Owner's Manual
[RRFTSMRlio
6.0 HORSEPOWER
20" REAR DISCHARGE
ROTARY LAWN MOWER
Model No.
917.387280
, Safety
®Assembly
,Operation
®Maintenance
,, EspaSol
,, Repair Parts
CAUTION:
Read and follow all
Safety Rules and instructions
before operating this equipment
Sears, Roebuck and Co., Hoffman Estates, IL 60179

Warranty 2 Product Specifications 11
Safety Rules 2 Service and Adjustments 13
Assembly 4 Storage 14
Operation 6 Troubleshooting 15
Maintenance Schedule I0 Repair Parts 32
Maintenance ,:_ 10 Parts Ordering Back Cover
UMtTED TWO YEAR WARRANTY' ON CRAFTSMAN POWER MOWER
For two years from date of _hurchase,when this Craftsman Lawn Mower is maintained,
lubricated, and tuned up according to the operating and maintenance instructions in the
owner's manual, Sears will repair free of charge any defect in material or workmanship.
If this Craftsman Lawn Mower is used for commercial or rental purposes, this warranty
applies for only 90 days from the date of purchase.
This Warranty does not cover:
• Expendable items which become worn during normal use, such as rotary mower
b_ades,blade adapters, belts, air cleaners and spark p_ug.
- Repairs necessary because of operator abuse or negligence, including bent crank_
shafts and the failure to maintain the equipment according to the instructions con-
tained in the owner's manual.
Warranty service is available by returning the Craftsman power mower to the nearest
Sears Service Center/Department in the United States. This warranty applies only while
this product is in use in the United States.
This Warranty gives you specific legai rights, and you may also have other rigt_tswhich
vary from state to state. ._
SEARS, ROEBUCK AND CO,, D/8t7 WA, HOFFMAN ESTATES, 1LLINOIS 60179
TRAINING:
• Read this operator's manual carefully.
Become familiar with the controls and
know how to operate your mower
proper_y. Learn how to quickly stop
mower,
, Do not altow children to use _jourmower.
Never a_towadults to Use mower without
proper instructions.
= Keep the area_f operation clear of a!l
persons, especi_.llysmall children and
pets.
• Use mower only as the manufacturer
intended and as described in this manual.
= Do not operate mower if it has been
dropped or damaged in any manner.
Always have damage repaired before
using your mower.
°Do not use accessoryattachments that
are not recommended by the manufac-
turer. Use of such attachments may be
hazardous.
, The blade turns when the engine is
running.
PREPARATION:
• Always thoroughly check the area to be
mowed and dear it of all stones, sticks,
wires, bones, and other foreign objects.
These objects wilt be thrown by the blade
and can cause severe injury.
•Always wear safety glasses or eye
shields when starting and while using
your mower.
,Dress properly. Do not operate mower
when barefoot or wearing open sandals.
Wear only solid shoes with good traction
when mowing.
= Check fuel tank before starting engine.
Do not fill gas tank indoors, when the
engine is running or when the engine is

hot.Allowtheenginetocootforseveral
minutesbeforefillingthegastank.Clean
offany spilled gasoline before starting the
engine.
Always make wheel height adjustments
before starting your mower. Never
attempt to do this while the engine is
running.
*Mow only in daylight or good artificial
light.
OPERATION:
- Keep your eyes and mind on your mower
and the area being cut. Do not letother
interests distract you.
° Do not mow wet or slippery grass. Never
run while operating your mower. Always
be sure of your footing -- keep a firm
hold on the handles and walk.
°Do not put hands or feet near or under
rotating parts. Keep clear of the discharge
opening at a!ltimes.
, Always stop the engine whenever you
leave or are not using your mower, or
before crossing driveways, walks_:roads,
and any gravel--covered areas.
, Never direct discharge of material toward
bystanders nor allow anyone near the
mower while you are operating itS'
° Before cleaning, inspecting, or repairing
your mower, stop the engine and make
absolutely sure the blade and all moving
parts have stopped. Then disconnect the
spark plug wire and keep it away !tom the
spark plug to prevent accidental starting.
* Do not continue to run your mower if you
hit aforeign object. Follow the procedure
outlined above, then repair any damage
before restarting and operating you
mower.
, Do not change the governor settings or
overspeed the engine. Engine damage or
personal injury may result.
-Do not operate your mower if it vibrates
abnormally. Excessive vibration is an
indication of damage; stop the engine,
safely check for the cause ofvibration
and repair as required.
o Do not run the engine indoors. Exhaust
fumes are dangerous.
o Never cut grass by pulling the mower
towards you. Mow across the face of
slopes, never up and down or you might
lose your footing, Do not mow exces-
sively steep slopes. Use caution when
operating the mower on uneven terrain
or when changing directions -- maintain
good footing.
o Never operate your mower without
proper guards, plates, grass catcher or
other safety devices in place.
MAINTENANCE AIID STORAGE:
•Check the blade and the engine mount-
ing bolts often to be sure they are
tightened properly.
Check all bolts, nuts and screws al
frequent intervals for proper tightness to
be sure mower is in safe working
condition.
,Keep all safety devices in place and
working.
o To reduce fire haza'rd, keep the engine
free of grass, leaves or excessive grease
and oil,
• Check grass catcher often for deteriora-
tion and wear and replace worn bags.
Use only replacement bags that are
recommended by and comply with
specifications of the manufacturer of your
mower.
, Always keep a sharp blade on your
mower.
o Allow engine to cool before storing in any
enclosure.
, Never store mower with fuei in the tank
inside a building where fumes may reach
an open flame or an ignition source such
as a hot water heater, space heater,
clothes dryer, etc,
CAUTION: Always disconnect spark
plug wire and place wire where it
cannot contact spark plug in order to
prevent accidental starting when
setting up, transporting, adjusting or
making repairs.
WARNING
The engine exhaust from this product
contains chemicals known to the State
of California to cause cancer, birth
defects, or other reproductive harm.

Theseaccessoneswereavailablewhenthis
lawnmowerwasproduced.Theyarealso
availableatmostSearsretailoutletsand
servicecenters.MostSearsstorescanalso
LAWN MOWER PERFORMANCE
CLIPPING DEFLECTOR
FOR REAR DISCHARGE LAWN MOWERS
GRASS CATCHERS
FOR
REAR DISCHARGE
LAWN MOWERS
LAWN MOWER MAINTENANCE
MUFFLERS
BELTS BLADES
order repair parts foryou, when you provide
the model number of your lawn mower.
Some of these accessories may not apply
to your lawn mower.
MULCHER KITS
GRASS CATCHERS
FOR
SIDE DISCHARGE
LAWN MOWERS
AIR FILTERS
BLADE ADAPTERS WHEELS
STABILIZER
GAS CANS
SPARK PLUGS
ENGINE OIL
IMPORTANT: Tf !s cutting machine is
capable of amput&ting hands and feet and
throwing objects, Failure to observe the
following safety instructions could result in
serious injury or death.
Safety standards require operator pres-
ence controls to minimize the risk of injury.
Your unit is equipped with such controls.
Do not attempt to defeat the function of the
operator presence controls under any
circumstances.
Read these instructions and this manual in
its entirety before you attempt to assemble
or operate your new lawn mower. Your new
lawn mower has been assembled at the
factory with the exception of those parts left
unassembled for shipping purposes. All
parts such as nuts, washers, bolts, etc.,
necessary to complete the assembly have
been placed in the parts bag. To ensure
safe and proper operation of your fawn
mower, all parts and hardware you as-
semble must be tightened securely. Use the
correct tools as necessary to ensure proper
tightness.
TO REMOVE LAWN MOWER FROM
CARTON
• Remove loose parts included with
mower.
,, Cut down two end comers of carton
and lay end panel down flat.
,, Remove all packing materials except
padding between upper and lower
handle and padding holding operator
presence control barto upper handle.
• Roll lawn mower out of carton and
check carton thoroughly for additional
loose parts.
4

HOW TO SET UP YOUR LAWN
MOWER
TO UNFOLD HANDLE
IMPORTANT: Unfold handles carefully so
as not to pinch or damage control cables.
•Raise handles until lower handle section
Iocks into place in mowing position.
•Remove protective padding, raise upper
handle section into place on !ower
handles and tighten both handle knobs.
= Remove handle padding holding
operator presence conlrot bar to upper
handle.
o Your lawn mower handle can be
adjusted for your mowing comfort. Refer
to "Adjust Handle" in the Service and
Adjustment section of this manual,
Operator presenc_
control bar
Lift up
Lower
handle
Mowing
position
TO iNSTALL ATTACHMENTS
Your lawn mower was shipped ready to be
used as a mulcher. To convert to bagging
or discharging:
• Open rear door and remove mulcher
plug. Store mufcher plug in a safe place.
• You can now install catcher or optional
clipping deflector.
To return to mulching operation, install
mulcher plug into discharge opening of
mower,
Mulcher plug 1
CAUTION: Do not run your lawn mower
without muicher plug in place or approved
clipping deflector or grass catcher in
place. Never attempt to operate the lawn
mower with the rear door removed or
propped open.

KNOW YOUR LAWN MOWER
READ THIS OWNER'S MANUALAND SAFETY RULES BEFORE OPERATING YOUR LAWN
MOWER. Compare the illustrationswith yourlawn mower to familiarizeyourself with the
locationofvarious controlsand adjustments. Savethis manual forfuture reference
These symbols may appear on your lawn mower or in titerattJre supplied with the
product. Learn and understand their meaning.
CAUTION ENGfNE ENGtNE FAST SLOW CHOKE FUEL OtL DANGER, KEEP HANDS
O£ WARNING ON OFF AND FEET AWAY
Operator presence control bar
Engine zone control cable
Handle knob
Grass catcher
Gasoline _fer cap
Muicher plug
Engine oil cap//'
with dipstick
Lawn mower housing
Wheel adjuster
(oneachwheel)
MEETSCPSC SAFETY REQUIREMENTS
Sears rotarywalk-behindpower lawn mowersconform to the safetystandards of theAmerican
NationalStandardsinstitute andthe U.S.Consumer Product SafetyCommission. The blade
turns when the engine isru_
Operator Presence Control Bar- must be
helddown to the handle tostartthe engine.
Releasetostop the engine.
Primer- pumps additionalfuel from the
carburetorto the cylinderfor use when starting
acold engine.
Starter Handle - used for starting the engine,
Mulcher Plug - located at the discharge
opening must be removed when converting to
bagging or discharging operation.
6

The operationof any dawnmower can resultin
foreignobjectsthrowninto the eyes,which can
resultin severe eye damage. Always wear
safetyglassesor eye shieldswhile operating
your lawn moweror performing any adiust-
meritsor repairs. We recommend awide
vision safety mask overthe spectacles or
standard saietyglasses.
HOW TO USE YOUR LAWN MOWER
ENGINE SPEED CONTROL
The engine speed was set at the factory
for optimum performance. Speed is not
adjustable.
ENGINE ZONE CONTROL
CAUTION: Federal regulations require
an engine control to be installed on this
lawn mower in order to minimize the risk
of blade contact injury. Do not under any
circumstances attempt to defeat the
function of the operator control. The blade
turns when the engine is running.
, Your lawnmower is equipped ,Mthan
operatorpresence control barwhich
requiresthe operator tobe positioned
behind the lawnmower handle tostart and
operatethe lawnmower, _;
TO ADJUST CUTTING HEIGHT
• Raisewheels for towcut and towerwheels
for high c_.
, Adjust cuttingheight tosuit your require-
ments. Medi_m posilion isbest for most
tawns.
• To change cutting height, squeeze adjuster
levertoward wheel. Move wheel up or down
to suityourrequirements. Be sure allwheels
are inthe same setting.
NOTE: Adjuster isproperly positionedwhen
plate tab insertsinto hole in lever.Also, 9-
positionadjusters(ifso equipped)allow lever
to be positioned between the plate tabs,
Lower Wheels for High Cut
RaiseWheelsIorLowCut
TO ATrACH GRASS CATCHER
Ctose the flip lid. Flip lid must bedosed
while operating lawn mower,
° Liftthe reardoor on the mower housingand
place the grasscatcher frameontothe
formed tabs on the rear door hingebracket.
*The grasscatcher is securedto the lawn
mower housing when the rear dooris
lowered onto the grass catcher frame.
CAUTION: Do not run your lawnmower
withoutdipping deflector or approvedgrass
catcher in place. Never attempt tooperatethe
lawnmower with the rear door removedor
proppedopen.
ear door
Hinge
bracket Grass catcher
frame
Formed
tabs --_
TO EMPTY GRASS CATCHER
,, To removegrass catcher, release operator
presence control bar to stop engine.
* Liftup rear door and remove the grass
catcher bythe handle.
NOTE: Do not drag the bag when emptying;
itwit1causeunnecessary wear.
7

BEFORE STARTING ENGINE
OIL
"fourlawn mower is shippedwithout oilin the
engine,
,' Besuremower is level and area around oit
fillis clean.
,, Removeengine oilcap w/dipstick and fillto
the full lineonthe dipstick.
o Use 20ozs,of oil. Fortype and grade ofoil
to use,see "ENGINE" in Customer
Responsibilitiessection of thismanual.
Pouroilslowly. Do not overfill.
. Check oi!!eve!beforeeach use. Add oilif
needed. Filltofull lineon dipstick,
,, To readproper tevel,tightenengine oilcap
eachtime,
o ReinstalIengine oil cap andtighten.
• Change the oilafter every25 hoursof
operationor each season, You may need
tochange the oil more often under dusty,
dirtyconditions.
GAS
. Fillfuel tank. Use fresh, clean, regular
unleadedgasolinewith a minimum of 87
octane.Do not mixoilwith gasoline.
Purchasefuel in quantitiesthat can be used
within30days to assurefuel freshness.
WARNING: Experience indicates that
alcohol blended fuels (cailed gasohof or
using ethanol or methanol) can attract
moisture which leads to separation and
formation of acids during storage. Acidic
gas can damage_the fue! system of an
engine while in storage. To avoid engine
problems, the fuel system should be
emptied before storage of 30 days or
longer. Drain the fuel tank, start the engine
and let it run until fuel lines and carburetor
are empty. Use fresh fuel next season.
See Storage Instructions for additional
information. Never use engine or carbure-
tor cleaner products in fuel tank or
permanent damage may occur.
TO START ENGINE
. To start a cold engine, push primer five (5)
times beforetryingto start. Use a finn push,
This step is not usually necessarywhen
startingan engine which hasalready run for
afew minutes.
°Holdoperator presence control bardown to
the handle andpult starterhandle quickly,
Do not aliow starter rope to snap back.
. To stop.engine;reiease operatorpresence
controlbar.
NOTE: Incoolerweather it may be necessary
to repeatpriming steps, tnwarmer weather
over priming may cause flooding and engine
will not start, ifyou do flood engine, wait a few
minutes beforeattempting to startanddo not
repeat priming steps,
MOWING TIPS
*Under certain conditions, such asvery tail
grass, itmay be necessaryto raise the
height ofcut toreduce pushing effortand to
keepfrom overloading the engine and
leavingclumps of grass clippings.
, For extremely heavy cutting, reduce the
widthof cut and raisethe rear ofthe lawn
mower housingone (1) wheel adjuster
settinghigher than the front for better
discharge ofgrass.
,, When using a rear discharge lawn mower in
moist,iteavy grass, clumps of cutgrass
may not enter the grass catcher.Reduce
ground speed (pushing speed)and/or nan
the lawn mower over the area a second
time.
o Ifatrailof grassclippings is leftonthe right
side ofa rear discharge lawn mower, mow
in aclockwise direction with a smalloverlap
to collectthe clippings on the nextpass.
, Keeptop of engine around starterclear and
clean of grassclippings and chaff.This will
helpengine airflow and extend engine life.
, Pores incloth grass catchers can become
filledwith dirt and dust with useand
catchers will collect less grass. To prevent
this, regularlyhose catchers offwith water
andletdry before using.

MULCHINGMOWINGTIPS
IMPORTANT: For best performance_
keep mower housing free of built-up grass
and trash. Clean UNDERSIDE OF
MOWER HOUSING after each use. See
"Cleaning" in CUSTOMER
RESPONSIBILITIES section of this
manual.
=The specialmulching bladewill recutthe
grass clippings manytimes andreduce
them in size so that as they fall ontothe
lawn theywiltdisperse intothe grassand
not be noticed. Also,the mulched grasswill
biodegrade quicklyto provide nutrientsfor
the lawn.Always mulch with your highest
engine (blade) speed as thiswill provide the
best recutting action ofthe blades.
,Avoid cuttingyour lawnwhen it iswet. Wet
grass tendsto form ciumps and interferes
with the mulching action.The best timeto
mow your lawn isthe early afternoon.Atthis
timethe grass has dried and the ne_,Aycut
area wiltnot be exposed tothe directsun.
,, For best results,adjust the lawnmower
cuttingheight so thatthe fawn mowercuts
off onlythe top one-thirdof the grassblades.
Ifthe lawn is overgrown itwiltbe necessary
to raisethe heightofcut to reducepushing
effort and to keep from overloading the
engine and leavingclumps of mulc_ed
grass. For extremely heavy mulching,
reduce yourwidth ofcut, mow slowlyand
raise the rear ofthe lawn mower onewheel
adjustersetting higher than the front.
o Certaintypes of grassand grassconditions
may requirethat an area be mulcheda
second time to completely hidethe
clippings.When doing a secondcut, mow
across or perpendicular tothe firstcut path.
,, Change yourcutting pattern from weekto
week. Mow north to south one weekthen
change toeast to west the'nextweek. This
will help prevent matting and grainingof the
lawn.
MAX 1/3

MAINTENANCE SCHEDULE
RLL IN DATES
AS YOU COMPLETE 7SERVICE DATEs
REGULAR SERVICE
mCheck |or Loose Fasteners " _
_ G_a_C_icher i ........... I _---
(,Eq._pp_> V" Iv" i _ I I i..............L
M! Clean Lawn MOwe_ _ I ....f./ t ..............
i Ctegn Under" Drive Cover i I t I t t 1 1 t
_--_I_lttoutleys I_ E t t _ ' J t ] t E
i _Powe r-P ropeltoaMowe_'s) I [ [ ............ 1 [----_-_--_'---
aiC_ec_'Sharpen/RgP'ac_8_de' [ i I _ l [ !_
....[_E_o_.os_,_uo_,01 i _ J, ,,,l,,,_,, i [
'E ICheckE._e O_ILevel V" t l 1 I [
G ....... l
-Chat_ge mone o_te_ when _p_mi_g und_' a hee_ to_d or _ hig_ a mbiet_t le_'_lpem_m_,
2"_eWice raefe Dfte_ wEen _e_Jng ir_ _i_ty ,'_1d#sly ¢or_k_m
3- Replace Made_ rr_r_ _f_en _h_w mo_g _ sa_ soil
GENERAL RECOMMENDATIONS
The warranty on this lawn mower does not
cover items that have been subjected to
operator abuse or negligence. To receive futi
value from the warranty, operator must
maintain mower as instructed in this manual.
Some adiustments witt need to be made
periodically to propedy maintain your unit.
All adjustments in the Service and Adjustments
section of this manuai should be checked at
least once each season.
• Once a year, replace the spark piug, replace
air filter element and check blade for wear. A
new spark plug and c_aWnew air filter
element assures proper air4uet mixture and
helps your engine run better and last longer.
,Fotlow the maintenance schedule in this
manual
BEFORE EACH USE
° Check engine oil level.
o Check for loose fasteners.
LUBRICATION
Keep unit welI lubricated (See "LUBRICATION
CHART").
LUBRICATION CHART
Wheet
adjusters
(_ Brake spring
bracket
Engine oil
(_) Rear
door (_ Handle bracket
hinge mounting pin
(_ SPRAY LUBRICANT
(_ SAE 30 MOTOR OIL. REFER TO
ENGINE * CUSTOMER
RESPONSiBILiTiES SECTION.
IMPORTANT: DO not oil or grease plastic
wheel bearings.Viscous lubricantswiil
attractdust and dirtthat willshortenthe
life of the self lubricating bearings. If you
feet they must be lubricated, useonlya
dry, powdered graphite type lubricant
sparingly.
10

PRODUCT SPEC!FICATRONS
MODEL NUMBER 917.387280
SERIAL NUMBER
DATE OF PURCHASE
HORSEPOWER: 6.0
DISPLACEMENT: 11,5 CU. IN.
GASOLINE CAPACITY/TYPE: t .5 QUARTS
UNLEADED REGULAR
OIL TYPE (API-SFISGfSH): SAE 30 (ABOVE32°F)
SAE 5W_3'0 (BELOW 32°F)
OIL CAPACITY: 20 OZS.
SPARK PLUG(GAP: .030") CHAMPION RJt9LM
VALVECLEARANCE: iNTAKE: .004 -,008
EXHAUST: .004 - .008
SOLID STATE IGNITION
A1R GAP: .0125 IN.
BLADE BOLT TORQUE: 35-40 FT. LBS.
The model and serial numbers will be found on a decal attached to the rear of the
lawn mower housing.Record both serial number and date of purchase in space
provided above,
LAWN MOWER
Alwaysobserve safety ruleswhen performing
any maintenance.
TIRES
•Keep tiresfree of gasoline, oil,or insect
control chemicalswhich can harm rubber.
• Avoid stumps, stones, deep ruts,sharp
objectsand other hazardsthat may cause
tire damage.
BLADE CARE
For best results,mower blade must be kept
sharp. Replace bentor damaged blades.
TO REMOVE BLADE
. Disconnect sparkplug wirefrom spark plug
andplace wirewhere it cannotcome in
contactwith spark plug.
• Turnlawn mower on its side. Make sureair
filterandcarburetor are up.
• Use a wood block between blade and
mower housing to preventbladefrom
turningwhen removing blade bolt.
- Protectyour handswith gloves and/or wrap
bladewith heavycloth.
, Remove bladebolt byturningcounter-
clockwise. Use a 9/16" box or open-end
wrench.
. Remove bladeand attaching hardware
(bolt,lock washer and hardened washer).
NOTE: Remove the blade adapter and
checkthe keyinside hubof blade adapter.
The key must be in good conditionto work
properly,Replace adapter if damaged,
TO REPLACE BLADE
,, Positionthe blade adapter onthe engine
crankshaft. Be surekey in adapter and
keyway in crankshaft are aligned.
. Positionblade onthe blade adapter
aligningthe two (2)holes in the bladewith
the raised lugson the adapter.
• Be surethe trailingedge is uptoward the
engine.
,, Installthe blade bolt with the lock washer
andhardened washer into blade adapter
andcrankshaft.
,, Use block ofwood between blade and
lawnmower housing and tighten the blade
belt,turningclockwise.
• The recommended tightening torqueis3,5-
40ft. Ibs.
IMPORTANT: Blade bolt isgrade 8 heat
treated.
11

NOTE: We do not recommend sharpening
blade -but if you do, be sure the biade is
balanced.
TO SHARPEN BLADE
Careshould betaken to keepthe blade
balanced.An unbalanced bladewitlcause
eventual damage tolawn mower or engine,
The bladecan be sharpenedwith a file or
on agrindingwheel. Do not attempt to
sharpenwhile Onthe mower.
.To check bladebalance, drive a nail intoa
beam or wall, Leaveabout one inchofthe
straightnail exposed. Piacecenter hole of
bladeoverthe head ofthe nail.Ifblade is
balanced,it shouldremainir_a horizontal
position,ffeither end ofthe blademoves
downward,sharpen the heavy end untilthe
btadeis balanced.
GRASS CATCHER
. The grasscatcher may be hosedwith
water, but must be dry when used,
,, Checkyour grass catcher oftenfor damage
ordeterioration.Through normaluse itwill
wear. If catcher needs replacing,repface
onlywith a manufacturer approved
replacementcatcher.Givethe lawnmower
modeinumber when ordering.
Blade
adaptor _
Blade. \ Key_
Bolt I\" "
Lockwasher Hardened
Crank shaft
_____.....I, ._yway
/
washer Trailing adaptor
edge
ENGINE
LUBRICATION
Use only high quality detergent oil rated
with APt service classification SF, SH or
SG, Select the oil's SAE viscosity grade
according to your expected operating
temperature,
12
NOTE: Although muTti--viscosity oils
(5W30. 10W3O etc.) improve starting in
cold wealher, those multi--viscosity oils
will result in increased oil consumption
when used above 32°F. Check your
engine oil level more frequently to avoid
possible engine damage from running low
on oil.
Change the oil after every 25 hours ofopera-
tion or at least once ayear ifthe lawn mower
is not used for 25 hours in one year.
Check the crankcase oil level before
starting the engine and after each five (5)
hours of continuous use. Tighten oil plug
securely eachtime you check the oil level.
TO CHANGE ENGINE OIL
NOTE: Before tipping lawn mower to drain
oil, drain fuel tank by running engine until
fuel tank is empty,
. Disconnect spark plug wire from spark
plug and place wire where it cannot
come in contact with spark plug.
Remove engine oil cap; lay aside on a
clean surface.
• Tip lawn mower on its side and drain oft
into a suitable container, Rock lawn
mower back and forth to remove any oil
trapped inside of engine,
o Wipe off any spilled oil on lawn mower
and Onside of engine.
o Fill engine with oil. FilI only to the "FULL"
line on the dipstick. DO NO] OVER
FILL,
,' Replace engine oil cap.
, Reconnect spark plug wire to spark
plug.
Container
AIR FILTER
",'our engine will not run properly and may
be damaged by using a dirty air filter,
Reptace the air filter every year, more
often if you mow in very dusty, dirty
conditions. Do not wash air filter.
TO CHANGE AIR FILTER
=Remove the air filter cover by turning
counterclockwise to the stop and pull
away from collar,
o Remove filter from inside of cover,
• Ctean the inside of the cover and the

collar to remove any dirt accumulation.
o Insert new filter into cover.'
o Put air filter cover and filter into collar
aligning the tab with the slot.
Push in on cover and turn clockwise to
tighten.
MUFFLER
Inspect and replace corroded muffler as it
could create a
fire hazard and/or damage.
SPARK PLUG
Change your spark plug each year to
make your engine start easier and run
better. Set spark plug gap at .030 inch.
Collar_ Tum
counter--
clockwise to
remove
Slot clockwise
to tighten
Air filter cover
CLEANING ..
iMPORTANT: For best performance,
keep mower housing free of builtmup
grass and trash. Clean underside of
mower housing after each use.
CAUTION: Disconnect spark plug wire
from spark plug and place wire where it
cannot come in contact with the spark
plug,
Turn lawn mower on its side. Make sure
air filter and carburetor are up. Clean the
underside of your lawn mower by
scraping to remove build--up of grass
and trash.
Clean engine often to keep trash from
accumulating. A clogged engine runs
hotter and shortens engine life.
Keep finished surfaces and wheels free
of all gasoline, oil, etc.
- We DO NOT recommend using a
garden hose to clean lawn mower
unless the electrical system, muffler, air
filter and carburetor are covered to keep
water out. Water in engine can result in
shortened encine life.
CAUTION: Before performing any
service or adjustments: "
,, Release control bar.
,, Make sure the blade and all moving
parts have completely stopped.
, Disconnect spark plug wire from
spark plug and place where it cannot
come in contact with plug.
LAWN MOWER
TO ADJUST CUTTING HEIGHT
See "TOADJUST CUTTING HEIGHT" in
the Operation section of this manual.
REAR DEFLECTOR
The rear deflector, attached between the
rear wheels of your lawn mower, is
provided to minimize the possibility that
objects will be thrown out the rear of the
lawn mower into the operatoCs mowing
position.
If the rear deflector becomes damaged, it
should be replaced.
TO ADJUST HANDLE
Your lawn mower handle can be raised or
lowered for your mowing comfort, Four
(4) positions are available: high, medium
high, medium tow and low. Handles are
shipped mounted in the medium low
position.
= To change from medium low to medium
high position, the upper and lower
handle sections will have to be turned
over.
,' Remove the cable clips.-_
-Remove the controls and operator
presence control bar from the upper
handle.
, Remove hairpin cotters.
= Disconnect the lower handle from the
handle brackets.
, Turn the handle over and reassemble
the hairpin cotters that have been
removed.
= Reassemble ihe controls and the
operator presence contrpt bar to the
upper handle_ !_.
CAUTION: The operator presence control
bar must pivot freely to pe[mit blade brake
engagement when control._bar is released.
Do not over tighten the fasteners holding
the controls to the upper handle.
To change from medium low to high
position only the upper handle section
wil! have to be turned over.
t3

To change from medium low to low
position, only the lower handte section
will have to be turned over.
Medium Low
Shipping Position
MediumHigh
"" Lower Handle
Squeeze to
remove
Handle
Bracket
HairpinClip
ENGINE
CARBURETOR
"Yourcarburetor has a non-adiustable fixed
main jet fbr mixture control. Ifyour engine
does not operate properly due to sus-
pected carburetor problems, take your
lawn mower to an authorized service
center for repair or adjustment.
ENGINE SPEED
"Yourengine speed has been factory set.
Do not attempt to increase engine speed
or it may result in personal injury, tf you
believe that the engine is running too fast
or too slow, take your lawn mower to an
authorized service center for repair and
adjustment.
Immediately prepareyour lawn mowerfor
storage atthe end ofthe season or if the unit
wiltnot be usedfor 30 days or more.
LAWN MOWER
When lawnmower is tobe stored for a period
of time,clean itthd_oughly,remove all dirt,
grease, leaves, etc. Store in a clean,dry area.
, Clean entire lawnmower (See "CLEANING"
in the Customer Responsibilities sectionof
thismanual).
, Lubricate asshown in the Customer
Responsibilitiessectionofthis manual.
• Be sure that all nuts,bolls, screws, and pins
are securelyfastened, Inspect moving
parts for damage, breakageand wear.
Replaceifnecessary.
- Touch up allrusted or chipped paint
surfaces;sand lightlybefore painting.
HANDLE
"Youcan fold your lawn mower handle for
storage.
, Squeezethe bottomends of the lower
handle toward each other until the lower
handle clearsthe handle bracket,then
move handle forward.
• Loosen upperhandle mounting bolts
enoug!_to allow upper handle tobe folded
back.
IMPORTANT: When folding the handle
for storage or transportation, be sure to
fold the handle as shown or you may
damage the control cables.
,, When setting upyour handle from the
storageposition, the lower handle ,wilt
lock intothe mowing position.
Lower Handle
Handle
Squeeze to fold
Operator Presence
Contro{ Bar
Hairpin
Cotter
Upper Handle
Fold Forward
14 For Storage
Fold Backward
Mowing Position
Lower Handle

ENGINE
FUEL SYSTEM
iMPORTANT: it isimportant to prevent
gum deposits from forming in essential
fuel system parts such as carburetor, fuel
filter, fuel hose, or tank during storage,
Also, experience indicates that alcohol
blended fuels (called gasohot or using
ethanol or metllanol) can attract moisture
which leads to separation and formation
of adds during storage. Acidic gas can
damage the fuel system of an engine
while in storage.
• Drain the fuel tank.
° Start the engine and letit run untilthe fue_
lines andcarburetor areempty.
• Never use engine or carburetorcleaner
products in the fuel tank or permanent
damage may occur.
• Use fresh fuel next season.
NOTE: Fuel stabilizerisan acceptable
aitemativein minimizingthe formation offuel
gumdeposits during storage. Add stabilizerto
gasolinein fuel tank or storage container.
Always followthe mixratiofound on stabilizer
container. Run engine at least t0 mi0utes
after adding stabilizertoaltow the stabilizerto
reachthe carburetor. Do not drain the gas
tank and carburetorif usingfuel stabi{izer.
ENGINE OIL
Drain oil (with enginewarm) and replace with
clean engine oil, (See "ENGINE" inthe
Customer Responsibilitiessectionofthis
manua0.
CYLINDER
oRemove sparkplug.
*Pourone ounce(29 ml) of oil through spark
plug hole intocylinder.
, Pullstarterhandie slowly a fewtimes to
distributeoil,
. Replace with new spark plug.
OTHER
o Do not store gasolinefrom one season to
another.
- Replaceyourgasoline can ifyour can stads
to rust. Rustand/ordirt in your gasolinewill
cause problems.
- tfpossible, storeyour unit indoors and cover
it togive protectionfrom dust anddirt.
, Coveryour unitwith a suitableprotective
cover that does not retain moisture. Do not
use plastic. Plasticcannot breathe which
allows condensationto form and will cause
your unitto rust.
IMPORTANT: Never cover mower while
engine and exhaust areas are stillwarm.
CAUTION: Neverstore the lawn mowerwith
gasoline in the tank inside a buitdingwhere
fumes may reachan open flame or spark.
Allow the engine tocoo_before storingin any
enclosure.
TROUBLESHOOTING
PROBLEM
Does not start
CHART
CAUSE
oDirty airfilter.
• Out of fuel.
• Stale fuel.
oWater in fuel.
• Spark plug wire is
dlsconnected.
Bad sparkplug,
o Loose bladeor brokenblade
adapter.
• Control barin released
position.
,Controlbardefective.
CORRECTION
• Clear_ireplaceairfilter.
• Fillfuel tank.
= Draintank and refillwith
freshclean fuel.
• Drainfuel tank and
carburetorand refilltank
withfresh gasoline.
" Connectwire toplug,
• Replace spark plug.
• Tightenblade bolt or
replaceblade adapter.
° Depresscontrol barto
handle.
,, Replacecontrol bar.
!5

"ROUBLESHOOTtNG CHART
.OB,EM_ }CAUSE.............................CORRECTIO.....
Loss of power , Rear of lawn mower housing , Set to "Higher Cut"
Poor cut- uneven
Excessive
vibration
Starter rope hard
to pull
Grass catcher
not filling (if so
quipped)
or cuttingblade dragging
in heavy grass.
Cuttingtoo much grass.
oDirty air filter.
° Buildup of grass, leaves,
and trash under mower.
• Too much oit in engine.
=Watking speed too fast.
Io Worn, bent or loose blade.
• Wheel heights uneven.
Hardto push
,* Buildupof grass,leaves
andtrash undermower.
,, Wom, bent or loose blade.
° Bent engine crankshaft.
o Engine flywheel brake is on
when control bar is reIeased.
o Bent engine crankshaft.
° Blade adapter broken.
=BIade dragging ingrass.
pos_ion.
, Setto"Higher Cut"
positibn.
, Clean/replace airfilter.
Cleanunderside of mower
housing.
, Checkoil level.
,' Cut atslower walking
speed.
° Replaceblade. Tighten
bladebolt.
= Setall wheels at same
height
,Clean underside of
mower housing.
,, Replace blade. Tighten
blade bolt.
,, Contact an authorized
service center.
!:; Depress control bar to
upper handle before
pulling starter rope.
, Contact an authorized
service center.
• Replace blade adapter.
Move lawn mower to cut
grass or to hard surface
to start engine.
Cutting height too tow.
= Lift on blade worn off.
= Catcher not venting air.
,, Grass is too high or wheel
height is too tow.
° Rear of lawn mower
housing or blade dragging
in grass.
o Grass catcher too full.
Handle height position not
right for you.
,, Raise cutting height.
• Replace blade.
Clean grass catcher.
,, Raisecutting height.
, Raise rear of lawn mower
housingone (1) setting
higher.
= Emptygrass catcher.
• Adjust handle height to
su_.
16

CRAFTSMAN Model No. _9t 7.387280
Garantfa 17 Especificaciones del Producto 25
Regias de Seguridad 17 Servicio y Adjustes 27
Montaje 19 Almacenamiento 28
Operaci6n 20 tdentificaci6n de problemas 30
Mantenimiento 24 Partes de repuesto Vea e] manual
Programa de Mantenimiento 24 ingI_s de] due_o
Orden de Partes Contratapa
GARANT[A LIMITADA DE DOS AI_OS PARA LA SEGADORA A MOTOR CRAFTSMAN
Pot dos (2) aSos, a partir de la fecha de compra, cuando esta Segadora Craftsman se mantenga, _ubrique
y afine segSn 1as instr_cciones para la operadSn yet rnantenimiento en el manuaJ det due_5o, Soars
reparar& gratis todo defec|o en el material y Ja mano de obra.
Si la Segadora Craftsman se usa para fines comerciales o de arriendo, esta garantia s61o se aptica per
noventa (90) dias a par_ir de Ia fecha de compra.
Esta Garantfa no cobre:
• Articulos que se desgastan durante el uso normaJ tales como las c_chiiias segadoras rotatorias, los
adaptadores de la cuchilla, las correas, los fiitros de aire y ias bujias.
• Reparaciones necesarias debido aJabt_,so o a ta negfigencia det operador, ir_uy_ndose a los
cig(Je_'_Jes doblades y a ]a fatta de mantenimiento del equipe seg_Jn tas instrucciones que se incluyen
en el manual det due_,o.
EL SERVICIO DE GARANTiA ESTA DIS_PONIBLE al devotver la segadpra a motor Craftsman ai centroi
departmento de servicio Sears mas cemano en los Estados Unidos. Esta garant_a se aplica so_amente
miantms el producto este en uso en !os Estados Unidos.
Esta Gar_qtia Ie otorga derechos tegafes especificos, y puede que tambien tenga otros derechos que
varian de estado a estado.
Sears, Roebuckand Co., Df817WA, Hoff_llan Estates, IL 60179 USA
Los estandrares de seguridad exigen tapres_ncia
de]operator enios controies parareducir a un
minimo etriesgo de lesionarse. Su unidad viane
equipada con dichos controtes. Pot ningun motivo
trate deIeliminar fafunci6n de los cont_es que
exigen la presenciadel operador.
ENTRENAMIENTO:
-Lea estemanual deloperador
cuidadosamente. Famitiaricese con los
controfes y aprenda aoperar su segadora en
forma adecuada. Aprenda a parar su
segadora rapidamente.
•No pennita que los niSos usen su segadora.
Nunca perrnita cluelosaduttos operenla
segadora sin contar con las lostrucciones
ade_Jadas.
., Mantenga el &tea deoperaci6n despejada
de genre, especiaJmentede nii=lospequeiSos
y de animales dome_ticos.
o Use la segadora soiamente paralos
fines pmpuestos porel fabdcanta y
seg,Jntasexplicacionesdescritas en
este manual.
No opere Iasegadora si se ha ca[do odaSado
ancLlaiquieraioupa. Siempre repare losda_os
antes de usada.
, No use accesorios que no hayan sido
recomendados per el fabrloante. EI use de
dichos accesorios puede ser peligreso.
* Lacuchilla gira cuando etmotor est&
funcionando.
PREPARACI6N:
o Siempre revise cuidedosamente el _.rea que
se va a segar y desp_jela de todas]aspiedras,
palos, aiambres, hue,sosy afros
objetos extraSos.Estos objetos
ser_n lanzados con taoJchiUay pueden
producir lesionesgraves. ._
Siempre use anteojos de seguridad o
protectoresde ojos coando arranque y du-
rante el tiempo queuse la segadora.
o Vistase en fonna adeoJada. No opere Ia
segadora sin zapatoso con sandalias
abiertas. Use solamente zapatos sSIidoscon
buena tracci6n cuande siegue.
17

Vistase en farina adecuada. No opere la
segadora sin zapatos o con sandalias
mientras que el motor estb, funeionando.
,Siegue siempre duranle et alia o con buena
tuz artificial.
OPERACt6N:
* Mantenga sus ojos y su mente en [a
segadora y en et &rea que se est& cortando.
No permita qiJe o_os intereses to distraigan.
- No corte c_sped mojado o resbaloso. Nunca
corra mientras eg|_ operando su segadora.
Siempre aseg,3rese de mantener el equilibrio
- mantenga el mango agarrado firrnemente y
camine.
, No ponga Ias manes o los pies cerca odebajo
de las partes rotatorias. Mant_ngase
alejado de ta abertura de descarga en todo
memento.
* Siempre pare el motor cuando se vaya
ocuando no est,_ usando su segadora, o
antes de atravesar Ias entradas para autos,
los senderos, carninos y &reas cubiertas de
ripio,
- Nunca dirija la descarga del material hacia
los espectadores ni permita a nadie cerca de
ta segadora mientras la est6 operando.
. Antes de timpia), inspeccionar o de reparar t
a segadora, pare e[ motor y este
completamente seguro de que ia euchilta y
que todas Ias partes que se mueven se
hayan detenido. Luego, desconecte et
alambre de Ia bujia y mant_ngalo alejado de
_sta para evitar el arranque per accidente.
- No contin0e haciendo funcionar su segadora
site pega a un objeto extrafio. Siga e!
procedimiento descrito anteriormente, fuego
repare cualquier daffo antes de volver a
arrancar y de operar su segadora.
- No cambie los ajustes de[ regulador o
hagaque el motor ande a una ve!ocidad
excesiva. Se pueden producir daffos en el
motor y I esiones personales.
° No opere su segadora si vibra fuera de Io
normal. La vibraci6n excesiva es una
indicaci6n de daffo; pare el motor, revise en
forma segura ta causa de ta vibraci6n y haga
las reparaciones seg_n sea necesario.
-No haga funcionar et motor en
recintoscerrados. Los gases de escape son
petigrosos.
o Nunca corte ei c6sped tirando ta segadora
hacia usted. Siegue a trav6s de {a cara de
las pendientes, nunca hacia arriba o hacia
abajo pues puede perder el equilibrio. No
siegue pendientes demasiado empinadas.
Tenga cuidado cuando opere Ia segadora en
terreno disparejo o cuando cambie de
direcciOn - mantenga un buen equilibdo.
Nunca opere la segadora sin las
protecciones adecuadas, las planchas, el
recogedor de c_,sped y otros dispositivos de
segur_dad en su lugar.
MANTENIMIENTO YALMACENAMIEN_
TO:
o Revise ta cuchilfa y los pemos de montaje
del motor amenudo, para asegurarse que
est_,n apretados en la forma adecuada.
o Revise redes los pemos, tuercas y tomillos a
intervalos frecuentes, para verificar si est_in
apretados en forma adecuada, y
asegurarseque la segadora se encuentra en
condiciones de funcionamiento seguro.
°Mantenga todos los dispositivos de seguridad
en su Jugar y listos para luncionar.
*Rata reducir el peligro de incendio,
mantenga el motor sin c6sped, hojas y grasa
o aceite en exceso.
°Revise el recogedor de c6sped a menudo
para verificar si hay deterioro y desgaste y
cambie las bolsas desgastadas. Use
solamertte las boisas de repuesto
recomendadas per el fabricante de su
segadora oque cumpten con las
especi[icaciones de _ste.
, Siempre man(enga una cuchiIla afilada en su
segadora.
Siempre permita que et motor se enfrie
antes d_._guardarla en cualquier recinto
cerrado'. _
Nunca guarde la segadora con combustible
en el estanque dentro de un edificio endonde
los gases pueden alcanzar una llama
expuesta o una fuente de ignici6n, tal come el
calentador de agua, la estufa de
calefaoci6n, fa secadora de ropa, etc.
PRECAUCI_N" Siempre desconecte el
alambre de Ia bujia y p6ngalo donde no pueda
entrar en contacto con ta bujia, para evitar et
arranque per accidente, durante la preparaci6n,
el transporte, el ajuste o cuando se hacen
reparaciones.
PRECAUCt_)N: Es conocido per el Estado de
California que los gases de escape del motor de
este productor contienen quimicos los cuales a
ciertos niveies, pueden ocasionar, c_,ncer,
defectos de nacimiento, y otros daffos atsistema
reproductive.
18

Estos accesorios estaban disponibtes cuando
se produjo ta segadora. Tambi_n est&n
disponibies en {a mayoria de las tiendas de
Sears yen los centros de servicio. La mayoria
RENDIMIENTO DE LA SEGADORA
de {as tiendas Sears tarnbi6n pueden mandar a
pedir partes de repuesto para usted, si bs
preperciona el n_3mero de! modelo de su
segadora. Atgunos de estos accesofios tal vez
no se ap{iquen a su segadora.
OESV_ADOR DE RECORTES
PARA SSGADORAS CON DESCARGA TRASERA
RECOREDOR
PARA
SEGADORAS
CON DESCARGA
TRASERA
JUEGOS PARA LA ACOLCHADORA
_---"_ eECO*EDOR
PARA
SEGADORAS
CON DESCARGA
LATERAL
ESTABIUZADORES
ENVASES
DE GASOUNA
MANTENIMtENTO DE LA SEGADORA
RLTROS DE A{RE
ADAPTADORES
DE CUCH|LLA RUEDAS
mtJfAS
ACEITE
DEL MOTOR
Lea estas instmcdones y este rrk_nual
completamente antes detratar de rnontar uoperar
su segadora nuev& Su segadora nueva ha side
montada en la f&bricacon la excepci6n de aquetlas
partes que se dejaron sin montar per razones de
envio. Todas tas partes come lastuercas, Ins
arandefas, los pemos, etc., que son nec_sad_
pare completar ei montaje hart side cobcadas en la
bolsade pa_es.Para asegurarse quesu segadera
funcione enforma segura y ader'j.Jada,todas ias
#aries y losart{cutos de ferreteda que se monten
tienenque ser apretados seguramente. Use las
herramientas correctas, come sea necesano, para
asegurar que se aprieten adecuadamente.
PARA REMOVER LA SEGADORA DE
LA CAJA DE CARTON
o Remueva tas paries suettas que se incluyen con
{asegadora.
-Corte Insdes esquinas de los extremes de la
ca_ade cariSny tienda el panel del extreme
plano,
oRemueva lode el rnateri_ de empaque, excepto
facuF_ entre el mangosupenor y el inferior, y la
cut]a quesujeta la barra de {oscentre{que exige
la presenda defoperador junto con el mango
superior.
Haga rodar la segadora hacia afuem de Iacaia
decart6n y revisela cuidadosamente para
veffficar si todavia quedan partes sueltas
adidonales.
COMe PREPARARSU SEGADORA
PARA DESDOBLAR EL MANGO
IMPORTANTE: Despliegue el mango con mucho
cuidado parano pell[zcaro da_ar _oscabIesde
control
-Levante bs mangos hasta que Ia secci6ndel
mango inferior se asegure en su _ugar,en la
posici6npar_ segar.
.Remueva IacuF'-,aprotecto_, levante Iaseod6n
del mango supenor hasta su lugar enel mango
infenor y apdete ambas manillas deImango.
*Remueva tacuF_adel mango que sujeta{a barra
de los control que ex{ge Ia presenc{a deI
operador junto con el mango superior,
,, Et mango de la segadora puede ajustarsesegen
le acornode para segar. Refi6rase a "AJUSTE
DEL MANGO" en la Secci6n de Servicio y
Ajustes de este manual
t9

Barra de control que exige la
presencia deI operador
Mango superior
Levantar
Mango Posici6r_
inferior para segar
PAPA |NSTALAR LOS ACCESORIOS
Susegadora rue erMada lista para usarse como
una acolchadora decapa vegetal. Paraconve_ida
de modo que pueda ensacar o descargar
, Abra la puertatrasera y remueva la tapon
acolchadora. Gu_rdeta enun lugar seguro.
Ahora puede instalar el recogedor o el desviador
de recortes opcional.
FAMILIARICESE CON SU SEGADORA
- Para volver a la operaci6n de acolchamiento con
capa vegetal, instale la tapon acolchadora en Ia
abertum de descan:ja de la segadora.
PRECAUCt6N: No haga funcionar su
segadora sin Ia tapon acolchadora aprobada en su
lugar, o sin et desviador de recortes, o sin el
recogedor de c_sped, aprobados, en su tugar.
Nunca trate de operar la segadora cuando se ha
removido la puerta _rasera o cuaodo estA un poco
abierta.
Tapon aicolchadera
LEA ESTE MANUAL DEL DUENO Y LAS REGLAS DE SEGURIDAD ANTES DE OPERAR SU
SEGADOP_. Compare tas ilustradones con su segadora para familiadzarse con ta ubicaci6n de los
diversos controles y ajustes. Guarde este manual para referencia en el futuro.
Estos s[mbolos pueden apareser sobre su segadora o en ia literatura proporcionada con el
producto. Aprenday comprenda sus significados.
A'r __'44_1_'4 O f_)TOA _,fzD[0}_ t4_P_Llo tE_tTO _ S}'_ NGtt _-O_,_. ACEIT_, p_UG_{<_,,GUA£_SLA$
AOVER'rEtCC#, LAC,_4_N BU._T_BLF M^ r;OS Y LOS 21ES LEJO8
Barra de control qua exige ta
Cable de control de la
ve!oc}dad det motor presencia del operador
?
Manilla del mango
Cord6n
arrancador Tapa de{ relleno de la
Recogedor del gasolina
c,_sped
Cebador
Filtro deI aire
Tapon de Ia
acolchadera Ajustador de larueda {en
Tapa de! deposito de aceite del cada [ueda)
motor con varitla indicadora de
nivel Oaja
CUMPLE CON LOS REQUISITOS DE SEGURIDAD DE LA CPSC
Las segadoras a motor, que se conducen desde la paLte de atms, rotatodas, Sears, cumplen con Ios
estb_ndares de segur_dad del Amedcan National Standards institute y de la U.S. Consumer Product Safety
Commission. La cuchilla gim,cuando el motor est& fundonando.
Barra de control que exige la presencia det
operador_ tiene que sujetarse abajo, iunto con el
mango, para hacer arrancar el motor. Su61tela para
parar e{ motor.
Cebador-- bombea combustible adidonal desde et
carburador ai cilindro pare uso cuando se necesita
hacer arrancar un motor (rio.
Cord6n arrancador--se usa para hacer arrancar
el motor.
Tapon de la acolchador,,_,-- permite ia conve_6n
pare la operacibn de descarga o ensacado.
