desgaste, daSos y deterioro,
que pueden exponer las partes en
movimiento o permitirque objetos sean
disparados. Contrelar frecuentemente y
cuando sea necesario sustituircon partes
aconsejadas por el fabricante.
•Las cuchillas de la segadora estdn afiladas
y pueden cortar. Cubrir las hojas o Ilevar
guantes, y utilizar precauciones especiales
cuando se efect0a mantenimiento sobre las
mismas.
•No cambie el ajuste del reguladordel motor
ni exceda su velocidad.
Estos accesodos estaban disponibles cuando se predujo la segadora. No son facilltados
junto al cortacesped. Tambi_n estdn disponibles en la mayorfa de las tiendas de Sears y en
los centros de servicio. La mayorfa de las tiendas Sears tambidn pueden mandar a pedir
partes de repuesto para usted, si les proporciona el n0mero del modelo de su segadora.
Algunos de estos accesorios tal vez no se apliquen a su segadora.
RENDIMIENTO DE LA SEGADORA
DESVIADOR DE RECORTES J
PARASEGADORAS CON DESCARGA TRASERA JUEGOS PARA LA ACOLCHADORA
_\\'" _ RECOREDOR _RECOREDOR
/\ _ PARA PARA
\
.\ \, SEGADORAS SEGADORAS
_\ I_"_- ]11 CON OESCARGA CON DESCARGA
TRASERA LATERAL
MANTENIMIENTO DE LA SEGADORA
ESTABILIZADORES
ENVASES
DE GASOUNA
SILENCIADORES
CORREAS CUCHILLAS
FILTROS DE AIRE
ADAPTAOORES
DE CUCHILLA
BUJiAS
RUEDAS DEL MOTOR
2O
