Craftsman BRUSHWACKER C944.514560 User manual

r
32cc / 1.9 cu.in. 2-Cycle
GASOLINE BRUSHWACKER
WARNING:
Read and follow all Safety Rules and Operating
Instructions before first use of this product.
Instruction Manual
Model No.
C944.514560
530164843 3/22/04
Sears Canada, Inc., Toronto, Ontario M5B 2B8
S
SS
SSafety
S
SS
SAssembly
S
SS
SOperation
S
SS
SMaintenance
S
SS
SParts List
For Occasional Use Only

2
TABLE OF CONTENTS
Warranty Statement 2
Safety Rules 2
Assembly 5
Operation 9
Maintenance 18
Service & Adjustments 19
Storage 20
Troubleshooting Table 21
Emissions Statement 22
Parts List Center Section
Parts and Ordering Back Cover
WARRANTY STATEMENT
LIMITED TWO (2) YEAR WARRANTY ON CRAFTSMANR
RR
RGAS POWERED
BRUSHWACKERR
RR
RBLADED TRIMMER
For two (2) years from the date of purchase, Sears Canada, Inc., will repair or
replace free of charge at Sears option parts which are defective as a result of
material or workmanship.
COMMERCIAL OR RENTAL USE:
Warranty on Gas Brushwacker will be 90 days from the date of purchase if used
for commercial or rental purposes.This warranty does not cover:
1. Spark plugs, filter, line, spool, starter rope, and blade.
2. Damages to the motor of the unit when operated without the proper fuel
mixture (see manual).
Warranty service is available by returning the Brushwacker to the nearest Sears Ser-
vice Centre/Department in Canada. This warranty applies only while this product is in
use in Canada.
This warranty is in addition to any statutory warranty and does not exclude or limit
legal rights you may have but shall run concurrently with applicable provincial
legislation. Furthermore,some provinces do NOT allow limitations on how long an
implied warranty will last, so the above limitations may not apply to you.
Sears Canada, Inc., Toronto, Ontario M5B 2B8
SAFETY RULES
WARNING: When using gar-
dening appliances, basic safety pre-
cautions must always be followed to
reduce the risk of fire and serious
injury. Read and follow all instructions.
DANGER: This power tool can
be dangerous! This unit can cause se-
rious injury including amputation or
blindness to the operator and others.
The warnings and safety instructions
in this manual must be followed to pro-
vide reasonable safety and efficiency
in using the unit. The operator is re-
sponsible for following the warnings
and instructions in this manual and on
the unit. Read the entire instruction
manual before assembling and using
the unit! Restrict the use of this unit to
persons who read, understand, and
follow the warnings and instructions in
this manual and on the unit. Never al-
low children to operate this unit.
SAFETY INFORMATION
ON THE UNIT
INSTRUCTION
MANUAL
DANGER: Blade can thrust vio-
lently away from material it does not
cut. Blade thrust can cause amputa-
tion of arms or legs.
WARNING: Blade/trimmer line
can throw objects violently. You and
others can be blinded or injured. Wear
safety glasses and leg protection.

3
Leg Guards
Boots
Eye
Protection
ALWAYS WEAR:
Thrown
Objects
WARNING: Hazard zone for
thrown objects. Blade/Trimmer line
can throw objects violently. Others can
be blinded or injured. Keep people
and animals 50 feet (15 meters) away.
Hazard Zone
50 Feet
(15 Meters)
WARNING: Do not use trimmer
head as a fastening device for the
blade.
WARNING: The blade continues
to spin after the throttle is released or
engine is turned off. The coasting blade
can throw objects or seriously cut you if
accidentally touched. Stop the blade by
contacting the left hand side of the
coasting blade with material already cut.
Stop coasting
blade by contact
with cut material.
If situations occur which are not cov-
ered in this manual, use care and
good judgment. If you need assis-
tance, contact your Sears Service
Centre.
OPERATOR SAFETY
SDress properly. Always wear safety
glasses or similar eye protection
when operating, or performing main-
tenance, on your unit (safety
glasses are available). Eye protec-
tion should be marked Z87.
SAlways wear face or dust mask if op-
eration is dusty.
SAlways wear heavy, long pants, long
sleeves, boots, and gloves. Wearing
safety leg guards is recommended.
SAlways wear foot protection. Do not
go barefoot or wear sandals. Stay
clear of spinning line/blade.
SSecure hair above shoulder length.
Secure or remove loose clothing or
clothing with loosely hanging ties,
straps, tassels, etc. They can be
caught in moving parts.
SBeing fully covered also helps protect
you from debris and pieces of toxic
plants thrown by spinning line/blade.
SStay Alert. Do not operate this unit
when you are tired, ill, upset or un-
der the influence of alcohol, drugs,
or medication. Watch what you are
doing; use common sense.
SWear hearing protection.
SNever start or run inside a closed
room or building. Breathing exhaust
fumes can kill.
SKeep handles free of oil and fuel.
SAlways use the handlebar and a
properly adjusted shoulder strap
with a blade (see ASSEMBLY).
UNIT / MAINTENANCESAFETY
WARNING: Disconnect the
spark plug before performing mainte-
nance except carburetor adjustments.
SLook for and replace damaged or
loose parts before each use. Look
for and repair fuel leaks before use.
Keep in good working condition.
SThrow away blades that are bent,
warped, cracked, broken, or dam-
aged in any other way. Replace trim-
mer head parts that are chipped,
cracked, broken, or damaged in any
other way before using the unit.
SMaintain unit according to recom-
mended procedures. Keep blade
sharp. Keep cutting line at proper
length.
SUse only Craftsman!replacement
line. Never use wire, rope, string, etc.
SInstall required shield properly be-
fore using the unit. Use the metal
shield for all metal blade use. Use
the plastic shield for all line trimmer
use.

4
WARNING: Only use brushcut-
ter attachments that provide a metal
shield with proboscis nose.
Proboscis
nose
SUse only specified blade or trimmer
head; make sure it is properly
installed and securely fastened.
SMake sure unit is assembled cor-
rectly as shown in this manual.
SNever start engine with clutch
shroud removed. The clutch can fly
off and cause serious injury.
SBe sure blade or trimmer head stops
turning when engine idles.
SMake carburetor adjustments with
lower end supported to prevent
blade or trimmer line from contacting
any object. Hold unit by hand; do
not use the shoulder strap for sup-
port.
SKeep others away when making car-
buretor adjustments.
SUse only recommended Craftsman
accessories and replacement parts.
SHave all maintenance and service
not explained in this manual per-
formed by a Sears Service Centre.
FUEL SAFETY
SMix and pour fuel outdoors.
SKeep away from sparks or flames.
SUse a container approved forfuel.
SDo not smoke or allow smoking near
fuel or the unit.
SAvoid spilling fuel or oil. Wipe up all
fuel spills.
SMove at least 10 feet (3 meters)
away from fueling site before start-
ing engine.
SStop engine and allow to cool before
removing fuel cap.
SAlways store gasoline in a container
approved for flammable liquids.
CUTTING SAFETY
WARNING: Inspect the area to
be cut before each use. Remove ob-
jects (rocks, broken glass, nails, wire,
etc.) which can be thrown or become
entangled in the blade or trimmer line.
SKeep others including children, ani-
mals, bystanders, and helpers at
least 50 feet (15 meters) away. Stop
engine immediately if you are ap-
proached.
SAlways keep engine on the right
hand side of your body.
SHold the unit firmly with both hands.
SKeep firm footing and balance. Do
not overreach or use from unstable
surfaces such as ladders, trees,
steep slopes, rooftops, etc.
SKeep blade/trimmer head (or other
optional attachment) below waist
level and away from all parts of your
body. Do not raise engine above
your waist.
SKeep all parts of your body away
from muffler and spinning line/blade
(or other optional attachment).
SKeep engine below waist level. A
hot muffler can cause serious burns.
SCut only from your left to your right.
Cutting on right side of the shield will
throw debris away from the operator.
SUse only in daylight or good artificial
light.
SUse only for jobs explained in this
manual (or manuals for optional at-
tachments).
TRANSPORTINGAND STORAGE
SAllow engine to cool before storing
or transporting in vehicle.
SEmpty the fuel tank before storing or
transporting the unit. Use up fuel left
in the carburetor by starting the en-
gine and letting it run until it stops.
SStore unit and fuel in area where fuel
vapors cannot reach sparks or open
flames from water heaters, electric
motors or switches, furnaces, etc.
SStore unit so the blade or line limiter
blade cannot accidentally cause inju-
ry. The unit can be hung by the shaft.
SStore unit out of reach of children.
SAFETY NOTICE: Exposure to vibra-
tions through prolonged use of gaso-
line powered hand tools could cause
blood vessel or nerve damage in the
fingers, hands, and joints of people
prone to circulation disorders or ab-
normal swellings. Prolonged use in
cold weather has been linked to blood
vessel damage in otherwise healthy
people. If symptoms occur such as
numbness, pain, loss of strength,
change in skin color or texture, or loss
of feeling in the fingers, hands, or
joints, discontinue the use of this tool
and seek medical attention. An anti--
vibration system does not guarantee
the avoidance of these problems. Us-
ers who operate power tools on a con-
tinual and regular basis must monitor
closely their physical condition and
the condition of this tool.

5
SPECIAL NOTICE: This unit is
equipped with a temperature limiting
muffler and spark arresting screen
which meets the requirements of Cali-
fornia Codes 4442 and 4443. All U.S.
forest land and the states of California,
Idaho, Maine, Minnesota, New Jersey,
Oregon, and Washington require by
law that many internal combustion en-
gines be equipped with a spark arrest-
ing screen. If you operate in a locale
where such regulations exist, you are
legally responsible for maintaining the
operating condition of these parts.
Failure to do so is a violation of the
law. For normal homeowner use, the
muffler and spark arresting screen will
not require any service. After 50
hours of use, we recommend that your
muffler be serviced or replaced by
your Sears Service Centre.
ASSEMBLY
CARTON CONTENTS
Check carton contents against the fol-
lowing list.
Model C944.514560
SPowerhead
SLower attachment (with trimmer
head installed)
SCupped washer
SLarge nut for installing blades
SHex wrench
SHandlebar
SBracket cover
SBracket cover screws (2)
SMetal blade shield
SBlade shield screws (4)
S4--point weed blade
SPlastic shield
SWing nut (screwed onto plastic
shield)
SShoulder strap with warning
SContainer of oil
Examine parts for damage. Do not
use damaged parts.
NOTE: If you need assistance or find
parts missing or damaged, contact
your Sears Service Centre.
It is normal for the fuel filter to rattle in
the empty fuel tank.
Finding fuel or oil residue on muffler is
normal due to carburetor adjustments
and testing done by the manufacturer.
TOOLS REQUIRED
SHex wrench (provided)
SAdjustable wrench
SPhillips screwdriver
ASSEMBLY
WARNING: Always stop unit
and disconnect spark plug before per-
forming any assembly procedures.
WARNING: If received as-
sembled, repeat all steps to ensure
your unit is properly assembled and all
fasteners are secure.
INSTALLING BRUSHCUTTER
ATTACHMENT
CAUTION: When installing brushcut-
ter attachment, place the unit on a flat
surface for stability.
1. Loosen the coupler by turning the
knob counterclockwise.
Coupler
Knob
LOOSEN
TIGHTEN
Shipping
protector
2. Remove shipping protector from
coupler.
3. Remove the shaft cap from the
brushcutter attachment (if present).
4. Position locking/release button of
attachment into guide recess of
coupler.
5. Push the attachment into the cou-
pler until the locking/release but-
ton snaps into the primary hole.
6. Before using the unit, tighten the
knob securely by turning clockwise.
Coupler Primary Hole
Upper
Shaft Locking/
Release
Button Lower
Attachment
Guide Recess
WARNING: Make sure the lock-
ing/release button is locked in the pri-
mary hole and the knob is securely
tightened before operating the unit.
All attachments are designed to be
used in the primary hole.

6
For optional attachments, see the AS-
SEMBLY section of the applicable at-
tachment instruction manual.
ATTACHING THE HANDLEBAR
DANGER: To avoid serious inju-
ry, the barrier portion of the handlebar
must be installed as shown to provide
a barrier between operator and the
spinning blade.
1. Locate the decal on the handlebar.
This decal includes an arrow. Posi-
tion the handlebar with the mount-
ing bracket at the end of the arrow.
2. Position the bracket cover over
the handlebar. Again make sure
the handlebar is at the end of the
arrow.
3. Insert screws and hand tighten only.
Be sure the handlebar is installed
correctly; then, tighten each screw
securely with the hex wrench.
Screw
Mounting
Bracket
Handlebar
Bracket Cover
ASSEMBLY OF SHOULDER STRAP
WARNING: Proper shoulder
strap and handlebar adjustments must
be made with the engine completely
stopped before using unit.
1. Insert your right arm and head
through the shoulder strap and al-
low it to rest on your left shoulder.
Make sure the danger sign is on
your back and the hook is to the
right side of your waist.
NOTE: A one-half twist is built in the
shoulder strap to allow the strap to rest
flat on the shoulder.
2. Adjust the strap, allowing the hook
to be about 6 inches below the
waist.
3. Fasten the strap hook to the clamp
located between the trigger handle
and the handlebar clamp base and
lift the tool to the operating position.
4. Try on shoulder strap and adjust
for fit and balance before starting
the engine or beginning a cutting
operation.It may be necessary to
relocate the shoulder strap clamp
on the shaft for proper balancing
of unit.
NOTE: It may be necessary to relo-
cate the shoulder strap clamp on the
shaft for proper balancing of unit.
TO RELOCATE SHOULDER STRAP
CLAMP:
1. Loosen and remove both clamp
screws.
2. Place the upper shoulder strap
clamp over the shaft.
3. Position the lower shoulder strap
clamp under the shaft and align the
upper and lower clamp screw holes.
Upper Shoulder
Strap Clamp
Screws
Lower Shoulder
Strap Clamp
4. Insert two screws into the screw
holes.
5. Secure shoulder strap clamp by
tightening screws with a hex
wrench.
30 inches
HARNESS
ADJUSTMENT
FOR BALANCE
4--12
inches
above
ground
6 inches
below
waist
30 inches

7
CONFIGURINGYOUR UNIT
You can configure your unit using a cut-
ting head for grass and light weeds, or
a weed blade for cutting grass, weeds,
and brush up to 1/2 inch (1 cm) in
diameter. To assemble your unit, go to
the section for the desired configuration
and follow the instructions.
ASSEMBLY INFORMATION --
TRIMMER HEAD
TRIMMER
HEAD
NOTE: Remove the blade and metal
shield before attaching the plastic shield
and trimmer head. To remove blade,
align hole in the dust cup with the hole
in the side of the gearbox by rotating
the blade. Insert a small screwdriver
into aligned holes. This will keep the
shaft from turning while loosening the
blade nut. Remove blade nut by turning
clockwise. Remove the screwdriver.
Remove both washers and blade. To
remove metal shield, loosen and re-
move the four mounting screws. See
ATTACHING THE METAL SHIELD and
INSTALLATION OF THE METAL BLADE for
illustrations. Be sure to store all parts
and instructions for future use.
ATTACHING THE PLASTIC SHIELD
AND TRIMMER HEAD
WARNING: The shield must be
properly installed. The shield provides
partial protection to the operator and
others from the risk of thrown objects,
and is equipped with a line limiter
blade which cuts excess line to the
proper length. The line limiter blade
(on underside of shield) is sharp and
can cut you.
1. Remove wing nut from shield.
2. Insert bracket into slot on shield.
3. Pivot shield until bolt passes
through hole in bracket.
4. Tighten the wing nut securely.
NOTE: If your unit has a plastic cover
over the threads on the threaded
shaft, remove the covering to expose
the threads. Before installing the trim-
mer head, make sure the dust cup
and retaining washer are positioned
on the gearbox as shown.
Wing Nut
Dust Cup
Bracket
Slot
Shield Gearbox
Retaining Washer
NOTE: Make sure all parts are prop-
erly installed as shown in the illustra-
tion before installing the trimmerhead.
5. Align hole in the dust cup with the
hole in the side of the gearbox by
rotating the dust cup.
6. Insert a small screwdriver into
aligned holes. This will keep the
shaft from turning while tightening
trimmer head.
Screwdriver
7. While holding the screwdriver in
position, thread trimmer head onto
the shaft by turning counterclock-
wise. Tighten until secure.
NOTE: The retaining washer must be
positioned with the raised section facing
toward the gearbox.
ASSEMBLY INFORMATION -- WEED
BLADE
WEED
BLADE
NOTE: Remove the trimmer head and
plastic shield before attaching the metal
shield and installing the weed blade. To
remove the trimmer head, align hole in
the dust cup with the hole in the side of
the gearbox by rotating the dust cup.

8
Insert a small screwdriver into aligned
holes. This will keep the shaft from turn-
ing while loosening the trimmer head.
Remove the trimmer head by turning
clockwise. Remove the screwdriver. To
remove the plastic shield, loosen and
remove wing nut. Pivot shield to release
bracket from slot. See INSTALLATION OF
THE CUTTING HEAD and ATTACHING
THE PLASTIC SHIELD for illustrations. Be
sure to store all parts and instructions
for future use. Never use the trimmer
head with the metal blade installed.
ATTACHING THE METAL SHIELD
WARNING: The metal shield
must be properly installed on the tool
anytime the tool is used with a blade.
The forward tip of the metal shield
helps to reduce the occurrence of
blade thrust which can cause serious
injury such as amputation to the oper-
ator or bystanders. Failure to install
the shield in the position shown can
result in serious injury to the operator.
The length of the shield must be
aligned with the length of the shaft.
1. Place the metal shield under the
gearbox, and align the screw holes.
Shield
Gearbox
2. Insert and thread the 4 mounting
screws through the holes of the
gearbox and the metal shield.
Tighten evenly and securely with
the hex wrench provided.
INSTALLATION OF THE METAL
BLADE
WARNING: Wear protective
gloves when handling or performing
maintenance on the blade to avoid in-
jury. The blade is sharp and can cut
you even when it is not moving.
WARNING: Do not use any
blades, or fastening hardware other
than the washers and nuts shown in the
following illustrations. These parts must
be provided by Sears and installed as
shown below. Failure to use proper
parts can cause the blade to fly off and
seriously hurt you or others.
NOTE: The dust cup and retaining
washer are located on the gearbox
shaft and not in the parts bag. All other
fasteners mentioned in the following as-
sembly steps are in the parts bag.
1. Remove the retaining washer from
the threaded shaft of the gearbox.
Leave the dust cup on the shaft.
2. Install the blade and the retaining
washer over the threaded shaft.
3. Make sure the raised part of the re-
taining washer is facing the gearbox
and the raised area fits into the hole
in the center of the blade.
4. Slide the blade and retaining wash-
er onto the shaft of the gearbox.
5. Place the cupped washer onto the
shaft. Make sure the cupped side
of the washer is toward the blade.
6. Install the blade nut by threading
onto the shaft counterclockwise.
Shield
Blade
Retaining
Washer
Dust Cup
Cupped
Washer Nut
Threaded Shaft
Gearbox
NOTE: Make sure all parts are in place
as illustrated, and the blade is sand-
wiched between the dust cup and the
retaining washer. There should be no
space between the blade and the dust
cup or the retaining washer.
7. Align hole in dust cup with hole in
side of gearbox by rotating the
blade.
8. Insert a small screwdriver into
aligned holes. This will keep the
shaft from turning while tightening
the blade nut.

9
Screwdriver
9. Tighten blade nut firmly with a
wrench while holding screwdriver
in position.
10. Remove the screwdriver.
11. Turn blade by hand. If the blade
binds against the shield, or appears
to be uneven, the blade is not cen-
tered, and you must reinstall.
NOTE: To remove blade, insert screw-
driver into aligned holes. Unthread the
nut and remove parts. Be sure to store
parts and instructions for future use.
OPERATION
KNOW YOUR TRIMMER
READ THIS INSTRUCTION MANUAL AND SAFETY RULES BEFORE OPERATING YOUR
UNIT. Compare the illustrations with your unit to familiarize yourself with the location
of the various controls and adjustments. Save this manual for future reference.
Line Limiter
Blade
Primer Bulb
Handlebar
Starter Handle
Throttle Trigger
Choke
Lever
Shield
Trimmer Head Shaft
Muffler
ON/OFF Switch
Coupler
Blade
ON/OFF SWITCH
The ON/OFF switch is located on the
trigger handle and is used to stop the
engine. Move the switch to the OFF
position to stop the engine.
PRIMER BULB
The PRIMER BULB removes air from
the carburetorand fuel lines and fills
them with fuel. This allows you to start
the engine with fewer pulls on the
starter rope. Activate the primer bulb
by pressing it and allowing it to return
to its original form.
CHOKE
The CHOKE helps to supply fuel to the
engine to aid in cold starting. Activate
the choke by moving the choke lever to
the FULL CHOKE position. After the en-
gine attempts to start, move the choke
lever to the HALF CHOKE position. Once
engine has started, move the choke le-
ver to the OFF CHOKE position.
COUPLER
The COUPLER enables optional at-
tachments to be installed on the unit.
BEFORE STARTING ENGINE
WARNING: Be sure to read
the fuel information in the safety rules
before you begin. If you do not under-
stand the safety rules, do not attempt
to fuel your unit. Contact your Sears
Service Centre.
FUELING ENGINE
WARNING: Remove fuel cap
slowly when refueling.
This engine is certified to operate on
unleaded gasoline. Before operation,
gasoline must be mixed with a good
quality synthetic 2-cycle air-cooled en-
gine oil. We recommend Craftsman
brand synthetic oil. Mix gasoline and oil

10
at a ratio of 40:1. A 40:1 ratio is ob-
tained by mixing 3.2 ounces (95 ml) of
oil with 1 gallon (4 litres) of unleaded
gasoline. Included with this trimmer is a
3.2 ounce (95 ml) container of oil. Pour
the entire contents of this container into
1 gallon (4 litres) of gasoline to achieve
the proper fuel mixture. DO NOT USE
automotive oil or marine oil. These oils
will cause engine damage. When mix-
ing fuel, follow instructions printed on
container. Once oil is added to gasoline,
shake container momentarily to assure
that the fuel is thoroughly mixed. Always
read and follow the safety rules relating
to fuel before fueling your unit.
IMPORTANT
Experience indicates that alcohol
blended fuels (called gasohol or using
ethanol or methanol) can attract mois-
ture which leads to separation and
formation of acids during storage.
Acidic gas can damage the fuel sys-
tem of an engine while in storage.
To avoid engine problems, empty the
fuel system before storage for 30 days
or longer. Drain the gas tank, start the
engine and let it run until the fuel lines
and carburetor are empty. Use fresh
fuel next season. Never use engine or
carburetorcleaner products in the fuel
tank or permanent damage may oc-
cur. See the STORAGE section for
additional information.
HOW TO STOP YOUR UNIT
STo stop the engine, move the
ON/OFF switch to the OFF position.
SIf engine does not stop, move choke
lever to FULL CHOKE position.
Throttle Trigger
ON/OFF
Switch
HOW TO START YOUR UNIT
WARNING: Avoid any contact
with the muffler. A hot muffler can
cause serious burns.
STARTING A COLD ENGINE (or a
warm engine after running out of
fuel)
Starting Position
Muffler
Choke
Lever
Starter Handle
Primer
Bulb
1. Set unit on a flat surface.
2. Move ON/OFF switch to the ON
position.
3. Slowly press the primer bulb 6
times.
4. Move choke lever to FULL CHOKE
by aligning lever with position
shown on decal (see illustration
below).
Choke
position
decal
5. Squeeze the throttle trigger fully and
hold through all remaining steps.
6. Pull starter rope handle sharply
until engine sounds as if it is trying
to start,but do not pull rope more
than 6 times.
7. As soon as engine sounds as if it
is trying to start, move choke lever
to HALF CHOKE by aligning lever
with position shown on decal (see
following illustration).
Choke
position
decal
8. Pull starterrope sharply until en-
gine runs, but no more than 6
pulls. If the engine doesn’t start af-
ter 6 pulls (at the HALF CHOKE
position), move the choke lever to
the FULL CHOKE position and
press the primer bulb 6 times.
Squeeze and hold the throttle trig-
ger and pull the starter rope 2
more times. Move the choke lever
to the HALF CHOKE position and
pull the starter rope until the en-
gine runs, but no more than 6

11
pulls. If the engine doesn’t start,
repeat procedure 2 additional
times. NOTE: If engine still doesn’t
start, it is probably flooded. Proceed
to STARTING A FLOODED ENGINE.
9. Once the engine starts, allow it to
run 10 seconds, then move the
choke lever to OFF CHOKE by
aligning lever with position shown
on decal (see illustration below).
Allow the unit to run for 30 more
seconds at OFF CHOKE before re-
leasing the throttle trigger. NOTE:
If engine dies with the choke lever
in the OFF CHOKE position, move
the choke lever to the HALF
CHOKE position and pull the rope
until engine runs, but no more
than 6 pulls.
Choke
position
decal
STARTING A WARM ENGINE
1. Move ON/OFF switch to the ON
position.
2. Move the choke lever to the HALF
CHOKE position.
3. Squeeze and hold the throttle trig-
ger. Keep throttle trigger fully
squeezed until the engine runs
smoothly.
4. Pull starter rope sharply until en-
gine runs, but no more than 5
pulls.
5. Allow engine to run 15 seconds,
then move the choke lever to the
OFF CHOKE position.
NOTE: If engine has not started, pull
starterrope 5 more pulls. If engine still
does not run, it is probably flooded.
STARTING A FLOODED ENGINE
Flooded engines can be started by
placing the choke lever in the OFF
CHOKE position; then, pull the rope to
clear the engine of excess fuel. This
could require pulling the starter handle
many times depending on how badly
the unit is flooded.
If the unit still doesn’t start, refer to
TROUBLESHOOTING TABLE or contact
your Sears Service Centre.
OPERATING THE COUPLER
This model is equipped with a coupler
which enables optional attachments to
be installed. The optional attach-
ments are:
Edger C944.511573................
Cultivator C944.511580.............
Blower C944.511601...............
Pruner C944.514610...............
WARNING: Always stop unit
and disconnect spark plug before re-
moving or installing attachments.
REMOVING TRIMMER ATTACH-
MENT (OR OTHER OPTIONAL AT-
TACHMENTS)
CAUTION: When removing or instal-
ling attachments, place the unit on a
flat surface for stability.
1. Loosen the coupler by turning the
knob counterclockwise.
Coupler
Knob
LOOSEN
TIGHTEN
Upper Shaft
Lower
Attachment
2. Press and hold the locking/release
button.
Locking/Release
Button
Coupler Upper Shaft
Lower Attachment
3. While securely holding the engine
and upper shaft, pull the attach-
ment straight out of the coupler.
INSTALLING OPTIONAL ATTACH-
MENTS
1. Remove the shaft cap from the at-
tachment (if present).
2. Position locking/release button of
attachment into guide recess of
coupler.
3. Push the attachment into the cou-
pler until the locking/release but-
ton snaps into the primary hole.
4. Before using the unit, tighten the
knob securely by turning clock-
wise.

12
Coupler Primary Hole
Upper
Shaft Locking/
Release
Button Attachment
Guide Recess
WARNING: Make sure the lock-
ing/release button is locked in the pri-
mary hole and the knob is securely
tightened before operating the unit.
OPERATING POSITION
Boots
Heavy,
Long Pants
Eye Protection
ALWAYS WEAR:
Cut from your left to your right.
Hearing
Protection
When operating unit, clip shoulder
strap onto clamp, stand as shown and
check for the following:
SWear eye protection and heavy
clothing.
SExtend your left arm and hold
handlebar grip with your left hand.
SHold throttle grip with your right hand
with finger on throttle trigger.
SKeep unit below waist level.
SKeep shoulder strap pad centered
on your left shoulder and danger
sign centered on your back.
SMaintain full weight of tool on your
left shoulder.
SWithout bending over, keep the
blade or trimmer head near and
parallel to the ground and not
crowded into material being cut.
OPERATING INSTRUCTIONSFOR
USE WITH TRIMMER HEAD
WARNING: Always wear eye
protection. Never lean over the trim-
mer head. Rocks or debris can rico-
chet or be thrown into eyes and face
and cause blindness or other serious
injury.
Before trimming, bring engine to a a
speed sufficient to cut material to be
trimmed.
Do not run the engine at a higher
speed than necessary. The cutting
line will cut efficiently when the engine
is run at less than full throttle.At lower
speeds, there is less engine noise and
vibration. The cutting line will last
longer and will be less likely to “weld”
onto the spool.
Always release the throttle trigger and
allow the engine to return to idle
speed when not cutting.
To stop engine:
SRelease the throttle trigger.
SMove the ON/OFF switch to the OFF
position.
TRIMMER LINE ADVANCE
The trimmerline will advance approxi-
mately 2 inches (5 cm) each time the
bottom of the trimmer head is tapped
on the ground with the engine running
at full throttle.
The most efficient line length is the
maximum length allowed by the line
limiter. Always keep the shield in
place when the tool is being operated.
To advance line:
SOperate the engine at full throttle.
SHold the trimmerhead parallel to
and above the grassy area.
STap the bottom of the trimmer head
lightly on the ground one time.
Approximately 2 inches (5 cm) of
line will be advanced with each tap.
Always tap the trimmer head on a
grassy area. Tapping on surfaces such
as concrete or asphalt can cause ex-
cessive wear to the trimmer head.If the
line is worn down to 2 inches (5 cm) or
less, more than one tap will be required
to obtain the most efficient line length.
WARNING: Use only 0.080"(2
mm) diameter line. Other sizes of line
will not advance properly and can
cause serious injury. Do not use other
materials such as wire, string, rope,
etc. Wire can break off during cutting
and become a dangerous missile that
can cause serious injury.
CUTTING METHODS
WARNING: Use minimum
speed and do not crowd the line when
cutting around hard objects (rock,
gravel, fence posts, etc.), which can
damage the trimmer head, become
entangled in the line, or be thrown
causing a serious hazard.

13
SThe tip of the line does the cutting.
You will achieve the best perform-
ance and minimum line wear by not
crowding the line into the cutting
area. The right and wrong ways are
shown below.
Tip of the line
does the cutting.
Right Wrong
Line crowded into
work area.
SThe line will easily remove grass
and weeds from around walls,
fences, trees and flower beds, but it
also can cut the tender bark of trees
or shrubs and scar fences.
SFor trimming or scalping, use less
than full throttle to increase line life
and decrease head wear, especially:
SDuring light duty cutting.
SNear objects around which the line
can wrap such as small posts,
trees or fence wire.
SFor mowing or sweeping, use full
throttle for a good clean job.
TRIMMING -- Hold the bottom of the
trimmerhead about 3 in. (8 cm) above
the ground and at an angle. Allow only
the tip of the line to make contact. Do
not force trimmer line into work area.
Trimming
3 inches (8 cm)
above ground
SCALPING -- The scalping technique
removes unwanted vegetation down
to the ground. Hold the bottom of the
trimmerhead about 3 in. (8 cm) above
the ground and at an angle. Allow the
tip of the line to strike the ground
around trees, posts, monuments, etc.
This technique increases line wear.
Scalping
MOWING -- Your trimmer is ideal for
mowing in places conventional lawn
mowers cannot reach. In the mowing
position, keep the line parallel to the
ground. Avoid pressing the head into
the ground as this can scalp the
ground and damage the tool.
Mowing
SWEEPING -- The fanning action of the
rotating line can be used to blow away
loose debris from an area. Keep the line
parallel to and above the area surface
and swing the tool from side to side.
Sweeping
OPERATING INSTRUCTIONSFOR
USE WITH WEED BLADES
SBlade Thrust is a reaction that only
occurs when using a bladed unit.
This reaction can cause serious in-
jury such as amputation. Carefully
study this section. It is important that
you understand what causes blade
thrust, how you can reduce the
chance of its occurring, and how
you can remain in control of unit if
blade thrust occurs.
SWHAT CAUSES BLADE
THRUST -- Blade Thrust can oc-
cur when the spinning blade con-
tacts an object that it does not cut.
This contact causes the blade to

14
stop for an instant and then sud-
denly move or “thrust” away from
the object that was hit. The “thrust-
ing” reaction can be violent
enough to cause the operator to
be propelled in any direction and
lose control of the unit. The uncon-
trolled unit can cause serious in-
jury if the blade contacts the op-
erator or others.
SWHEN BLADE THRUST OC-
CURS -- Blade Thrust can occur
without warning if the blade snags,
stalls, or binds. This is more likely
to occur in areas where it is diffi-
cult to see the material being cut.
By using the unit properly, the oc-
currence of blade thrust will be re-
duced and the operator will be
less likely to lose control.
SCut only grass, weeds, and woody
brushupto1/2inch(1cm)indi-
ameter with the weed blade. Do not
let the blade contact material it can-
not cut such as stumps, rocks,
fences, metal, etc., or clusters of
hard, woody brush having a diame-
ter greater than 1/2 inch (1 cm).
SKeep the blade sharp. A dull blade
is more likely to snag and thrust.
SCut only at full throttle. The blade
will have maximum cutting power
and is less likely to bind or stall.
S“Feed” the blade deliberately and
not too rapidly. The blade can
thrust away if it is fed too rapidly.
SCut only from your left to your
right. Cutting on right side of the
shield will throw debris away from
the operator.
SUse the shoulder strap and keep a
firm grip on the unit with both
hands. A properly adjusted shoul-
der strap will support the weight of
the unit, freeing your arms and
hands to control and guide the
cutting motion.
SKeep feet comfortably spread
apart and braced for a possible
sudden, rapid thrust of unit. Do not
overreach. Keep firm footing and
balance.
SKeep blade below waist level; it will
be easier to maintain control of unit.
SDo not raise the engine above
your waist as the blade can come
dangerously close to your body.
SDo not swing unit with such force
that you are in danger of losing your
balance.
Bring the engine to cutting speed be-
fore entering the material to be cut.If
the blade does not turn when you
squeeze the throttle trigger, make sure
shaft is fully inserted into the engine.
Always release the throttle trigger and
allow engine to return to idle speed
when not cutting. The blade should
not turn while the engine is running at
idle. If the blade turns at idle, do not
use your unit. Refer to the CARBURE-
TOR ADJUSTMENT section or contact
your Sears Service Centre.
SMaintain good firm footing while
using the unit. Do this by planting
feet firmly in a comfortable apart
position.
SCut while swinging the upper part
of your body fromleft to right.
SAs you move forward to the next
area to cut, be sure to maintain
your balance and footing.
Cut using the 2
o’clock to 4 o’clock
position of the
blade
2 o’clock
4 o’clock
RECOMMENDED CUTTING POSITION
WARNING: The operator or oth-
ers must not try to clear away cut mate-
rial with the engine running or the blade
turning to avoid serious injury. Stop en-
gine and blade before removing materi-
als wrapped around blade or shaft.

15
ADDITIONAL SAFETY RULES
FOR OPTIONAL ATTACHMENTS
WARNING: For each optional
attachment used, read entire instruc-
tion manual before use and follow all
warnings and instructions in manual
and on attachment.
WARNING: Ensure handlebar
remains installed on upper shaft (en-
gine end of unit) at all times.
Handlebar
EDGER SAFETY
WARNING: Inspect the area to
be edged before each use. Remove
objects (rocks, broken glass, nails,
wire, etc.) which can be thrown by the
blade or can wrap around the shaft.
SBlade rotates momentarily after the
trigger is released. The blade can
seriously cut you or others.
SAllow blade to stop before removing
it from the cut.
SThrow away blades that are bent,
warped, cracked, broken or dam-
aged in any other way. Replace
parts that are cracked, chipped, or
damaged before using the unit.
SDo not attempt to remove cut material
nor hold material to be cut when the
engine is running or when cutting
blade is moving.
SAlways keep the wheel and depth ad-
justing skid in contact with the ground.
SAlways push the unit slowly over the
ground. Stay alert for uneven side-
walks, holes in the terrain, large
roots, etc.
SAlways use the handlebar when us-
ing edger attachment.
BLOWER/VACUUM SAFETY
WARNING: Inspect area before
starting unit. Remove all debris and
hard objects such as rocks, glass,
wire, etc. that can ricochet, be thrown,
or otherwise cause injury or damage
during operation.
SDo not set unit on any surface except
a clean, hard area while engine is
running. Debris such as gravel, sand,
dust, grass, etc., could be picked up
by the air intake and thrown out
through discharge opening, damaging
unit, property, or causing serious injury
to bystanders or operator.
SNever place objects inside the blow-
er tubes, vacuum tubes or blower
outlet. Always direct the blowing de-
bris away from people, animals,
glass, and solid objects such as
trees, automobiles, walls, etc. The
force of air can cause rocks, dirt, or
sticks to be thrown or to ricochet
which can hurt people or animals,
break glass, or cause other damage.
SNever run unit without the proper
equipment attached. When using
your unit as a blower, always install
blower tubes.
SCheck air intake opening, blower
tubes or vacuum tubes frequently,
always with engine stopped and
spark plug disconnected. Keep
vents and discharge tubes free of
debris which can accumulate and
restrict proper air flow.
SNever place any object in air intake
opening as this could restrict proper
air flow and cause damage to the unit.
SNever use for spreading chemicals,
fertilizers, or other substances which
may contain toxic materials.To avoid
spreading fire, do not use near leaf or
brush fires, fireplaces, barbecue pits,
ashtrays, etc.
CULTIVATOR SAFETY
WARNING: Rotating tines can
cause serious injury. Keep away from
rotating tines. Stop the engine and
disconnect the spark plug before un-
clogging tines or making repairs.

16
WARNING: Inspect the area to
be cultivated before starting the unit.
Remove all debris and hard and sharp
objects such as rocks, vines, branch--
es, rope, string, etc.
SAvoid heavy contact with solid objects
that might stop the tines. If heavy
contact occurs, stop the engine and
inspect the unit for damage.
SNever operate the cultivator without
the tine cover in place and properly
secured.
SKeep the tines and guard clear of
debris.
SAfter striking a foreign object, stop
the engine, disconnect the spark
plug and inspect the cultivator for
damage. Repair before restarting.
SDisconnect attachment from the drive
engine before cleaning the tines with
a hose and water to remove any
build--up. Oil the tines to prevent rust.
SAlways wear gloves when servicing
or cleaning the tines. The tines be-
come very sharp from use.
SDo not run unit at high speed unless
cultivating.
HEDGE TRIMMER SAFETY
DANGER: RISK OF CUT; KEEP
HANDS AWAY FROM BLADE -- Blade
moves momentarily after the trigger is
released. Do not attempt to clear away
cut material when the blade is in mo-
tion. Make sure the switch is in the OFF
position, the spark plug wire is discon-
nected, and the blade has stopped
moving before removing jammed mate-
rial from the cutting blade. Do not grab
or hold the unit by the cutting blade.
Allow blades to stop
before removing
them from the cut.
Blades move
momentarily
after the
trigger is
released.
WARNING: Inspect the area be-
fore starting the unit. Remove all de-
bris and hard objects such as rocks,
glass, wire, etc. that can ricochet, be
thrown, or otherwise cause injury or
damage during operation.
SDo not use a cutting blade that is
bent, warped, cracked, broken or
damaged in any other way. Have
worn or damaged parts replaced by
your Sears Service Centre.
SAlways keep unit in front of your
body. Keep all parts of your body
away from the cutting blade.
SKeep the cutting blade and air vents
clear of debris.
POLE PRUNER SAFETY
WARNING: The reciprocating
blade/rotating chain can cause severe
injury. Inspect the unit before use. Do
not operate unit with a bent, cracked
or dull blade or dull chain. Keep away
from the blade/chain.
WARNING: The reciprocating
blade/rotating chain is sharp. Do not
touch. To prevent serious injury, al-
ways stop engine and ensure blade/
chain has stopped moving, disconnect
spark plug, and wear gloves when
changing or handling the blade or
chain.
WARNING: A coasting blade/
rotating chain can cause injury while it
continues to move after the engine is
stopped. Maintain proper control of
the unit until the blade/chain has com-
pletely stopped moving. Keep hands,
face and feet at a distance from all
moving parts. Do not attempt to touch
or stop the blade or chain when it is
moving.
WARNING: Falling objects can
cause severe head injury. Wear head
protection when operating this unit
with a pole pruner attachment.

17
WARNING: To prevent serious
injury, do not use more than one boom
extension with a pole pruner attach-
ment.
WARNING: Keep the pruner
away from power lines or electrical
wires.
SOnly use for pruning limbs or
branches up to 4 inches in diameter.
SDo not operate the unit faster than
the speed needed to prune. Do not
run the unit at high speed when not
pruning.
SAlways stop the unit when work is
delayed or when walking from one
cutting location to another.
SIf you strike or become entangled
with a foreign object, stop the engine
immediately and check for damage.
Have any damage repaired by a
Sears Service Centre before at-
tempting further operations. Discard
blades that are bent, warped,
cracked or broken.
SStop the unit immediately if you feel
excessive vibration. Vibration is a
sign of trouble. Inspect thoroughly
for loose nuts, bolts or damage be-
fore continuing. Contact Sears Ser-
vice for repair or replacement of af-
fected parts as necessary.
SNOW THROWER SAFETY
WARNING: Keep hands and
feet away from the rotor when starting
or running the engine. Never attempt
to clear the rotor with the engine/motor
running. Stop engine and disconnect
spark plug before unclogging snow or
debris from discharge chute or when
adjusting vanes.
WARNING: Never lean over dis-
charge chute. Rocks or debris could
be thrown into the eyes and face and
cause serious injury or blindness.
WARNING: Inspect the area
where the unit is to be used. Remove
objects that could be thrown or dam-
age the unit. Some objects may be
hidden by fallen snow -- be alert for
the possibility.
SDirect material discharge away from
glass enclosures, automobiles, etc.
SDo not run engine at high speed
while not removing snow.
SBe attentive when using the snow-
thrower, and stay alert for holes in the
terrain and other hidden hazards.
SMake sure the rotor will spin freely
before attaching the snowthrowerto
the powerhead.
SIf the rotor will not rotate freely due
to frozen ice, thaw the unit before
thoroughly before attempting to op-
erate under power.
SKeep the rotor clear of debris.
SDo not throw snow near other
people. The snow thrower could
propel small objects at high speed
causing injury.
SAfter striking a foreign object, stop
the engine, disconnect spark plug
and inspect the snowthrower for
damage and repair if necessary be-
fore restarting unit.
SNever operate the snowthrowernear
glass enclosures, automobiles and
trucks.
SNever attempt to use the snow-
thrower on a roof.
SNever operate the snowthrowernear
window wells, dropoffs, etc.
SNever discharge snow onto public
roads or near moving traffic.
SClear snow from slopes by going up
and down; never across. Use cau-
tion when changing directions. Nev-
er clear snow from steep slopes.
SLet snowthrower run for a few min-
utes after clearing snow so moving
parts do not freeze.
SLook behind and use care when
backing up. Exercise caution to
avoid slipping or falling, especially
when operating in reverse.
SKnow how to stop quickly.

18
MAINTENANCE
MAINTENANCESCHEDULE
Check for loose fasteners and parts Before each use
Check for damaged or worn parts Before each use
Inspect and clean unit and labels After each use
Clean air filter Every 5 hours of operation
Inspect muffler and spark arresting screen Every 50 hours of operation
Replace spark plug Yearly
CARE & MAINTENANCE TASK WHEN TO PERFORM
WARNING: Disconnect the spark plug before performing maintenance
except for carburetor adjustments.
GENERALRECOMMENDATIONS
The warranty on this unit does not
cover items that have been subjected
to operator abuse or negligence. To
receive full value from the warranty,
the operator must maintain unit as
instructed in this manual. Various ad-
justments will need to be made peri-
odically to properly maintain your unit.
CHECK FOR LOOSE
FASTENERS AND PARTS
SSpark Plug Boot
SAir Filter
SHousing Screws
SAssist Handle Screw
SDebris Shield
CHECK FOR DAMAGED OR
WORN PARTS
Contact your Sears Service Centre for
replacement of damaged or worn
parts.
SON/OFF Switch -- Ensure ON/OFF
switch functions properly by moving
the switch to the OFF position. Make
sure engine stops; then restart en-
gine and continue.
SFuel Tank -- Discontinue use of unit
if fuel tank shows signs of damage
or leaks.
SDebris Shield -- Discontinue use of
unit if debris shield is damaged.
INSPECT AND CLEAN UNIT AND
LABELS
SAfter each use, inspect complete
unit for loose or damaged parts.
Clean the unit and labels using a
damp cloth with a mild detergent.
SWipe off unit with a clean dry cloth.
CLEAN AIR FILTER
A dirty air filter decreases engine per-
formance and increases fuel con-
sumption and harmful emissions. Al-
ways clean after every 5 hours of
operation.
1. Clean the cover and the area
around it to keep dirt from falling
into the carburetor chamber when
the cover is removed.
2. Remove parts by pressing button
to release air filter cover.
NOTE: To avoid creating a fire hazard
or producing harmful evaporative
emissions, do not clean filter in gaso-
line or other flammable solvent.
3. Wash the filter in soap and water.
4. Allow filter to dry.
5. Replace parts.Air Filter
Air Filter
Cover
Button
REPLACE SPARK PLUG
Replace the spark plug each year to
ensure the engine starts easier and
runs better. Set spark plug gap at
0.025 inch (0.6 mm). Ignition timing is
fixed and nonadjustable.
1. Twist, then pull off spark plug boot.
2. Remove spark plug from cylinder
and discard.
3. Replace with Champion RCJ-6Y
spark plug and tighten securely
with a 3/4 inch (19 mm) socket
wrench.
4. Reinstall the spark plug boot.

19
SERVICE AND ADJUSTMENTS
REPLACINGTHE LINE
1. Move ON/OFF switch to the ON
position.
2. Disconnect the spark plug wire.
3. Remove spool by firmly pulling on
tap button.
4. Clean entire surface of hub and
spool.
5. Replace with a pre-wound spool, or
cut two lengths of 12-1/2 feet (3.8
meters) of 0.080"(2 mm) diameter
Craftsman!brand line.
WARNING: Never use wire,
rope, string, etc., which can break off
and become a dangerous missile.
6. Insert ends of the lines about 1/2
inch (1 cm) into the small holes on
the inside of spool.
Small
Holes
Spool
Hub
Line in Notch
Line in Notch
Line exit holes
7. Wind the line evenly and tightly
onto the spool. Wind in the direc-
tion of the arrows found on the
spool.
8. Push the lines into the notches,
leaving 3 to 5 inches (7 -- 12 cm)
unwound.
9. Insert the lines into the the exit
holes in the hub as shown in the
illustration.
10. Align the notches with the line exit
holes.
11. Push spool into hub until it snaps
into place.
12. Pull the lines extending outside of
the hub to release the lines from
the notches.
BLADE REPLACEMENT
Refer to the ASSEMBLY section for
blade replacement instructions and
illustrations.
CARBURETOR ADJUSTMENT
WARNING: Keep others away
when making idle speed adjustments.
The trimmer head, blade or any op-
tional attachmentwill be spinning dur-
ing most of this procedure. Wear your
protective equipment and observe all
safety precautions. After making ad-
justments, the trimmer head, blade or
any optional attachment must not
move/spin at idle speed.
The carburetor has been carefully set
at the factory. Adjustments may be
necessary if you notice any of the fol-
lowing conditions:
SEngine will not idle when the throttle is
released.
SThe trimmer head, blade or optional
attachment moves/spins at idle.
Make adjustments with the unit sup-
ported so the cutting attachment is off
the ground and will not make contact
with any object. Hold the unit by hand
while running and making adjust-
ments. Keep all parts of your body
away from the cutting attachment and
muffler.
Idle Speed Adjustment
Allow engine to idle. Adjust speed until
engine runs without trimmer head,
blade or optional attachment moving
or spinning (idle too fast) or stalling
(idle speed too slow).
STurn idle speed screw clockwise to
increase engine speed if engine
stalls or dies.
STurn idle speed screw
counterclockwise to decrease
engine speed if trimmer head, blade
or optional attachment moves or
spins at idle.
WARNING: Recheck the idle
speed after each adjustment. The
trimmer head, blade or optional at-
tachment must not move or spin at
idle speed to avoid serious injury to
the operator or others.

20
Idle Speed
Screw
Air Filter
Cover
If you require further assistance or are
unsure about performing this procedure,
contact your Sears Service Centre.
STORAGE
WARNING: Perform the follow-
ing steps after each use:
SAllow engine to cool before storing
or transporting.
SStore unit and fuel in a well venti-
lated area where fuel vapors cannot
reach sparks or open flames from
water heaters, electric motors or
switches, furnaces, etc.
SStore unit with all guards in place.
Position unit so that any sharp ob-
ject cannot accidentally cause injury.
SStore unit and fuel well out of the
reach of children.
SEASONALSTORAGE
Prepare unit for storage at end of sea-
son or if it will not be used for30 days
or more.
If your unit is to be stored for a period
of time:
SClean the entire unit before lengthy
storage.
SStore in a clean dry area.
SLightly oil external metal surfaces.
FUEL SYSTEM
Under FUELING ENGINE in the OPERA-
TION section of this manual, see mes-
sage labeled IMPORTANT regarding
the use of gasohol in your engine.
Fuel stabilizer is an acceptable alter-
native in minimizing the formation of
fuel gum deposits during storage. Add
stabilizer to the gasoline in the fuel
tank or fuel storage container. Follow
the mix instructions found on stabilizer
container. Run engine at least 5 min-
utes after adding stabilizer.
Craftsman 40:1, 2-cycle engine oil (air
cooled) is already blended with fuel
stabilizer. If you do not use this Sears
oil, you can add a fuel stabilizer to
your fuel tank.
ENGINE
SRemove spark plug and pour 1 tea-
spoon of 40:1, 2-cycle engine oil (air
cooled) through the spark plug
opening. Slowly pull the starter rope
8 to 10 times to distribute oil.
SReplace spark plug with new one of
recommended type and heat range.
SClean air filter.
SCheck entire unit for loose screws,
nuts, and bolts. Replace any dam-
aged, broken, or worn parts.
SAt the beginning of the next season,
use only fresh fuel having the proper
gasoline to oil ratio.
OTHER
SDo not store gasoline from one sea-
son to another.
SReplace your gasoline can if it starts
to rust.
